OYRCF-E325NWireless Access Point

User Guide Wireless Access Point M/N: CF‐E325N Trade Mark: COMFAST Manufacturer: Shenzhen Four Seas Global Link Network Technology Co., Ltd 1、 Network Bridge Installation （1）、AP mode：convert a wired network to wireless WIFI signal for other to connect to the Internet （2）、Repeater Mode：receive the remote wireless signal，and then transmit a wireless signal， the terminal devices can receive can receive this signal by wireless way or web cable. （3）、Router Mode：access a wired network of modem or switch, select the router mode, the device can send out wireless WIFI signal and share with other terminal devices. （4）、Client Mode：receive wireless WIFI signal, then convert wireless signal to a wired network, the terminal devices connect to the network by web cable. 2、AP Mode settings （1）、Select“AP mode”,then type in the IP Address, Subnet Mask and default gateway according to your Router’s network address, click on “Next”. （2）、Set your SSID name and select the type of oncryption, then click on “Apply”. 3、Bridge software interface （1）、Open a browser and type in 192.168.10.1 and enter the login interface, the device provides Chinese and English languages for choice ,the user name and password are both “admin” by default. （2）、Click to Login, enter the AP mode of the four working modes; here please select the corresponding working mode depending on your type use. 4、Repeater Mode （1）、Select the “Repeater Mode” ,enter the setting interface. （2）、Click the next step, the device will scan the surrounding wireless signals; choose the SSID, type in correct password and connect. （3）、The Repeater was connected by upper wireless network password network, if need change for new SSID, click the top” Function Settings” button, select Wireless Basic Parameter Settings” page to modify the SSID name. 5、Router Mode （1）、Select the “Router Mode”. （2）、click the next step, and the connections have “DHCP”, ”Static IP”, ”PPPOE” three types. Select the corresponding connection, click the next step depending on your network environment. （3）、Here take “PPOE” as an example, type in the ISP account user name and password correctly, then click on “Next” to set up the SSID name and wireless password, click on “apply” 6、Client Mode （1）、Select the “Client Mode” , click next step, the device will scan the wireless signal around here. （2）、Find the wireless signal to be connected, type in correct password to connect. Terminal equipment can convert the received wireless signal to a wired network through the network cable. 7、Frequently Asked Questions （1）、How many voltage power does the product,? Some models do not have power inter face, how to supply power? A：Product Support 48V power supply, and some models do not have the power inter face, they support 48V POE power supply. （2）、The product has two RJ45 ports, which port is POE power supply inter face?] A ：The device LAN port for POE power supply interface. （3）、Forget the IP address of the product, how to enter the setup interface? A：(1).Connect the device to a computer, set the computer’s IP address as automatically obtain, the obtained default gateway is the IP address of the device (2).Long press the reset button for 5‐10 seconds, release after LED lamps off, wait for a while, LED lamps are lit again, indicates successful restore factory settings, factory default gateway IP:192.168.10.1 （4）、Way product has been ser as PPPOE but can not get on line after dialing? A：When the product set as PPPOE dialing mode, the network cable need to connect to the product WAN port. （5）、Connect the computer with a network cable, local connection can not obtain an IP address, how to do? A：(1).When connecting a network cable, network cable must be connected to the LAN port of the product, plugging WAN port can not obtain an IP address; also check whether the local computer is automatically obtain IP address status. （2）、Plugging the LAN port still can not obtain IP address, you can set the IP address of the local connection manually, set the IP address as same segment of the product. （6）、How long the cable length does the product support? Insufficient power occurs, how to do? A：When using a long cable, try to choose a high‐quality project dedicated wire, suggested, length less than 60 meters, and use the original power supply. （7）、The computer shows connected, the signal is full, but actually it can’ t surf the internet. A：As long as the device power on, there will be a “Comfast” SSID name wireless signal. Even if the device is disconnected to external network, we still are able to connect to this signal properly, but no Internet access. Terminal devices require Internet access, then the product must connect to external network. （8）、What type of default working mode of the device? If use any of the working modes, need restart it? Answer: The default working mode is router mode, DHCP is enabled status, you can directly access the DHCP enabled router or switch to use. In addition to setting AP mode which requires resetting or manually setting the IP to enter the gateway of the device, other working modes can directly get into the gateway. FCC Warning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Shenzhen Four Seas Global Link Network Technology Co., Ltd Add: Room 607-610, Block B, TAOJINDI Electronic Business Incubation Base,Tenglong Road, Longhua District, Shenzhen, China Tel: 86-0755-86-83790059 Fax.: 86-0755-83790059-808 2015-06-19 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA FCC ID: OYRCF-E325N Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Shenzhen Four Seas Global Link Network Technology Co., Ltd, hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name): Wireless Access Point / CF-E325N, CF-E320N, CF-E330N, CF-E335N, CF-E350N, CF-E360N, CF-E500N, CF-E510N, CF-E214N, CF-E218N, CF-E316N, CF- E316N V2, CF-E318N, CF-E312A, CF-WR600N, CF-WR605N, CF-WR610N, CF-WR615N, CF- WR620N, CF-WR625N, CF-WA300N Sincerely, Client’s name / title : Raymond Wang / General Manager Contact information / address : Room 607-610, Block B, TAOJINDI Electronic Business Incubation Base,Tenglong Road, Longhua District, Shenzhen, China Tel: 86-0755-86-83790059 Fax.: 86-0755-83790059-808 Email: [email protected]

