P27MDC845FHD WiFi Mini Dome Camera

ADT Interactive Solutions: Control & Pulse MDC845 FHD Wi-Fi Mini Dome Camera Quick Installation Guide FCC ID:P27MDC845 IC: 527A-MDC845 ADT MDC845 FHD Wi-Fi Mini Dome Camera Quick Installation Guide MDC845 FHD Wi-Fi Mini Dome Camera Installation Guide 2 Table of Contents 1 Introduction............................................................................... 3 1.1 Feature Overview .......................................................................................... 1.2 Physical Details ............................................................................................. 1.3 Packaging Contents ...................................................................................... 2 Basic Setup ............................................................................... 5 2.1 Assembling the Camera................................................................................ 2.2 Power Up ....................................................................................................... 2.3 Final Steps .................................................................................................... 3 ADT Control Enrollment ............................................................ 9 3.1 Using a Wired Connection to Enroll the Camera .......................................... 3.2 Using Soft AP to Enroll Camera .................................................................... 4 ADT Pulse Enrollment .............................................................13 4.1 Using a Wired Connection to Enroll Camera ................................................ 4.2 Using WPS PIN to Enroll Camera .................................................................. 5 Ceiling Mounting .....................................................................23 6 Wireless Connectivity Troubleshooting ..................................26 6.1 If the Camera Continually Goes Offline ........................................................ 7 Appendix .................................................................................27 7.1 Technical Specifications ............................................................................... 7.2 Regulatory Approvals .................................................................................... 7.2.1 Federal Communication Commission Interference Statement .................................................................................................... 7.2.2 Industry Canada Statement .............................................................. ©2019 ADT LLC dba ADT Security Services. All rights reserved. ADT, the ADT logo, 1.800.ADT.ASAP and the product/service names listed in this document are marks and/or registered marks. Unauthorized use is strictly prohibited. MDC845 (11/19) Property of ADT, LLC. Information accurate as of published date and is provided “as is” without warranty of any kind. ADT MDC845 FHD Wi-Fi Mini Dome Camera Quick Installation Guide MDC845 FHD Wi-Fi Mini Dome Camera Installation Guide 3 1 Introduction This section provides information about the MDC845 FHD Wi-Fi Mini Dome Camera's features, components and capabilities. 1.1 Feature Overview The MDC845 is a Wi-Fi Mini Dome Camera with FHD resolution and 802.11ac Wi- Fi connectivity intended for use with both ADT Control ® and Pulse ® . • Standalone Design. The camera is a standalone system with built-in CPU and video encoder. It requires only a power source and a connection to the network (customer router for Control or ADT Pulse gateway). • Dual Video Support. The MDC845 supports H.264 and MJEPG video compression. • Day/Night Switch. With the day/night switching feature, you can view and record images even at night. • IR LED Support. The two infrared (IR) LEDs can provide illumination for up to 5 meters/16 feet, providing superior video quality under low-light conditions. • Built-in Heater. The built-in heater ensures that the camera operates even in extremely cold climates. The heater turns on when the temperature falls below -4°F (-20°C). • 802.11ac Support. The 802.11ac standard provides backward compatibility with the 802.11 a/b/g/n standards. • Supports Soft AP, WPS PIN, and Wired Enrollment. Software-enabled Access Point (Soft AP) connectivity is used on the Control platform. Wi-Fi Protected Setup PIN (WPS PIN) uses a push button and PIN to connect to the Pulse platform. Both platforms support wired enrollment. • Wireless and Wired Operation. The MDC845 operates either wired or wirelessly. 1.2 Physical Details ADT MDC845 FHD Wi-Fi Mini Dome Camera Quick Installation Guide MDC845 FHD Wi-Fi Mini Dome Camera Installation Guide 4 Component Description Power Port The red and black flying leads connect to the terminal block, which attaches to a power cable (not supplied) and power adapter. Connect the supplied 12V power adapter. Do not use other power adapters; doing so may damage the camera. LAN Port Use a standard Ethernet cable (not included) to connect the LAN port to either the customer’s router or the Pulse gateway. Status LED Off: Unit does not have power. On: ( Blue) Unit is booting up then LED will blink blue ten times indicating the boot-up process is complete. Blinking: ( Green/Amber) The power LED blinks green/amber after initial startup is completed. This indicates that the Soft AP OR WPS PIN mode is ready. On: (Green) Camera is connected to the network. Blinking: (Green) Camera has lost connection to the network Blinking: (Amber) Unit is in WPS PIN mode and/or the WPS connection is in progress. On: (Amber) If the LED is on for 5 seconds and then turns off, the WPS function has failed. WPS/Reset/Image Flip Button This button serves three functions on the camera. WPS PIN Mode: When pressed and held for 5 seconds during the Pulse enrollment process, the camera creates an encrypted secure wireless connection. Reset: When pressed and held for 15 seconds, the camera reboots and settings are restored to default values. Image Flip Button: When doubl…

Text truncated - open the document above for the full version.

