OX7-PROMIProximity Access Control System

0012PROMI_subc Page 1 of 15 Atlas Compliance & Engineering, Inc. 142 North Milpitas Blvd. PMB 376 Milpitas, CA 95035 Phone 831.761.2223 Fax 831.761.3223 .......... Atlas Compliance & Engineering, Inc. FCC Test Report FCC CFR 47 Part 15.209 COMPLIANCE RETH (USA), INC. 20257 Paseo Del Prado Walnut, CA 91789 USA Product: Proximity Access Control System Model: PROMI Test Report Number:0012PROMI_subc Date of Report:March 22, 2000 This report contains 15 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of Atlas Compliance & Engineering, Inc. 0012PROMI_subc Page 2 of 15 Atlas Compliance & Engineering, Inc. 142 North Milpitas Blvd. PMB 376 Milpitas, CA 95035 Phone 831.761.2223 Fax 831.761.3223 Scope of Accreditation 0012PROMI_subc Page 3 of 15 Atlas Compliance & Engineering, Inc. 142 North Milpitas Blvd. PMB 376 Milpitas, CA 95035 Phone 831.761.2223 Fax 831.761.3223 Table of Contents Scope of Accreditation..........................................................................................................................................2 Table of Contents...................................................................................................................................................3 General Information..............................................................................................................................................4 Test Equipment......................................................................................................................................................5 Test Configuration.................................................................................................................................................6 EUT Description / Note:....................................................................................................................................6 EUT Support Program.......................................................................................................................................6 EUT Modifications for Compliance..................................................................................................................6 EUT Support Devices........................................................................................................................................7 I/O Ports and Cables..........................................................................................................................................7 Equipment Under Test...........................................................................................................................................8 Equipment Block Diagram..................................................................................................................................10 Test Setup (Radiated Emissions).........................................................................................................................11 Test Methods for Emissions............................................................................................................................12 Temperature and Humidity..............................................................................................................................12 Sample Calculations........................................................................................................................................12 FCC Part 15 Subpart C 15.209 Limits.................................................................................................................13 Report of Measurements Radiated Data..........................................................................................................14 COMPLIANCE VERIFICATION REPORT......................................................................................................15 Table 1 - Support Equipment Used For Test.........................................................................................................7 Table 2 - EUT Port Termination’s.........................................................................................................................7 Table 3 - Host Port Termination's..........................................................................................................................7 Table 4 - Radiated Emission Limits, General Requirements...............................................................................13 Table 5 - Radiated Emission Level at 10 meter distance.....................................................................................14 Figure 1 - Test Setup Diagram.............................................................................................................................10 0012PROMI_subc Page 4 of 15 Atlas Compliance & Engineering, Inc. 142 North Milpitas Blvd. PMB 376 Milpitas, CA 95035 Phone 831.761.2223 Fax 831.761.3223 General Information Test Report Number:0012PROMI_subc Date Product Tested:March 6, 2000 Date of Report:March 22, 2000 Applicant:RETH (USA), INC. 20257 Paseo Del Prado Walnut, CA 91789 USA Contact PersonKevin Chen Equipment Tested:Proximity Access Control System Trade Name:PROMI-xxx Model:PROMI Purpose Of Test:To demonstrate the compliance of the Proximity Access Control System, PROMI, with the requirements of FCC CFR 47 Part 15 Rules and Regulations to the limits of Subpart C 15.209 using the procedure stated in ANSI C63.4-1992. Frequency Range Investigated:9 kHz to 1000 MHz Test Site Locations:OATS Atlas Compliance & Engineering, Inc. 726 Hidden Valley Road Watsonville, California 95076 Test Personnel:Bruce Smith EMC Engineer 0012PROMI_subc Page 5 of 15 Atlas Compliance & Engineering, Inc. 142 North Milpitas Blvd. PMB 376 Milpitas, CA 95035 Phone 831.761.2223 Fax 831.761.3223 Test Equipment The following list contains the test equipment that was utilized in making the measurements in this report. Description _ ModelSerial…

Text truncated - open the document above for the full version.

