P27-IP5446MIP5446M

i IP5446M WiFi Rou ter Quick St art Guid e P/N : 957DVS00SV Document Versi on: 1.0 Copyright 2023. All Rights Rese rved. All trademarks and trade names are the properties of their resp ective owners ii Package Contents The following items are included in the box: 1. IP5446M 2. Quick Start Guide 3. Power adapter4. WiFi credential card 5. Product label Model: IP5446M P/N:XXXXXXXXXX WiFi SSID:LIB-1234567 WiFi Password:1234567890AB Serial:yymmDQDnnnnnn FCC ID: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received,including interference that may cause undesired operation Polarity: Made in China MAC:1234567890AB WPS PIN:12345678 Input: 12V 2.5A 42JJ E210921 HW VER: XXX 1 Chapter 1 Introduction Thi s cha pter provi des details of theIP 5446M's featuresand capabilities . Overv iew The IP5446 M is a high-performance, full- featured WiFi router with premium 802 .11a x, as known as WiFi 6. It is powered by 2. 4G Hz and 5G Hz 4x 4 radio. Wi-Fi 6 routers offer improved speed, capacity, la tency, and efficiency, making them a great choice for homes and offices with mult iple devices and high-demand networking needs. Faster speeds: Wi-Fi 6 routers provide faster wireless speeds compared to previous generations. They can achieve mult i-gigabit data tra nsfer rates, enabli ng smoother streaming, faster downlo ads, and improved overall network performance. Features 2.5Gbps WAN po rt (1*Bl ue RJ 45) 1.0Gbps LAN po rts (3*Yellow RJ 45) USB po rt Re set But ton WPS But ton 12VDC Power Ada pt er Wireless Supp orts 11ac WiFi:802. 11ac is backwards compatible with 802. 11a/ b/g/n WPS Suppo rt:WPS (WiFi Protected Setup) simplifies the process of connecting any device to the wireless network by using the push button on the device Security Suppo rt:WPA2, WPA, and WPA+WPA2 mixed mode are supported for advanced encryption of all WiFi data 1 2 Chapter 2 Basi c Setup Thi s cha pter provi des details on ho w to setup theIP 5446M Front Panel Fig ure 1: Front Panel 1.Power/WAN (Green/Re d) Solid Red – No Internet. Solid Green - Internet connection is availa ble . Bli nking Red and Green - FW upgrade in-progress Off - No power 2. WiFi/ WPS LED (Blue /Green) Solid Green – WiFi enable d Off – WiFi disable d Slo w Bli nking Blu e - WPS is pairing. When WPS button is pressed, the LED will bli nk for 2 minutes. Solid Blu e - WPS failu re. The LED will stay on for 10 seconds and then turn off. Fast Bli nking Blu e-WPS success. The LED will bli nk quickly for 10 seconds, then turn off. 3. LAN LED (Green)Solid Green – LAN Et hernet cable connected Off - LAN Et hernet cable is not connected Bli nking Green – Active LAN Ethernet traffic 2 3 Back Panel Fig ure 2: Ba ck Panel 1. LAN Ports 1Gbps (Yellow) Connect to a PC or other Et hernet device using a standard Et hernet cable . 2. WAN Port 2.5Gbps (Blue ) Connect to a cable modem or PON using a standard Et hernet cable . 3. Reset But tonThis button is recessed; a pin or paper cli p can be used to press it. The button can be used while the unit is powered and the power LED is Green. Re set to manufa cturer de faul t value s and reboot.When pressed and held over 7 seconds, the settings of the IP544 6M will be set to their default valu es. Re boot.When pressed and held over 2 seconds and le ss than 5 seconds, the IP5446 M will reboot. 4.USB PortPower charging for smart phone or pad. 5. Power JackFind power adapter in the package. Insert the power adapter unit into the power outle t first. Then connect the power adapter with device via power connector and power jack. 6. WPS But ton Push the WPS button on the router and on your other WiFi device to perform WPS function that easily creates an encryption-secured WiFi connection automaticall y. 4 Set up the IP 5446M Setti ng up the IP5446 M is simple . Power up the IP5446 M with the provided power suppl y an d conne ct the WAN port (Blue) to your mode m with a stan da rd Et hern et cab le . By de fau lt , the IP544 6M uses the pre-con�igure d WiFi SSID an d pas sword mat ch what is shown on your WiFi Cre de ntial Card an d the lab el. If you hav e�iber serv ice at home, the unit will be re ady to use without an y addi tional con�igurat ion. If you hav e an other type of Internet service, follo w the instru ctions shown below to chan g e the WAN setti ng toDHCP. If you would li ke to set a custom WiFi SSID an d pas sword , you can als o use the IP5446 Mlo cal web pag e an d fol lo w the steps belo w. Set up Using Web Browser Step 1:Mak e sure yourmodem is on an d work ing properly . Step 2:Conne ct the IP5446MWAN port (Blue) with your mode m with a stan dard Et hern et cab le . Step 3:Conne ct an Et hern et cab le to an IP5446 M LAN port an d your PC. Step 4:Lau nch the browser an d enterht tp: //192. 168 .1.1 in the address box. Step 5:You will be prompted for a usern am e an d pas sword. Locat e the inclu de d IP5446 M Cre de ntial Card. Useadminfor the defa ult usern am e. The de vice speci�ic pas sword can be fou nd by scanni ng the QR code on the include d WiFi Crede ntial Card or on the IP5446 M lab el (shown as the WPS PIN). The pas sword can be chan ged af ter de vice setup. 5 Step 6:Choos e theBasicpag e, cli ckWAN Setup, to con�igure your WAN setti ngs. Step 7:The defa ultConnect io n Typeis PPPoE for Internet service over�iber. For other type of services, select DH CP an d cli ck Apply . 6 Step 8:To chan ge the WiFi SSID an d pas sword, select theWir elesspag e, cli ck Basic Setup,then go to the Setup menu an d chan ge the SSID an d pas sword. When you are�inished, cli ck Apply to save your chan ges. 7 Chapter 3 Safety Thi s cha pter provides yo u some safety operation warnin gs. 1.Use the power suppl y adap ter pro vide d in the pac kage only . Using an y other ada pters may cau se dam ag e to the equipment or re sult in operat ion fai lu re s. 2.The ele ctri cal lo ad ca…

