P27IP822LMHome Plug 802.11g Residential Access Point

HomePlug 802.11g Access Point User's Guide i TABLE OF CONTENTS CHAPTER 1 INTRODUCTION..............................................................................................................1 Features of your HomePlug 802.11g Access Point....................................................................2 Package Contents.............................................................................................................................2 Physical Description........................................................................................................................3 CHAPTER 2 INSTALLATION...............................................................................................................5 Requirements....................................................................................................................................5 Procedure...........................................................................................................................................5 CHAPTER 3 ACCESS POINT SETUP..................................................................................................7 Overview.............................................................................................................................................7 Preparation........................................................................................................................................7 Configuration....................................................................................................................................8 Status Screen..................................................................................................................................10 HomePlug Settings.........................................................................................................................11 Wireless Settings Screen.............................................................................................................13 Wireless Security..........................................................................................................................15 LAN IP Setup Screen.....................................................................................................................17 Set Password Screen......................................................................................................................18 CHAPTER 4 WIRELESS CLIENT CONFIGURATION...................................................................19 Overview...........................................................................................................................................19 Wireless Settings...........................................................................................................................19 CHAPTER 5 OPERATION AND STATUS.........................................................................................20 Operation..........................................................................................................................................20 Status Screen..................................................................................................................................20 Attached Devices.............................................................................................................................21 CHAPTER 6 MAINTENANCE..............................................................................................................23 Overview...........................................................................................................................................23 Backup Settings..............................................................................................................................23 Firmware Upgrade..........................................................................................................................25 APPENDIX A SPECIFICATIONS........................................................................................................26 HomePlug 802.11g Access Point................................................................................................26 Wireless Interface..........................................................................................................................26 APPENDIX B TROUBLESHOOTING.................................................................................................28 Overview...........................................................................................................................................28 General Problems...........................................................................................................................28 APPENDIX C WINDOWS TCP/IP......................................................................................................29 Overview...........................................................................................................................................29 Checking TCP/IP Settings - Windows 9x/ME:.........................................................................29 Checking TCP/IP Settings - Windows NT4.0...........................................................................31 Checking TCP/IP Settings - Windows 2000.............................................................................32 Checking TCP/IP Settings - Windows XP................................................................................34 ii P/N: 9560TP0001 Copyright  2005. All Rights Reserved. Document Version: 1.0 All trademarks and trade names are the properties of their respective owners. 1 Chapter 1 Introduction This Chapter provides an overview of the HomePlug 802.11g Access Point's features and capabilities. Congratulations on the purchase of your new HomePlug 802.11g Access Point. The HomePlug 802.11g Access Point links your 802.11b or 802.1x Wireless Stations to yo…

Text truncated - open the document above for the full version.

Exclusive Certification Corp. 4F-2, No. 28, Lane 78, Xing-Ai Rd. Nei-hu, Taipei City 114 Taiwan R.O.C 11478284-2F Tel: 886-2-2792-3366 Fax: 886-2-2792-1100 To whom it may concern: The enclosed documents constitute a formal submittal and application for a Grant of Equipment Authorization pursuant to Subpart C of Part 15 of FCC rules (CFR47) regarding HomePlug 802.11g Access Point for the SerComm Corporation model IP822LM. Data within this report demonstrates that the equipment tested complied with the FCC limits for intentional radiators. Exclusive Certificate Corp. (ECC), as duly authorized agent prepared this submittal. A copy of the letter of our appointment as agent is enclosed. If there are any questions or if further information is needed, please contact ECC for assistance. Signature: ________________________________ Name: Ivy Chen Title: Office Assistant TEL: +886-2-2792-3366 # 204 FAX: +886-2-2792-1100 E-mail: [email protected]

0560 FCC ID: P27IP822LM IP822LM SerComm

Internal Photos

Frequency range for 802.11b/g: 2412 MHz - 2462 MHz Frequency range for Homeplug: 4.3 MHz - 20.9 MHz