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Shenzhen Four Seas Global Link Network Technology Co., Ltd 2015-06-19 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: OYRCF-E325N We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s name / title : Raymond Wang / General Manager Contact information / address : Room 607-610, Block B, TAOJINDI Electronic Business Incubation Base,Tenglong Road, Longhua District, Shenzhen, China Tel: 86-0755-86-83790059 Fax.: 86-0755-83790059-808 Email: [email protected]

Shenzhen Four Seas Global Link Network Technology Co., Ltd Add: Room 607-610, Block B, TAOJINDI Electronic Business Incubation Base,Tenglong Road, Longhua District, Shenzhen, China Tel: 86-0755-86-83790059 Fax.: 86-0755-83790059-808 2016-06-19 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD We, Shenzhen Four Seas Global Link Network Technology Co., Ltd, declare that this EUT (FCC ID: OYRCF-E325N) doesn’t have Ad Hoc mode function on“non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Client’s name / title : Raymond Wang / General Manager Contact information / address : Room 607-610, Block B, TAOJINDI Electronic Business Incubation Base,Tenglong Road, Longhua District, Shenzhen, China Tel: 86-0755-86-83790059 Fax.: 86-0755-83790059-808 Email: [email protected]

Shenzhen Four Seas Global Link Network Technology Co., Ltd Add: Room 607-610, Block B, TAOJINDI Electronic Business Incubation Base,Tenglong Road, Longhua District, Shenzhen, China Tel: 86-0755-86-83790059 Fax.: 86-0755-83790059-808 Date: 2015-06-23 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA FCC ID: OYRCF-E325N Dear Sir/Madam, We, Shenzhen Four Seas Global Link Network Technology Co., Ltd Hereby declares the following statement for SIEMIC, INC, PCB board, circuit, structure and internal of these model(s) are the same, Only color and model number is different for these model: Product name: Wireless Access Point Model no.: CF-E325N, CF-E320N, CF-E330N, CF-E335N, CF-E350N, CF-E360N, CF-E500N, CF- E510N, CF-E214N, CF-E218N, CF-E316N, CF-E316N V2, CF-E318N, CF-E312A, CF-WR600N, CF-WR605N, CF-WR610N, CF-WR615N, CF-WR620N, CF-WR625N, CF-WA300N Sincerely, Client’s name / title : Raymond Wang / General Manager Contact information / address : Room 607-610, Block B, TAOJINDI Electronic Business Incubation Base,Tenglong Road, Longhua District, Shenzhen, China Tel: 86-0755-86-83790059 Fax.: 86-0755-83790059-808 Email: [email protected]

