P27PC801ANIEEE802.11n Draft Wireless card

IEEE802.11n Draft Wireless PC card User Guide i Table of Contents CHAPTER 1 INTRODUCTION ............................................................................................. 1 Package Contents .............................................................................................................. 1 LEDs ................................................................................................................................... 1 Operation ........................................................................................................................... 1 CHAPTER 2 INITIAL INSTALLATION .............................................................................. 2 Requirements ..................................................................................................................... 2 Procedure ........................................................................................................................... 2 CHAPTER 3 USING THE WINDOWS UTILITY ................................................................ 5 Overview ............................................................................................................................ 5 System Tray Icon...............................................................................................................5 Auto Connect ..................................................................................................................... 6 Site Survey Screen .............................................................................................................6 Profile Manager Screen .................................................................................................... 8 Network Status Screen .................................................................................................... 12 About Screen....................................................................................................................13 APPENDIX A SPECIFICATIONS ....................................................................................... 14 Wireless Adapter ............................................................................................................. 14 APPENDIX B ABOUT WIRELESS LANS .......................................................................... 15 Modes ............................................................................................................................... 15 BSS/ESS............................................................................................................................ 15 Channels ........................................................................................................................... 16 WEP & WPA-PSK .......................................................................................................... 16 Wireless LAN Configuration.......................................................................................... 16 P/N: 956YDM0001 Copyright © 2007. All Rights Reserved. Document Version: 1.0 (January, 2007) All trademarks and trade names are the properties of their respective owners. 1 Chapter 1 Introduction This Chapter provides an overview of the Wireless Adapter's features and capabilities. Congratulations on the purchase of your new Wireless Adapter. The Wireless Adapter provides a wireless network interface for your Notebook. Package Contents The following items should be included: • The Wireless Adapter Unit • 2 Antenna • Quick Start Guide • CD-ROM containing the on-line manual. If any of the above items are damaged or missing, please contact your dealer immediately. LEDs Wireless Adapter The Wireless Adapter has a single Link/Activity LED. Link/Act LED • On - Associated with the network. • Off - Not associated with the network. • Blinking - Data being transferred. Operation You should install the supplied software on the CD-ROM before inserting the Wireless adapter. 1 2 Chapter 2 Initial Installation This Chapter covers the software installation of the Wireless Adapter. Requirements • Windows 2000/XP. • CD-ROM drive. • IEEE802.11n, IEEE802.11b or IEEE802.11g wireless LAN. Procedure You should install the supplied software BEFORE inserting the Wireless Adapter. 1. Insert the CD-ROM into the drive on your PC. 2. The installation program should start automatically. If it does not, run the SETUP.EXE program. 3. Select the desired installation language on the screen. Figure 1: Start Installation 4. On the screen above, click "Next" to start the installation. 5. Step though the procedure. 6. After the installation is complete, select Yes, I want to shutdown my computer now and then click "Finish". 2 Initial Installation 3 Figure 2: Installation Screen 7. Insert the Card into your computer. • Remove the cover on one side of the computer. • Find an empty PCI expansion slot inside the computer. • Press the Card firmly into the slot. • Connect the supplied antenna cable to the port on the Card. • Replace the computer’s cover and power it on. 8. The Windows "New Hardware" wizard will then start. • Select Install the software automatically to allow it to complete the installation of the Windows driver • If using Windows XP, you may see a warning screen like the example below. If you do see this screen, just click "Continue Anyway" Figure 3: Windows XP Warning 9. When the Windows wizard is complete, you will now have a new icon in your system tray, as shown below. Figure 4: System Tray Icon Wireless Adapter User Guide 4 Wireless Adapter Icon Table Connection to the Wireless Adapter is established. The length of green color indicates the signal strength. No connection to the Wireless Adapter. The Wireless Adapter is unplugged. 10. You can double- click this icon to configure the Wireless interface. See the following chapter for details. 5 Chapter 3 Using the Windows Utility This Chapter provides Setup details for the AP mode of the Wireless Adapter. Overview If using Wind…

Text truncated - open the document above for the full version.

