OYOPWTHMobile Phone

Feb. 99 QUICK GUIDE ALCATEL 4073 GS MOBILE TELEPHONE DIGITAL PWT QUICK GUIDE 2 Getting to know your Alcatel 4073 GS Smart telephone Navigator: Earpiece Integral radio antenna Allows you to move through the menus, and to confirm entries: [NAVC] Display previous choice. Erase last character entered. Erase a complete field (long press). [NAV] Display next in list. Transfer (long press) [OK] Validate entry or initiate a call by name. [ ‹ ] Scroll the display pages. Personal directory Function keys: The function is obtained by a long press on the key (2 beeps). [ * ] Sending DTMF codes (long press). Microphone [ i ] [ 0 ] Customizing your telephone. R: send timed break (long press) [ # ] Adjusting your telephone (long press). [ 8 ] Activating vibrate mode while deactivating the ringer, or vice-versa (long press). [ M ] Message function. Forward function (long press) [ I ] On-Off (long press) [ V ] During a call: adjusting earpiece sound volume. QUICK GUIDE 3 Green light indicating: Incoming call: flashes with call ringing if ringer and vibrate mode are deactivated. Going out of radio coverage: fast flashing. Display and corresponding icons: Has 2 lines of 16 alphanumeric characters and 1 line of 8 icons. Radio reception icon (1): [iRad.1] Limit of coverage or outside coverage (flashing). Poor reception (light on). [iRad.2] Reception OK (light on) Battery icon (1): [iBAT1] Battery discharged or defective (flashing). [iBAT2] Battery on charge (flashing). [iBAT3] Battery fully charged (light on). Option icons (4): [iV] Lock/unlock [iM] Message [iRenv.] Forward [iSon.] Ringer disabled Call keys: [DECR] Lift receiver Call Redial function (long press) [RACC] Hang up QUICK GUIDE 4 GETTING STARTED Installing the battery in the telephone remove the cover connect the battery socket. Check correct polarity: red wire towards inside of telephone position the two wires under the battery and slide the battery into position click the cover into position Switching on your telephone: [ i ] display comes on your telephone is switched on long press wait a moment ( ª 3 sec) battery and radio coverage icons light up Conversely, if the display does not come on, charge the battery. If you are outside radio coverage, the radio coverage icon flashes. If "AUTO- INSTALL, System-OK?" is displayed, see paragraph "Registering your telephone in the system". Switching off your telephone: [ i ] long press SETTING UP Selecting language [ i ] short press you have the choice of 4 predefined languages QUICK GUIDE 5 Selecting language (cont.) [NAV] select language [OK] or or or or [OK] [RACC] validate return to idle status Adjusting the audio functions When your telephone is in standby, you can customize some of its functions: [ # ] long press [OK] you have the choice of various options* 1 - Ringer 2 - Vibrate mode 3 - Key tone 4 - Radio beep ... messages related to functions are displayed * [NAV] to select the option For each function, transition between "active" mode and "inactive" mode (and vice-versa) is obtained by: [OK] Example: Please select: 1 - Ringer on [OK] Please select: 1 - Ringer off Ringer active Ringer disabled When the selection is completed: [RACC] and again [RACC] to return to idle status QUICK GUIDE 6 Adjusting your ringer You can select your ringer tune (choice of 7) and adjust the volume (3 levels): [ i ] short press the tune number and volume level number are displayed To play the various ringer tunes proposed: several presses Adjusting ringer volume: Validate: several presses [OK] and [RACC] to return to idle status Selecting your receiver sound volume during a call several presses (1 to 3) A beep indicates maximum volume selected. The last adjustment entered is retained for the next call. USING YOUR TELEPHONE Making a call [DECR] and you have a call in progress dial or dial directly Answering a call: To terminate a call: [DECR] or remove telephone from charger [RACC] Lift receiver. Hang up. QUICK GUIDE 7 Calling your correspondent by name (company directory) [ A ] short press correspondent’s name is displayed first letters of correspondent’s name When name found is OK: [OK] or [RACC] make the call exit from mode Calling from your personal directory [ A ] [ 0 ] [OK] the system automatically dials the number long press directory number required (0 to 9) or [ A ] [NAV] [OK] the system automatically dials the number long press to select directory Calling from the common directory Your terminal has access to the common directory of short outside numbers: short number Redialling the last number dialled (redial) [DECR] [long press] last number dialled is redialled Requesting automatic callback Internal line busy [ # ] display acknowledges callback [RACC] short press QUICK GUIDE 8 HANDLING SEVERAL CALLS Making a second call during a conversation during a conversation the first call is placed on hold dial the second number directly Recovering the first call: [ ‹ ] long press the first call is recovered the second call is automatically placed on hold place the second call on hold If you make a mistake, hang up [RACC]. Your telephone rings and you recover your first call by pressing [DECR]. Answering a second call during a conversation you are in conversation and you hear a repeated beep [Smith] [OK] long press the first call is placed on hold caller’s name for 3 seconds Recovering the first call: [ ‹ ] long press identical to previous case place the second call on hold Transferring a call To transfer your call to another number: during a conversation your call is placed on hold [NAV] long press or [RACC] destination number if allowed by your telephone configuration QUICK GUIDE 9 Switching between calls (Broker call) During a call, a second call is on hold. To switch between the two calls: [ ‹ ] long press the other call is placed on hold Three-way conference with internal and/or external correspondents (conference) During a conversation, another call is on hold: For a three-way conference: To hang up all calls: [NAV…

