OZSTECHNOPO-WTWalkie Talkie

Techno Power Technology Ltd. Application For Certification (FCC ID: OZSTECHNOPO-WT) Transmitter WO# 0005223 WL/at May 26, 2000 INTERTEK TESTING SERVICES FCC ID: OZSTECHNOPO-WT i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1 :General Description EXHIBIT 2 :System Test Configuration EXHIBIT 3 :Emission Results EXHIBIT 4 :Equipment Photographs EXHIBIT 5 :Product Labelling EXHIBIT 6 :Technical Specifications EXHIBIT 7 :Instruction Manual EXHIBIT 8 :Miscellaneous Information INTERTEK TESTING SERVICES FCC ID: OZSTECHNOPO-WT ii MEASUREMENT/TECHNICAL REPORT Techno Power Technology Ltd. - MODEL: WT-222 Additional Model: 3DIGI 3DGRINCH FCC ID: OZSTECHNOPO-WT May 26, 2000 This report concerns (check one:)Original Grant X Class II Change Equipment Type: Low Power Transmitter (example: computer, printer, modem, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)?Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37?Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [10-1-96 Edition] provision. Report prepared by:Wilson Loke Intertek Testing Services 2/F., Garment Center, 576, Castle Peak Road, HONG KONG Phone: 852-2173-8575 Fax:852-2745-8306 INTERTEK TESTING SERVICES FCC ID: OZSTECHNOPO-WT iii Table of Contents 1.0 General Description................................................................................................................ 2 1.1 Product Description ............................................................................................................... 2 1.2 Related Submittal(s) Grants ................................................................................................... 2 1.3 Test Methodology .................................................................................................................. 3 1.4 Test Facility............................................................................................................................ 3 2.0 System Test Configuration...................................................................................................... 5 2.1 Justification ............................................................................................................................ 5 2.2 EUT Exercising Software ....................................................................................................... 5 2.3 Special Accessories ................................................................................................................ 5 2.4 Equipment Modification ........................................................................................................ 6 2.5 Support Equipment List and Description ............................................................................... 6 3.0 Emission Results...................................................................................................................... 8 3.1 Field Strength Calculation ...................................................................................................... 9 3.2 Radiated Emission Configuration Photograph ..................................................................... 11 3.3 Radiated Emission Data ....................................................................................................... 12 4.0 Equipment Photographs....................................................................................................... 15 5.0 Product Labelling.................................................................................................................. 17 6.0 Technical Specifications........................................................................................................ 19 7.0 Instruction Manual................................................................................................................ 21 8.0 Miscellaneous Information................................................................................................... 23 8.1 Measured Bandwidth ........................................................................................................... 24 8.2 Emissions Test Procedures...................................................................................................25 INTERTEK TESTING SERVICES FCC ID: OZSTECHNOPO-WT iv List of attached file Exhibit typeFile Descriptionfilename Cover LetterLetter of Agencyletter.pdf Test ReportTest Reportreport.doc Operation DescriptionTechnical Descriptiondescri.pdf Test Setup PhotoRadiated Emissionradiated1.jpg, radiated2.jpg Test ReportBandwidth Plotbw.pdf External PhotoExternal Photoophoto1.jpg to ophoto2.jpg Internal PhotoInternal Photoiphoto1.jpg to iphoto2.jpg Block DiagramBlock Diagramblock.pdf SchematicsCircuit Diagramcircuit.pdf ID Label/LocationLabel Artwork and Locationlabel.pdf User ManualUser Manualmanual.pdf INTERTEK TESTING SERVICES FCC ID: OZSTECHNOPO-WT 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: OZSTECHNOPO-WT 2 1.0General Description 1.1Product Description The Equipment Under Test (EUT) is a Walkie Talkie operating at 49.86 MHz. The EUT is powered by 9V d.c. (1 x 9V “6LR61” battery). To turn the walkie talkie on, ON / OFF switch which is located on the back of the figure was moved to the “ON” position. When the “TALK” button on the left side of the unit is pressed, user can transmit his voice through the speaker / microphone to any compatible walkie talkie. Once the talk button is released, the user can listen to another person talking on another unit. Also, it can transmit Morse Code by pressing the Morse Code button. The Model: 3DIGI & 3DGRINCH are the same as the Model: WT-222 in hardware aspect. The difference in model number serves as marketing strategy. For electronic filing, the brief circuit description is saved with filename: descri.pdf 1.2Related Submittal(s…
