OZ5URCTRFUZ1Base Station

G Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 1 / 1 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 APPENDIX H : USER’S MANUALG TRF-UZ1 Z Extender Owner’s Manual TRF-UZ1 Z EXTENDER 500 Mamaroneck Avenue, Harrison, NY 10528 Phone: (914) 835-4484 Fax: (914) 835-4532 TRF-UZ1 Z Extender Owner's Manual © 2012 Universal Remote Control, Inc. The information in this manual is copyright protected. No part of this manual may be copied or reproduced in any form without prior written consent from Universal Remote Control, Inc. UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR OPERATIONAL, TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN THIS MANUAL. The information in this manual may be subject to change without prior notice. URC - Control the Experience is a registered trademark of Universal Remote Control, Inc. All other brand or product names are trademarks or registered trademarks of their respective companies or organizations. TRF-UZ1 Z EXTENDER Congratulations!1 Features and Benefits1 Parts Guide1 TRF-UZ1 Panel Descriptions2 Specifications3 USA Limited Warranty Statement4 Federal Communication Commission Interference Statement6 Regulatory Information to the user7 Delaration of Conformity8 Page 1 TRF-UZ1 Z EXTENDER Congratulations! Thank you for purchasing the Total Control TRF-UZ1 Z Extender for use with an MRX Advanced Network System Controller. This device allows for optimal placement of the system’s RF antenna, allowing for more robust coverage in all corners of the home or small office space. Designed to work on URC’s 2.4GHz wireless network, this compact device works with other devices that use the same network protocol, like the MRX-10 Controller, TRC-780 Remote and the THZ-100 Thermostat. Features and Benefits  Replaces the internal antenna on the MRX-10 to allow for optimal placement and communication, through the wired network, between devices operating on URC’s 2.4GHz network. Using the optional TRF-UZ1 Z disables the internal antenna on the MRX-10 and uses its own internal antenna as the new “point of origin” for the RF signal. This feature provides an abundance of placement options, minimizes the need for ZR series repeaters, and ensures a robust signal to auxiliary devices.  Adds a 2.4GHz network antenna to the MRX-20 Advanced Network System Controller Without an included 2.4GHz antenna, the MRX-20 requires the use of the TRF-UZ1 Z to enable communication, over the 2.4GHz network, to compatible devices (TRC-780, THZ-100, etc.). Using this external antenna allows for optimal placement in the home or small office space.  Compact design for easy installation Easily and discretely install the TRF-GE1 Extender. Maintain your home decor while controlling your Total Control MRX Advanced Network System Controller. Parts Guide The TRF-UZ1 Z Extender includes: 1 - TRF-UZ1 Z Extender 1 - Owner’s Manual TRF-UZ1 Panel Descriptions The front, rear and bottom panel consists of: Power LED:When illuminated this light indicates the TRF-UZ1 is ON. Status LED: The Status LEDsignifies when the TRF-UZ1 is connected to the network: Connected: Illuminates green. Not Connected: Remains OFF. Pairing: Illuminates orange. Data LED: The Data LEDflashes as the TRF-UZ1 receives and transmits data. DC 12V (1A): Plug in the included AC/DC adapter to power up the TRF-UZ1. LAN: Communicate over the network to an MRX-10/20 using an Ethernet cable. Reset: Pressing the Reset button, with a stylus or paper clip, refreshes the TRF-UZ1. Unplugging and re-plugging the power cable also resets the unit. Pressing and holding the Reset button for 10 seconds, factory defaults the TRF-UZ1 and places the unit back to its original factory condition. Page 2 TRF-UZ1 Z EXTENDER POWER LED STATUS LED DATA LED DC 12V LAN Reset TRF-UZ1 Z EXTENDER Specifications Microprocessor:ARM32-bit Cortex- M3(120MHz) Power Supply:12V DC 1A RAM:128Mbyte Mobile DDR RF Range(radio frequency):50 to 100 feet, depending upon the environment RF Freqency:2.405~2.480 GHz NAND: 128Mbyte FLASH: 768Kbytes SRAM: 128 + 4 Kbyte Weight:3.058 oz Size:3.74” X 2.7” X 1.1” Power:12V DC 1A Page 3 TRF-UZ1 Z EXTENDER USA Limited Warranty Statement Your Universal Remote Control, when delivered to you in new condition, is warranted against defects in materials or workmanship as follows: UNIVERSAL REMOTE CONTROL, INC.warrants this product against defects in material or workmanship for a period of one (1) year and as set forth below. Universal Remote Control will, at its sole option, repair the product using new or comparable rebuilt parts, or exchange the product for a comparable new or rebuilt product. In the event of a defect, these are your exclusive remedies. This Limited Warranty covers only the hardware components packaged with the Product. It does not cover technical assistance for hardware or software usage and it does not cover any software products whether or not contained in the Product; any such software is provided "AS IS" unless expressly provided for in any enclosed software Limited Warranty. To obtain warranty service, you must deliver the product, freight prepaid, in its original packaging or packaging affording adequate protection to Universal Remote Control at the address provided in the Owner's Manual. It is your responsibility to backup any macro programming, artwork, software or other materials that may have been programmed into your unit. It is likely that such data, software, or other materials will be lost during service and Universal Remote Control will not be responsible for any such damage or loss.A dated purchase receipt, Bill of Sale, Installation Contract or other verifiable Proof of Purchase is required. For product support and other important information visit Universal Remote Control's website: http://www.UniversalRemote.comor call the Customer Service Center (914) 835-4484. This Limited Warranty only covers product issues caused by defects in material or workmanship during ordinary c…