DTS‐UNIIDeviceDeclarationLetter Towhomitmayconcern: WehavedeclaredbelowfeaturedforFCCequipmentauthorization, DeviceFCCID:P27MDC845 (1)DFSDevice--Master,ClientwithRadardetectioncapability, ■Clientwithoutradardetectioncapability,N/A (2)Active/PassiveScanning,Adhocmodeaccesspointcapability Frequency Band(MHz) ActiveScanning (thedevicecantransmit aprobe(beacon)) passivescanning (wherethedeviceiscan listenonlywithno probes) AdHocModeor WIFIDirect capability Accesspoint capability 2412-2462 ■Yes,NoYes,■NoYes,■NoYes,■No 2422-2452 ■Yes,NoYes,■NoYes,■NoYes,■No 5180-5240 ■Yes,NoYes,■NoYes,■NoYes,■No 5190-5230 ■Yes,NoYes,■NoYes,■NoYes,■No 5210 ■Yes,NoYes,■NoYes,■NoYes,■No 5260-5320 Yes,■No■Yes,NoYes,■NoYes,■No 5270-5310 Yes,■No■Yes,NoYes,■NoYes,■No 5290 Yes,■No■Yes,NoYes,■NoYes,■No 5500-5700 Yes,■No■Yes,NoYes,■NoYes,■No 5510-5670 Yes,■No■Yes,NoYes,■NoYes,■No 5530 Yes,■No■Yes,NoYes,■NoYes,■No 5745-5825 ■Yes,NoYes,■NoYes,■NoYes,■No 5755-5795 ■Yes,NoYes,■NoYes,■NoYes,■No 5775 ■Yes,NoYes,■NoYes,■NoYes,■No (3)Countrycodeselectionability-Yes,■No Ifyes,plsexplainhowitwasimplemented:(plsalsohelptoprovidedetailofoptionsforeach countryselection) (4)Meet15.202requirement-■Yes,No, Plscheckbelow: Amasterdeviceisdefinedasadeviceoperatinginamodeinwhichithasthecapabilityto transmitwithoutreceivinganenablingsignal.Inthismodeitisabletoselectachannelandinitiate anetworkbysendingenablingsignalstootherdevices. ■Aclientdeviceisdefinedasadeviceoperatinginamodeinwhichthetransmissionsofthe deviceareundercontrolofthemaster.Adeviceinclientmodeisnotabletoinitiateanetwork. (5)Forclientdevicesthathavesoftwareconfigurationcontroltooperateindifferentmodes(active scanninginsomeandpassivescanninginothers)indifferentbands(deviceswithmultiple equipmentclassesorthosethatoperateonnon-DFSfrequencies)ormodulardeviceswhich configurethemodesofoperationsthroughsoftware,theapplicationmustprovidesoftwareand operationsdescriptiononhowthesoftwareand/orhardwareisimplementedtoensurethat properoperationsmodescannotbemodifiedbyenduseroraninstaller. Apply,■NoApply(Ifapply,plshelptoprovideexplanationonitwasimplement,andhow softwarewascontrolled) (6)Pleasehelptoprovidejustificationhowdevicewasrestrictedtooperatein5600-5650MHzin below. __________________________(Signature) CompanyName:SercommCorporation Name&title:NickWu/Manager Telephone:886-2-2655-3988ext.2556 E-Mail:[email protected]

Date：December 27, 2019 To : SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Sercomm Corporation 8F, No. 3-1, YuanQu St. NanKang, Taipei City Taiwan Dear Sir or Madam, Due to the business consideration, we hereby declare that our product of FHD WiFi Mini Dome Camera Model: MDC845xxxxxxxx (the 1st x should be "blank" or "-"; the rest x could be 0 to 9, A to Z, a to z, "blank" or "-" , for marketing purpose) have as following difference for all the specification and layout are identical except they come with different model number for marketing purposes. Any questions regarding this declaration, please don’t hesitate to contact us. Your Sincerely, Nick Wu / Manager Sercomm Corporation Phone: 886-2-2655-3988 ext. 2556 E-Mail: [email protected]