0019PROMI_subc Page 14 of 16 Atlas Compliance & Engineering, Inc. 142 North Milpitas Blvd. PMB 376 Milpitas, CA 95035 Phone 831.761.2223 Fax 831.761.3223 Report of Measurements Radiated Data The following table reports the results of the radiated measurements for the Proximity Access Control System, PROMI. Table 5 - Radiated Emission Level 15.209 Limit dBμV/m Fundamental Frequency kHz Level dBμV/m DetectorTest Distance Limit dBμV/m Margin dB Antenna 25.46 @ 300 meters128.066.81AV10108.9642.15Loop 15.209 Limit dBμV/m Unwanted Frequency kHz Level dBμV DetectorTest Distance Limit dBμV Margin dB Antenna 19.44 @ 300 meters256.042.42AV10102.9460.52Loop 15.92 @ 300 meters384.040.61AV1099.4258.81Loop 33.42 @ 30 meters512.042.23QP1060.3918.16Loop 31.48 @ 30 meters640.054.70QP388.0133.31Loop 29.90 @ 30 meters768.060.97QP356.8725.46Loop 28.56 @ 30 meters896.036.40QP1055.5319.13Loop 27.40 @ 30 meters1024.037.08QP1054.3717.29Loop 26.38 @ 30 meters1152.036.09QP1053.3517.26Loop 25.46 @ 30 meters1280.041.18QP1052.4311.25Loop Test Method:ANSI C63.4-1992Note:AV = Average Spec Limit:FCC 15.209QP = Quasi Peak No other emissions were observed. COMMENTS: System continuously running. Ambient temperature 62°F and relative humidity of 55%. Test distance of 3 meters was due to the presents of ambient radio noise. Limits are extrapolated at 56.53 dB/decade derived by taking measurements at two distances at one radial (see 15.31 (f)(2)). Calculation of limit at 128kHz: Limit in microvolts/meter 2400/128=18.75μV/m at 300 meters Convert to dbμV 20 Log 18.75μV/m = 25.46dBμV/m at 300 meters Take the Log of the ratio of the distance between 300 and 10 Log 300/10 = 1.477 Multiply this distance ratio with the extrapolation factor 1.477*56.53dB/decade = 83.50 factor for 10 meter distance Add this factor to the limit of 25.46dBμV/m 25.46+83.50=108.96dBμV/m at 10 meters 0019PROMI_subc Page 15 of 16 Atlas Compliance & Engineering, Inc. 142 North Milpitas Blvd. PMB 376 Milpitas, CA 95035 Phone 831.761.2223 Fax 831.761.3223 Calculation of extrapolation factor at 128kHz, 3 meter to 10 meter distance: The reading level in dB at 10 meter subtracted from the level in dB at 3 meter 96.37-66.81 = 29.56 Subtract the log of the two distances Log (10)-Log (3) = 1-0.477121 = 0.522879 Divide the ratio of the readings by the ratio of the distance 29.56/0.522879 = 56.53 Actual Extrapolation Factor derived from measurements at 3 meters and 10 meters on fundamental frequency 56.53 dB/decade Levels at 3 and 10 meters were measured, levels at 30 and 300 meters are calculated. Table 6 - 128kHz Extrapolation Factor Data Distance in meters31030300 Level dBuV/m96.3766.8139.84-16.70 Limit dBuV/m (40dB/decade)105.4684.5465.4625.46 Limit dBuV/m (56.53dB/decade)138.52108.9681.8925.46 Figure 2 - Extrapolation Factor Plot Extrapolation Plot of 128.0 kHz (OX7-PROMI) 96.37 66.81 39.84 -16.70 105.46 84.54 65.46 25.46 -30 -20 -10 0 10 20 30 40 50 60 70 80 90 100 110 1101001000 Test Distance in meters Amplitude in dBuV/m Emission LevelLimit Level
