OZAES315V1Containment Seal Tracking

Note: This report may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC ID PER PART 15.231 User Manual FOR P-SERV TECHNOLOGIES PTE LTD. Blk1093, Lower Delta Road, #07-05/08 Tiong Bahru Industrial Estate Singapore 169204 FCC ID: OZAES315V1 April 24, 2000 This Report Concerns: Original Report Equipment Type: Electronic Container Seal Transmitter (315 MHz), ITE Test Engineer:Thomas Huang Test Date:April 14, 2000 Reviewed By: John Y. Chan - Director, Compliance Engineering Prepared By:Bay Area Compliance Laboratory Corporation 230 Commercial Street, Suite 2 Sunnyvale, CA 94086 (408) 732-9162 P-SERV Technologies PTE LTD. FCC ID: OZAES315V1 Report # manual.docFCC ID Report Page 2 of 34 TABLE OF CONTENTS 1 - GENERAL INFORMATION.................................................................................................................................3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)..............................................................................3 1.2 OBJECTIVE............................................................................................................................................................3 1.3 RELATED SUBMITTAL(S)/GRANT(S):.....................................................................................................................3 1.4 TEST METHODOLOGY............................................................................................................................................3 1.5 TEST FACILITY......................................................................................................................................................3 1.6 TEST EQUIPMENT LIST..........................................................................................................................................4 1.7 EQUIPMENT UNDER TEST (EUT)...........................................................................................................................4 1.8 SUPPORT EQUIPMENT............................................................................................................................................4 1.9 EUT CONFIGURATION DETAILS AND LIST............................................................................................................4 1.10 EXTERNAL I/O CABLING.....................................................................................................................................4 2 - SYSTEM TEST CONFIGURATION....................................................................................................................5 2.1 JUSTIFICATION......................................................................................................................................................5 2.2 BLOCK DIAGRAM..................................................................................................................................................5 2.3 TEST SETUP BLOCK DIAGRAM..............................................................................................................................6 2.4 EQUIPMENT MODIFICATIONS................................................................................................................................7 APPENDIX B – USER MANUAL...............................................................................................................................8 APPENDIX C – AGENCY AUTHORIZATION LETTER...................................................................................34 P-SERV Technologies PTE LTD. FCC ID: OZAES315V1 Report # manual.docFCC ID Report Page 3 of 34 1 - GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) The P-SERV TECHNOLOGIES PTE LTD., model ES315V1 or the "EUT" as referred to in this report is a 315MHz RF transmitter which is a part of the Electronic Container Seal (ECS) designed to be used by all shippers, aimed to improve the efficiency of port operation. The EUT transmits 315MHz FM signal. The EUT output impedance shall be 50Ÿ. The EUT measures 2.0” L x 1.0” W x 4.0” H. 1.2 Objective This Type approval report is prepared on behalf of P-SERV TECHNOLOGIES PTE LTD. in accordance with Part 2, Subpart J, and Part 15, Subparts A and B of the Federal Communication Commissions rules. The objective of the manufacturer is to demonstrate compliance with FCC rules, Part 15, sec 231 for conducted and radiated margin. 1.3 Related Submittal(s)/Grant(s) No Related Submittals 1.4 Test Methodology All measurements contained in this report were conducted with ANSI C63.4 –1992, American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the range of 9 kHz to 40 GHz. All radiated and conducted emissions measurement was performed at Bay Area Compliance Laboratory, Corp. The radiated testing was performed at an antenna-to-EUT distance of 3 meters. 1.5 Test Facility The Open Area Test site used by Bay Area Compliance Laboratory Corporation to collect radiated and conducted emission measurement data is located in the back parking lot of the building at 230 Commercial Street, Suite 2, Sunnyvale, California, USA. Test sites at Bay Area Compliance Laboratory Corporation has been fully described in reports submitted to the Federal Communication Commission (FCC) and Voluntary Control Council for Interference (VCCI). The details of these reports has been found to be in compliance with the requirements of Section 2.948 of the FCC Rules on February 11 and December 10, 1997 and Article 8 of the VCCI regulations on December 25, 1997. The facility also complies with the radiated and AC line conducted test site criteria set forth in ANSI C63.4-1992. The Federal Communications Commission and Voluntary Control Council for Interference has the reports on file and is lis…

Text truncated - open the document above for the full version.

