P27IP3442MAC2600 Wi-Fi Mesh Router

i IP3442M WiFi Router Quick Start Guide P/N: 957DFR00E5 Document Version: 1.0 Copyright 2020. All Rights Reserved. All trademarks and trade names are the properties of their respective owners ii Package Contents The following items are included in the box: 1. IP3442M 2. Quick Start Guide 3. Power adapter / 4. Wifi credential card If any of these items are damaged or missing, please contact your service provider immediately. 1 Chapter 1 Introduction This chapter provides details of the IP3442M's features and capabilities. Overview The IP3442M is designed to enhance the connectivity between your WiFi router and wireless client device while increasing the coverage of your existing WiFi network. With its simple setup, this high-speed 802.11ac extender works seamlessly with most routers. Features  Easy Setup: WPS button setup or web browser configuration Wireless Features  Supports 11ac WiFi: 802.11ac is backwards compatible with 802.11a/b/g/n  WPS Support: WPS (WiFi Protected Setup) simplifies the process of connecting any device to the wireless network by using the push button on the device  Security Support: WPA2, WPA, and WPA+WPA2 mixed mode are supported for advanced encryption of all WiFi data 1 2 Chapter 2 Basic Setup This chapter provides details on how to setup the IP3442M Front Panel Figure 1: Front Panel 1. Power/WAN (Green/Red) Red On, Green off – No internet. Blink Red,Green off - The Power LED will blink(Red) during boot up Green On, Red off-Internet connection is available. Interleave Red and Green-FW upgrade Off - No power. 2. WiFi/ WPS LED (Blue/Green) Green On-Wireless enable. Green off-Wireless disable Blue Slow blink, Green off - WPS is pairing. When WPS button is pressed, the LED will be blinking for 2 minutes. Blue Off - WPS feature is not in use. Blue On - WPS failure. Keep light for 10 seconds Blue off,Green off-During boot up 3. LAN LED (Green) On (Green) - LAN connection is available. Off - LAN is not connected. Blinking-The traffic is running 2 3 Back Panel Figure 2: Back Panel 1. LAN port*3 Connect to a PC or other Ethernet device using a standard Ethernet cable. 2. WAN port Connect to a cable modem or PON using a standard Ethernet cable. 3. Reset Button This button is recessed; a pin or paper clip can be used to press it. The button can be used while the unit is powered and the power LED is Green.  Reset to manufacturer default values and reboot. When pressed and held over 7 seconds, the settings of the IP3442M will be set to their default values.  Reboot. When pressed and held over 2 seconds and less than 5 seconds, the IP3442M will reboot. 4.USB port Power charging for smart phone or pad. 5. DC Jack  Connect to power with the accessory power adapter. 4 Side Panel Figure 3: Back Panel WPS Button Push the WPS button on the device and on your other WiFi device to perform WPS function that easily creates an encryption-secured WiFi connection automatically. 5 Setup the IP3442M You can set up your IP3442M using web browser. Setup Using Web Browser Step 1: Make sure the WiFi router is on and working properly. Step 2: Connect the Router WAN port with your cable modem or PON device with an Ethernet cable. Step 3: Connect an Ethernet cable to the Router and your PC. Step 4: Launch the browser and enter http://192.168.1.1 in the Address box. Step 5: You will be prompted for a username and password. Use the default values, admin for the username, and WPS PIN for the password by scanning the QR code in your WiFi credential card. Step 6: Choose the Wireless page, click Basic Setup, you can set your WiFi name and password . 2 2 6 Chapter 3 Safety This chapter provides you some safety operation warnings . 1. Use the power supply adapter provided in the package only. Using any other adapters may cause damage to the equipment or result in operation failures. 2. The electrical load capacity of the socket and cables should meet the device’s requirement. Power socket overload, broken cables or broken plugs may cause electric shock or fire. Check the power supply wires and cables regularly. 3. Install the equipment in a well-ventilated environment. Avoid areas with high temperature or direct sunlight to protect the equipment and its components from overheating. 4. Do not place this equipment in a dram or moist place. 5. Do not lay this equipment on an unsteady base. 3 7 Appendix A Regulatory FCC Statement This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example - use only shielded interface cables when connecting to computer or peripheral devices). FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that m…

Text truncated - open the document above for the full version.