Text truncated - open the document above for the full version.

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 86 of 87 Exhibit 13 Exhibit 13: Cover Letters April 12, 2000 FEDERAL COMMUNICATIONS COMMISSION Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: Enclosed is a FCC Part 15, Subpart D, Certification application for the Alcatel Model 4073 GS-3BN 67108, FCC ID: OYOPWTH. Please let me know if I can be of further assistance. Sincerely yours, COMMUNICATION CERTIFICATION LABORATORY Joseph W. Jackson V.P. Marketing COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 87 of 87 Exhibit 13 Request for Confidentiality

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 5 of 87 Exhibit 3 Exhibit 3: Photographs of Overall Appearance Front View of the 4073 GS-3BN 67108 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 6 of 87 Exhibit 3 Back View of the 4073 GS-3BN 67108 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 7 of 87 Exhibit 3 Speaker Phone Charger for Handset Model 3BN66085ABAA COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 8 of 87 Exhibit 3 Charger for Handset Model 3BN66083ABAA

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 1 of 87 Exhibit 1 Exhibit 1: FCC ID Label Equipment Identification Label In accordance with the requirements of Sections 15.19 (a)(3), 15.311, 2.925 and 2.926 of the FCC Rules, the following information will be permanently affixed to the Alcatel Model 4073 GS-3BN 67108. Shown below are the label and a photograph showing where the label will be placed on the Base Station. COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 2 of 87 Exhibit 1 Label COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 3 of 87 Exhibit 1 Photograph showing label placement

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 74 of 87 Exhibit 9 Exhibit 9: Internal Photographs Inside View of the 4073 GS-3BN 67108 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 75 of 87 Exhibit 9 Front view of the radio board and keypad board COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 76 of 87 Exhibit 9 Back view of the radio board and keypad board COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 77 of 87 Exhibit 9 Back view of the radio board (with RF cans) COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 78 of 87 Exhibit 9 Front view of the radio board (without RF cans) COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 79 of 87 Exhibit 9 Back view of the radio board (without RF cans) COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 80 of 87 Exhibit 9 Front view of the keypad board COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 81 of 87 Exhibit 9 Back view of the keypad board

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 84 of 87 Exhibit 12 Exhibit 12: Operational Description § 15.203 Antenna Requirements The 4073 GS-3BN 67108 uses a Dipole antenna that is permanently soldered to radio board and is not accessible by the user. The same type as specified by the manufacturer can only replace these antennas; therefore, it meets the requirements of this section. § 15.307 Coordination with fixed microwave service Enclosed on the following page is the UTAM affidavit stating compliance to this section. COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 85 of 87 Exhibit 12 UTAM Affidavit

