CB801A/AS IEEE 802.11g Wireless PC Card Quick Installation Guide Regulatory Approvals FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communica- tions. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example - use only shielded interface cables when connecting to computer or peripheral devices). Channel The Wireless Channel sets the radio frequency used for communication. Access Points use a fixed Channel. You can select the Channel used. This allows you to choose a Channel which provides the least interference and best performance. In the USA and Canada, 11 channel are available. If using multiple Access Points, it is better if adjacent Access Points use different Channels to reduce interference. In "Infrastructure" mode, Wireless Stations normally scan all Channels, looking for an Access Point. If more than one Access Point can be used, the one with the strongest signal is used. (This can only happen within an ESS.) If using "Ad-hoc" mode (no Access Point), all Wireless stations should be set to use the same Channel. However, most Wireless stations will still scan all Channels to see if there is an existing "Ad-hoc" group they can join. This device has been tested and meets the FCC RF exposure guidelines. The maximum SAR value reported is 0.88w/kg About This Guide This Quick Installation Guide describes the basic installation of the CB801A/AS. It covers the following topics: n Before You Begin n Installing the Wireless Configuration Utility n Installing the PC Card Driver For complete instructions on using the PC Card, see the CB801A/AS Wireless 54Mbps 11g PC Card User Guide on the Installation CD. Before You Begin Before installing the PC Card, perform the following checks: n Check the package contents n Verify that your computer meets the system requirements Check the Package Contents Before starting with the installation, verify that your PC Card package includes the following items: n One OfficeConnect Wireless 54Mbps 11g PC Card n Warranty flyer n Installation CD, which contains the setup programs and drivers for the Wireless PC Card System Requirements You can install the PC Card on any computer running Microsoft® Windows® XP, Windows 2000, Windows 98 SE, or Windows Me. Your computer must also have, at least, the following: n PCMCIA card slot n 400 MHz processor or higher n 128 MB of RAM n CD-ROM drive Installing the Wireless Configuration Utility Your Wireless PC Card includes a configuration utility that you can use to manage your PC Card. Windows XP Service Pack 2 has a built-in service called Wireless Zero Configuration (WZC) that can also be used to manage your wireless connections. If you intend to use WZC to manage your PC Card, you do not have to install the configuration utility. To install the wireless configuration utility: 1. With the computer on and Windows running, insert the Installation CD into the CD-ROM drive. The CB801A/AS Wireless Utility Installation wizard automatically starts. If the installation wizard does not start automatically, click Start > Run, and then type d:\setup.exe (where d: is the drive letter assigned to your CD-ROM drive). 2. Follow the instructions on the wizard to install the wireless configuration utility. If a message appears, informing you that the driver has not passed the Windows Logo testing, click Continue Anyway to complete the installation. 3. When the message “InstallShield Wizard Complete” appears, click Finish to complete installing the wireless configuration utility. Installing the PC Card Driver 1. Insert the PC Card into your computer’s PCMCIA card slot. 2. Click Install the software automatically (Recommended), and then click Next. n If a message appears, informing you that the driver has not passed the Windows Logo testing, click Continue Anyway to continue with the installation. n If the wizard does not automatically detect the driver for the PC Card and prompts its the location, click Browse, and then select the appropriate Windows driver on the Installation CD. The PC Card drivers on in the \Driver folder on the CB801A/AS Installation CD. Click Open, and then OK to continue. Windows installs the driver for the PC Card. 3. When the message “Completing the Found New Hardware Wizard” appears, click Finish to complete the driver installation. Appendix A Specifications This Appendix covers the most likely problems and their solutions. PC Card Adapter Standards: IEEE 802.11b, IEEE 802.11g Computer slot type: CardBus Chipset Atheros AR2414(CB801AS)/AR2413(CB801A) Receive Sensitivity: 802.11g54Mbps: -70dBm, 10% PER 48Mbps: -72dBm, 10% PER 36Mbps: -75dBm, 10% PER 24Mbps: -80dBm, 10% PER 18Mbps: -82dBm, 10% PER 12Mbps: -84dBm, 10% PER 9Mbps: -87dBm, 10% PER 6Mbps: -88dBm, 10% PER 802.11b11Mbps: -86dBm, 8% PER 5.5Mbps: -88dBm, 8% PER 2Mbps: -89dBm, 8% PER 1Mbps: -91dBm, 8% PER Data Rates: 802.11g: 54, 48, 36, 2…

Text truncated - open the document above for the full version.