Date: November 7, 2019 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding FCC ID: P27MDC845 To whom it may concern: We, the undersigned, hereby authorizeKevin Tsai / Deputy Manager of SGS Compliance Certification Services Inc.to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Sercomm Corporation. This authorization is valid until further written notice from the applicant. Nick Wu / Manager Sercomm Corporation Phone: 886-2-2655-3988 ext. 2556 E-Mail: [email protected]

To:SGSNorthAmericaInc. 620OldPeachtreeRoad SUITE100 Suwanee,Georgia UnitedStates From:SercommCorporation 8F,No.3-1,YuanQuSt.NanKang, TaipeiCity Taiwan Regarding:ConfidentialityRequestregardingapplicationforFCCID:P27MDC845 LONGTERMCONFIDENTIALITY Pursuantto47CFRSection0.459and0.457ofthecommission’srules,theapplicantherebyrequest confidentialtreatmentofthedocumentslistedbelow,associatedwiththecertificationapplication referencedabove. Schematic(s) BlockDiagrams OperationalDescriptions Thedocumentsabovecontainproprietaryinformationnotreleasedtothepublic.Publicdisclosureofthis informationmayproveharmfultothebusinessoftheapplicant. Sincerely, NickWu/Manager SercommCorporation Phone:886-2-2655-3988ext.2556 E-Mail:[email protected]

Page: 1 / 14 Report No.: T191003D02 Rev.: 01 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Page: 2 / 14 Report No.: T191003D02 Rev.: 01 Page: 3 / 14 Report No.: T191003D02 Rev.: 01 Page: 4 / 14 Report No.: T191003D02 Rev.: 01 Page: 5 / 14 Report No.: T191003D02 Rev.: 01 Adapter APD / WB-18D12FU

Page: 6 / 14 Report No.: T191003D02 Rev.: 01 INTERNAL PHOTOGRAPHS OF EUT Page: 7 / 14 Report No.: T191003D02 Rev.: 01 Camera Page: 8 / 14 Report No.: T191003D02 Rev.: 01 Page: 9 / 14 Report No.: T191003D02 Rev.: 01 Page: 10 / 14 Report No.: T191003D02 Rev.: 01 Camera PCB Page: 11 / 14 Report No.: T191003D02 Rev.: 01 Page: 12 / 14 Report No.: T191003D02 Rev.: 01 Page: 13 / 14 Report No.: T191003D02 Rev.: 01 Antenna Page: 14 / 14 Report No.: T191003D02 Rev.: 01 Module Crystal

FCC ID: P27MDC845 Page 1 / 9 Report No.: T191003D02-MF Rev.: 01 No.11, Wugong 6th Rd., Wugu Dist., New Taipei City 24891, Taiwan / 新北市五股區五工六路11號 t:(886-2) 2299-9720 f:(886-2) 2298-1882 www.sgs.tw www.ccsrf.com IEEE C95.1 2005 KDB 447498 D03 47 C.F.R. Part 1, Subpart I, Section 1.1310 47 C.F.R. Part 2, Subpart J, Section 2.1091 RF EXPOSURE REPORT For FHD WiFi Mini Dome Camera Model: MDC845xxxxxxxx (the 1st x should be "blank" or "-"; the rest x could be 0 to 9, A to Z, a to z, "blank" or "-" , for marketing purpose) Trade Name: ADT Issued to Sercomm Corporation 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan Issued by Compliance Certification Services Inc. Wugu Laboratory No.11, Wugong 6th Rd., Wugu Dist., New Taipei City 24891, Taiwan. (R.O.C.) Issue Date: December 30, 2019 Note: This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NIST or any government agencies. The test results in the report only apply to the tested sample. Page 2 / 9 Report No.: T191003D02-MF Rev.: 01 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 December 30, 2019 Initial Issue ALL Doris Chu Page 3 / 9 Report No.: T191003D02-MF Rev.: 01 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION ........................................................................ 