Request for non-disclosure RF_501_02 SerComm Corporation 8F, No.3-1, YuanQu St., NanKang Taipei Taiwan, R.O.C. To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for non-disclosure (FCC ID:P27PC801AN) Reference number: PC801An; WNC-0600 Date: 2008/01/17 Dear FCC TCB, Persuant to 47 CFR Section 0.459(a) & (b), SerComm Corporation hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application for FCC ID: ( P27PC801AN) a. Schematic diagrams b. Operational description c. Block Diagram Above materials contain secrets, proprietary and technical information, which would customarily be quarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. SerComm Corporation understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Ronnie Cheng/ Associate Manager/ R&D Division Signature:

RF_160, Issue 02 Declaration of Authorization We Name: SerComm Corporation Address: 8F, No.3-1, YuanQu St., NanKang, City: Taipei Country: Taiwan, R.O.C. Declare that: Name Representative of agent: Delia Feng. (1) Agent Company name: Exclusive Certification Corporation Address: 4F-2, No.28 Lang 78, Xing-Ai Rd. City: Nei-hu Taipei City 114 Country Taiwan, R.O.C. is authorized to apply for Certification of the following product(s): Product description: IEEE802.11n Draft Wireless PC Card Type designation: PC801An; WNC-0600 Trademark: SerComm on our behalf. Date: 2008/01/17 City: Taipei Name: Ronnie Cheng (2) Function: Associate Manager/ R&D Division Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 1 of 4 FCC Test Report: FI07120302-A Appendix A. Photographs of EUT 07120302-A 07120302-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 2 of 4 FCC Test Report: FI07120302-A 07120302-A 07120302-A

Label & Location 料 號 Top label/PC801An/中性 932YH80001 Notes: 1.材質:50#白色特多龍,上霧P,背膠 2.尺寸/印刷:如圖示 4.尺寸公差:+0.2mm Wireless PCI Adaptor PC812RN V.3 PC801An FCCID:P27PC801AN 46.5 mm 50.0 mm 0.5

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 3 of 4 FCC Test Report: FI07120302-A 07120302-A 07120302-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 4 of 4 FCC Test Report: FI07120302-A 07120302-A

1.1. Test Result of RF Exposure Evaluation . Product: IEEE802.11n Draft Wireless PC Card . Test Item: RF Exposure Evaluation Data . Test site: OATSI-SD . Test Mode: Normal Operation 1.1.1. Antenna Gain The maximum Gain is 2.0 dBi. 1.1.2. EUT Operation condition Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 1.1.3. Output Power into Antenna & RF Exposure Evaluation Distance (1) Modulation Standard: IEEE 802.11b(11Mbps) Test Date: Dec. 18, 2007 Temperature: 22 Humidity: 60 Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density (S) (mW/cm 2 ) 01 2412 18.23 0.021 06 2437 18.09 0.020 11 2462 17.93 0.020 (2) Modulation Standard: IEEE 802.11g(24Mbps) Test Date: Jan. 04, 2008 Temperature: 22 Humidity: 60 Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density (S) (mW/cm 2 ) 01 2412 15.10 0.010 06 2437 15.45 0.011 11 2462 15.01 0.010 (3) Modulation Standard: IEEE 802.11 Draft n, 20MHz(6.5Mbps) Test Date: Dec. 18, 2007 Temperature: 22 Humidity: 60 Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density (S) (mW/cm 2 ) 01 2412 11.20 0.004 06 2437 11.01 0.004 11 2462 11.03 0.004 (4) Modulation Standard: IEEE 802.11 Draft n, 40MHz(13.5Mbps) Test Date: Dec. 18, 2007 Temperature: 22 Humidity: 60 Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density (S) (mW/cm 2 ) 03 2422 10.93 0.004 06 2437 10.89 0.004 09 2452 11.11 0.004 The MPE is calculated as 0.021 mW / cm 2 < limit 1 mW / cm 2 . So, RF exposure limit warning or SAR test are not required. For 2412-2462 MHz, the EUT will only be used with a separation of 20cm or greater between the antenna and nearby persons and can therefore be considered a mobile transmitter per 47CFR2.1091 (b). The RF Exposure Information page from the manual is included here for reference.

