Compliance Certification Services Inc. Report No.: T100603205-RP1 FCC ID: P27OC810 Date of Issue: July 21, 2010 Page 76 Rev. 00 APPENDIX I RADIO FREQUENCY EXPOSURE LIMIT According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter. EUT Specification EUT Wireless Outdoor camera Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5.825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power IEEE 802.11b mode: 14.41 dBm (27.60 mW) IEEE 802.11g mode: 22.02dBm (159.22 mW) draft 802.11n Standard-20 MHz Channel mode: 21.74 dBm (149.27 mW) draft 802.11n Wide-40 MHz Channel mode: 21.55 dBm (142.88 mW) Antenna gain (Max) 5.4 dBi (Numeric gain: 3.46) Evaluation applied MPE Evaluation* SAR Evaluation N/A Remark: 1. The maximum output power is 22.02dBm (149.27 mW) at 2412MHz (with 3.46 numeric antenna gain.) 2. DTS device is not subject to routine RF evaluation; MPE estimate is used to justify the compliance. 3. For mobile or fixed location transmitters, no SAR consideration applied. The maximum power density is 1.0 mW/cm2 even if the calculation indicates that the power density would be larger. TEST RESULTS No non-compliance noted. MPE EVALUATION No non-compliance noted. Compliance Certification Services Inc. Report No.: T100603205-RP1 FCC ID: P27OC810 Date of Issue: July 21, 2010 Page 77 Rev. 00 Calculation Given d GP E ×× = 30 & 3770 2 E S= Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 3770 30 d GP S ×× = Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields () () 2 2 0796.0 100/3770 1000/30 d GP d GP S × ×= × ×× = Equation 1 Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Maximum Permissible Exposure Substituting the MPE safe distance using d = 20 cm into Equation 1: Yields GPS××=000199.0 Where P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Compliance Certification Services Inc. Report No.: T100603205-RP1 FCC ID: P27OC810 Date of Issue: July 21, 2010 Page 78 Rev. 00 IEEE 802.11b mode: EUT output power = 27.60 mW Numeric Antenna gain = 3.46 Æ Power density = 0.0190 mW / cm 2 IEEE 802.11g mode: EUT output power = 159.22 mW Numeric Antenna gain = 3.46 Æ Power density = 0.1096 mW / cm2 draft 802.11n Standard-20 MHz Channel mode: EUT output power = 149.27 mW Numeric Antenna gain = 3.46 Æ Power density = 0.1027 mW / cm2 draft 802.11n Wide-40 MHz Channel mode: EUT output power = 142.88 mW Numeric Antenna gain = 3.46 Æ Power density = 0.0983 mW / cm2 (For mobile or fixed location transmitters, the maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger.)