4 2. LIMIT .................................................................................................................... 5 3. EUT SPECIFICATION .......................................................................................... 6 4. TEST RESULTS................................................................................................... 8 5. MAXIMUM PERMISSIBLE EXPOSURE .............................................................. 9 Page 4 / 9 Report No.: T191003D02-MF Rev.: 01 1. TEST RESULT CERTIFICATION We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10: 2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247. The test results of this report relate only to the tested sample EUT identified in this report. APPLICABLE STANDARDS STANDARD TEST RESULT IEEE C95.1 2005 KDB 447498 D03 47 C.F.R. Part 1, Subpart I, Section 1.1310 47 C.F.R. Part 2, Subpart J, Section 2.1091 No non-compliance noted Statements of Conformity Determination of compliance is based on the results of the compliance measurement, not taking into account measurement instrumentation uncertainty. Approved by: Reporter: Kevin Tsai Doris Chu Deputy Manager Report coordinator Compliance Certification Services Inc. Compliance Certification Services Inc. Page 5 / 9 Report No.: T191003D02-MF Rev.: 01 2. LIMIT According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter. Page 6 / 9 Report No.: T191003D02-MF Rev.: 01 3. EUT SPECIFICATION EUT FHD WiFi Mini Dome Camera Model MDC845xxxxxxxx (the 1st x should be "blank" or "-"; the rest x could be 0 to 9, A to Z, a to z, "blank" or "-" , for marketing purpose) Model Discrepancy All the above models are identical except for the designation of model numbers. The suffix of (The 1st x should be "blank" or "-"; the rest x could be 0 to 9, A to Z, a to z, "blank" or "-") on model number is just for marketing purpose only. Frequency band (Operating) Bluetooth: 2402MHz-2480MHz 802.11b/g/n HT20: 2412MHz ~ 2462 MHz 802.11n HT40: 2422MHz ~ 2452MHz 802.11a/n HT20: 5180MHz ~ 5240MHz / 5745MHz ~ 5825MHz 802.11n HT40: 5190MHz ~ 5230MHz / 5755MHz ~ 5795MHz 802.11ac VHT80: 5210MHz / 5775MHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna Specification 2.4G Ant No. Type Peak Gain Ant 1 Dipole 4.7 dBi Ant 2 Dipole 1.9 dBi 1. Power Directional Gain: 3.52 5G Ant No. Type Peak Gain Ant 1 Dipole 4.3 dBi Ant 2 Dipole 3.8 dBi 1. Power Directional Gain: 4.06 2.4GHz: Directional Gain :3.52 dBi (Numeric gain:2.25) Worst 5GHz: Directional Gain : 4.06 dBi (Numeric gain:2.55)Worst Page 7 / 9 Report No.: T191003D02-MF Rev.: 01 Maximum Measurement Average Power 2.4GHz IEEE 802.11b Mode: 27.03 dBm (504.661 mW) IEEE 802.11g Mode: 24.69 dBm (294.442 mW) IEEE 802.11n HT 20 Mode: 22.34 dBm (171.396 mW) IEEE 802.11n HT 40 Mode: 22.41 dBm (174.181 mW) 5GHz IEEE 802.11a Mode: 22.74 dBm (187.932 mW) IEEE 802.11n HT 20 Mode: 27.03 dBm(504.661 mW) IEEE 802.11n HT 40 Mode: 27.21 dBm(526.017 mW) IEEE 802.11ac VHT 80 Mode: 24.02 dBm (252.348 mW) Maximum tune up power 2.4GHz IEEE 802.11b Mode: 28.80 dBm(758.578 mW) IEEE 802.11g Mode: 26.30 dBm (426.580 mW) IEEE 802.11n HT 20 Mode: 24.20 dBm (263.027 mW) IEEE 802.11n HT 40 Mode: 24.20 dBm (263.027 mW) 5GHz IEEE 802.11a Mode: 24.60 dBm (288.403 mW) IEEE 802.11n HT 20 Mode: 28.60 dBm (724.436 mW) IEEE 802.11n HT 40 Mode: 29.00 dBm(794.328 mW) IEEE 802.11ac VHT 80 Mode: 26.00 dBm (398.107 mW) Evaluation applied MPE Evaluation* SAR Evaluation N/A Page 8 / 9 Report No.: T191003D02-MF Rev.: 01 4. TEST RESULTS No non-compliance noted. Calculation Given d GP E × × = 30 & 377 2 E S= Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 377 30 d G P S …

