Thermo Cryotechnics REMOTE DATA/ALARM SYSTEM SYSTEM ADMINISTRATORS MANUAL ABRIDGED FOR FCC APPLICATION FULL VERSION AVALIABLE IF REQUIRED (85 Pages) REMOTE DATA SYSTEM FCC REGULATONS NOTE: This equipment has been tested and found to comply with the limits for a class A digital device, persuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user wil be required to correct the interference at his own expense. IMPORTANT INFORMATION ! READ BEFORE USE CAUTION Modifications to this equipment which are not expressly approved By Thermo Life Sciences development department could void the Users authority to operate this equipment. WARNING Do NOT short circuit the battery as this may cause a risk of explosion. ELECTRIC SHOCK RISK. Isolate the power supply before removing any cover. BURN HAZARD. Installation and maintenance of temperature probes should only be carried out by users who are qualified and are familiar with the required safety procedures applicable to the equipment to which the probe is being fitted. Ensure each part of the system is installed securely and in such a way that it does not obstruct normal access to surrounding areas and is kept away from excessive heat and moisture. Read the user manual before installing or making changes to the system. Version 1.00 2001-03-05 CONTENTS IMPORTANT INFORMATION !....................2 READ BEFORE USE................................................................................................2 INTRODUCTION........................................................................................................5 CHAPTER ONE..........................................................................................................6 SYSTEM PLANNING..............................................................................................6 SITE SURVEY........................................................................................................8 CHAPTER TWO.......................................................................................................11 INSTALLING THE SYSTEM................................................................................11 RECEIVER INSTALLATION...............................................................................11 TRANSPONDER INSTALLATION......................................................................12 TESTING THE TRANSPONDER.........................................................................13 TRANSMITTER INSTALLATION........................................................................13 TESTING THE TRANSMITTER..........................................................................14 TRANSMITTER BATTERY OPERATION............................................................14 TRANSMITTER MAINS OPERATION................................................................14 CHAPTER THREE...................................................................................................16 PROGRAMMING THE RECEIVER......................................................................16 CHAPTER FOUR......................................................................................................17 PROGRAMMING THE TRANSMITTERS...........................................................17 CHAPTER FIVE.......................................................................................................18 OPERATING THE RECEIVER..............................................................................18 MAIN DISPLAY MODE.......................................................................................18 CHAPTER SIX..........................................................................................................19 ALARMS.................................................................................................................19 CHAPTER SEVEN....................................................................................................20 SYSTEM MANAGEMENT....................................................................................20 DAY TO DAY SYSTEM OPERATION........................................................20 CHAPTER EIGHT....................................................................................................21 PROGRAMMING THE SD1+ AUTODIALLER...................................................21 CHAPTER NINE.......................................................................................................22 DATA LOGGING...................................................................................................22 CHAPTER TEN.........................................................................................................23 SYSTEM FAULT FINDING..................................................................................23 CHAPTER TEN.........................................................................................................24 RF EMMISIONS TESTS........................................................................................24 CHAPTER ELEVEN.................................................................................................25 RDS WINDOWS SOFTWARE..............................................................................25 APPENDIX A.............................................................................................................26 SOURCES OF INTERFERENCE...........................................................................26 APPENDIX B.....................................................................................................…

Text truncated - open the document above for the full version.

RDS1 SIMPLIFIED TRANSMITTER BLOCK DIAGRAM 914.5MHz FM Transmitter Power output complies with FCC PART 15 limits 18 bit serial encoder internal clock 7KHz Microcontroller 2MHz clock Power management circuit (Linear) RAM Controlled via 100KHz I2C Bus 100KHz I2C Bus Touchpanel DC Control LinesDC Control Lines Battery 9V PP3 520MAh Infra-Red Programming interface 125Hz

Thermo Life Sciences TRANSMITTER OUTSIDE PHOTOGRAPHS RDSTXUS1 FCC ID: P26RDSTXUS1 RDS TRANSMITTER OUTSIDE FRONT VIEW FCC ID: P26RDSTXUS1 RDS TRANSMITTER OUTSIDE REAR VIEW NOTE: FC symbol has now been removed from label RDS TRANSMITTER OUTSIDE REAR VIEW WITH OPEN BATTERY COMPARTMENT FCC ID: P26RDSTXUS1