Exclusive Certification Corp. 4F-2, No. 28, Lane 78, Xing-Ai Rd. Nei-hu, Taipei City 114 Taiwan R.O.C 11478284-2F Tel: 886-2-2792-3366 Fax: 886-2-2792-1100 To whom it may concern: The enclosed documents constitute a formal submittal and application for a Grant of Equipment Authorization pursuant to Subpart C of Part 15 of FCC rules (CFR47) regarding IEEE 802.11g Wireless PC Card for the SerComm Corporation model CB801AS. Data within this report demonstrates that the equipment tested complied with the FCC limits for intentional radiators. Exclusive Certificate Corp. (ECC), as duly authorized agent prepared this submittal. A copy of the letter of our appointment as agent is enclosed. If there are any questions or if further information is needed, please contact ECC for assistance. Signature: ________________________________ Name: Ivy Chen TEL: +886-2-2792-3366 # 204 FAX: +886-2-2792-1100 E-mail: [email protected]

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 June 4, 2005 RE: Sercomm Corporation FCC ID: P27CB801AS I have a few comments on this Application. Depending on your responses, kindly understand there may be additional comments. 1.) The SAR statement on page 2 of the manual is incorrect. Kindly see the SAR report results or consult with the SAR testing laboratory for proper language. Please review and correct. 2.) The frequency band listed in section 2.2 of the Manual is incorrect. Please review and correct. 3.) Since a SAR report is provided, there is no need to include an MPE report for this device inside the Test Report. Please review and remove. William H. Graff President and Director of Engineering mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

External Photos

64.50 mm 4 0 . 0 0 m m R25x4 FCC ID: P27CB801AS IEEE 802.11g Wireless PC Card / CB801AS

Internal Photos

Part Number Date Subject pages2 CB801AS Operation Principle 1. The CB801AS project is the PCI interface for Wireless LAN IEEE 802.11b/g. It’s protable device, used for 2.4GHz ISM band. Support 6,9,12,18,24,36,48,54 Mbps for OFDM; 11,5.5Mbps for CCK; 1,2 Mbps for Barker modulation; Atheros super G mode, offering up to 108 Mbps. 2. CPU, U1, AR2414 is an all CMOS, single chip solution for dual-mode, IEEE 802.11b/g wireless local area network (WLANs). 3. The AR2414 transceiver consists of the major functional blocks l Receiver l Transmitter l Frequency synthesizer l Associated bias / control 4. Components: 1. CPU AR2414 WLAN 802.11 b/g MAC/BB/Radio processor. 2. Power Amplifier GP1214 2.4GHz high performance power amplifier 3. Low Noise Amplifier SIRENZA SGA-8343 4. PCB Layout 4 layers 5. LED part: LED 1 LED 2 Description Slow rate blink off Power save mode Alternate blink Alternate blink Looking for network association Blink Blink Associated or joined with network; off off Power off or PCI/CardBus slot disabled . EEPROM, U3, M24C32, 32Kbits. It is supports 400KHz protocol.

