WLINK TECHNOLOGY LTD. Product Specification __________________________________________________________________________________ Page 1 of Taiwan H/Q Add.: No.46, Aly. 108-3 , Ln. 445 , Sec. 2, Meishi Rd., Yangmei City, Taoyuan County 326, Taiwan (R.O.C.) Tel: +886-3-4811534 Features: Bluetooth 3.0 Audi o Module, Class 2 The BT3GMD-A30P offers the following features: ● A2DP1.2 using SBC decoder for streaming audio over Version: V1.0 Bluetooth and AVRCP 1.4 for remote control functionality Mar 2012 ● Configurable seven-band speaker equalization as well as ten presets allowing multiple music listening styles ● High quality 96 dB SNR DACs with 44.1 and 48 kHz sample rates for high-fidelity playback ● Single-chip Bluetooth 3.0 transceiver supporting Bluetooth 2.1 + Enhanced Data Rate (EDR) and Bluetooth 2.0, 1.2, and 1.1 backward compatibility ● Best-in -class Bluetooth radio with up to 8 dBm transmit power and -91dBm receive sensitivity ● Support for side tone and digital microphones ● Supports microphone and speaker HW equalization ● automatic volume control (AVC) ● Switching regulator, battery charger, and power management unit ● Supports fast charging, power dissipation monitoring, and optional charger voltage regulation ● Dual high quality 8 kHz and 16 kHz audio MIC inputs ● Multilanguage voice prompt ● Voice command recognition Product Description: The BT3GMD-A30P is a Bluetooth 3.0 Module solution integrating common components required for cost and performance-optimized stereo headset designs. The BT3GMD-A30P also delivers differentiating features including enhanced audio quality, reduced charging times, A2DP, and multipoint connections through the integration of various noise suppression technologies, noise and echo reduction headset, for high-end 12 WLINK TECHNOLOGY LTD. Product Specification __________________________________________________________________________________ Page 2 of Taiwan H/Q Add.: No.46, Aly. 108-3 , Ln. 445 , Sec. 2, Meishi Rd., Yangmei City, Taoyuan County 326, Taiwan (R.O.C.) Tel: +886-3-4811534 and cost and performance-optimized stereo headsets. The BT3GMD-A30P supports Bluetooth SIG-compliant wideband speech implementation to greatly enhance the audio quality with both PCs and cell phones. The BT3GMD-A30P supports the Bluetooth 3.0 standard, adding enhanced power control, simple and secure pairing, and enhanced inquiry response as value-added features for Bluetooth headsets. All major functional blocks required for a Bluetooth stereo headset, including switcher, charger, and stereo audio codec are The module includes EEPROM, crystal, and PCB antenna. Applications: ● High-End Stereo Wireless Headsets ● High-END Mono Headsets ● Hands-Free Car Kits ● Wireless Speakers Functional Block Diagram: Figure 1: BT30MD-A30P Block Diagram 12 WLINK TECHNOLOGY LTD. Product Specification __________________________________________________________________________________ Page 3 of Taiwan H/Q Add.: No.46, Aly. 108-3 , Ln. 445 , Sec. 2, Meishi Rd., Yangmei City, Taoyuan County 326, Taiwan (R.O.C.) Tel: +886-3-4811534 Physical Description: The BT30MD-A30P is a 13.5mm×22mm FR4 PCB with 30 pads located around the perimeter. Table 1 shows the pinout diagram of the module. Table 1 Pin Location Figure 2: Module PCB Top View 12 WLINK TECHNOLOGY LTD. Product Specification __________________________________________________________________________________ Page 4 of Taiwan H/Q Add.: No.46, Aly. 108-3 , Ln. 445 , Sec. 2, Meishi Rd., Yangmei City, Taoyuan County 326, Taiwan (R.O.C.) Tel: +886-3-4811534 Table 2 Pin Function Descriptions 12 WLINK TECHNOLOGY LTD. Product Specification __________________________________________________________________________________ Page 5 of Taiwan H/Q Add.: No.46, Aly. 108-3 , Ln. 445 , Sec. 2, Meishi Rd., Yangmei City, Taoyuan County 326, Taiwan (R.O.C.) Tel: +886-3-4811534 Supporting Documentions: Reference Schematic: The most recent schematic , bill of materil ,and layout file are available from the WLINK TECHNOLOGY LTD.. Contact your WLINK representative for details. Layout Considerations: The BT30MD-A30P module is placed at the location where the antenna is away from the power supply(i.e.,BT1 Battery contacts)and any digital signal traces.. The antenna keep-out area which is 5mm around the parameter of the module region is shown in the red dotted box. PCB material and signal traces should not be placed within the antenna keep-out area to assure