Text truncated - open the document above for the full version.

Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 1 / 1 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 APPENDIX A : ATTESTATION STATEMENT  Authorization  DoC for computer peripheral portion February 14, 2011 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. To whom it may concern: We, the undersigned, hereby authorize GUMI College EMC Center to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relation to these matters. Any and all acts carried out by GUMI College EMC Center on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to the application is subject of a denial of benefits, including FCC benefits, pursuant 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Sincerely, HAK-KI, KIM / General Manager OHSUNG ELECTRONICS CO., LTD. OHSUNG ELECTRONICS CO., LTD #181 Gongdan-Dong, Gumi-Si,Gyeongsangbuk-Do, Korea Tel: +82-54-468-7282, Fax: +82-54-461 -8368 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 1435 Oakland Mills Road Columbia, MD 21046 U.S.A November 6, 2012 Subject: FCC Application for OZ5URCTRFUZ1 We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Sincerely, --------------------------------------------- Hak-Ki Kim, Q.C Manager OHSUNG ELECTRONICS CO., LTD

SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 OHSUNG ELECTRONICS CO., LTD #181 Gongdan-Dong, Gumi-Si,Gyeongsangbuk-Do, Korea Tel: +82-54-468-7282, Fax: +82-54-461-8368 November 15, 2012 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, OHSUNG ELECTRONICS CO., LTD, hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Name: Base Station FCC ID: OZ5URCTRFUZ1 We affirm that between SIEMIC and OHSUNG ELECTRONICS CO., LTD, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, --------------------------------------------- Hak-Ki Kim, Q.C Manager OHSUNG ELECTRONICS CO.,LTD

OHSUNG ELECTRONICS CO., LTD #181 Gongdan-Dong, Gumi-Si,Gyeongsangbuk-Do, Korea Tel: +82-54-468-7282, Fax: +82-54-461-8368 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Federal Communications Commission Authorization and Evaluation Division November 15, 2012 Confidentiality Request regarding application for certification of FCC ID: OZ5URCTRFUZ1 We hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name BLOCK DIAGRAM URCTRFUZ1_BlkDia.pdf SCHEMETIC DIAGRAM URCTRFUZ1_SchDia.pdf OPERATIONAL DESCRIPTION URCTRFUZ1_OpeDes.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. In addition to above mentioned documents, pursuant to Public DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR 2.803 and the importation rules in 47 CFR 2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following for 180 days. Exhibit Type File Name TEST SET UP PHOTOS URCTRFUZ1_Tsup.pdf EXTERNAL PHOTOGRAPHS URCTRFUZ1_ExtPho.pdf INTERNAL PHOTOGRAPHS URCTRFUZ1_IntPho.pdf USER’S MANUAL URCTRFUZ1_UseMan.pdf The applicant understands that pursuant to Section 0.457& 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, --------------------------------------------- Hak-Ki Kim, Q.C Manager OHSUNG ELECTRONICS CO., LTD

Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 1 / 5 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 APPENDIX F : EXTERNAL PHOTOGRAPHS Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 2 / 5 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 < Front > Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 3 / 5 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 < Rear > Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 4 / 5 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 < I/O port > Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 5 / 5 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 < Adapter >

Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 1 / 2 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 APPENDIX B : ID SAMPLE LABEL & LOCATION Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 2 / 2 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 LABELLING REQUIREMENTS The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase.  ID Label  ID Label Location of EUT ID Label

Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 1 / 6 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 APPENDIX G : INTERNAL PHOTOGRAPHS Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 2 / 6 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 < Inside > Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 3 / 6 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 < Main board front > Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 4 / 6 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 < Main board rear > Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 5 / 6 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 < RF module front > Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 6 / 6 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 < RF module rear >

Order Number : GETEC-C1-12-307 FCC Certification Test Report Number : GETEC-E3-12-107 Page 1 / 3 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 APPENDIX L : MAXIMUM PERMISSIBLE EXPOSURE Order Number : GETEC-C1-12-307 FCC Certification Test Report Number : GETEC-E3-12-107 Page 2 / 3 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 Maximum Permissible Exposure 1.1 Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device (A) Limits for Occupational / Controlled Exposure Frequency range(MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density(S) (mW/cm2) Averaging Time |E|2, |H|2 or S (minutes) 0.3 ~ 3.0 614 1.63 (100)* 6 3.0~30 1842/f 4.89/f (900/f)* 6 30~300 61.4 0.163 1.0 6 300 ~ 1,500 f/300 6 1,500 ~ 100,000 5.0 6 (B) Limits for General Population / Uncontrolled Exposure Frequency range(MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density(S) (mW/cm2) Averaging Time |E|2, |H|2 or S (minutes) 0.3 ~ 1.34 614 1.63 (100)* 30 1.34 ~ 30 824/f 2.19/f (180/f)* 30 30~ 300 27.5 0.073 0.2 30 300 ~ 1,500 f/1500 30 1,500 ~ 100,000 1.0 30 Note: f=frequency in MHz; *Plane-wave equivalent power density 1.2 MPE Calculation Method d GP mVE   30 )/( Power Density: 377 )/( 2 2 E mWPd E = Electric field (V/m) P = Peak RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to 2 377 30 d GP Pd    From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Order Number : GETEC-C1-12-307 FCC Certification Test Report Number : GETEC-E3-12-107 Page 3 / 3 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 1.3 Calculated Result and Limit Antenna type: chip antenna Antenna gain (dBi) Antenna gain (numeric) Peak output power (dBm) Peak output power (mW) Power Density (s) (mW/cm 2 ) Limit of Power density (S) (mW/cm 2 ) 3.05 2.02 17.74 59.43 0.024 1

Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 1 / 4 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1 APPENDIX E : TEST SET UP PHOTOGRAPHS Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 2 / 4 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1  Conducted Test Picture (Front)  Conducted Test Picture (Rear) Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 3 / 4 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1  Radiated Test Picture (Front): Below 30 MHz  Radiated Test Picture (Rear): Below 1 GHz Order Number : GETEC-C1-12-307 FCC Part 15 subpart C Test Report Number : GETEC-E3-12-107 Page 4 / 4 EUT Type: Base Station FCC ID.: OZ5URCTRFUZ1  Radiated Test Picture (Front): Above 1 GHz