Thermo Life sciences www.thermo-lifesciences.co.uk Serial numberRDS100001024 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, Including interference that may cause undesired operation. FCC ID: P26RDSTXUS1 ! WARNING: Read Instructions Before use RDS1 TransmitterBattery operation only RDS TRANSMITTER LABEL RDS1 FCC PART 15 LABEL REQUIREMENTS TRANSMITTER (RDSTXUS1) This label will be attached to the rear panel of the transmitter enclosure. FCC ID: P26RDSTXUS1 SIZE60x40mm MATERIALWHITE VINYL

Thermo Life Sciences TRANSMITTER INSIDE PHOTOGRAPHS RDSTXUS1 FCC ID: P26RDSTXUS1 RDS TRANSMITTER INSIDE VIEW FCC ID: P26RDSTXUS1 RDS TRANSMITTER INSIDE VIEW WITH RF MODULE SCREEN REMOVED RDS TRANSMITTER PCB REAR VIEW FCC ID: P26RDSTXUS1 RDS TRANSMITTER CLOSE UP VIEW OF RF MODULE WITH SCREEN REMOVED FCC ID: P26RDSTXUS1

Thermo Life Sciences J. Walker Thermo Life Sciences R&D department 20-11-2001 REMOTE DATA SYSTEM RDS-1 TRANSMITTER (RDSTXUS1) FCC ID: P26RDSTXUS1 PRODUCT DESCRIPTION The RDS system has been designed as an integrated data acquisition and equipment monitoring system. Almost any type of equipment can be monitored by using an RDS transmitter and a suitable type of sensor. The transmitter monitors the equipment to which it is attached and should the programmed limit be crossed (temp,voltage etc) then an alarm signal is sent to the reciever which alerts the user to the fault. An audible and visual alarm is also given by the transmitter itself to alert anyone in the immediate area to the fault. Transmitters can be added to the system as required up to a limit of 255 per reciever. Being battery operated and wireless the transmitters require no special installation. All operational parameters for the transmitters are programmed using an infra-red link from the receiver. The transmitters can reprogrammed as many times as required but only using the receiver. This gives complete system security and integrity as no unathorised changes can be made to the remote transmitter units. FCC ID: P26RDSTXUS1