Note: This report may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC ID PER PART 15.231 EUT external photo FOR P-SERV TECHNOLOGIES PTE LTD. Blk1093, Lower Delta Road, #07-05/08 Tiong Bahru Industrial Estate Singapore 169204 FCC ID: OZAES315V1 April 24, 2000 This Report Concerns: Original Report Equipment Type: Electronic Container Seal Transmitter (315 MHz), ITE Test Engineer:Thomas Huang Test Date:April 14, 2000 Reviewed By: John Y. Chan - Director, Compliance Engineering Prepared By:Bay Area Compliance Laboratory Corporation 230 Commercial Street, Suite 2 Sunnyvale, CA 94086 (408) 732-9162 P-SERV Technologies PTE LTD. FCC ID: OZAES315V1 Report # EUT external.docFCC ID Report Page 2 of 11 TABLE OF CONTENTS 1 - GENERAL INFORMATION.................................................................................................................................3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)..............................................................................3 1.2 OBJECTIVE............................................................................................................................................................3 1.3 RELATED SUBMITTAL(S)/GRANT(S)......................................................................................................................3 1.4 TEST METHODOLOGY............................................................................................................................................3 1.5 TEST FACILITY......................................................................................................................................................3 1.6 TEST EQUIPMENT LIST..........................................................................................................................................4 1.7 EQUIPMENT UNDER TEST (EUT)...........................................................................................................................4 1.8 SUPPORT EQUIPMENT............................................................................................................................................4 1.9 EUT CONFIGURATION DETAILS AND LIST............................................................................................................4 1.10 EXTERNAL I/O CABLING.....................................................................................................................................4 2 - SYSTEM TEST CONFIGURATION....................................................................................................................5 2.1 JUSTIFICATION......................................................................................................................................................5 2.2 BLOCK DIAGRAM..................................................................................................................................................5 2.3 TEST SETUP BLOCK DIAGRAM..............................................................................................................................6 2.4 EQUIPMENT MODIFICATIONS................................................................................................................................7 3 – EUT PHOTOGRAPHS..........................................................................................................................................8 3.1 EUT: TOP VIEW....................................................................................................................................................8 3.2 EUT: REAR VIEW.................................................................................................................................................9 APPENDIX A – AGENCY AUTHORIZATION LETTER...................................................................................10 P-SERV Technologies PTE LTD. FCC ID: OZAES315V1 Report # EUT external.docFCC ID Report Page 3 of 11 1 - GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) The P-SERV TECHNOLOGIES PTE LTD., model ES315V1 or the "EUT" as referred to in this report is a 315MHz RF transmitter which is a part of the Electronic Container Seal (ECS) designed to be used by all shippers, aimed to improve the efficiency of port operation. The EUT transmits 315MHz FM signal. The EUT output impedance shall be 50Ÿ. The EUT measures 2.0” L x 1.0” W x 4.0” H. 1.2 Objective This Type approval report is prepared on behalf of P-SERV TECHNOLOGIES PTE LTD. in accordance with Part 2, Subpart J, and Part 15, Subparts A and B of the Federal Communication Commissions rules. The objective of the manufacturer is to demonstrate compliance with FCC rules, Part 15, sec 231 for conducted and radiated margin. 1.3 Related Submittal(s)/Grant(s) No Related Submittals 1.4 Test Methodology All measurements contained in this report were conducted with ANSI C63.4 –1992, American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the range of 9 kHz to 40 GHz. All radiated and conducted emissions measurement was performed at Bay Area Compliance Laboratory, Corp. The radiated testing was performed at an antenna-to-EUT distance of 3 meters. 1.5 Test Facility The Open Area Test site used by Bay Area Compliance Laboratory Corporation to collect radiated and conducted emission measurement data is located in the back parking lot of the building at 230 Commercial Street, Suite 2, Sunnyvale, California, USA. Test sites at Bay Area Compliance Laboratory Corporation has been fully described in reports submitted to the Federal Communication Commission (FCC) and Voluntary Control Council for Interference (VCCI). The details of these reports has been found to be in compliance with the requirements of Sectio…

Text truncated - open the document above for the full version.