Report No： 054L140SF Page: 1 of 117 Version:1.0 SAR Test Report Product Name ： IEEE802.11g Wireless PC Card Model No. ： CB801AS Applicant ：SerComm Corporation Address ：8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Date of Receipt：2005/05/20 Issued Date ：2005/05/31 Report No. ：055L140SF The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No： 054L140SF Page: 2 of 117 Version:1.0 Test Report Certification Issued Date: 2005/05/31 Report No.:055L140SF Product Name ： IEEE802.11g Wireless PC Card Applicant ： SerComm Corporation Address ： 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Manufacturer ： SerComm Corporation Model No. ： CB801AS Applicable Standard ： FCC Oet65 Supplement C June 2001 Test Result ： Max. SAR Measurement (1g) 802.11b: 0.880 W/kg 802.11g: 0.500 W/kg Application Type Certification The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Documented By ： (Rita Haung ) Tested By ： (Hsiu Ho) Approved By ： (Gene Chang) Report No： 054L140SF Page: 3 of 117 Version:1.0 TABLE OF CONTENTS Description Page 1. General Information.............................................................................. 5 1.1 EUT Description ............................................................................................................5 1.2 Test Environment ...........................................................................................................5 2. SAR Measurement System .................................................................. 6 2.1 ALSAS-10U System Description .................................................................................. 6 2.1.1 Applications ................................................................................................................ 6 2.1.2 Area Scans................................................................................................................... 6 2.1.3 Zoom Scan (Cube Scan Averaging)............................................................................ 7 2.1.4 ALSAS-10U Interpolation and Extrapolation Uncertainty......................................... 7 2.2 Isotropic E-Field Probe .................................................................................................. 7 2.2.1 Isotropic E-Field Probe Specification ......................................................................... 9 2.3 Boundary Detection Unit and Probe Mounting Device ................................................. 9 2.4 Daq-Paq (Analog to Digital Electronics) ..................................................................... 10 2.5 Axis Articulated Robot ................................................................................................ 10 2.6 ALSAS Universal Workstation.................................................................................... 11 2.7 Universal Device Positioner......................................................................................... 11 2.8 Phantom Types............................................................................................................. 11 2.8.1 APREL SAM Phantoms ........................................................................................... 12 2.8.2 APREL Laboratories Universal Phantom ................................................................. 12 3. Tissue Simulating Liquid ................................................................... 13 3.1 The composition of the tissue simulating liquid .......................................................... 13 3.2 Tissue Calibration Result ............................................................................................. 13 3.3 Tissue Dielectric Parameters for Head and Body Phantoms ....................................... 14 4. SAR Measurement Procedure ........................................................... 15 4.1 SAR System Validation................................................................................................ 15 4.1.1 Validation Dipoles..................................................................................................... 15 4.1.2 Validation Result ....................................................................................................... 15 4.2 SAR Measurement Procedure ...................................................................................... 16 5. SAR Exposure Limits ......................................................................... 17 6. Test Equipment List............................................................................ 18 7. Measurement Uncertainty .................................................................. 19 8. Test Results ......................................................................................... 20 8.1 SAR Test Results Summary ......................................................................................... 20 8.2 SAR System Validation Data ....................................................................................... 22 8.3 SAR Measurement Data............................................................................................... 26 Report No： 054L140SF Page: 4 of 117 Version:1.0 Test Setup Photographs ...................................................................................................... 84 EUT Photographs ............................................................................................................... 86 Probe Calibration ............................................................................................................... 87 Dipole Calibration............................................................................................................ 108 Report No： 054L140SF Page: 5 of 117 Version:1.0 1. General Information 1.1 …

Text truncated - open the document above for the full version.