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 83 of 87 Exhibit 11 Exhibit 11: RF Exposure/Environmental Evaluation Section 15.319 (i) Requirement: Unlicensed PCS devices are subject to the radiofrequency radiation exposure requirements specified in § 1.1307(b), 2.1091 and 2.1093 of this chapter, as appropriate. All equipment shall be considered to operate in a “general population/uncontrolled” environment. Applications for equipment authorization of devices operating under this section must contain a statement confirming compliance with these requirements for both fundamental emissions and unwanted emissions. Technical information showing the basis for this statement must be submitted to the Commission upon request. Demonstration of Compliance: The 4073 GS-3BN 67108 is classified as a portable device. Therefore, the 4073 GS-3BN 67108 is subject to routine environmental evaluation for RF exposure as per § 2.1093(c). Testing to demonstrate compliance to this section was performed by the University of Utah and the results of this test was sent as a separate pdf file.

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 12 of 87 Exhibit 6 Exhibit 6: Test Report TEST REPORT FROM: COMMUNICATION CERTIFICATION LABORATORY 1940 W. Alexander Street Salt Lake City, Utah 84119-2039 Type of Report: Certification TEST OF: 4073 GS-3BN 67108 FCC ID: OYOPWTH To Part 15 Subpart D of the FCC Rules and Regulations Test Report Serial No: 73-7158 Applicant: Alcatel 7 Stiles Road 2 nd Floor Salem, NH 03079 Date(s) of Test: January 24 – 28, 2000 Issue Date: April 12, 2000 Equipment Receipt Date: January 21, 2000 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 13 of 87 Exhibit 6 CERTIFICATION OF ENGINEERING REPORT This report has been prepared by Communication Certification Laboratory to evaluate the device described below with the requirements of FCC Part 15, Subpart D. Specific identifying information for the device tested is given below. - Applicant Alcatel 7 Stiles Road 2 nd Floor Salem, NH 03079 - Manufacturers: Alcatel Business Systems 1, Route du Dr. A. Schweitzer Illkirch Ce Cedex, 67408 France Alcatel Citesa S.A. Parque Technologico de Andalucia Campanillas Malaga, SP-29590 Spain - Trade Name: ALCATEL - Model Number: 4073 GS-3BN 67108 - FCC ID Number: OYOPWTH On this 12 th day of April 2000, I, individually, and for Communication Certification Laboratory, certify that the statements made in this engineering report are true, complete, and correct to the best of my knowledge, and are made in good faith. COMMUNICATION CERTIFICATION LABORATORY Checked by: William S. Hurst, P.E. Vice President Tested by: Roger J. Midgley EMC Engineering Manager COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 14 of 87 Exhibit 6 SECTION 1 GENERAL INFORMATION 1.1 Product Description The 4073 GS-3BN 67108 is the handset portion of a wireless system telephone system. The system consists of a controller, base station and wireless handset. The base station is hard wired to the controller. The controller connects to a PBX to provide all of the PBX functions to the wireless handset. This application is for the handset, which is identified by FCC ID: OYOPWTH. The base station, which is identified by FCC ID: OYOPWTB, application is being submitted concurrently with this application. 1.2 Test Specification The 4073 GS-3BN 67108 is an Isochronous device that operates in the 1920-1930 MHz sub-band; therefore the 4073 GS-3BN 67108 is subject to the provisions of FCC Part 15, Subpart D. Unlicensed Personal Communications Service Devices. 