|---------- ( Cambridge Ltd. ) ----------| Testing EMCEMC Consultancy EMC Training or : 01223 241140 (accounts) 23, Headington Drive, Cambridge. CB1 4HE Tel : 01954 251974 (test site) Fax : 01954 251907 email: [email protected] web : www.dbtechnology.co.uk REPORT ON ELECTROMAGNETIC COMPATIBILITY TESTS Performed at: TWENTY PENCE TEST SITE Twenty Pence Road, Cottenham, Cambridge U.K. CB4 4PS on Thermo Life Sciences Ltd. RDSTXUS1 dated 12 December 2001 1 of 17 Page: Test Report T0548 Test No: FCC ID: P26RDSTXUS1 R1482_1 Report No: dB Technology (Cambridge) Ltd. Equipment Under Test (EUT):RDSTXUS1 Test Commissioned by:Thermo Life Sciences Ltd. Unit 5, The Ringway Centre, Edison Road Basingstoke Hampshire RG21 6YH Representative:Jerry Walker Test Started: 16 November 2001 Test Completed: 12 December 2001 Test Engineer:Dave Smith Date of Report: 12 December 2001 Report: Written by:Dave SmithChecked by:Derek Barlow Signature:Signature: Date:12 December 2001Date:12 December 2001 Test Standards Applied CFR 47 : 2001 Code of Federal Regulations: Pt 15 Subpart C - Radio Frequency Devices - PASS Intentional Radiators 2 of 17 Page: Test Report T0548 Test No: FCC ID: P26RDSTXUS1 R1482_1 Report No: dB Technology (Cambridge) Ltd. Emissions Test Results Summary CFR 47 : 2001PASS TestPortMethodLimitPASS/FAILNotes Conductedac powerANSI C63.4:1992FCC_CN/A#1 Emissions Radiated ANSI C63.4:1992FCC_CPASS#2 Emissions #1Test not applicable because EUT was battery powered and had no ac power port. #2Tested to limits of section 15.249. 3 of 17 Page: Test Report T0548 Test No: FCC ID: P26RDSTXUS1 R1482_1 Report No: dB Technology (Cambridge) Ltd. Contents 17 PLOT 7 Radiated Emissions - Centered on 10th Harmonic of Transmitter ........................ 16 PLOT 6 Radiated Emissions - Centered on 9th Harmonic of Transmitter ......................... 15 PLOT 5 Radiated Emissions - Centered on 8th Harmonic of Transmitter ......................... 14 PLOT 4 Radiated Emissions - Centered on 7th Harmonic of Transmitter ......................... 13 PLOT 3 Radiated Emissions - Centered on 6th Harmonic of Transmitter ......................... 12 PLOT 2 Radiated Emissions - 1GHz to 5GHz ............................................... 11 PLOT 1 Radiated Emissions - 30MHz to 1GHz ............................................. 10 4.1 Radiated Emissions Results ........................................................... 9 4 Test Results ........................................................................... 9 3.1 Radiated Emissions ................................................................... 9 3 Test Methods .......................................................................... 8 2 Test Equipment ........................................................................ 7 Photograph 2 General Arrangement of EUT - Front ........................................... 7 Photograph 1 General Arrangement of EUT - Back ............................................ 6 Figure 1 General Arrangement of EUT and Peripherals ........................................ 5 1.3 EUT Operating Modes ................................................................. 5 1.2 Modifications to EUT and Peripherals .................................................... 5 1.1 General .............................................................................. 5 1 EUT Details ............................................................................ 4 of 17 Page: Test Report T0548 Test No: FCC ID: P26RDSTXUS1 R1482_1 Report No: dB Technology (Cambridge) Ltd. 1 EUT Details 1.1 General The EUT was a Thermo Life Sciences RDSTXUS1. The device is an electronic temperature probe with a radio transmitter which relays temperature readings back to a receiving station (RDSRXUS1). The radio link operates at a frequency of 914.5MHz and was tested under the requirements of section 15.249 of the CFR 47 rules. The unit is battery powered. The antenna is fixed and not user changeable. Details of the EUT and associated peripherals used during the tests are listed below. Figure 1 shows the interconnections between the EUT and peripherals. ItemManufacturerModelDescriptionSerial No:FCC ID 1Thermo Life SciencesRDSTXUS1EUTP13P26RDSTXUS1 with RF module MKT6-914.5 2PT100 probe 1.2 Modifications to EUT and Peripherals Details of any modifications that were required to achieve compliance are listed below. The modification numbers are referred to in the results sections as appropriate. ModDetails No: 0 Original unit - no modifications were made during the course of testing. 1.3 EUT Operating Modes The EUT was tested in the following operating mode or modes. Generally, operating modes are chosen that will exercise the functions of the EUT as fully as possible and in a manner likely to produce maximum emission levels or susceptibility. Individual OperatingDetails Mode 1 Normal transmitting mode. 5 of 17 Page: Test Report T0548 Test No: FCC ID: P26RDSTXUS1 R1482_1 Report No: dB Technology (Cambridge) Ltd. Figure 1 General Arrangement of EUT and Peripherals Fixed Antenna PT100 Probe RDSTXUS1 #1 #11m unscreened twisted pair temperature probe wire. 6 of 17 Page: Test Report T0548 Test No: FCC ID: P26RDSTXUS1 R1482_1 Report No: dB Technology (Cambridge) Ltd. Photograph 1 General Arrangement of EUT - Back Photograph 2 General Arrangement of EUT - Front 7 of 17 Page: Test Report T0548 Test No: FCC ID: P26RDSTXUS1 R1482_1 Report No: dB Technology (Cambridge) Ltd. 2 Test Equipment The test equipment used during the tests was one or more of the items listed below. Individual test result sheets indicate which items were used. Ref No:ManufacturerModelDescriptionSerial NumberCal Due R4Rohde and Schwarz ESVS10RF Receiver (20MHz - 1GHz)843744/004 December 2001 R5Hewlett PackardHP 8595ESpectrum Analyser3412A007015 November 2002 R5BHewlett PackardHP87405APre-amp3207A003225 November 2002 R6Marconi Instruments2390Spectrum Analyser239010109 September 2002 A3EMCO3147HF Log Per. Antenna (200MHz - 5GHz…

Text truncated - open the document above for the full version.

Contents 2 Photograph 2 General Arrangement of EUT - Front ........................................... 2 Photograph 1 General Arrangement of EUT - Back ............................................ 1 of 2 Page: Test Photographs T0548 Test No: FCC ID: P26RDSTXUS1 R1482 Report No: dB Technology (Cambridge) Ltd. Photograph 1 General Arrangement of EUT - Back Photograph 2 General Arrangement of EUT - Front 2 of 2 Page: Test Photographs T0548 Test No: FCC ID: P26RDSTXUS1 R1482 Report No: dB Technology (Cambridge) Ltd.