Note: This report may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC ID PER PART 15.231 EUT FCC ID Label Location FOR P-SERV TECHNOLOGIES PTE LTD. Blk1093, Lower Delta Road, #07-05/08 Tiong Bahru Industrial Estate Singapore 169204 FCC ID: OZAES315V1 April 24, 2000 This Report Concerns: Original Report Equipment Type: Electronic Container Seal Transmitter (315 MHz), ITE Test Engineer:Thomas Huang Test Date:April 14, 2000 Reviewed By: John Y. Chan - Director, Compliance Engineering Prepared By:Bay Area Compliance Laboratory Corporation 230 Commercial Street, Suite 2 Sunnyvale, CA 94086 (408) 732-9162 P-SERV Technologies PTE LTD. FCC ID: OZAES315V1 Report # EUT ID Label .docFCC ID Report Page 2 of 10 TABLE OF CONTENTS 1 - GENERAL INFORMATION.................................................................................................................................3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)..............................................................................3 1.2 OBJECTIVE............................................................................................................................................................3 1.3 RELATED SUBMITTAL(S)/GRANT(S)......................................................................................................................3 1.4 TEST METHODOLOGY............................................................................................................................................3 1.5 TEST FACILITY......................................................................................................................................................3 1.6 TEST EQUIPMENT LIST..........................................................................................................................................4 1.7 EQUIPMENT UNDER TEST (EUT)...........................................................................................................................4 1.8 SUPPORT EQUIPMENT............................................................................................................................................4 1.9 EUT CONFIGURATION DETAILS AND LIST............................................................................................................4 1.10 EXTERNAL I/O CABLING.....................................................................................................................................4 2 - SYSTEM TEST CONFIGURATION....................................................................................................................5 2.1 JUSTIFICATION......................................................................................................................................................5 2.2 BLOCK DIAGRAM..................................................................................................................................................5 2.3 TEST SETUP BLOCK DIAGRAM..............................................................................................................................6 2.4 EQUIPMENT MODIFICATIONS................................................................................................................................7 3– FCC PRODUCT LABELING AND WARNING STATEMENT........................................................................8 3.1 FCC ID LABEL.....................................................................................................................................................8 3.2 PROPOSED LABEL LOCATION ON EUT..................................................................................................................8 3.3 FCC WARNING STATEMENT.................................................................................................................................8 APPENDIX A– AGENCY AUTHORIZATION LETTER......................................................................................9 P-SERV Technologies PTE LTD. FCC ID: OZAES315V1 Report # EUT ID Label .docFCC ID Report Page 3 of 10 1 - GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) The P-SERV TECHNOLOGIES PTE LTD., model ES315V1 or the "EUT" as referred to in this report is a 315MHz RF transmitter which is a part of the Electronic Container Seal (ECS) designed to be used by all shippers, aimed to improve the efficiency of port operation. The EUT transmits 315MHz FM signal. The EUT output impedance shall be 50Ÿ. The EUT measures 2.0” L x 1.0” W x 4.0” H. 1.2 Objective This Type approval report is prepared on behalf of P-SERV TECHNOLOGIES PTE LTD. in accordance with Part 2, Subpart J, and Part 15, Subparts A and B of the Federal Communication Commissions rules. The objective of the manufacturer is to demonstrate compliance with FCC rules, Part 15, sec 231 for conducted and radiated margin. 1.3 Related Submittal(s)/Grant(s) No Related Submittals 1.4 Test Methodology All measurements contained in this report were conducted with ANSI C63.4 –1992, American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the range of 9 kHz to 40 GHz. All radiated and conducted emissions measurement was performed at Bay Area Compliance Laboratory, Corp. The radiated testing was performed at an antenna-to-EUT distance of 3 meters. 1.5 Test Facility The Open Area Test site used by Bay Area Compliance Laboratory Corporation to collect radiated and conducted emission measurement data is located in the back parking lot of the building at 230 Commercial Street, Suite 2, Sunnyvale, California, USA. Test sites at Bay Area Compliance Laboratory Corporation has been fully described in reports submitted to the Federal Communication Commission (FCC) and Voluntary Control Council for Inter…

Text truncated - open the document above for the full version.