1.1. Test Result of RF Exposure Evaluation . Product: HomePlug 802.11g Access Point . Test Item: RF Exposure Evaluation Data . Test site: OATSI-SD . Test Mode: Normal Operation 1.1.1. Antenna Gain The maximum Gain is 0 dBi. 1.1.2. EUT Operation condition Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 1.1.3. Output Power into Antenna & RF Exposure Evaluation Distance Modulation Standard: IEEE 802.11b Test Date: Apr. 26, 2005 Temperature: 25 Humidity: 68 Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density (S) (mW/cm 2 ) 01 2412 13.01 0.0040 06 2437 12.89 0.0040 11 2462 12.24 0.0030 Modulation Standard: IEEE 802.11g Test Date: May. 18, 2004 Temperature: 25 Humidity: 58 Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density (S) (mW/cm 2 ) 01 2412 12.21 0.0030 06 2437 13.18 0.0040 11 2462 13.28 0.0040 The MPE is calculated as 0.0040 mW / cm 2 < limit 1 mW / cm 2 . So, RF exposure limit warning or SAR test are not required.

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 1 of 64 FCC Test Report: FI05041204-A FCC TEST REPORT according to FCC Rules and Regulations Part 15 Subpart C Laboratory accreditation 1332 † The test result refers exclusively to the test presented test model / sample., † Without written approval of Exclusive Certification Corp. the test report shall not be reproduced except in full. † The EUT is also considered as a kind of computer peripheral, because the connection to computer is necessary for typical use. It has been verified to comply with the requirements of FCC Part 15, Subpart B, Class B (DoC). The test report has been issued separately. Applicant SerComm Corporation Address 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, R.O.C. Equipment HomePlug 802.11g Access Point Model No. IP822LM FCC ID P27IP822LM Trade Name SerComm Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 2 of 64 FCC Test Report: FI05041204-A CONTENTS CERTIFICATE OF COMPLIANCE........................................................................................................4 1. Report of Measurements and Examinations..................................................................................5 1.1. List of Measurements and Examinations............................................................................5 2. Test Configuration of Equipment under Test..................................................................................6 2.1. Feature of Equipment under Test.......................................................................................6 2.2. RF Module Specifications..................................................................................................6 2.3. Test Mode and Test Software.............................................................................................6 2.4. Description of Test System................................................................................................7 2.5. Connection Diagram of Test System..................................................................................8 2.6. General Information of Test...............................................................................................9 2.7. History of this test report...................................................................................................9 3. Antenna Requirements..............................................................................................................10 3.1. Standard Applicable........................................................................................................10 3.2. Antenna Construction and Directional Gain......................................................................10 4. Test of Conducted Emission.......................................................................................................11 4.1. Test Limit........................................................................................................................11 4.2. Test Procedures..............................................................................................................11 4.3. Typical Test Setup..........................................................................................................12 4.4. Measurement equipment.................................................................................................12 4.5. Test Result and Data.......................................................................................................13 5. Test of Radiated Emission.........................................................................................................26 5.1. Test Limit.......................................................................................................................26 5.2. Test Procedures.............................................................................................................27 5.3. Typical Test Setup...........................................................................................................28 5.4. Measurment equipment...................................................................................................28 5.5. Test Result of Radiated emission.....................................................................................29 6. 6dB Bandwidth Measurement Data............................................................................................46 6.1. Test Limit........................................................................................................................46 6.2. Test Procedures..............................................................................................................46 6.3. Test Setup Layout...........................................................................................................46 6.4. List of Measuring Equipment Used...................................................................................46 6.5. Test Result and Data.......................................................................................................46 7. Maximum Peak Output Power...................................................................................................50 7.1. Test Limit........................................................................................................................50 7.2. Test Procedures..............................................................................................................50 7.3. Test Setup Layout...........................................................................................................50 7.4. Measurement equipment.................................................................................................50 7.5. Test Result and Data.......................................................................................................50 8. Band Edges Measurem…

Text truncated - open the document above for the full version.

