OZ8DRYSIGNALWet Sensor

USING THE DRY4LIFE BEDWETTING ALARM SE T UP : 1) Insert 1 size C battery into the alarm clock. 2) Press and release the silver button on top of the alarm. It will ring to indicate it is functional. 3) Leave the button in the downright position until ready for bedtime. It is now deactivated. (The clock will continue to tell t ime, but the wake up alarm is permanently disabled to prevent confusion.) PREPARATION FOR BED: 1) Cut a slit in a common, disposable, self-adhesive panty shield. 2) Insert the wet-sensor into the panty shield, the metal side facing the body. 3) Peel and stick the panty shield containing the wet sensor to the inside of close fitting underwear. (As close to the source of urine as possible.) 4) Release the alarm button. It will ring indicating the unit is ready to receive signals from the transmitter when the user wets. WHEN THE ALARM GOES OFF: 1) Depress the button. The alarm will stop sounding. 2) Clean the wet-sensor with soap and water.

FOUNTAIN TECHNOLOGIES, INC. COMPLIANCE LABORATORY 50 Randolph Rd. Somerset, NJ 08873 Tel: (732) 560-9010 Fax: (732) 560-9173 ELECTROMAGNETIC EMISSION COMPLIANCE REPORT of TRANSMITTER MODEL: DRYSIGNAL FCC ID: OZ8DRYSIGNAL May 15, 2000 This report concerns (check one): Original grant x Class II change Equipment type: TRANSMITTER Deferred grant requested per 47 CF 0.457(d)(1)(ii)? yes no x If yes, defer until: (date) Company agrees to notify the Commission by (date) of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? yes no x If no, assumed Part 15, Subpart B for unintentional radiators - the new 47 CFR [10-1-90 Edition] provision. Report prepared for: DRY 4 LIFE, INC. Report prepared by:Fountain Compliance Lab Report number:0048-2K0410-01T The test result in this report IS supported and covered by the NVLAP accreditation FCC ID: OZ8DRYSIGNAL ——————————————————————————————————————————————— Fountain Compliance Lab 50 Randolph Rd., Somerset, NJ 08873 Tel: (732) 560-9010 Fax: (732) 560-9173 2 Table of Contents Report Cover Page ........................................................................................................ 1 Table of Contents........................................................................................................... 2 Figures............................................................................................................................ 3 1. GENERAL INFORMATION...................................................................................4 1.1 Verification of Compliance .........................................................................4 1.2 Equipment Modifications............................................................................5 1.3 Product Information....................................................................................6 1.4 Test Methodology ........................................................................................6 1.5 Test Facility..................................................................................................6 1.6 Test Equipment ............................................................................................6 1.7 Statement of the Document Use..................................................................7 2. PRODUCT LABELING............................................................................................8 3. SYSTEM TEST CONFIGURATION.......................................................................9 3.1 Justification..................................................................................................9 3.2 Special Accessories......................................................................................9 3.3 Configuration of Tested System..................................................................9 4. SYSTEM SCHEMATICS .........................................................................................12 5. RADIATED EMISSION DATA...............................................................................13 5.1 Field Strength Calculation .........................................................................13 5.2 Test Methods and Conditions .....................................................................13 5.3 Test Data.......................................................................................................13 5.4 Occupied Bandwidth...................................................................................14 6. PHOTOS OF TESTED EUT ....................................................................................17 FCC ID: OZ8DRYSIGNAL ——————————————————————————————————————————————— Fountain Compliance Lab 50 Randolph Rd., Somerset, NJ 08873 Tel: (732) 560-9010 Fax: (732) 560-9173 3 Figures Figure 2.1 FCC ID Label ..............................................................................................8 Figure 2.2 Location of Label on Back of the EUT......................................................8 Figure 3.1 Radiated Test Setup, Position 1 .................................................................10 Figure 3.2 Radiated Test Setup, Position 2 .................................................................10 Figure 3.3 Radiated Test Setup, Position 3 .................................................................11 Figure 4.1 EUT Schematics ..........................................................................................12 Figure 5.1 Pulse Train Timing .....................................................................................15 Figure 5.2 Occupied Bandwidth ..................................................................................16 Figure 6.1 Front View...................................................................................................18 Figure 6.2 Rear View ....................................................................................................19 Figure 6.3 Component Side ..........................................................................................20 FCC ID: OZ8DRYSIGNAL ——————————————————————————————————————————————— Fountain Compliance Lab 50 Randolph Rd., Somerset, NJ 08873 Tel: (732) 560-9010 Fax: (732) 560-9173 4 1. GENERAL INFORMATION 1.1 Verification of Compliance EUT:TRANSMITTER Model:DRYSIGNAL Applicant:DRY 4 LIFE, INC. Test Type:FCC Part 15C CERTIFICATION Result:PASS Tested by:FOUNTAIN COMPLIANCE LABORATORY Test Date:05/12/00 Report Number:0048-2K0410-01T The above equipment was tested by Fountain Technologies, Inc. Compliance Laboratory for compliance with the requirement set forth in the FCC rules and regulations Part 15, subpart C. This said equipment in the configuration described in the report, shows the maximum emission levels emanating from equipment are within the compliance requirements. The estimated uncertainty of the test result is given as following. The method of uncertainty calculation …