Text truncated - open the document above for the full version.

FederalCommunicationsCommission 7435OaklandMillsRoad ColumbiaMD21046 Date:July4,2023 Subject:Certificationsconcerning“covered”equipmentpursuanttoPart2.911(d)(5)(i)and(ii) Towhomitmayconcern, [SercommCorporation](“theapplicant”)certifiesthattheequipment[FCCID:P27-IP5446M]forwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivinganequipmentauthorization pursuanttosection2.903oftheFCCrules. [SercommCorporation](“theapplicant”)certifiesthat,asofthedateofthefilingoftheapplication,theapplicant [isnot]identifiedontheCoveredList(asaspecificallynamedentityoranyofitssubsidiariesoraffiliates)asan entityproducing“covered”equipment. Sincerely, ________________________ Name:NickWu Title:Engineer E-mail:[email protected]

U.S.AgentforServiceofProcessAttestation Totheattentionof FederalCommunicationsCommission AuthorizationandEvaluationDivision U.S.Agent CompanyName:SercommTechnology,Inc. FRN:0028757110 ContactName:StephenLeotis StreetAddress:42808ChristySt.Ste231 City/Province/Zip:Fremont,CA94538,U.S.A TelephoneNo:+1-478-954-8427 Email:[email protected] ThisletteristoconfirmthatwehaveacceptedtheresponsibilitytoactasthedesignatedU.S. Agentforserviceofprocessasrequiredby§2.911(d)(7)onbehalfoftheApplicantnotedbelow. U.S.AgentSignature: Date:2023-05-30 SignedbyStephenLeotis Applicant Companyname:SercommCorporation FRN:0015548027 FCCID:P27-IP5446M ContactName:NickWu StreetAddress:8F,No.3-1,YuanQuSt,NanKang City/Province/Zip:Taipei,Taiwan,115 TelephoneNo:+886-2-2655-3988#2556 Email:[email protected] ThisletteristoconfirmthattheApplicanthasdesignatedtheU.SAgentnotedaboveforthe purposeofacceptingserviceofprocessontheirbehalfasrequiredby§2.911(d)(7).The Applicantfurtheracknowledgesacceptancetomaintainanagentfornolessthanoneyearafter thegranteehasterminatedallmarketingandimportationortheconclusionofanyCommission- relatedproceedinginvolvingtheequipment. ApplicantSignature: Date:2023-05-30 SignedbyNickWu

Date:2023/7/4 FederalCommunicationsCommission 7435OaklandMillsRd ColumbiaMD21046-1609 Subject:ProductCertificationRepresentativeAuthorizationLetter FCCID:P27-IP5446M Productname:IP5446M Towhomitmayconcern: Wetheundersigned,herebyauthorizefollowingpersontoactasouragentinthepreparationofanapplication forequipmentauthorizationofmodelIP5446MXXXtotheFCCRulesandRegulations. InternationalCertificationCorp. Address:No.3-1,Lane6,WenSan3rdSt.KweiShanDist.,TaoYuanCity333,Taiwan(R.O.C.) Name:GaryChang JobTitle:Manager e-mail: [email protected] Wefurthercertifiesthatneithertheapplicantnoranypartytothisapplication,asdefinedin47CFRCh. 1.2002(b),issubjecttoadenialtoFederalbenefits,thatincludeFCCbenefits,pursuanttosection5301ofthe Anti-DrugAbuseActof1998,21U.S.C.862. ThisappointmentalsoincludestheauthoritytocompleteFCCForm731onourbehalfandsignthe applicationasanauthorizedagent. Applicant: SercommCorporation Address:8F,No.3-1,YuanQuSt.,NanKang,Taipei115,Taiwan,R.O.C. Signature: NameandJobTitle.:NickWu,Engineer [email protected] Tel.+886-2-26553988