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 26 of 64 FCC Test Report: FI05041204-A 5. Test of Radiated Emission 5.1. Test Limit Radiated emissions from 30 MHz to 25 GHz were measured according to the methods defines in ANSI C63.4-2001. The EUT was placed, 0.8 meter above the ground plane, as shown in section 5.6.3. The interface cables and equipment positions were varied within limits of reasonable applications to determine the positions producing maximum radiated emissions For unintentional device, according to § 15.109(a), except for Class A digital devices, the field strength of radiated emissions from unintentional radiators at a distance of 3 meters shall not exceed the following values: Frequency (MHz) Distance Meters Radiated (μ V / M) Radiated (dB μ V/ M) 30-88 3 100 40.0 88-216 3 150 43.5 216-960 3 200 46.0 Above 960 3 500 54.0 For unintentional device, according to CISPR PUB.22, for Class B digital devices, the general requirement of field strength of radiated emissions from intentional radiators at a distance of 10 meters shall not exceed the above table. Frequency (MHz) Distance Meters Radiated (dB μ V/ M) 30-230 10 30 230-1000 10 37 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 27 of 64 FCC Test Report: FI05041204-A 5.2. Test Procedures 1. The EUT was placed on a rotatable table top 0.8 meter above ground. 2. The EUT was set 3 meters from the interference receiving antenna which was mounted on the top of a variable height antenna tower. 3. The table was rotated 360 degrees to determine the position of the highest radiation. 4. The antenna is a broadband antenna and its height is varied between one meter and four meters above ground to find the maximum value of the field strength both horizontal polarization and vertical polarization of the antenna are set to make the measurement. 5. For each suspected emission the EUT was arranged to its worst case and then tune the antenna tower (from 1 M to 4 M) and turn table (from 0 degree to 360 degrees) to find the maximum reading. 6. Set the test-receiver system to Peak or CISPR quasi-peak Detect Function and specified bandwidth with Maximum Hold Mode. 7. If the emission level of the EUT in peak mode was 3 dB lower than the limit specified, then testing will be stopped and peak values of EUT will be reported, otherwise, the emissions which do not have 3 dB margin will be repeated one by one using the quasi-peak method and reported. 8. For testing above 1GHz, the emission level of the EUT in peak mode was 20dB lower than average limit (that means the emission level in peak mode also complies with the limit in average mode), then testing will be stopped and peak values of EUT will be reported, otherwise, the emissions will be measured in average mode again and reported. Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 28 of 64 FCC Test Report: FI05041204-A 5.3. Typical Test Setup 5.4. Measurment equipment Instrument/Ancillary Type Manufacturer Valid Date EMI Receiver 8546A HP 2006/0413 Spectrum Analyzer FSP40 R&S 2005/12/28 Horn Antenna 3115 EMCO 2006/02/21 Horn Antenna 3116 EMCO 2006/02/21 Bilog Antenna CBL6112B Schaffner 2006/04/12 Amplifier 8447D Agilent 2006/02/14 Amplifier 8449B Agilent 2005/12/27 Turn Table 0.8M Equipment under Test Ground Plane Receiver * Test distance Antenna Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 29 of 64 FCC Test Report: FI05041204-A 5.5. Test Result of Radiated emission Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 30 of 64 FCC Test Report: FI05041204-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 31 of 64 FCC Test Report: FI05041204-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 32 of 64 FCC Test Report: FI05041204-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 33 of 64 FCC Test Report: FI05041204-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 34 of 64 FCC Test Report: FI05041204-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 35 of 64 FCC Test Report: FI05041204-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 36 of 64 FCC Test Report: FI05041204-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 37 of 64 FCC Test Report: FI05041204-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 38 of 64 FCC Test Report: FI05041204-A