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 5 1. EXTERIOR PHOTOGRAPHS Fig.1 Fig.2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 2 of 5 Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 3 of 5 Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 4 of 5 Fig.7 Fig.8 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 5 of 5 Fig.9

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 1 LABEL AND LOCATION Size: L7.0cm * W3.0cm Material: Tagboard Glue: adhesive sticker Font color: Black Label color: White Label And Location Shenzhen Four SeasGlobal Link Network Technology Co., Ltd Wireless Access Point Trade Mark: COMFAST M/N: CF-E325N FCC ID: OYRCF-E325N This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 3 1. INTERIOR PHOTOGRAPHS Fig.1 Fig.2 ANT_1 ANT_2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 2 of 3 Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 3 of 3 Fig.5 Fig.6

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 2 7. RADIO FREQUENCY EXPOSURE 7.1．Limit According to §1.1310 and §2.1091 RF exposure is calculated. Table: Limits for General Population/Uncontrolled Exposure F = frequency in MHz * = Plane-wave equivalent power density Maximum Permissible Exposure The MPE was calculated at 20cm to show compliance with the power density limit. S = PG/4πR 2 S = Power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna. Note: 1. Manufacturer declared that the maximum antenna gain is 3.0dBi(Max.). 2. Manufacturer declared that the nearest distance between human and the EUT is 20cm. 3. Only record worst case data. SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 2 of 2 Test Mode Channel Frequency (MHz) ANT_1 Power (dBm) ANT_1 Power Tune Up (dBm) ANT_2 Power (dBm) ANT_2 Power Tune Up (dBm) 802.11b Low 2412 17.24 17.0±1.0 17.21 17.0±1.0 Middle 2437 14.91 15.0±1.0 14.93 15.0±1.0 High 2462 12.67 13.0±1.0 12.61 13.0±1.0 802.11g Low 2412 17.60 17.0±1.0 17.55 17.0±1.0 Middle 2437 16.23 16.0±1.0 16.21 16.0±1.0 High 2462 13.08 13.0±1.0 13.13 13.0±1.0 802.11n HT20 Low 2412 17.14 17.0±1.0 17.16 17.0±1.0 Middle 2437 16.48 16.0±1.0 16.45 16.0±1.0 High 2462 13.79 13.0±1.0 13.83 13.0±1.0 802.11n HT40 Low 2422 16.05 16.0±1.0 16.09 16.0±1.0 Middle 2437 15.61 15.0±1.0 15.57 15.0±1.0 High 2452 14.47 14.0±1.0 14.45 14.0±1.0 7.2 Test Results Test Mode Channel ANT_1 Max. Tune Up Power (mW) ANT_1 MPE (mW/cm 2 ) ANT_2 Max. Tune Up Power (mW) ANT_2 MPE (mW/cm 2 ) ANT_1+ANT_2 MPE (mW/cm 2 ) Limit (mW/cm 2 ) 802.11b Low 63.10 0.0250 63.10 0.0250 N/A 1.0 Middle 39.81 0.0158 39.81 0.0158 N/A 1.0 High 25.12 0.0100 25.12 0.0100 N/A 1.0 802.11g Low 63.10 0.0250 63.10 0.0250 N/A 1.0 Middle 50.12 0.0199 50.12 0.0199 N/A 1.0 High 25.12 0.0100 25.12 0.0100 N/A 1.0 802.11n HT20 Low 63.10 0.0250 63.10 0.0250 0.0501 1.0 Middle 50.12 0.0199 50.12 0.0199 0.0398 1.0 High 25.12 0.0100 25.12 0.0100 0.0199 1.0 802.11n HT40 Low 50.12 0.0199 50.12 0.0199 0.0398 1.0 Middle 39.81 0.0158 39.81 0.0158 0.0316 1.0 High 31.62 0.0125 31.62 0.0125 0.0250 1.0 Antenna Gain (typical): 3.0dBi, 1.995(numeric) Prediction distance: >=20cm The power density level worst case at 20 cm is below the uncontrolled exposure limit.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 83 FCC TEST REPORT For Shenzhen Four Seas Global Link Network Technology Co., Ltd Wireless Access Point Test Model: CF-E325N Additional Model No. : See more details at section 1.1 Prepared for : Shenzhen Four Seas Global Link Network Technology Co., Ltd Address : Room 607-610, Block B, TAOJINDI Electronic Business Incubation Base,Tenglong Road, Longhua District, Shenzhen, China Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 1/F., Xingyuan Industrial Park, Tongda Road, Bao'an Avenue, Bao'an District, Shenzhen, Guangdong, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : May 26, 2015 Number of tested samples : 1 Serial number : 121518051502A000299 Date of Test : May 26, 2015 - June 08, 2015 Date of Report : June 19, 2015 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 2 of 83 FCC TEST REPORT FCC CFR 47 PART 15 C(15.247): 2014 Report Reference No. .............. : LCS1505130687E Date of Issue ................................ : June 19, 2015 Testing Laboratory Name ......... : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ........................................ : 1/F., Xingyuan Industrial Park, Tongda Road, Bao'an Avenue, Bao'an District, Shenzhen, Guangdong, China Testing Location/ Procedure ........ : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ....................... : Shenzhen Four Seas Global Link Network Technology Co., Ltd Address ........................................ : Room 607-610, Block B, TAOJINDI Electronic Business Incubation Base,Tenglong Road, Longhua District, Shenzhen, China Test Specification Standard ....................................... : FCC CFR 47 PART 15 C(15.247): 2014 / ANSI C63.10: 2013 Test Report Form No. ................ : LCSEMC-1.0 TRF Originator ............................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF .................................. : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test Item Description. ............... : Wireless Access Point Trade Mark .................................. : COMFAST Test Model ................................... : CF-E325N Ratings ......................................... : DC 48V/0.32A by SWITCHING MODE POWER SUPPLY Result ......................................... : Positive Compiled by: Supervised by: Approved by: Leo Lee/ File administrators Glin Lu/ Technique principal Gavin Liang/ Manager SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 3 of 83 FCC -- TEST REPORT Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCS1505130687E June 19, 2015 Date of issue Test Model.............................. : CF-E325N EUT......................................... : Wireless Access Point Applicant............................... : Shenzhen Four Seas Global Link Network Technology Co., Ltd Address.................................. : Room 607-610, Block B, TAOJINDI Electronic Business Incubation Base,Tenglong Road, Longhua District, Shenzhen, China Telephone............................... : / Fax.......................................... : / Manufacturer........................ : Shenzhen Four Seas Global Link Network Technology Co., Ltd Address................................... : Room 607-610, Block B, TAOJINDI Electronic Business Incubation Base,Tenglong Road, Longhua District, Shenzhen, China Telephone............................... : / Fax.......................................... : / Factory................................... : Shenzhen Four Seas Global Link Network Technology Co., Ltd Address................................... : Room 607-610, Block B, TAOJINDI Electronic Business Incubation Base,Tenglong Road, Longhua District, Shenzhen, China Telephone............................... : / Fax.......................................... : / SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: OYRCF-E325N Report No.: LCS1505130687E This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 4 of 83 TABLE OF CONTENTS 1. GENERAL INFORMATION .............................................................................................................................. 5 1.1. DESCRIPTION OF DEVICE (EUT) ....................................................................................................................... 5 1.2. HOST SYSTEM CONFIGURATION LIST AND DETAILS ......................................................................................... 6 1.3. EXTERNAL I/O ...............................................................................................................................…