Date:2020/6/8 FederalCommunicationsCommission 7435OaklandMillsRd ColumbiaMD21046-1609 Subject:ProductCertificationRepresentativeAuthorizationLetter FCCID:P27IP3442M Productname:AC2600Wi-FiMeshRouter Towhomitmayconcern: Wetheundersigned,herebyauthorizefollowingpersontoactasouragentinthepreparationofanapplication forequipmentauthorizationofmodelIP3442MXXXXXXXXXXtotheFCCRulesandRegulations. InternationalCertificationCorp. Address:No.3-1,Lane6,WenSan3rdSt.KweiShanDist.,TaoYuanCity333,Taiwan(R.O.C.) Name:GaryChang JobTitle:Manager e-mail: [email protected] Wefurthercertifiesthatneithertheapplicantnoranypartytothisapplication,asdefinedin47CFRCh. 1.2002(b),issubjecttoadenialtoFederalbenefits,thatincludeFCCbenefits,pursuanttosection5301ofthe Anti-DrugAbuseActof1998,21U.S.C.862. ThisappointmentalsoincludestheauthoritytocompleteFCCForm731onourbehalfandsignthe applicationasanauthorizedagent. Applicant:SercommCorporation Address:8F,No.3-1,YuanQuSt.,NanKang,Taipei115,Taiwan,R.O.C. Signature: ______________________ NameandJobTitle.:NickWu,Engineer E-mail:[email protected] Tel.:+886-2-26553988

Date:June8,2020 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRd ColumbiaMD21046-1609 Subject:Requestforconfidentiality FCCID:P27IP3442M Towhomitmayconcern: Short-termconfidentiality PursuanttoDA04-1705oftheCommission’spubicnotice,inordertocomplywiththemarketingregulationsin 47CFR § 2.803andtheimportationrulesin47CFR § 2.1204,whileensuringthatbusinesssensitiveinformation remainsconfidentialuntiltheactualmarketingofnewlyauthorizeddevices.Wearerequestingthecommissionto grantshort-termconfidentialityrequestonthefollowingattachmentsuntil180daysafterissuedate. ☒InternalPhotographs ☒ExternalPhotographs ☒User'smanual ☒TestSetupphoto Permanentconfidentiality PursuanttoSections0.457and0.459oftheCommission’sRules,theApplicantHerebyrequestsconfidential treatmentofinformationaccompanyingthisApplicationAsoutlinedbelow: ☒BlockDiagram ☒Schematics ☒OperationalDescription ☐BillofMaterials ☐Tuneupprocedure Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedtothepublic. Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovideunjustifiedbenefitstoits competitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthisapplicationandall accompanyingdocumentationwillnotbemadebeforethedateoftheGrantforthisapplication. Shouldyourequireanyfurtherinformation,pleasecontacttheundersigned. Thankyouforyourconsiderationinthismatter. Applicant:SercommCorporation Address:8F,No.3-1,YuanQuSt.,NanKang,Taipei115,Taiwan,R.O.C. Signature: NameandJobTitle.:NickWu,Engineer E-mail:[email protected] Tel.:+886-2-26553988

Date:June8,2020 Subject:AdHocModeFunctionDeclaration FCCID:P27IP3442M ToWhomitmayconcern, We,SercommCorporationdeclarethatthedevicedoesnotsupportany non-USchannels,countrycodeselectionandChannel12and13in2.4GHz bandinalltheoperationalmode(s).Also,theclientsoftwareandassociated driverswillnotinitiateanytransmissiononDFSfrequencieswithoutinitiation byamasterandthedevicewithoutsupportDFSdetectioncapability.This includesrestrictionontransmissionsforbeaconsandsupportforad-hoc peer-to-peermodes. Regards, Applicant:SercommCorporation Address: 8F,No.3-1,YuanQuSt.,NanKang,Taipei115,Taiwan, R.O.C. Signature: NameandJobTitle.:NickWu,Engineer [email protected] Tel.+886-2-26553988

