OYP21PHONE01FM TRANSMITTER

MAX LIGHT Report Number: MLT0003P15003 FCC ID: OYP21PHONE01 Technology Lab MAX LIGHT Report Number: MLT0003P15003 FCC ID: OYP21PHONE01 Technology Lab MAX LIGHT Report Number: MLT0003P15003 FCC ID: OYP21PHONE01 Technology Lab MAX LIGHT Report Number: MLT0003P15003 FCC ID: OYP21PHONE01 Technology Lab

MAX LIGHT Report Number: MLT0003P15003 FCC ID: OYP21PHONE01 Technology Lab Label Format: Label Position: This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,and (2) This device must accept any interference received ,including. Interference that may cause undesired operation. Model: SP-001 FCC ID: OYP21PHONE01 MADE IN CHINA Equipment Lable 2.5CMX4CM

Product : FM TRANSMITTER Applicant : Hanming Industries Company FCC ID : OYP21PHONE01 Model : SP-001 Report No. : MLT0003P15003 Test Date : March 28,2000 Test By Max Light Technology Co.,Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Tel: 886-2-363-2447 Fax: 886-2-363-2597 T T h h e e t t e e s s t t r r e e p p o o r r t t c c o o n n s s i i s s t t s s o o f f 1 1 7 7 p p a a g g e e s s i i n n t t o o t t a a l l . . I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . MAX LIGHT MEASUREMENT REPORT Page: 2/17 Report Number: MLT0003P15003 FCC ID: OYP21PHONE01 Technology Lab Table of Contents : I. General 4. II. Conducted Emissions Requirements 7. III. Radiated Emissions Requirements 8. IV. Emissions Band Measurement 16. Appendix I (EUT Test Setup) 17. MAX LIGHT MEASUREMENT REPORT Page: 3/17 Report Number: MLT0003P15003 FCC ID: OYP21PHONE01 Technology Lab CERTIFICATION We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4-1992. All test were conducted by MLT (Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance radiated emission limit of FCC Rules Part 15 Subpart C Section 15.239. EUT: FM TRANSMITTER Applicant: HANMING INDUSTRIES COMPANY. UNIT B,5/F,HAVEN COMM. BLDG., 6-8 TSING FUNG ST., Hong Kong Manufacturer: SHENZHEN A POWER TECHNOLOGY CO.,LTD. E.5F,S.BLDG.,ZHONGHANGS SHAHE INDUSTRIAL AREA,OVERSEAS CHINESE TOWN,SHENZHE,CHINA Model No: SP-001 FCC ID: OYP21PHONE01 Prepared by : Approved by : Country Huang Roger Chen MAX LIGHT MEASUREMENT REPORT Page: 4/17 Report Number: MLT0003P15003 FCC ID: OYP21PHONE01 Technology Lab I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of HANMING INDUSTRIES COMPANY. In support of an Intentional Periodic Radiator certification in accordance with Part2 Subpart J and Part 15 Subpart A And C of the Commission’s and Regulations. 1.2 Description of EUT EUT : FM TRANSMITTER Applicant : HANMING INDUSTRIES COMPANY. UNIT B,5/F,HAVEN COMM. BLDG., 6-8 TSING FUNG ST., Hong Kong Manufacturer : SHENZHEN A POWER TECHNOLOGY CO.,LTD. E.5F,S.BLDG.,ZHONGHANGS SHAHE INDUSTRIAL AREA,OVERSEAS CHINESE TOWN,SHENZHE,CHINA Model No : SP-001 FCC ID : OYP21PHONE01 Power Type : Powered by Batter (Size: AA) The EUT(SP-001) is wireless ear-phone’s transmitter product. The operation frequency is 89.22MHz.Connect the audio input of emitter and the audio output of TV set or cassette player ... by using the audio cord and hear the audio signal of TV set or cassette player ... ,through your FM Radio. The receiver is FM radio. While testing the EUT was adjusted at a position which transmit the maximum. MAX LIGHT MEASUREMENT REPORT Page: 5/17 Report Number: MLT0003P15003 FCC ID: OYP21PHONE01 Technology Lab 1.3 Description of Support Equipment In order to construct the minimum system which required by the ANSI C63.4-1991, following equipments were used as the support units. Cassette Player: KOKA Model No.: KW-240 Serial No.: KS3303 MAX LIGHT MEASUREMENT REPORT Page: 6/17 Report Number: MLT0003P15003 FCC ID: OYP21PHONE01 Technology Lab 1.4 Configuration of System Under Test During testing the EUT(FM TRANSMITTER) correctly insert two new batteries(size AA). Connect the audio input of emitter and the audio output of cassette player by using the audio cord. 1.5 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI C63.4-1992 "Measurement of Intentional Radiators." 1.6 General Test Condition The conditions under which the EUT operates were varied to determine their effect on the equipment's emission characteristics. The final configuration of the test system and the mode of operation used during these tests was chosen as that which produced the highest emission levels. However, only those conditions which the EUT was considered likely to encounter in normal use were investigated. Cassette Player EUT Audio Cord MAX LIGHT MEASUREMENT REPORT Page: 7/17 Report Number: MLT0003P15003 FCC ID: OYP21PHONE01 Technology Lab II. Conducted Emissions Requirements The EUT operates solely by the battery. According to the rule of Section 15.207(c), the EUT exempt to the power line conducted test. MAX LIGHT MEASUREMENT REPORT Page: 8/17 Report Number: MLT0003P15003 FCC ID: OYP21PHONE01 Technology Lab III. Radiated Emissions Requirements 3.1 General & Setup : Prior to open-field testing, the EUT was placed in a shielded enclosure and scanned at a close distance to determine its emission characteristics. The physical arrangement of the EUT was varied (within the scope of arrangements likely to be encountered in actual use) to determine the effect on the unit's emanations in amplitude, directivity, and frequency. The exact system configuration which produced the highest emissions was noted so it could be reproduced later during the open-field tests. This was done to ensure that the final measurements would demonstrate the worst-case interference potential of the EUT. Final radiation measurements were made on a three-meter, open-field test site. The EUT system was placed on a nonconductive turntable which is 0.8 meters height, top s…

Text truncated - open the document above for the full version.

Dear Joe: Thank for your information . I would like to send re-measurement graph of tow marker indicated as above data is for bandwidth value, and it just means the bandwidth value is 188.3KHz. I will ask my client to modify the EUT if the device was need to be modified. Please find measurement graph for your reference. Sorry to bother you again Please let me know if you have any question on the data. Tks. With Best Regards, Country Huang