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 1 of 106 FCC Test Report: FI07120302-A FCC TEST REPORT according to FCC Rules and Regulations Part 15 Subpart C Applicant : SerComm Corporation Address : 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Equipment : IEEE802.11n Draft Wireless PC card Model No. : PC801An Series No. : WNC-0600 FCC ID : P27PC801AN Trade Name : SerComm Laboratory Accreditation ‚ The test result refers exclusively to the test presented test model / sample., ‚ Without written approval of Exclusive Certification Corp. the test report shall not be reproduced except in full. ‚ The EUT is also considered as a kind of computer peripheral, because the connection to computer is necessary for typical use. It has been verified to comply with the requirements of FCC Part 15, Subpart B, Class B (DoC). The test report has been issued separately. Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 2 of 106 FCC Test Report: FI07120302-A Contents 1. Report of Measurements and Examinations .................................................................................... 5 1.1 List of Measurements and Examinations ................................................................................... 5 2. Test Configuration of Equipment under Test ................................................................................... 6 2.1 Feature of Equipment under Test............................................................................................... 6 2.2 Test Mode & Test Software ........................................................................................................ 7 2.3 Description of Test System......................................................................................................... 7 2.4 Connection Diagram of Test System.......................................................................................... 8 2.5 General Information of Test........................................................................................................ 9 2.6 Description of Series No. ........................................................................................................... 9 2.7 Measurement Uncertainty .......................................................................................................... 9 2.8 History of this test report ..........................................................................................................10 3. Antenna Requirements..................................................................................................................... 11 3.1 Standard Applicable ................................................................................................................. 11 3.2 Antenna Construction and Directional Gain............................................................................. 11 4. Test of Conducted Emission............................................................................................................12 4.1 Test Limit.................................................................................................................................. 12 4.2 Test Procedures.......................................................................................................................12 4.3 Typical Test Setup ...................................................................................................................13 4.4 Measurement equipment ......................................................................................................... 13 4.5 Test Result and Data................................................................................................................14 4.6 Test Photographs .....................................................................................................................20 5. Test of Radiated Emission ...............................................................................................................21 5.1 Test Limit.................................................................................................................................. 21 5.2 Test Procedures.......................................................................................................................22 5.3 Typical Test Setup ....................................................................................................................23 5.4 Measurement equipment ......................................................................................................... 23 5.5 Test Result and Data................................................................................................................24 5.6 Test Photographs .....................................................................................................................60 6. 6dB Bandwidth Measurement Data .................................................................................................61 6.1 Test Limit .................................................................................................................................. 61 6.2 Test Procedures .......................................................................................................................61 6.3 Test Setup Layout ....................................................................................................................61 6.4 Measurement equipment ......................................................................................................... 61 6.5 Test Result and Data................................................................................................................61 7. Maximum Peak Output Power .........................................................................................................71 7.1 Test Limit ...............................................................…

Text truncated - open the document above for the full version.