Text truncated - open the document above for the full version.

FCC ID: P27MDC845 Page: 1 / 131 Report No.: T191003D02-RP2 Rev.: 01 No.11, Wugong 6th Rd., Wugu Dist., New Taipei City 24891, Taiwan / 新北市五股區五工六路11號 t:(886-2) 2299-9720 f:(886-2) 2298-1882 www.sgs.tw www.ccsrf.com FCC RADIO TEST REPORT FCC 47 CFR PART 15 SUBPART E Test Standard FCC Part 15.407 Brand name ADT Product name FHD WiFi Mini Dome Camera Model No. MDC845xxxxxxxx (the 1st x should be "blank" or "-"; the rest x could be 0 to 9, A to Z, a to z, "blank" or "-" , for marketing purpose) Test Result Pass Statements of Conformity Determination of compliance is based on the results of the compliance measurement, not taking into account measurement instrumentation uncertainty. The test Result was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were given in ANSI C63.10: 2013 and compliance standards. The test results of this report relate only to the tested sample (EUT) identified in this report. The test Report of full or partial shall not copy. Without written approval of Compliance Certification Services Inc. (Wugu Laboratory) Approved by: Kevin Tsai Deputy Manager Page: 2 / 131 Report No.: T191003D02-RP2 Rev.: 01 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 December 30, 2019 Initial Issue ALL Doris Chu 01 January 21, 2020 1. Modify Test Procedure in section 4.2.2. 2. Modify 5180MHz 99% test result. 3. Modify test result in section 4.6.4. P.17-18, P.19, P130-131 Doris Chu Page: 3 / 131 Report No.: T191003D02-RP2 Rev.: 01 Table of contents 1. GENERAL INFORMATION ..................................................................................................... 4 1.1 EUT INFORMATION ............................................................................................................... 4 1.2 EUT CHANNEL INFORMATION ............................................................................................ 5 1.3 ANTENNA INFORMATION ..................................................................................................... 6 1.4 MEASUREMENT UNCERTAINTY .......................................................................................... 6 1.5 FACILITIES AND TEST LOCATION ...................................................................................... 7 1.6 INSTRUMENT CALIBRATION ............................................................................................... 8 1.7 SUPPORT AND EUT ACCESSORIES EQUIPMENT ............................................................. 9 1.8 TEST METHODOLOGY AND APPLIED STANDARDS ......................................................... 9 2. TEST SUMMERY .................................................................................................................. 