Note: This report may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC ID PER PART 15.231 EUT Internal Photo FOR P-SERV TECHNOLOGIES PTE LTD. Blk1093, Lower Delta Road, #07-05/08 Tiong Bahru Industrial Estate Singapore 169204 FCC ID: OZAES315V1 April 24, 2000 This Report Concerns: Original Report Equipment Type: Electronic Container Seal Transmitter (315 MHz), ITE Test Engineer:Thomas Huang Test Date:April 14, 2000 Reviewed By: John Y. Chan - Director, Compliance Engineering Prepared By:Bay Area Compliance Laboratory Corporation 230 Commercial Street, Suite 2 Sunnyvale, CA 94086 (408) 732-9162 P-SERV Technologies PTE LTD. FCC ID: OZAES315V1 Report # EUT internal photo.docFCC ID Report Page 2 of 11 TABLE OF CONTENTS 1 - GENERAL INFORMATION.................................................................................................................................3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)..............................................................................3 1.2 OBJECTIVE............................................................................................................................................................3 1.3 RELATED SUBMITTAL(S)/GRANT(S)......................................................................................................................3 1.4 TEST METHODOLOGY............................................................................................................................................3 1.5 TEST FACILITY......................................................................................................................................................3 1.6 TEST EQUIPMENT LIST..........................................................................................................................................4 1.7 EQUIPMENT UNDER TEST (EUT)...........................................................................................................................4 1.8 SUPPORT EQUIPMENT............................................................................................................................................4 1.9 EUT CONFIGURATION DETAILS AND LIST............................................................................................................4 1.10 EXTERNAL I/O CABLING.....................................................................................................................................4 2 - SYSTEM TEST CONFIGURATION....................................................................................................................5 2.1 JUSTIFICATION......................................................................................................................................................5 2.2 BLOCK DIAGRAM..................................................................................................................................................5 2.3 TEST SETUP BLOCK DIAGRAM..............................................................................................................................6 2.4 EQUIPMENT MODIFICATIONS................................................................................................................................7 3 – EUT PHOTOGRAPHS..........................................................................................................................................8 3.1 EUT: INSIDE COMPONENT VIEW...........................................................................................................................8 3.2 EUT: INSIDE CIRCUIT VIEW.................................................................................................................................9 APPENDIX A – AGENCY AUTHORIZATION LETTER...................................................................................10 P-SERV Technologies PTE LTD. FCC ID: OZAES315V1 Report # EUT internal photo.docFCC ID Report Page 3 of 11 1 - GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) The P-SERV TECHNOLOGIES PTE LTD., model ES315V1 or the "EUT" as referred to in this report is a 315MHz RF transmitter which is a part of the Electronic Container Seal (ECS) designed to be used by all shippers, aimed to improve the efficiency of port operation. The EUT transmits 315MHz FM signal. The EUT output impedance shall be 50Ÿ. The EUT measures 2.0” L x 1.0” W x 4.0” H. 1.2 Objective This Type approval report is prepared on behalf of P-SERV TECHNOLOGIES PTE LTD. in accordance with Part 2, Subpart J, and Part 15, Subparts A and B of the Federal Communication Commissions rules. The objective of the manufacturer is to demonstrate compliance with FCC rules, Part 15, sec 231 for conducted and radiated margin. 1.3 Related Submittal(s)/Grant(s) No Related Submittals 1.4 Test Methodology All measurements contained in this report were conducted with ANSI C63.4 –1992, American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the range of 9 kHz to 40 GHz. All radiated and conducted emissions measurement was performed at Bay Area Compliance Laboratory, Corp. The radiated testing was performed at an antenna-to-EUT distance of 3 meters. 1.5 Test Facility The Open Area Test site used by Bay Area Compliance Laboratory Corporation to collect radiated and conducted emission measurement data is located in the back parking lot of the building at 230 Commercial Street, Suite 2, Sunnyvale, California, USA. Test sites at Bay Area Compliance Laboratory Corporation has been fully described in reports submitted to the Federal Communication Commission (FCC) and Voluntary Control Council for Interference (VCCI). The details of these reports has been found to be in compliance with the requirements of Section 2.94…

Text truncated - open the document above for the full version.