optimum antenna performance. Figure 3: Design reference Electrical Characteristics: Table 3: Maximum Electrical Rating 12 WLINK TECHNOLOGY LTD. Product Specification __________________________________________________________________________________ Page 6 of Taiwan H/Q Add.: No.46, Aly. 108-3 , Ln. 445 , Sec. 2, Meishi Rd., Yangmei City, Taoyuan County 326, Taiwan (R.O.C.) Tel: +886-3-4811534 Table 4:Power Supply Current (with a Nominal 3.7V Battery Voltage) Table 5: Audio DAC Path Performance Specifications, 8 kHz and 16 kHz Sample Rate 12 WLINK TECHNOLOGY LTD. Product Specification __________________________________________________________________________________ Page 7 of Taiwan H/Q Add.: No.46, Aly. 108-3 , Ln. 445 , Sec. 2, Meishi Rd., Yangmei City, Taoyuan County 326, Taiwan (R.O.C.) Tel: +886-3-4811534 RF Specification: Table 6 : Receiver RF Specifications 12 WLINK TECHNOLOGY LTD. Product Specification __________________________________________________________________________________ Page 8 of Taiwan H/Q Add.: No.46, Aly. 108-3 , Ln. 445 , Sec. 2, Meishi Rd., Yangmei City, Taoyuan County 326, Taiwan (R.O.C.) Tel: +886-3-4811534 Table7: Transmitter RF Specifications 12 WLINK TECHNOLOGY LTD. Product Specification __________________________________________________________________________________ Page 9 of Taiwan H/Q Add.: No.46, Aly. 108-3 , Ln. 445 , Sec. 2, Meishi Rd., Yangmei City, Taoyuan County 326, Taiwan (R.O.C.) Tel: +886-3-4811534 Application Examples: ·Stereo Headphones ·Wireless stereo speakers ·Soun…
Text truncated - open the document above for the full version.
Taiwan Wlink Electronic Technology Co., Ltd Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Taiwan Wlink Electronic Technology Co., Ltd would like the following documents regarding this submission for FCC ID: OZJBT3GMD-A30P to be kept confidential. 1. Schematic 2. Block diagram 3. Circuit description The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Name: lu zhou Title: Manager September 5, 2012
Taiwan Wlink Electronic Technology Co., Ltd Declaration of Authorization We Name: Taiwan Wlink Electronic Technology Co., Ltd Address: No.46, Aly. 108- 3, Ln. 445, Sec. 2, Meishi Rd., Yangmei City: Taoyuan Country: Taiwan Declare that: Name Representative of agent: Cathy Wang Agent Company name: Neutron Engineering, Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification of the following product(s): Product description: Bluetooth 3.0 Audio Module Type designation: BT3GMD-A30P Trademark: WLINK on our behalf. Date: 2012-09-05 City: Taoyuan Name: lu zhou Function: Manager Signature: -----------------------------------------
Modular Approval Request FCC(per DA 00-1407) Company name: Taiwan Wlink Electronic Technology Co., Ltd Address:No.46, Aly. 108- 3, Ln. 445, Sec. 2, Meishi Rd., Yangmei , Taoyuan, Taiwan FCC ID ˖OZJBT3GMD-A30P Items to be covered Answer from applicant 1.The modular transmitter must have its own RF shielding. NO, Without any shielding. 2.The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. YES, the component which control this function is U1 ˄BCM20771). 3.The modular transmitter must have its own power supply regulation. YESˈthe IC U2˄24C256˅is to stable the voltage for this kind of module. 4.The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable).. YES, it is printed antenna 5.The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. YES, The EUT is tested in a stand-alone configuration as the test photos show 6.The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: OZJBT3GMD-A30P” or “Contains FCC ID: OZJBT3GMD-A30P.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. YES, please refer to the exhibition label sample for this module 7.The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. YES, please refer to the user manual 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. YES, due to the output power and EIRP value is much lower than FCC SAR exemption threshold, this module comply with any applicable RF exposure requirement. Note: If compliance with one or more of the numbered requirements, listed above, cannot be demonstrated, it may be possible to obtain a “Limited Modular Approval” (LMA). 1DPHDQGVXUQDPHRIDSSOLFDQW RUDXWKRUL]HGUHSUHVHQWDWLYH OX]KRX 'DWH6LJQDWXUH
Neutron Engineering Inc. Project No.: 1208C194 Page 2 of 4 1208C194 1208C194 Neutron Engineering Inc. Project No.: 1208C194 Page 3 of 4 1208C194 1208C194 Neutron Engineering Inc. Project No.: 1208C194 Page 4 of 4 1208C194