10 3. DESCRIPTION OF TEST MODES ........................................................................................ 11 3.1 THE WORST MODE OF OPERATING CONDITION ............................................................ 11 3.2 THE WORST MODE OF MEASUREMENT .......................................................................... 12 3.3 EUT DUTY CYCLE ............................................................................................................... 13 4. TEST RESULT ...................................................................................................................... 14 4.1 AC POWER LINE CONDUCTED EMISSION ....................................................................... 14 4.2 26dB BANDWIDTH, 6DB BANDWIDTH AND OCCUPIED BANDWIDTH (99%) ................ 17 4.3 OUTPUT POWER MEASUREMENT .................................................................................... 41 4.4 POWER SPECTRAL DENSITY ............................................................................................ 45 4.5 RADIATION BANDEDGE AND SPURIOUS EMISSION ...................................................... 59 4.6 FREQUENCY STABILITY .................................................................................................. 129 APPENDIX 1 - PHOTOGRAPHS OF EUT Page: 4 / 131 Report No.: T191003D02-RP2 Rev.: 01 1. GENERAL INFORMATION 1.1 EUT INFORMATION Applicant Sercomm Corporation 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan Manufacturer Sercomm Corporation 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan Equipment FHD WiFi Mini Dome Camera Model Name MDC845xxxxxxxx (the 1st x should be "blank" or "-"; the rest x could be 0 to 9, A to Z, a to z, "blank" or "-" , for marketing purpose) Model Discrepancy All the above models are identical except for the designation of model numbers. The suffix of (The 1st x should be "blank" or "-"; t he rest x could be 0 to 9, A to Z, a to z, "blank" or "-") on model number is just for marketing purpose only. Trade Name ADT Received Date October 03, 2019 Date of Test October 14 ~ November 14, 2019 Power Supply VDC from Power Adapter APD / WB-18D12FU I/P: 100-240V~, 50-60Hz, 0.5A Max O/P: 12VDC, 1.5A Output Power(W) Band Mode Frequency Range (MHz) Output Power (W) U-NII-1 IEEE 802.11a 5180 ~ 5240 0.0630 IEEE 802.11n HT 20 MHz 5180 ~ 5240 0.0880 IEEE 802.11n HT 40 MHz 5190 ~ 5230 0.0939 IEEE 802.11ac VHT 80 MHz 5210 0.0982 U-NII-3 IEEE 802.11a 5745 ~ 5825 0.1879 IEEE 802.11n HT 20 MHz 5745 ~ 5825 0.5047 IEEE 802.11n HT 40 MHz 5755 ~ 5795 0.5260 IEEE 802.11ac VHT 80 MHz 5775 0.2524 Page: 5 / 131 Report No.: T191003D02-RP2 Rev.: 01 1.2 EUT CHANNEL INFORMATION Frequency Range UNII-1 IEEE 802.11a 5180 ~ 5240 MHz IEEE 802.11n HT 20 MHz 5180 ~ 5240 MHz IEEE 802.11n HT 40 MHz 5190 ~ 5230 MHz IEEE 802.11ac VHT 20 MHz 5180 ~ 5240 MHz IEEE 802.11ac VHT 40 MHz 5190 ~ 5230 MHz IEEE 802.11ac VHT 80 MHz 5210 MHz UNII-3 IEEE 802.11a 5745 ~ 5825 MHz IEEE 802.11n HT 20 MHz 5745 ~ 5825 MHz IEEE 802.11n HT 40 MHz 5755 ~ 5795 MHz IEEE 802.11ac VHT 20 MHz 5745 ~ 5825 MHz IEEE 802.11ac VHT 40 MHz 5755 ~ 5795 MHz IEEE 802.11ac VHT 80 MHz 5775 MHz Modulation Type 1. IEEE 802.11a mode: O…

Text truncated - open the document above for the full version.