Project No.: 051403 Page No. : 1 of 15 Photographs of EUT Project No.: 051403 Page No. : 2 of 15 Project No.: 051403 Page No. : 3 of 15 Project No.: 051403 Page No. : 4 of 15 Project No.: 051403 Page No. : 5 of 15 Project No.: 051403 Page No. : 6 of 15 Project No.: 051403 Page No. : 7 of 15 Project No.: 051403 Page No. : 8 of 15

2020.06.15 9 1 1 1 11 IP3442M-L/XX Judy Du Fanking Fan Fanking Fan Product label/Liberty Latin America 單位用量1 此处轧齿刀线,方便撕开,label与label间距,边距3mm DIM LINE NO PRINT 20191227 R1 Initial Release 20200224 20200319 R2 R3 Add:Sercomm P/N (The factory Print example) #50 white Mylar 932DFR01E5 label <Scale1:1> BarcodeCode 128 TEXT SIZE:Arial/6Pt Notes: 1.材質: 50#白色Mylar, 上打字用雾面PET 2.背压花胶 3.尺寸/印刷:如图 4.公差:0.- 0.2mm 5.本料件使用之材料須符合RoHS & UL Notes: 1.MATERIAL: #50 white Mylar, Can type with matt PET 2.ADHESIVE:Embossed Adhesive 3.SIZE:as drawing 4.PRINTING COLOR:as note 5.TOLERANCES:0,- 0.2mm 6.The material must comply with RoHS & UL Wetting tension（表面张力）>=32dyne/cm Wetting tension（表面张力）>=32dyne/cm 2 2 SN: yymmcccnnnnnn (13 digits Sercomm SN??) yy : last two digit (19 for 2019) mm : 01-12 ccc : product code nnnnnn : serial number Model: IP3442M-L/XX P/N: XXXXXXXXXX Made in China Login: http://192.168.1.1 Username: admin Password: 12345678 WiFi SSID: LIB-1234567 WiFi Password: 1234567890AB WPS PIN: 12345678 Serial: yymmcccnnnnnn MAC: 1234567890AB 30*30mm Polarity Input: 12V 2A This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received,including interference that may cause undesired operation FCC ID: P27IP3442M Add:FCC logo and R4 Update:“Sercomm P/N” for“P/N” 20200323 TEXT SIZE:Arial/5Pt QR Code Made in China Polarity Input: 12V 2A This device complies with Part 15 of theFCC Rules. Operation is subject to thefollowing two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interferencereceived,including interference that maycause undesired operation FCC ID: P27IP3442M Made in China Polarity Input: 12V 2A This device complies with Part 15 of theFCC Rules. Operation is subject to thefollowing two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interferencereceived,including interference that maycause undesired operation FCC ID: P27IP3442M Made in China Polarity Input: 12V 2A This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received,including interference that may cause undesired operation FCC ID: P27IP3442M 20200427R5 Adjust details according to factory requirements 20200511 20200514 UpdateLogin: http://192.168.1.1 Add“FCC ID: P27IP3442M” R6 R7 20200529 R8 Update Model: IP3442M-L/XX 20200615 R9 Adjust safty logo location Bottom FCC ID: P27IP3442M

Project No.: 051403 Page No. : 9 of 15 Project No.: 051403 Page No. : 10 of 15 Project No.: 051403 Page No. : 11 of 15 Project No.: 051403 Page No. : 12 of 15 Project No.: 051403 Page No. : 13 of 15 Project No.: 051403 Page No. : 14 of 15 Project No.: 051403 Page No. : 15 of 15