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 39 of 64 FCC Test Report: FI05041204-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 40 of 64 FCC Test Report: FI05041204-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 41 of 64 FCC Test Report: FI05041204-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 42 of 64 FCC Test Report: FI05041204-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 43 of 64 FCC Test Report: FI05041204-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 44 of 64 FCC Test Report: FI05041204-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 45 of 64 FCC Test Report: FI05041204-A 5.5.1. Test Photographs FRONT VIEW REAR VIEW Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 46 of 64 FCC Test Report: FI05041204-A 6. 6dB Bandwidth Measurement Data 6.1. Test Limit The minimum of 6dB Bandwidth Measurement is 0.5 MHz. 6.2. Test Procedures 1. The transmitter output was connected to the spectrum analyzer. 2. Set RBW of spectrum analyzer to 100 KHz and VBW to 100 KHz. 3. The 6 dB bandwidth is defined as the total spectrum the power of which is higher than peak power minus 6 dB. 6.3. Test Setup Layout 6.4. List of Measuring Equipment Used Instrument/Ancillary Type Manufacturer Serial No. Valid Date. Spectrum Analyzer FSP40 R&S 100047 2005/12/28 6.5. Test Result and Data (1) Modulation Standard: IEEE 802.11b Test Date: Apr. 26, 2005 Temperature: 25 Humidity: 68% Atmospheric pressure: 1023 mmHg Channel Frequency (MHz) 6dB Bandwidth (MHz) 01 2412 7.6 06 2437 7.6 11 2462 7.6 (2) Modulation Standard: IEEE 802.11g Test Date: Apr. 26, 2005 Temperature: 25 Humidity: 68% Atmospheric pressure: 1023 mmHg Channel Frequency (MHz) 6dB Bandwidth (MHz) 01 2412 15.2 06 2437 15.2 11 2462 15.2 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 47 of 64 FCC Test Report: FI05041204-A Modulation Standard:802.11b (11Mbps) Channel:01 Channel:06 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 48 of 64 FCC Test Report: FI05041204-A Channel:11 Modulation Standard:802.11g (54Mbps) Channel:01 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 49 of 64 FCC Test Report: FI05041204-A Channel:06 Channel:11 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 50 of 64 FCC Test Report: FI05041204-A 7. Maximum Peak Output Power 7.1. Test Limit The Maximum Peak Output Power Measurement is 30dBm. 7.2. Test Procedures The antenna portRF outputof the EUT was connected to the inputRF inputof a power meter. Power was read directly from the meter and cable loss connection was added to the reading to obtain power at the EUT antenna terminal. The EUT Output Power was set to maximum to produce the worse case test result. 7.3. Test Setup Layout 7.4. Measurement equipment Instrument/Ancillary Type Manufacturer Serial No. Valid Date. Spectrum Analyzer FSP40 R&S 100047 2005/12/28 7.5. Test Result and Data (1) Modulation Standard: IEEE 802.11b Test Date: Apr. 26, 2005 Temperature: 25 Humidity: 68% Atmospheric pressure: 1023 mmHg Channel Frequency (MHz) Peak Power Output (dBm) Peak Power Output (mW) 01 2412 13.01 19.999 06 2437 12.89 19.454 11 2462 12.24 16.749 (2) Modulation Standard: IEEE 802.11g Test Date: Apr. 26, 2005 Temperature: 25 Humidity: 68% Atmospheric pressure: 1023 mmHg Channel Frequency (MHz) Peak Power Output (dBm) Peak Power Output (mW) 01 2412 12.21 16.634 06 2437 13.18 20.797 11 2462 13.28 21.281 Note: Conducted Power = Reading Value + Cable Loss Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 51 of 64 FCC Test Report: FI05041204-A Modulation Standard:802.11b (11Mbps) Channel:01 Channel:06 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 52 of 64 FCC Test Report: FI05041204-A Channel:11 Modulation Standard:802.11g (54Mbps) Channel:01 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 53 of 64 FCC Test Report: FI05041204-A Channel:06 Channel:11 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 54 of 64 FCC Test Report: FI05041204-A 8. Band Edges Measurement 8.1. Test Limit Below –20dB of the highest emission level of operating band (in 100kHz Resolution Bandwidth) 8.2. Test Procedure 1. The transmitter output was connected to the spectrum analyzer via a low lose cable. 2. Set both RBW and VBW of spectrum analyzer to 100 KHz with convenient frequency span including 100 KHz bandwidth from band edge. 3. The band edges was measured and recorded. 8.3. Test Setup Layout 8.4. Measurement equipment Instrument/Ancillary Type Manufacturer Serial No. Valid Date. Spectrum Analyzer FSP40 R&S 100047 2005/12/28 8.5. Test Result and Data (1) Modulation Standard: IEEE 802.11b Test Date: Apr. 27, 2005 Temperature: 25 Humidity: 69% Atmospheric pressure: 1028 mmHg Channel Frequency maximum value in frequency (MHz) maximum value is (dBm) 01 2412 2500.00 -45.73 11 2462 2500.10 -39.77 (2) Modulation Standard: IEEE 802.11g Test Date: Apr. 27, 2005 Temperature: 25 Humidity: 69% Atmospheric pressure: 1028 mmHg Channel Frequency maximum value in frequency (MHz) maximum value is (dBm) 01 2412 2400.00 -49.99 11 2462 2488.10 -53.93 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: May. 30, 2005 55 of 64 FCC Test Report: FI05041204-A Modulation Standard:802.11b (11Mbps) Channel:01 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued …

Text truncated - open the document above for the full version.

Test Setup Photos