Date:July4,2023 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRd ColumbiaMD21046-1609 Subject:Requestforconfidentiality FCCID:P27-IP5446M Towhomitmayconcern: Short-termconfidentiality PursuanttoDA04-1705oftheCommission’spubicnotice,inordertocomplywiththemarketingregulationsin 47CFR§2.803andtheimportationrulesin47CFR§2.1204,whileensuringthatbusinesssensitiveinformation remainsconfidentialuntiltheactualmarketingofnewlyauthorizeddevices.Wearerequestingthecommissionto grantshort-termconfidentialityrequestonthefollowingattachmentsuntil180daysafterissuedate. ☒InternalPhotographs ☒ExternalPhotographs ☒User'smanual ☒TestSetupphoto Permanentconfidentiality PursuanttoSections0.457and0.459oftheCommission’sRules,theApplicantHerebyrequestsconfidential treatmentofinformationaccompanyingthisApplicationAsoutlinedbelow: ☒BlockDiagram ☒Schematics ☒OperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedtothepublic. Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovideunjustifiedbenefitstoits competitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthisapplicationandall accompanyingdocumentationwillnotbemadebeforethedateoftheGrantforthisapplication. Shouldyourequireanyfurtherinformation,pleasecontacttheundersigned. Thankyouforyourconsiderationinthismatter. Applicant:SercommCorporation Address:8F,No.3-1,YuanQuSt.,NanKang,Taipei115,Taiwan,R.O.C. Signature: NameandJobTitle.:NickWu,Engineer E-mail:[email protected] Tel.:+886-2-26553988

Project No.: EP351201 Page No. : 1 of 17 Photographs of EUT Project No.: EP351201 Page No. : 2 of 17 Project No.: EP351201 Page No. : 3 of 17 Project No.: EP351201 Page No. : 4 of 17 Project No.: EP351201 Page No. : 5 of 17 Project No.: EP351201 Page No. : 6 of 17 Project No.: EP351201 Page No. : 7 of 17 Project No.: EP351201 Page No. : 8 of 17

Product label 1:1 R7 IP5446M 20230705 932DQD0101 Notes: 1.材質: 50#白色Mylar，黑色印刷 2.背压花膠/ 葛拉馨底紙,,成捲 3.公差:+0/- 0.2mm(Tolerance: + 0/ - 0.2 mm) 4.本料件使用之材料須符合RoHS UL 5.材质表面打印张力>=32dpne/cm 1.Made in XXXXX产地根据实际生产地打印:Made in Philippines or China 2.SDXX(UL Factory ID)需要根据生产厂地选择 Factroy ID:SD0 (Zhunan*Taibei) SD7(Tangzhuang*China) SD8(Chunhui*China) SD10(P site*Philippines ) SD11(M site*Philippines ) 厂内列印示意，具体依据实际要求列印 SN/MAC) 69.40 39.40 3,00 R1.00 Model: IP5446M P/N:XXXXXXXXXX WiFi SSID:LIB-1234567 WiFi Password:1234567890AB Serial:yymmDQDnnnnnn FCC ID: P27-IP5446M This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received,including interference that may cause undesired operation Polarity: Made in China MAC:1234567890AB WPS PIN:12345678 Input: 12V 2.5A 42JJ E210921 HW VER: XXX FCC ID:P27-IP5446M

Project No.: EP351201 Page No. : 9 of 17 Project No.: EP351201 Page No. : 10 of 17 Project No.: EP351201 Page No. : 11 of 17 Project No.: EP351201 Page No. : 12 of 17 Project No.: EP351201 Page No. : 13 of 17 Project No.: EP351201 Page No. : 14 of 17 Project No.: EP351201 Page No. : 15 of 17 Project No.: EP351201 Page No. : 16 of 17 Project No.: EP351201 Page No. : 17 of 17