Report No.: FA051403 Page : 1 of 7 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : P27IP3442M Equipment : AC2600 Wi-Fi Mesh Router Model No. : IP3442MXXXXXXXXXX (refer to item 1.1.1 for more details) Brand Name : Sercomm Applicant : Sercomm Corporation Address : 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Standard : 47 CFR FCC Part 2.1091 Received Date : May 14, 2020 Tested Date : May 19 ~ Jun. 12, 2020 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any agency of government. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FA051403 Page : 2 of 7 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 4 1.1 Information .............................................................................................................................................. 4 2 MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 5 2.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 5 2.2 MPE EVALUATION FORMULA ............................................................................................................. 5 2.3 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE ................................... 5 2.4 MEASUREMENT UNCERTAINTY ......................................................................................................... 5 2.5 MPE EVALUATION RESULTS .............................................................................................................. 6 2.6 MPE EVALUATION OF SIMULTANEOUS TRANSMISSION ................................................................ 6 3 TEST LABORATORY INFORMATION ................................................................................................. 7 Report No.: FA051403 Page : 3 of 7 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA051403 Rev. 01 Initial issue Jun. 23, 2020 Report No.: FA051403 Page : 4 of 7 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Product Details The following models are provided to this EUT. Model Name Description IP3442MXXXXXXXXXX the 1st x should be "blank" or "-"; the rest x could be 0 to 9, A to Z, "blank", “-“ or "/" , for marketing purpose  The above models, model IP3442M was selected as a representative one for the final test and only its data was recorded in this report. Report No.: FA051403 Page : 5 of 7 Report Version: Rev. 01 2 MPE EVALUATION OF MOBILE DEVICES 2.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE Frequency Range (MHz) Power Density (mW /cm 2 ) Averaging Time (minutes) 300~1500 F/1500 30 1500~100000 1.0 30 2.2 MPE EVALUATION FORMULA Pd = 2 **4RPi Pt Where Pd= Power density in mW/cm 2 Pt= EIRP in mW Pi= 3.1416 R= Measurement distance 2.3 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE None 2.4 MEASUREMENT UNCERTAINTY The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2) Parameters Uncertainty Conducted power ±0.808 dB Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FA051403 Page : 6 of 7 Report Version: Rev. 01 2.5 MPE EVALUATION RESULTS Non-beamforming mode Frequency Range (MHz) Maximum Conducted Power (dBm) Rated Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) Ratio* Pass / Fail 2412~2462 26.59 27 3.1 20 0.204 1 0.204 Pass 5180-5240 26.15 26.5 3.1 20 0.181 1 0.181 Pass 5745-5825 26.67 27 2.9 20 0.194 1 0.194 Pass *Ratio = Power density / Limit. Beamforming mode Frequency Range (MHz) Maximum Conducted Power (dBm) Rated Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) Ratio* Pass / Fail 5180-5240 24.82 25.0 8.73 20 0.470 1 0.470 Pass 5745-5825 26.41 26.5 8.50 20 0.629 1 0.629 Pass *Ratio = Power density / Limit. Note: For 5150~5250MHz: Directional gain = 10 x log((10 3.1/20 +10 2.4/20 +10 2.2/20 +10 3.1/20 ) 2 /4) = 8.73 dBi. For 5725~5850MHz: Directional gain = 10 x log((10 2.4/20 +10 2.2/20 +10 2.4/20 +10 2.9/20 ) 2 /4) = 8.50 dBi. 2.6 MPE EVALUATION OF SIMULTANEOUS TRANSMISSION Non-beamforming mode Mode Max Ratio of Each Mode WLAN 2.4GHz 0.204 WLAN 5GHz 0.194 Sum 0.398 Limit 1 Pass / Fail Pass Beamforming mode Mode Max Ratio of Each Mode WLAN 2.4GHz 0.204 WLAN 5GHz 0.629 Sum 0.833 Limit 1 Pass / Fail Pass Report No.: FA051403 Page : 7 of 7 Report Version: Rev. 01 3 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corp (EMC and Wireless Communication Laboratory), it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise and devotion to …