Page: 41 / 131 Report No.: T191003D02-RP2 Rev.: 01 4.3 OUTPUT POWER MEASUREMENT 4.3.1 Test Limit According to §15.407 (a)(1) UNII-1 : For client devices in the 5.15-5.25 GHz band, the maximum conducted output power over the frequency band of operation shall not exceed 250 mW provided the maximum antenna gain does not exceed 6 dBi. In addition, the maximum power spectral density shall not exceed 11 dBm in any 1 megahertz band. If transmitting antennas of directional gain greater than 6 dBi are used, both the maximum conducted output power and the maximum power spectral density shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6 dBi. UNII-3: For the band 5.725-5.85 GHz, the maximum conducted output power over the frequency band of operation shall not exceed 1 W. In addition, the maximum power spectral density shall not exceed 30 dBm in any 500-kHz band. If transmitting antennas of directional gain greater than 6 dBi are used, both the maximum conducted output power and the maximum power spectral density shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6 dBi. UNII-1 Limit Antenna not exceed 6 dBi：24dBm Antenna with DG greater than 6 dBi： [Limit = 24 – (DG – 6)] UNII-3 Limit Antenna not exceed 6 dBi：30dBm Antenna with DG greater than 6 dBi： [Limit = 24 – (DG – 6)] Page: 42 / 131 Report No.: T191003D02-RP2 Rev.: 01 4.3.2 Test Procedure Test method Refer as KDB 789033 D02. 1. The EUT RF output connected to the power meter by RF cable. 2. Setting maximum power transmit of EUT. 3. The path loss was compensated to the results for each measurement. 4. Measure and record the result of Average output power. in the test report. 4.3.3 Test Setup Page: 43 / 131 Report No.: T191003D02-RP2 Rev.: 01 4.3.4 Test Result Conducted output power： chain0chain1chain0chain1 3651800-16.87-16.870.0486 4452200-17.71-17.710.0590 4852400-17.99-17.990.0630 3651800014.3617.3419.110.0815 4452200015.2317.3419.420.0875 4852400015.4417.2419.440.0880 3851900015.3217.3919.490.0889 4652300014.9317.9819.730.0939 IEEE 802.11ac VHT80 Data rate: MCS8 4252100016.7617.0619.920.0982 24 AV Power(dBm) AV Total Power (dBm) Power Set UNII-1 IEEE 802.11a Data rate: 6Mbps IEEE 802.11n HT20 Data rate: MCS 0 IEEE 802.11n HT40 Data rate: MCS 0 Limit (dBm) AV Total Power (W) ConfigCH Freq. (MHz) Page: 44 / 131 Report No.: T191003D02-RP2 Rev.: 01 chain0chain1chain0chain1 149574520-22.74-22.740.1879 157578520-22.68-22.680.1854 165582520-22.61-22.610.1824 1495745202021.9923.6325.890.3882 1575785202022.9324.8927.030.5047 1655825202022.9424.8627.010.5023 1515755202023.1924.8727.130.5164 1595795202023.2524.9727.210.5260 1555775202021.0620.9624.020.2524 IEEE 802.11n HT20 Data rate: MCS0 IEEE 802.11n HT40 Data rate: MCS0 30 IEEE 802.11ac VHT80 Data rate: MCS8 IEEE 802.11a Data rate: 6Mbps UNII-3 ConfigCH Freq. (MHz) AV Power(dBm) AV Total Power (dBm) AV Total Power (W) Limit (dBm) Power Set G Page: 45 / 131 Report No.: T191003D02-RP2 Rev.: 01 4.4 POWER