Note: This report may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC ID PER PART 15.231 EUT Schematics FOR P-SERV TECHNOLOGIES PTE LTD. Blk1093, Lower Delta Road, #07-05/08 Tiong Bahru Industrial Estate Singapore 169204 FCC ID: OZAES315V1 April 24, 2000 This Report Concerns: Original Report Equipment Type: Electronic Container Seal Transmitter (315 MHz), ITE Test Engineer:Thomas Huang Test Date:April 14, 2000 Reviewed By: John Y. Chan - Director, Compliance Engineering Prepared By:Bay Area Compliance Laboratory Corporation 230 Commercial Street, Suite 2 Sunnyvale, CA 94086 (408) 732-9162 P-SERV Technologies PTE LTD. FCC ID: OZAES315V1 Report # EUT schematics.doc FCC ID Report Page 2 of 11 TABLE OF CONTENTS 1 - GENERAL INFORMATION.................................................................................................................................3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)..............................................................................3 1.2 OBJECTIVE............................................................................................................................................................3 1.3 RELATED SUBMITTAL(S)/GRANT(S)......................................................................................................................3 1.4 TEST METHODOLOGY............................................................................................................................................3 1.5 TEST FACILITY......................................................................................................................................................3 1.6 TEST EQUIPMENT LIST..........................................................................................................................................4 1.7 EQUIPMENT UNDER TEST (EUT)...........................................................................................................................4 1.8 SUPPORT EQUIPMENT............................................................................................................................................4 1.9 EUT CONFIGURATION DETAILS AND LIST............................................................................................................4 1.10 EXTERNAL I/O CABLING.....................................................................................................................................4 2 - SYSTEM TEST CONFIGURATION....................................................................................................................5 2.1 JUSTIFICATION......................................................................................................................................................5 2.2 BLOCK DIAGRAM..................................................................................................................................................5 2.3 TEST SETUP BLOCK DIAGRAM..............................................................................................................................6 2.4 EQUIPMENT MODIFICATIONS................................................................................................................................7 APPENDIX A –EUT SCHEMATICS.........................................................................................................................8 APPENDIX B – AGENCY AUTHORIZATION LETTER...................................................................................10 P-SERV Technologies PTE LTD. FCC ID: OZAES315V1 Report # EUT schematics.doc FCC ID Report Page 3 of 11 1 - GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) The P-SERV TECHNOLOGIES PTE LTD., model ES315V1 or the "EUT" as referred to in this report is a 315MHz RF transmitter which is a part of the Electronic Container Seal (ECS) designed to be used by all shippers, aimed to improve the efficiency of port operation. The EUT transmits 315MHz FM signal. The EUT output impedance shall be 50Ÿ. The EUT measures 2.0” L x 1.0” W x 4.0” H. 1.2 Objective This Type approval report is prepared on behalf of P-SERV TECHNOLOGIES PTE LTD. in accordance with Part 2, Subpart J, and Part 15, Subparts A and B of the Federal Communication Commissions rules. The objective of the manufacturer is to demonstrate compliance with FCC rules, Part 15, sec 231 for conducted and radiated margin. 1.3 Related Submittal(s)/Grant(s) No Related Submittals 1.4 Test Methodology All measurements contained in this report were conducted with ANSI C63.4 –1992, American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the range of 9 kHz to 40 GHz. All radiated and conducted emissions measurement was performed at Bay Area Compliance Laboratory, Corp. The radiated testing was performed at an antenna-to-EUT distance of 3 meters. 1.5 Test Facility The Open Area Test site used by Bay Area Compliance Laboratory Corporation to collect radiated and conducted emission measurement data is located in the back parking lot of the building at 230 Commercial Street, Suite 2, Sunnyvale, California, USA. Test sites at Bay Area Compliance Laboratory Corporation has been fully described in reports submitted to the Federal Communication Commission (FCC) and Voluntary Control Council for Interference (VCCI). The details of these reports has been found to be in compliance with the requirements of Section 2.948 of the FCC Rules on February 11 and December 10, 1997 and Article 8 of the VCCI regulations on December 25, 1997. The facility also complies with the radiated and AC line conducted test site criteria set forth in ANSI C63.4-1992. The Federal Communications Commission and Voluntary Control Council for Interference has the reports o…

Text truncated - open the document above for the full version.