Report No.: FA351201 Page : 1 of 7 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : P27-IP5446M Equipment : IP5446M Model No. : IP5446M Multiple Listing : IP5446MXXX (the X should be 0 to 9, A to Z, a to z, "blank" or "-", for the marketing purpose) Brand Name : Sercomm Applicant : Sercomm Corporation Address : 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Standard : 47 CFR FCC Part 2.1091 Received Date : May 12, 2023 Tested Date : May 15 ~ Jun. 01, 2023 We, International Certification Corporation, would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FA351201 Page : 2 of 7 Report Version: Rev. 01 Table of Contents 1 MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 4 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 4 1.2 MPE EVALUATION FORMULA ............................................................................................................. 4 1.3 REFERENCE GUIDANCE ..................................................................................................................... 4 1.4 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE ................................... 4 1.5 MEASUREMENT UNCERTAINTY ......................................................................................................... 4 1.6 MPE EVALUATION RESULTS .............................................................................................................. 5 1.7 MPE EVALUATION OF SIMULTANEOUS TRANSMISSION ................................................................ 6 2 TEST LABORATORY INFORMATION ................................................................................................. 7 Report No.: FA351201 Page : 3 of 7 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA351201 Rev. 01 Initial issue Jul. 07, 2023 Report No.: FA351201 Page : 4 of 7 Report Version: Rev. 01 1 MPE EVALUATION OF MOBILE DEVICES 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE Frequency Range (MHz) Power Density (mW /cm 2 ) Averaging Time (minutes) 300~1500 F/1500 30 1500~100000 1.0 30 1.2 MPE EVALUATION FORMULA Pd = 2 **4RPi Pt Where Pd= Power density in mW/cm 2 Pt= EIRP in mW Pi= 3.1416 R= Measurement distance 1.3 REFERENCE GUIDANCE 447498 D01 General RF Exposure Guidance v06 1.4 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE None 1.5 MEASUREMENT UNCERTAINTY The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2)). Parameters Uncertainty Conducted power ±0.808 dB Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FA351201 Page : 5 of 7 Report Version: Rev. 01 1.6 MPE EVALUATION RESULTS Non-beamforming mode Frequency Range (MHz) Maximum Conducted Power (dBm) Maximum Tune Up Limit (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) *Ratio Pass / Fail 2412-2462 27.63 28.0 3.1 24 0.178 1 0.178 Pass 5180-5240 27.19 27.5 3.2 24 0.162 1 0.162 Pass 5260-5320 22.77 23.0 3.2 24 0.058 1 0.058 Pass 5500-5720 23.62 24.0 3.0 24 0.069 1 0.069 Pass 5745-5825 29.54 30.0 3.1 24 0.282 1 0.282 Pass *Ratio = Power density / Limit. Beamforming mode Frequency Range (MHz) Maximum Conducted Power (dBm) Maximum Tune Up Limit (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) *Ratio Pass / Fail 2412-2462 25.46 25.5 8.97 24 0.387 1 0.387 Pass 5180-5240 26.89 27.0 9.00 24 0.550 1 0.550 Pass 5260-5320 20.95 21.0 9.00 24 0.138 1 0.138 Pass 5500-5720 21.07 21.5 8.82 24 0.149 1 0.149 Pass 5745-5825 27.04 27.5 8.80 24 0.589 1 0.589 Pass *Ratio = Power density / Limit. Remarks: For 2412~2462MHz: Directional gain = 10 x log((10 3.1/20 +10 3/20 +10 3.1/20 +10 2.6/20 ) 2 /4) = 8.97 dBi For 5180~5240MHz: Directional gain = 10 x log((10 3/20 +10 2.9/20 +10 3.2/20 +10 2.8/20 ) 2 /4) = 9.00 dBi For 5260~5320MHz: Directional gain = 10 x log((10 3/20 +10 2.9/20 +10 3.2/20 +10 2.8/20 ) 2 /4) = 9.00 dBi For 5500~5700MHz: Directional gain = 10 x log((10 2.6/20 +10 2.6/20 +10 3/20 +10 3/20 ) 2 /4) = 8.82 dBi For 5745~5825MHz: Directional gain = 10 x log((10 2.4/20 +10 3.1/20 +10 2.9/20 +10 2.7/20 ) 2 /4) = 8.8 dBi Report No.: FA351201 Page : 6 of 7 Report Version: Rev. 01 1.7 MPE EVALUATION OF SIMULTANEOUS TRANSMISSION Non-beamforming mode Mode Max Ratio of Each Mode WLAN 5GHz 0.178 BT 0.282 Sum 0.46 Limit 1 Pass / Fail Pass Beamforming mode Mode Max Ratio of Each Mode WLAN 5GHz 0.387 BT 0.589 Sum 0.976 Limit 1 Pass / Fail Pass Report No.: FA351201 Page : 7 of 7 Report Version: Rev. 01 2 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corporation (EMC and Wireless Communication Laboratory), it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to grant our clients with best EMC / RF se…