1.3 Test Methods & Procedures The 4073 GS-3BN 67108 was tested in accordance with ANSI C63.17-1998. COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 15 of 87 Exhibit 6 SECTION 2. SUMMARY OF TEST RESULTS: 2.1 Summary of Tests: FCC Section Description Report Section ANSI C63.17 Section Result 15.307 Affidavit from UTAM, Inc. certifying participation in UTAM, Inc. 3.2.1 N/A Complies 15.309 Cross Reference to Subpart B 3.2.2 6.1.6.3 Complies 15.311 Labelling Requirements 3.2.3 N/A Complies 15.315 AC power line conducted limits 3.2.4 N/A Complies 15.317 Antenna requirement 3.2.5 N/A Complies 15.319 (a) Frequency of operation 3.2.6 N/A Complies 15.319 (b) Modulation technique 3.2.7 6.1.4 Complies 15.319 (c) Peak transmit power and emission bandwidth 3.2.8 6.1.2 Complies 15.319 (d) Power spectral density 3.2.9 6.1.5 Complies 15.319 (e) Directional gain of antenna 3.2.10 N/A Complies 15.319 (f) Automatic discontinuance of transmission 3.2.11 N/A Complies 15.319 (i) IEEE C95.1-1991 and IEEE C95.3-1991 3.2.12 N/A Complies 15.323 (a) Channel allocation 3.2.13 N/A Complies COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 16 of 87 Exhibit 6 FCC Section Description Report Section ANSI C63.17 Section Result 15.323 (b) Channel packing 3.2.14 8.1.2 Complies 15.232 (c) Time and Spectrum monitoring 3.2.15 Sections 7 and 8 Complies 15.323 (c)(1) Transmit window monitoring 3.2.16 7.3.2.2 7.5 Complies 15.323 (c)(2) Monitoring threshold 3.2.17 7.3.2.1 Complies 15.323 (c)(3) Transmission duration 3.2.18 N/A Complies 15.323 (c)(4) Acknowledgments 3.2.19 8.2.1 8.1.3 Complies 15.323 (c)(5) Least interfered channel 3.2.20 7.3.2.1, 7.3.2.2 8.2.1 Complies 15.323 (c)(6) Random waiting interval 3.2.21 8.1.3 8.2.1 Complies 15.323 (c)(7) Threshold monitoring bandwidth, Threshold monitoring reaction time 3.2.22 7.4 7.5 Complies 15.323 (c)(8) Threshold monitoring antenna 3.2.23 N/A Complies 15.323 (c)(9) Monitoring threshold relaxation 3.2.24 N/A Complies 15.323 (c)(10) Duplex connections 3.2.25 8.2.3 Complies 15.323 (c)(11) Alternative monitoring interval 3.2.26 8.2.4 Complies 15.323 (c)(12) Limitation on use of Section (c)(10) or (c)(11) 3.2.27 N/A Complies COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 17 of 87 Exhibit 6 FCC Section Description Report Section ANSI C63.17 Section Result 15.323 (d) Spurious emissions 3.2.28 6.1.6 Complies 15.323 (e) Frame repetition stability / frame period and jitter 3.2.29 6.2.3 6.2.4 Complies 15.323 (f) Frequency stability 3.2.30 6.2.2 Complies COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 18 of 87 Exhibit 6 SECTION 3. MEASUREMENTS, EXAMINATIONS AND DERIVED RESULTS: 3.1 General Comments This section contains the test results only. Details of the test methods used, etc., can be found in Appendix A of this report. 3.2 Test Results 3.2.1 Coordination with fixed microwave service § 15.307 Measurement Data: The affidavit from UTAM, Inc. is enclosed in Exhibit 12. 3.2.2 Cross Reference to Subpart B § 15.309 The requirements of Subpart D apply only to the radio transmitter contained in the PCS device. Other aspects of the operation of a PCS device may be subject to requirements contained elsewhere in this Chapter. In particular, a PCS device that includes digital circuitry not directly associated with the radio transmitter also is subject to the requ…

Text truncated - open the document above for the full version.

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 71 of 87 Exhibit 7 Exhibit 7: Test Set-Up Photographs Front View of Worst Case Radiated and Line Conducted Emissions Test Set-up COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7158 FCC ID: OYOPWTH Page 72 of 87 Exhibit 7 Back View of Worst Case Radiated and Line Conducted Emissions Test Set-up