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 1 of 78 FCC Test Report: FI05012202-A FCC TEST REPORT according to FCC Rules and Regulations Part 15 Subpart C Laboratory accreditation 1332 † The test result refers exclusively to the test presented test model / sample., † Without written approval of Exclusive Certification Corp. the test report shall not be reproduced except in full. † The EUT is also considered as a kind of computer peripheral, because the connection to computer is necessary for typical use. It has been verified to comply with the requirements of FCC Part 15, Subpart B, Class B (DoC). The test report has been issued separately. Applicant SerComm Corporation Address 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Equipment IEEE802.11g Wireless PC Card Model No. CB801AS FCC ID P27CB801AS Trade Name SerComm Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 2 of 78 FCC Test Report: FI05012202-A CONTENTS CERTIFICATE OF COMPLIANCE.......................................................................................................4 1. Report of Measurements and Examinations.............................................................................5 1.1. List of Measurements and Examinations............................................................................5 2. Test Configuration of Equipment under Test............................................................................6 2.1. RF Module Specifications..................................................................................................6 2.2. Feature of Equipment under Test.......................................................................................7 2.3. Test Mode and Test Software.............................................................................................8 2.4. Description of Test System................................................................................................8 2.5. Connection Diagram of Test System..................................................................................9 2.6. General Information of Test.............................................................................................10 2.7. History of this test report.................................................................................................10 3. Antenna Requirements............................................................................................................11 3.1. Standard Applicable.........................................................................................................11 3.2. Antenna Construction and Directional Gain.......................................................................11 4. Test of Conducted Emission...................................................................................................12 4.1. Test Limit.......................................................................................................................12 4.2. Test Procedures.............................................................................................................12 4.3. Typical Test Setup..........................................................................................................13 4.4. Measurement equipment.................................................................................................13 4.5. Test Result and Data.......................................................................................................14 5. Test of Radiated Emission......................................................................................................29 5.1. Test Limit.......................................................................................................................29 5.2. Test Procedures.............................................................................................................30 5.3. Typical Test Setup...........................................................................................................31 5.4. Measurement equipment.................................................................................................31 5.5. Test Result and Data.......................................................................................................32 6. 6dB Bandwidth Measurement Data.........................................................................................55 6.1. Test Limit........................................................................................................................55 6.2. Test Procedures..............................................................................................................55 6.3. Test Setup Layout...........................................................................................................55 6.4. Measurement equipment.................................................................................................55 6.5. Test Result and Data.......................................................................................................55 7. Maximum Peak Output Power.................................................................................................60 7.1. Test Limit........................................................................................................................60 7.2. Test Procedures..............................................................................................................60 7.3. Test Setup Layout...........................................................................................................60 7.4. Measurement equipment.................................................................................................60 7.5. Test Result and Data.......................................................................................................60 8. Band Edges Measurement..........…

Text truncated - open the document above for the full version.

