OZ5URCMRX20Advanced Network System Controller

Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-13-032 Page 1 / 1 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 APPENDIX G : USER’S MANUAL MRX-20 Advanced Network System Controller Owner’s Manual 500 Mamaroneck Avenue, Harrison, NY 10528 Phone: (914) 835-4484 Fax: (914) 835-4532 MRX-20 Advanced Network System Controller Owner's Manual © 2012 Universal Remote Control, Inc. The information in this manual is copyright protected. No part of this manual may be copied or reproduced in any form without prior written consent from Universal Remote Control, Inc. UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR OPERATIONAL, TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN THIS MANUAL. The information in this manual may be subject to change without prior notice. URC - Control the Experience is a registered trademark of Universal Remote Control, Inc. All other brand or product names are trademarks or registered trademarks of their respective companies or organizations. T ABLE O F C ONTENTS Congratulations!1 Features and Benefits1 Parts Guide1 MRX-20 Front Panel Descriptions 2 MRX-20 Rear Panel Descriptions3 Navigating the MRX-20’s On-Screen Menu 4 On-Screen Menu Options Overview5 Using the On-Screen Menus7 Adjusting the Settings on the MRX-2020 Installing the MRX-2026 Specifications30 USA Limited Warranty Statement31 Federal Communication Commission Interference Statement33 Declaration of Conformity34 MRX-20 ADVANCEDNETWORKSYSTEMCONTROLLER Page 1 Congratulations! Thank you for purchasing the Total Control MRX-20 Advanced Network System Controller. The unit displays an on-screen interface to control all connected devices throughout the entire home using a Total Control compatible remote. Using the on-screen interface, make a selection to issue a command from the MRX-20 to any connected device such as turning off the lights in every room, viewing the home’s security cameras. View the artist name, song title and album art your child is listening to in their room from a Total Control remote or keypad. Also control whole house music from sources such as a DMS-1200, DMS-100, SNP-1 and a PSX-2. Features and Benefits • Control the Advanced Network System Controller’s on-screen interface using a TRG-100/200 Umotion remote. • Stores and issues commands and macros for all IP, IR, RS-232, Relay, Sensor and 12V controlled devices to MRX series base stations in a project. • Control URC One-Way Lighting with an optional RFTX-1 RF Transmitter. • View a slide show, on your display device, using pictures stored on an online photo sharing service like Picassa. • Can be programmed off premises via the internet. • Easy rack-mounting via optional RMK-2 rack mounting kit. Parts Guide The MRX-20 Advanced Network System Controller includes: 1 - MRX-20 Advanced Network System Controller 1 - Owner’s Manual 1 - Power Cord 10 - IR Emitters with standard 3.5mm plugs (Optional) - RMK-2 Rack Mount kit, RS-232 Cable, Video Sensor, Voltage Sensor MRX-20 Front Panel Descriptions The front panel consists of: Power Status LED: When illuminated this light indicates the MRX-20 is ON. Ethernet Status LED: The Ethernet LED indicates when the MRX-20 is connected to the network: • Connected: Illuminated. • Not Connected: Blinks. HDMI