OZ5URCRFX-250RF Receiver

Order Number : GETEC-C1-10-148 FCC Certification Test Report Number : GETEC-E3-10-081 Page 1 / 1 EUT Type: RF Receiver FCC ID.: OZ5URCRFX-250 APPENDIX H : USER’S MANUAL RFX-250 Installation Manual Optimizing Narrow Band Reception with the MRF-300 or MSC-400 Page 1 RFX-250 INSTALLATIONMANUAL Overview - Compatibility The RFX-250 is a narrow band RF receiver. It replaces an RFX-150 receiv- er in either an MRF-300 or MSC-400 system. It is tuned to receive a much narrower band and is more immune to the interference found near com- ponent racks (generated by microprocessors and power supplies). It is NOT compatible with all URC remote controls. Connections NOTE:The RFX-250 is ONLY compatible with the current versions of the MX-3000, MX-950, MX-900 and the TX-1000 remote controls. The RFX- 250 is NOT compatible with MX-3000 remote controls manufactured before April 1, 2005. You can identify the build date of an MX-3000 by looking at the serial number. The first 6 digits indicate the build date. If the serial number appears as 122905 014054, the first 6 digits indicate that the remote was built on December 29, 2005. When the RFX-250 can be placed within 10 feet of the MRF/MSC unit, you can utilize the cable with 3.5 mm plugs on both ends. When you need a longer wire or are connecting up to three RFX-250’s, use a cable with a minimum of three conductors. If you use CAT 5, utilize two conductors each from two of the twisted pairs for DATA and two from the other twisted pairs for 5V. Use all four of the other conductors twisted in with each pair for GND.This provides better shielding and conductivity for long runs. Connect ONE (only) of either of the RFX- 250’s RF OUT connec- tors to ONE (only) of either of the RF IN connectors on the MRF or the MSC. Once the RFX-250 is correctly connect- ed, the POWER LED lights. If the RF LED lights, the RFX-250 must be moved to a new mounting location. It is receiving in-band RF INTERFERENCE. Page 2 RFX-250 INSTALLATIONMANUAL Optimizing Range and Reliability 1. Power on all AV components, dim all dimmers to 50% and power on anything that may create RF (particularly devices with high speed microprocessors or hard drives). Observe the RF LED of the RFX-250 by cupping your hand over it. If it is glowing or flickering you must relo- cate the RFX-250. If you cannot relocate the RFX-250, try removing its antenna. 2. Once you have found a location that is absolutely clean with everything on, test to see if the range is adequate and that macro reliability is perfect. Start with the antenna angle set to 45 degrees and positioned so that the long side of the antenna is facing the customer’s favorite seating position. 3. When testing, set both the remote and the MRF/MSC to the same VALID RFID#. Keep in mind that zero (0) is not a valid RFID#. Watch the STATUS LED on MRF/MSC - it should light every time you press a button on the remote. This will tell you that the signal was received and understood. Ignore the RF LED on the RFX-250 (it only indicates that a signal was received, not that it was understood). 4. If the range is inadequate, you may extend wire to any area that is not giving good results and place an additional RFX-250 in that area. Up to three RFX-250’s can be connected to each MRF/MSC. NOTE:The RFX-250 is ONLY compatible with additional RFX-250s. You cannot mix RFX-150s in a system with RFX-250s. Suggested antenna angle. Page 3 RFX-250 INSTALLATIONMANUAL USALimited Warranty Statement Your Universal Remote Control, when delivered to you in new condition, is warrantedagainst defects in materials or workmanship as follows: UNI- VERSALREMOTE CONTROL,INC. warrants this product against defects in material or workmanship for a period of one(1) year and as set forth below. Universal Remote Control will, at its sole option, repair theproduct using new or comparable rebuilt parts, or exchange the product for a comparablenew or rebuilt product. In the event of a defect, these are your exclusive remedies. This Limited Warranty covers only the hardware components packaged with the Product. Itdoes not cover technical assistance for hardware or software usage and it does not coverany software products whether or not contained in the Product; any such software is pro-vided "AS IS" unless expressly provided for in any enclosed software Limited Warranty. To obtain warranty service, you must deliver the product, freight prepaid, in its originalpackaging or packaging affording adequate protection to Universal Remote Control at theaddress provided in the Owner's Manual. It is your responsibility to backup any macroprogramming, artwork, soft- ware or other materials that may have been programmed intoyour unit. It is likely that such data, software, or other materials will be lost during ser- viceand Universal Remote Control will not be responsible for any such damage or loss. Adated purchase receipt, Bill of Sale, Installation Contract or other verifiable Proof ofPurchase is required. For product support and other important information visit UniversalRemote Control's website: http://www.UniversalRemoteControl.com or call the UniversalRemote Control Customer Service Center (914) 835-4484. This Limited Warranty only covers product issues caused by defects in material or work-manship during ordinary consumer use. It does not cover product issues caused by anyother reason, including but not limited to product issues due to commercial use, acts ofGod, third-party installa- tion, misuse, limitations of technology, or modification of or to anypart of the Universal Remote Control product. This Limited Warranty does not coverUniversal Remote Control products sold as USED, AS IS, REFUR- BISHED, so-called "BSTOCK" or consumables (such as batteries). This Limited Warranty is invalid if the factory-applied serial number has been altered or removed from the product. This LimitedWarranty is valid only in the United States of America. This Limited Warranty specificallyex- cludes products sold by u…