Neutron Engineering Inc. Project No.: 1208C194 Page 3 of 4 1208C194 1208C194 Neutron Engineering Inc. Project No.: 1208C194 Page 4 of 4 1208C194
Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C194 Page 1 of 100 FCC Radio Test Report FCC ID: OZJBT3GMD-A30P This report concerns (check one) : Original Grant Class II Change Issued Date : Sep. 03, 2012 Project No. : 1208C194 Equipment : Bluetooth 3.0 Audio Module Model Name : BT3GMD-A30P Applicant : Taiwan Wlink Electronic Technology Co., Ltd Address : No.46, Aly. 108- 3, Ln. 445, Sec. 2, Meishi Rd., Yangmei , Taoyuan, Taiwan Manufacturer : Taiwan Wlink Electronic Technology Co., Ltd Address : No.46, Aly. 108- 3, Ln. 445, Sec. 2, Meishi Rd., Yangmei , Taoyuan, Taiwan Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Aug. 24, 2012 Date of Test: Aug. 24, 2012 ~ Sep. 02, 2012 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C194 Page 2 of 100 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C194 Page 3 of 100 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 18 4.2.1 RADIATED EMISSION LIMITS 18 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 19 4.2.3 TEST PROCEDURE 20 4.2.4 DEVIATION FROM TEST STANDARD 20 4.2.5 TEST SETUP 21 4.2.6 EUT OPERATING CONDITIONS 22 4.2.7 TEST RESULTS (BELOW 30MHZ) 23 4.2.8 TEST RESULTS (BETWEEN30 – 1000 MHZ) 24 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 28 5 . NUMBER OF HOPPING CHANNEL 52 5.1 APPLIED PROCEDURES / LIMIT 52 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 52 5.1.2 TEST PROCEDURE 52 5.1.3 DEVIATION FROM STANDARD 52 5.1.4 TEST SETUP 52 5.1.5 EUT OPERATION CONDITIONS 52 5.1.6 TEST RESULTS 53 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C194 Page 4 of 100 Table of Contents Page 6 . AVERAGE TIME OF OCCUPANCY 55 6.1 APPLIED PROCEDURES / LIMIT 55 6.1.1 MEASUREMENT INSTRUMENTS LIST 55 6.1.2 TEST PROCEDURE 55 6.1.3 DEVIATION FROM STANDARD 55 6.1.4 TEST SETUP 56 6.1.5 EUT OPERATION CONDITIONS 56 6.1.6 TEST RESULTS 57 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 69 7.1 APPLIED PROCEDURES / LIMIT 69 7.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 69 7.1.2 TEST PROCEDURE 69 7.1.3 DEVIATION FROM STANDARD 69 7.1.4 TEST SETUP 69 7.1.5 EUT OPERATION CONDITIONS 69 7.1.6 TEST RESULTS 70 8 . BANDWIDTH TEST 74 8.1 APPLIED PROCEDURES / LIMIT 74 8.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 74 8.1.2 TEST PROCEDURE 74 8.1.3 DEVIATION FROM STANDARD 74 8.1.4 TEST SETUP 74 8.1.5 EUT OPERATION CONDITIONS 74 8.1.6 TEST RESULTS 75 9 . PEAK OUTPUT POWER TEST 79 9.1 APPLIED PROCEDURES / LIMIT 79 9.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 79 9.1.2 TEST PROCEDURE 79 9.1.3 DEVIATION FROM STANDARD 79 9.1.4 TEST SETUP 79 9.1.5 EUT OPERATION CONDITIONS 79 9.1.6 TEST RESULTS 80 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 84 10.1 APPLIED PROCEDURES / LIMIT 84 10.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 84 10.1.2 TEST PROCEDURE 84 10.1.3 DEVIATION FROM STANDARD 84 10.1.4 TEST SETUP 84 10.1.5 EUT OPERATION CONDITIONS 84 10.1.6 TEST RESULTS 85 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C194 Page 5 of 100 Table of Contents Page 11 . EUT TEST PHOTO 97 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C194 Page 6 of 100 1. CERTIFICATION Equipment : Bluetooth 3.0 Audio Module Brand Name : WLINK Model Name : BT3GMD-A30P Applicant : Taiwan Wlink Electronic Technology Co., Ltd Factory : Taiwan Wlink Electronic Technology Co., Ltd Address : No.46, Aly. 108- 3, Ln. 445, Sec. 2, Meishi Rd., Yangmei , Taoyuan, Taiwan Date of Test : Aug. 24, 2012 ~ Sep. 02, 2012 Test Item : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2009 FCC Public Notice DA 00-705, March 30, 2000. The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The te…
Text truncated - open the document above for the full version.
Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C194 Page 97 of 100 11. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C194 Page 98 of 100 Radiated Measurement Photos 9K~30MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C194 Page 99 of 100 Radiated Measurement Photos 30M~1000MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C194 Page 100 of 100 Radiated Measurement Photos Above 1000MHz
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 2.56 mW |

Audio BT module
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Audio BT module
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