Status LED: The HDMI Status LEDsignifies the MRX-20 has a valid HDMI connection: • Connected: Illuminated. • Problem: Flashes • Not Connected: Not illuminated. Reset: Press to resetthe MRX-20. Resetting the unit will not lose its programming. Press and hold the Reset button for 15 seconds to erase all programming and set the MRX-20 to its original factory condition. Total Control Illumination: Attractive, adjustable accent lighting. Page 2 MRX-20 ADVANCEDNETWORKSYSTEMCONTROLLER Power Status Ethernet Status HDMI Status Reset ButtonLight Pipe MRX-20 Rear Panel Descriptions The rear panel consists of: Power: Plug the included Power cableinto the rear of the MRX-20. Network: Communicate over the Networkto a MRX-20 using an Ethernet cable. USB: For future use! IR Outputs: Ten standard 3.5mm IR emitter portswith individual output level attenuators. HDMI IN: Three HDMI IN ports for transfer of digital HD video and multichannel audio viewable via the display device connected to the HDMI OUT port. HDMI OUT: One HDMI OUTport used to connect a display device. 12 Volt: Two programmable 12V/0.2Aoutputs. Each may be programmed to turn ON, OFF or momentarily TOGGLE its output. Relays: Four programmable Relays to be normally opened (NO), normally closed (NC) or momentary contacts. A maximum of 30V/.5A can be used per relay. Sensors: Four Sensorports allow programming of state dependent and triggered macros. Compatible with URC Video (URC part:VID- 6) and Voltage (URC part: VS-100) sensors. RS-232: Four RS-232 ports support TX (Transmit), RX (Receive) and GND (Ground) connections for two-way communication. Compatible with URC cables RS232F and RS232M. Trigger IN: For future use! RFTX-1: Attach an optional RFTX-1transmitter to control URC One- Way Lighting products via 418MHz or 433.92MHz wireless RF. Page 3 MRX-20 ADVANCEDNETWORKSYSTEMCONTROLLER Power 12 VoltRelaysSensorsRS-232TriggerRFTX-1 USBIR OutputsHDMI INHDMI OUTNetwork Page 4 MRX-20 ADVANCEDNETWORKSYSTEMCONTROLLER Navigating the MRX-20’s On-Screen Menu Navigating through the MRX-20’s on-screen interface is very simple. Control the on-screen menu’s using URC’s Umotion remotes (TRG-100/200). While moving the remote, notice that the on-screen cursormimic’s your movements. Place the cursor over a button to reveal its hovered stateand select. TRG-100 TRG-200 On-Screen Menu Options Overview Quick Bar Menu The Quick Bar menu was designed to contain up to ten of the most needed commands for the device that is being used. Your Custom Professional programs these commands, so any changes to your current view will need to be adjusted by your installer. Device Menu When the basic commands found in the Quick Bar do not include …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 OHSUNG ELECTRONICS CO., LTD #181 Gongdan-Dong, Gumi-Si,Gyeongsangbuk-Do, Korea Tel: +82-54-468-7282, Fax: +82-54-461-8368 July 8, 2013 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, OHSUNG ELECTRONICS CO., LTD, hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Name: Advanced Network System Controller FCC ID: OZ5URCMRX20 We affirm that between SIEMIC and OHSUNG ELECTRONICS CO., LTD, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, --------------------------------------------- Hak-Ki Kim, Q.C Manager OHSUNG ELECTRONICS CO.,LTD

