External Photos

44mm 2 6 . 5 m m 9320LZ001 V Model No.: Serial No.: Server Name: Input: 12VDC800~1000mAPolarity: + + 0.2 0 . 2 - - Made in Taiwan IP806MA Wireless BroadBand Router SerComm Corporation Tested to Comply With FCC Standards FOR HOME OR OFFICE USE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received. including interference that may cause undesired operation. FCC ID: P27IP806MA

Internal Photos

IP806MA Operation Principle 1. CPU, U7, RTL8651B have a 32-bit RISC processor integrated, operation frequency is 200MHz. It needs an external 25MHz crystal for system reference frequency. This chip is responsible to control Flash/SDRAM IC and LED. This chip also has 5 integrated 10/100 Ethernet MAC/PHY. 2. FLASH: U1, MX29LV160BBTC-90, 2Mbytes Flash, and 90ns. It is used to store the normal and test firmware. 3. Wireless q RC2326(U2): IEEE 802.11 b/g RFFE ISM Band, highly integrated 802.11 b/g radio Radio, fully integrated up/down converters, LNA, PA, TX detector and T/R switches q RC2422(U8): IEEE 802.11 b/g IQ/IF Transceiver With Dual VCO Synthesizers, Highly integrated 802.11 b/g radio IQ/IF Transceiver PLL ASIC, Fully integrated IF and RF VCOs and synthesizer q (U1)TNETW1130GVF Wireless MAC and Baseband processor 4. Switching Controller: It is integrated in CPU RTL8651B which provide 5 ports of ethernet interface. 5. Power part: U10, FP5452 is used to generate 3.3V and 1.8V DC voltage from 12V DC power input. 1.8V is CPU core voltage. 6. Switch button, S1, it is used to factory restore or system reboot.

1.1. Test Result of RF Exposure Evaluation . Product: Wireless Broadband Router . Test Item: RF Exposure Evaluation Data . Test site: OATSI-SD . Test Mode: Normal Operation 1.1.1. Antenna Gain The maximum Gain is 2.0 dBi. 1.1.2. EUT Operation condition Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 1.1.3. Output Power into Antenna & RF Exposure Evaluation Distance Modulation Standard: IEEE 802.11b Test Date: Feb. 23, 2005 Temperature: 24 Humidity: 69 Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density (S) (mW/cm 2 ) 01 2412 12.88 0.0040 06 2437 12.75 0.0040 11 2462 12.85 0.0040 Modulation Standard: IEEE 802.11g Test Date: May. 18, 2004 Temperature: 25 Humidity: 58 Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density (S) (mW/cm 2 ) 01 2412 12.97 0.0040 06 2437 12.94 0.0040 11 2462 12.79 0.0040 The MPE is calculated as 0.0040 mW / cm 2 < limit 1 mW / cm 2 . So, RF exposure limit warning or SAR test are not required.
