OXFCT67TXAutomobile Security Remote Control

FCC ID.: OXFCT67TX Rev. No 1.0 FCC Part 15 Subpart C EMI TEST REPORT of E.U.T. : REMOTE CONTROL FCC ID. : OXFCT67TX MODEL : CT67TX Working Frequency : 390 MHz for APPLICANT : KACETO ELECTRONIC CO., LTD. ADDRESS: 2F, NO. 4-1, ALLEY 25, LANE 10, PAO CHIEN RD., CHUNG HO, TAIPEI, TAIWAN, R.O.C. Test Performed by ELECTRONICS TESTING CENTER, TAIWAN NO. 8 LANE 29, WENMIMG ROAD, LOSHAN TSUN, KWEISHAN HSIANG, TAOYUAN, TAIWAN, R.O.C. Tel:(03)3280026-32 Fax:(03)3280034 Report Number : ET89R-05-077 ETC Report No.:ET89R-05-077FCC ID.: OXFCT67TX Rev. No 1.0 TEST REPORT CERTIFICATION Applicant: KACETO ELECTRONIC CO., LTD. 2F, NO. 4-1, ALLEY 25, LANE 10, PAO CHIEN RD., CHUNG HO, TAIPEI, TAIWAN, R.O.C. Manufacturer: KACETO ELECTRONIC CO., LTD. 2F, NO. 4-1, ALLEY 25, LANE 10, PAO CHIEN RD., CHUNG HO, TAIPEI, TAIWAN, R.O.C. Description of EUT: a) Type of EUT: REMOTE CONTROL b) Trade Name: KACETO c) Model No.: CT67TX d) FCC ID: OXFCT67TX e) Working Frequency : 390 MHz f) Power Supply: DC 12V Regulation Applied: FCC Rules and Regulations Part 15 Subpart C (1998) I HEREBY CERTIFY THAT; The data shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Note : 1. The results of the testing report relate only to the items tested. 2. The testing report shall not be reproduced except in full, without the written approval of ETC. Issued Date :MAY 30, 2000 Test Engineer : ( S. S. Liou ) Approve & Authorized Signer : Will Yauo, Supervisor EMI Test Site of ELECTRONICS TESTING CENTER, TAIWAN ETC Report No.:ET89R-05-077FCC ID.: OXFCT67TX Rev. No 1.0 Table of Contents Page 1. GENERAL INFORMATION ........................................................................................................................................ 1 1.1 P RODUCT D ESCRIPTIO N ................................................................................................................................................... 1 1.2 C HARACTERISTICS OF D EVICE : ........................................................................................................................................ 1 1.3 T EST M ETHODOLOGY ...................................................................................................................................................... 1 1.4 T EST F ACILITY ................................................................................................................................................................. 1 2. DEFINITION AND LIMITS.......................................................................................................................................... 2 2.1 D EFINITION ..................................................................................................................................................................... 2 2.2 R ESTRICTED B ANDS OF O PERATION ................................................................................................................................. 2 2.3 L IMITATION ..................................................................................................................................................................... 2 2.4 L ABELIN G R EQ UIREMEN T ................................................................................................................................................. 4 2.5 U SER I NFORMATION ........................................................................................................................................................ 4 3. RADIATED EMISSION MEASUREMENT................................................................................................................. 5 3.1 A PPLICABLE S TANDARD .................................................................................................................................................. 5 3.2 M EASUREMEN T P ROCEDURE ............................................................................................................................................ 5 3.3 T EST D ATA ...................................................................................................................................................................... 7 3.4 F IELD S TREN GTH C ALCULATIO N ...................................................................................................................................... 8 3.5 T RANSMISSION T IME M EASUREMEN T .............................................................................................................................. 8 3.6 A CTIVATE T IME ............................................................................................................................................................... 8 3.7 C ALCULATION OF D UTY F ACTOR ..................................................................................................................................... 8 3.8 R ADIATED T EST E QUIPMENT ............................................................................................................................................ 9 3.9 M EASURIN G I N STRUMEN T S ETUP ..................................................................................................................................... 9 3.10 R ADIATED M EASUREMEN T P HOTOS ............................................................................................................................. 10 4. BANDWIDTH OF EMISSION.................................................................................................................................... 11 4.1 A PPLICABLE S TANDARD P LO T G RAPHIC OF B ANDWIDTH ............................................................................................... 11 4.2 B ANDWIDTH T EST E QUIPMENT ......................................................................................…