SPECTRAL DENSITY 4.4.1 Test Limit According to §15.407 (a)(1) UNII-1 : FCC: The maximum power spectral density shall not exceed 11 dBm in any 1 megahertz band. UNII-3: For the band 5.725-5.85 GHz, the maximum conducted output power over the frequency band of operation shall not exceed 1 W. In addition, the maximum power spectral density shall not exceed 30 dBm in any 500-kHz band. If transmitting antennas of directional gain greater than 6 dBi are used, both the maximum conducted output power and the maximum power spectral density shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6 dBi.i. UNII-1 Limit Antenna not exceed 6 dBi：11 dBm Antenna with DG greater than 6 dBi： [Limit = 11 – (DG – 6)] UNII-3 Limit Antenna not exceed 6 dBi：30 dBm Antenna with DG greater than 6 dBi： [Limit = 30 – (DG – 6)] Page: 46 / 131 Report No.: T191003D02-RP2 Rev.: 01 4.4.2 Test Procedure Test method Refer as KDB 789033 D02 1. The EUT RF output connected to the spectrum analyzer by RF cable. 2. Setting maximum power transmit of EUT 3. UNII-1, UNII-2a and UNII-2c, SA set RBW = 1MHz, VBW = 3MHz and Detector = RMS, to measurement Power Density. 4. UNII-3, SA set RBW = 500kHz, VBW = 2MHz and Detector = RMS, to measurement Power Density 5. The path loss and Duty Factor were compensated to the results for each measurement by SA. 6. Mark the maximum level. 7. Measure and record the result of power spectral density. in the test report. 4.4.3 Test Setup Page: 47 / 131 Report No.: T191003D02-RP2 Rev.: 01 4.4.4 Test Result UNII-1 Test mode: IEEE 802.11a mode Channel Frequency (MHz) chain 0 PPSD (dBm) chain 1 PPSD (dBm) Total PPSD (dBm) Limit (dBm) Low 5180 3.425 - 3.425 11 Mid 5220 3.742 - 3.742 High 5240 4.053 - 4.053 Test mode: IEEE 802.11n HT20 mode Channel Frequency (MHz) chain 0 PPSD (dBm) chain 1 PPSD (dBm) Total PPSD (dBm) Limit (dBm) Low 5180 2.472 2.479 5.49 11 Mid 5220 2.684 2.643 5.67 High 5240 2.780 2.330 5.57 Test mode: IEEE 802.11n HT40 mode Channel Frequency (MHz) chain 0 PPSD (dBm) chain 1 PPSD (dBm) Total PPSD (dBm) Limit (dBm) Low 5190 -0.975 -0.209 2.44 11 High 5230 -0.775 -0.369 2.44 Test mode: IEEE 802.11ac VHT80 mode Channel Frequency (MHz) chain 0 PPSD (dBm) chain 1 PPSD (dBm) Total PPSD (dBm) Limit (dBm) Mid 5210 -5.814 -2.101 -0.56 11 Page: 48 / 131 Report No.: T191003D02-RP2 Rev.: 01 UNII-3 Test mode: IEEE 802.11a mode Channel Frequency (MHz) chain 0 PPSD (dBm) chain 1 PPSD (dBm) Total PPSD (dBm) Limit (dBm) Low 5745 2.754 - 2.754 30 Mid 5785 3.142 - 3.142 High 5825 3.029 - 3.029 Test mode: IEEE 802.11n HT20 mode Channel Frequency (MHz) chain 0 PPSD (dBm) chain 1 PPSD (dBm) Total PPSD (dBm) Limit (dBm) Low 5745 0.775 1.676 4.26 30 Mid 5785 1.230 1.463 4.36 High 5825 1.351 1.887 4.64 Test mode: IEEE 802.11n HT40 mode Channel Frequency (MHz) chain 0 PPSD (dBm) chain 1 PPSD (dBm) Total PPSD (dBm) Limit (dBm) Low 5755 -2.626 -1.130 1.20 30 High 5795 -2.371 -0.845 1.47 Test mode: IEEE 802.11ac VHT80 mode Channe…