OHSUNG ELECTRONICS CO., LTD #181 Gongdan-Dong, Gumi-Si,Gyeongsangbuk-Do, Korea Tel: +82-54-468-7282, Fax: +82-54-461-8368 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Federal Communications Commission Authorization and Evaluation Division July 8, 2013 Confidentiality Request regarding application for certification of FCC ID: OZ5URCMRX20 We hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name BLOCK DIAGRAM MRX20_BlkDia.pdf SCHEMETIC DIAGRAM MRX20_SchDia.pdf OPERATIONAL DESCRIPTION MRX20_OpeDes.pdf PART LIST MRX20_PrtLst.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. In addition to above mentioned documents, pursuant to Public DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR 2.803 and the importation rules in 47 CFR 2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following for 180 days. Exhibit Type File Name TEST SET UP PHOTOS MRX20_Tsup.pdf EXTERNAL PHOTOGRAPHS MRX20_ExtPho.pdf INTERNAL PHOTOGRAPHS MRX20_IntPho.pdf USER’S MANUAL MRX20_UseMan.pdf The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, --------------------------------------------- Hak-Ki Kim, Q.C Manager OHSUNG ELECTRONICS CO.,LTD

           !  " # $ %& ' (  '  ) *+,++ - .   / 0  1   2*'3 1 '      4    1  !! 4  !  1  11 4      +        2*'3 1 '    4     44   4  .+ 0   4   !   !!  5 4   4 4 1  4 ! $  4  61   4 788  *+,++ 8$9:+ , ;<6<3 <3' = 2 '1 %;,*>2 ?-(%>3, %+ ?-+ G

Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 1 / 2 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 APPENDIX F : EXTERNAL PHOTO GRAPHS Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 2 / 2 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 <Front> < Rear >

Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 1 / 3 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 APPENDIX B : ID SAMPLE LABEL & LOCATION Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 2 / 3 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 LABELLING REQUIREMENTS The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase.  ID Label Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 3 / 3 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20  ID Label Location of EUT ID Label ID Label

Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 1 / 12 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 APPENDIX F : INTERNAL PHOTO GRAPHS Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 2 / 12 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 <Inside> Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 3 / 12 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 <Main board front> <Main board Rear> Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 4 / 12 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 <Network board Front> < Network board Rear> Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 5 / 12 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 < Front board 1 Front> < Front board 1 Rear> Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 6 / 12 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 < Front board 2 Front> < Front board 2 Rear> Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 7 / 12 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 <Sub Board 1 Front> <Sub Board 1 Rear> Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 8 / 12 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 <Sub Board 2 Front> <Sub Board 2 Rear> Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 9 / 12 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 <RF Board Front> <RF Board Rear> RF Antenna Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 10 / 12 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 <Body Frame> <Floor Frame > Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 11 / 12 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 <Rear Frame 1> <Rear Frame 2> Order Number : GETEC-C1-13-118 FCC Part 15 subpart C Test Report Number : GETEC-E3-1 3-032 Page 12 / 12 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 <SMPS>

Order Number : GETEC-C1-13-118 FCC Part 15 Subpart C Test Report Number : GETEC-E3-1 3-032 Page 1 / 3 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 APPENDIX L : MAXIMUM PERMISSIBLE EXPOSURE Order Number : GETEC-C1-13-118 FCC Part 15 Subpart C Test Report Number : GETEC-E3-1 3-032 Page 2 / 3 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 Maximum Permissible Exposure 1.1 Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device (A) Limits for Occupational / Controlled Exposure Frequency range(MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density(S) (mW/cm2) Averaging Time |E|2, |H|2 or S (minutes) 0.3 ~ 3.0 614 1.63 (100)* 6 3.0~30 1842/f 4.89/f (900/f)* 6 30~300 61.4 0.163 1.0 6 300 ~ 1,500 f/300 6 1,500 ~ 100,000 5.0 6 (B) Limits for General Population / Uncontrolled Exposure Frequency range(MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density(S) (mW/cm2) Averaging Time |E|2, |H|2 or S (minutes) 0.3 ~ 1.34 614 1.63 (100)* 30 1.34 ~ 30 824/f 2.19/f (180/f)* 30 30~ 300 27.5 0.073 0.2 30 300 ~ 1,500 f/1500 30 1,500 ~ 100,000 1.0 30 Note: f=frequency in MHz; *Plane-wave equivalent power density 1.2 MPE Calculation Method d GP mVE ×× = 30 )/( Power Density: 377 )/( 2 2 E mWPd= E = Electric field (V/m) P = Peak RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to 2 377 30 d GP Pd × ×× = From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Order Number : GETEC-C1-13-118 FCC Part 15 Subpart C Test Report Number : GETEC-E3-1 3-032 Page 3 / 3 EUT Type: Advanced Network System Controller FCC ID.: OZ5URCMRX20 1.3 Calculated Result and Limit Antenna type: chip antenna Antenna gain (dBi) Antenna gain (numeric) Peak output power (dBm) Peak output power (mW) Power Density (s) (mW/cm 2 ) Limit of Power density (S) (mW/cm 2 ) 4.00 2.51 4.94 3.119 0.001 1