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 29 of 78 FCC Test Report: FI05012202-A 5. Test of Radiated Emission 5.1. Test Limit Radiated emissions from 30 MHz to 25 GHz were measured according to the methods defines in ANSI C63.4-2001. The EUT was placed, 0.8 meter above the ground plane, as shown in section 5.6.3. The interface cables and equipment positions were varied within limits of reasonable applications to determine the positions producing maximum radiated emissions For unintentional device, according to § 15.109(a), except for Class A digital devices, the field strength of radiated emissions from unintentional radiators at a distance of 3 meters shall not exceed the following values: Frequency (MHz) Distance Meters Radiated (μ V / M) Radiated (dB μ V/ M) 30-88 3 100 40.0 88-216 3 150 43.5 216-960 3 200 46.0 Above 960 3 500 54.0 For unintentional device, according to CISPR PUB.22, for Class B digital devices, the general requirement of field strength of radiated emissions from intentional radiators at a distance of 10 meters shall not exceed the above table. Frequency (MHz) Distance Meters Radiated (dB μ V/ M) 30-230 10 30 230-1000 10 37 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 30 of 78 FCC Test Report: FI05012202-A 5.2. Test Procedures 1. The EUT was placed on a rotatable table top 0.8 meter above ground. 2. The EUT was set 3 meters from the interference receiving antenna which was mounted on the top of a variable height antenna tower. 3. The table was rotated 360 degrees to determine the position of the highest radiation. 4. The antenna is a broadband antenna and its height is varied between one meter and four meters above ground to find the maximum value of the field strength both horizontal polarization and vertical polarization of the antenna are set to make the measurement. 5. For each suspected emission the EUT was arranged to its worst case and then tune the antenna tower (from 1 M to 4 M) and turn table (from 0 degree to 360 degrees) to find the maximum reading. 6. Set the test-receiver system to Peak or CISPR quasi-peak Detect Function and specified bandwidth with Maximum Hold Mode. 7. If the emission level of the EUT in peak mode was 3 dB lower than the limit specified, then testing will be stopped and peak values of EUT will be reported, otherwise, the emissions which do not have 3 dB margin will be repeated one by one using the quasi-peak method and reported. 8. For testing above 1GHz, the emission level of the EUT in peak mode was 20dB lower than average limit (that means the emission level in peak mode also complies with the limit in average mode), then testing will be stopped and peak values of EUT will be reported, otherwise, the emissions will be measured in average mode again and reported. Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 31 of 78 FCC Test Report: FI05012202-A 5.3. Typical Test Setup 5.4. Measurement equipment Instrument/Ancillary Type Manufacturer Valid Date EMI Receiver 8546A HP 2006/0413 Spectrum Analyzer FSP40 R&S 2005/12/28 Horn Antenna 3115 EMCO 2006/02/21 Horn Antenna 3116 EMCO 2006/02/21 Bilog Antenna CBL6112B Schaffner 2006/04/11 Amplifier 8447D Agilent 2006/02/22 Amplifier 8449B Agilent 2005/12/27 Turn Table 0.8M Equipment under Test Ground Plane Receiver * Test distance Antenna Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 32 of 78 FCC Test Report: FI05012202-A 5.5. Test Result and Data Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 33 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 34 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 35 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 36 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 37 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 38 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 39 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 40 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 41 of 78 FCC Test Report: FI05012202-A

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 42 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 43 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 44 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 45 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 46 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 47 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 48 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 49 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 50 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 51 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 52 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 53 of 78 FCC Test Report: FI05012202-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 54 of 78 FCC Test Report: FI05012202-A 5.5.1. Test Photographs Front View Rear View

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 55 of 78 FCC Test Report: FI05012202-A 6. 6dB Bandwidth Measurement Data 6.1. Test Limit The minimum of 6dB Bandwidth Measurement is 0.5 MHz. 6.2. Test Procedures 1. The transmitter output was connected to the spectrum analyzer. 2. Set RBW of spectrum analyzer to 100 KHz and VBW to 100 KHz. 3. The 6 dB bandwidth is defined as the total spectrum the power of which is higher than peak power minus 6 dB. 6.3. Test Setup Layout 6.4. Measurement equipment Instrument/Ancillary Type Manufacturer Serial No. Valid Date. Spectrum Analyzer FSP40 R&S 100047 2005/12/28 6.5. Test Result and Data (1) Modulation Standard: IEEE 802.11b (11 Mbps) Test Date: May. 10, 2005 Temperature: 25 Humidity: 69% Atmospheric pressure: 1028 mmHg Channel Frequency (MHz) 6dB Bandwidth (MHz) 01 2412 11.3 06 2437 11.3 11 2462 11.2 (2) Modulation Standard: IEEE 802.11g (54 Mbps) Test Date: May. 10, 2005 Temperature: 25 Humidity: 69% Atmospheric pressure: 1028 mmHg Channel Frequency (MHz) 6dB Bandwidth (MHz) 01 2412 16.5 06 2437 16.4 11 2462 16.5 (3) Modulation Standard: IEEE 802.11 Super G (108 Mbps) Test Date: May. 10, 2005 Temperature: 25 Humidity: 69% Atmospheric pressure: 1028 mmHg Channel Frequency (MHz) 6dB Bandwidth (MHz) 06 2437 31.6 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 56 of 78 FCC Test Report: FI05012202-A Modulation Standard:802.11b (11Mbps) Channel:01 Channel:06 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 10, 2005 57 of 78 FCC Test Report: FI05012202-A Channel:11 Modulation Standard:802.11g (54Mbps) Channel:01…
