P270HRB7Wireless DSL/Cable Router

Sercomm Corporation
Wireless DSL/Cable Router - FCC ID P270HRB7 - Sercomm Corporation
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
May 02, 2002
Application Purpose
Original Equipment
Date of Application
May 02, 2002
Equipment Note
Wireless DSL/Cable Router
Frequency Range
2412.00000000 - 2462.00000000
Company
Sercomm Corporation
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

β†—

Cover Letter(s)

β†—
β†—
β†—
β†—

External Photos

β†—
β†—

ID Label/Location Info

β†—
β†—

Internal Photos

β†—
β†—

Operational Description

β†—

RF Exposure Info

β†—

Test Report

Test Setup Photos

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Multi-Function Wireless Router Wireless Access Point Broadband Internet Access Print Server User's Guide i TABLE OF CONTENTS CHAPTER 1 INTRODUCTION..............................................................................................................1 Wireless Router Features..............................................................................................................1 Package Contents.............................................................................................................................3 Physical Details................................................................................................................................4 CHAPTER 2 INSTALLATION...............................................................................................................7 Requirements....................................................................................................................................7 Procedure...........................................................................................................................................7 CHAPTER 3 SETUP..................................................................................................................................9 Overview.............................................................................................................................................9 Configuration Program.................................................................................................................10 Setup Wizard...................................................................................................................................12 LAN Screen.....................................................................................................................................15 Wireless Screen.............................................................................................................................17 Password Screen.............................................................................................................................20 CHAPTER 4 PC CONFIGURATION...................................................................................................21 Overview...........................................................................................................................................21 Windows Clients.............................................................................................................................21 Printer Setup for Windows...........................................................................................................33 Macintosh Clients...........................................................................................................................39 Linux Clients...................................................................................................................................39 Other Unix Systems.......................................................................................................................40 Wireless Station Configuration..................................................................................................41 CHAPTER 5 OPERATION AND STATUS.........................................................................................42 Operation..........................................................................................................................................42 Status Screen..................................................................................................................................43 Connection Status - PPPoE...........................................................................................................45 Connection Status - PPTP.............................................................................................................47 Connection Details - Fixed/Dynamic IP Address......................................................................48 CHAPTER 6 ADVANCED FEATURES...............................................................................................50 Overview...........................................................................................................................................50 Advanced Internet Screen.............................................................................................................50 URL Filter........................................................................................................................................54 Virtual Servers...............................................................................................................................56 Dynamic DNS..................................................................................................................................59 Remote Management......................................................................................................................61 Access Control................................................................................................................................62 Firmware Upgrade..........................................................................................................................67 CHAPTER 7 ADVANCED CONFIGURATION.................................................................................68 Overview...........................................................................................................................................68 PC Database Screen.......................................................................................................................69 Options..............................................................................................................................................71 Printer Port.........................................................................................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

Inform Letter Dear Customer, According to FCC’s regulation, the following Declaration of Conformity has to be made by a company located in USA. They are: This device has been confirmed to be in compliance with the requirements of ANSI C63.4 & FCC part 15 regulations. The test result has been shown in the ADT test report with number RF910403R02. And this compliance is subject to the following two conditions: This device may not cause harmful interference and, This device must accept any interference received, including interference that may cause undesired operation. This declaration can be a separate sheet and be sure that the following message will be also included in this declaration: Product name, model name and trade name. Company name, and address of the one who is responsible for this declaration. Name, title, telephone and fax number as well as the signature of the contact person. Thanks for your attention.

External Photos

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

External Photos

Page 8 Page 9

Internal Photos

Page 3 Page 4 Page 5

Internal Photos

Page 6 Page 7 Page 8

Operational Description

FCC ID: P270HRB7 ADT No.910403R02 Operational Description The transmitter of the EUT (Wireless DSL/Cable Router) is powered by power adapter. The antenna is Dipole antenna. The antenna connector is Reversed SMA. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

RF Exposure Info

ADT No: 910403R02 1 FCC TEST REPORT REPORT NO.: RF910403R02 MODEL NO.: OEM MODEL NO.: IP716E SS2624 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:SerComm Corporation ADDRESS: 10F, No. 19-13, San-Chung Road, Nan-Kang, Taipei 115, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 ADT No: 910403R02 2 RF Exposure Measurement 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz ADT No: 910403R02 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5 Climate Condition The temperature and related humidity: 23 deg. C and 55 % RH 6. Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20 cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. ADT No: 910403R02 4 7 Test Results 7.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 5dBi or 3.16 (numeric). 7.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241212.791.79 6243714.961.94 11246216.332.03 The minimum allowable distance is very close to the enclosure of the antenna. So, the user has no need to worry about the harmfulness of radiation. But it is recommended to always keep, at least, 20 cm separation distance with the antenna.

Contact Information

Applicant

Nick Wu(Engineer)
[email protected]886-2-2655-3988Fax: 886-2-2655-3965

Technical Contact

Advance Data Technology CorporationAlan Lane
[email protected]+886 3 327 0910

13-1, Lane 19, WenShan 3rd St Β· Taoyuan Β· Taiwan

Test Firm

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchRichard Chen
[email protected]886-2-2605-2180-3Fax: 886-2-2605-2943

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz16.00 mW
Confidentiality
Long Term
Grant Notes
Power Output listed is Conducted. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This authorization is approved under the interim blanket waiver for Digital Transmission Systems meeting the requirements pursuant to the Further Notice of Proposed Rulemaking and Order, ET Docket No. 99-231 (FCC 01-158). The authorization is conditioned upon compliance with any final rules that may be adopted in the proceeding.