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 83 of 106 FCC Test Report: FI07120302-A Modulation Standard: 802.11b (11Mbps) Channel: 11 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 84 of 106 FCC Test Report: FI07120302-A Modulation Standard: 802.11g (6Mbps) Channel: 01 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 85 of 106 FCC Test Report: FI07120302-A Modulation Standard: 802.11g (6Mbps) Channel: 11 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 86 of 106 FCC Test Report: FI07120302-A Modulation Standard: 802.11Draft n, 20MHz (6.5Mbps) –TX0 Channel: 01 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 87 of 106 FCC Test Report: FI07120302-A Modulation Standard: 802.11Draft n, 20MHz (6.5Mbps) –TX0 Channel: 11 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 88 of 106 FCC Test Report: FI07120302-A Modulation Standard: 802.11Draft n, 20MHz (6.5Mbps) –TX1 Channel: 01 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 89 of 106 FCC Test Report: FI07120302-A Modulation Standard: 802.11Draft n, 20MHz (6.5Mbps) –TX1 Channel: 11 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 90 of 106 FCC Test Report: FI07120302-A Modulation Standard: 802.11Draft n, 40MHz (13.5Mbps) –TX0 Channel: 03 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 91 of 106 FCC Test Report: FI07120302-A Modulation Standard: 802.11Draft n, 40MHz (13.5Mbps) –TX0 Channel: 09 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 92 of 106 FCC Test Report: FI07120302-A Modulation Standard: 802.11Draft n, 40MHz (13.5Mbps) –TX1 Channel: 03 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 93 of 106 FCC Test Report: FI07120302-A Modulation Standard: 802.11Draft n, 40MHz (13.5Mbps) –TX1 Channel: 09 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 94 of 106 FCC Test Report: FI07120302-A 8.6 Restrict band emission Measurement Data Modulation Standard: IEEE 802.11b (11Mbps) Test Date: Dec. 27, 2007 Temperature: 22 Humidity: 65% Atmospheric pressure: 1030 hPa a) Channel 1 Limit@3m (dBuV/m) Frequency (MHz) Ant-Pol H/V Meter Reading Corrected Factor Result (dBuV/m) Remark Peak Ave. Margin (dB) Table (Deg.) Ant High (m) 2370.38 H 51.66 -3.17 48.50 Peak 74 54 -25.50 220 1.2 2370.08 H 40.18 -3.17 37.01 Ave 74 54 -16.99 220 1.2 2368.85 V 65.25 -3.17 62.08 Peak 74 54 -11.92 198 1.0 2370.08 V 54.04 -3.17 50.87 Ave 74 54 -3.13 198 1.0 b) Channel 11 Limit@3m (dBuV/m) Frequency (MHz) Ant-Pol H/V Meter Reading Corrected Factor Result (dBuV/m) Remark Peak Ave. Margin (dB) Table (Deg.) Ant High (m) 2485.64 H 49.44 -2.75 46.69 Peak 74 54 -27.31 220 1.2 2497.42 H 38.01 -2.71 35.30 Ave 74 54 -18.70 220 1.2 2499.89 V 55.83 -2.70 53.13 Peak 74 54 -20.87 198 1.0 2500.00 V 44.63 -2.70 41.93 Ave 74 54 -12.07 198 1.0 Modulation Standard: 802.11g (6Mbps) Test Date: Dec. 27, 2007 Temperature: 22 Humidity: 65% Atmospheric pressure: 1030 hPa a) Channel 1 Limit@3m (dBuV/m) Frequency (MHz) Ant-Pol H/V Meter Reading Corrected Factor Result (dBuV/m) Remark Peak Ave. Margin (dB) Table (Deg.) Ant High (m) 2370.89 H 52.27 -3.16 49.11 Peak 74 54 -24.89 220 1.2 2367.33 H 39.86 -3.18 36.68 Ave 74 54 -17.32 220 1.2 2389.76 V 65.70 -3.10 62.60 Peak 74 54 -11.40 198 1.0 2389.97 V 53.76 -3.10 50.67 Ave 74 54 -3.33 198 1.0 b) Channel 11 Limit@3m (dBuV/m) Frequency (MHz) Ant-Pol H/V Meter Reading Corrected Factor Result (dBuV/m) Remark Peak Ave. Margin (dB) Table (Deg.) Ant High (m) 2499.39 H 49.78 -2.70 47.08 Peak 74 54 -26.92 220 1.2 2497.11 H 37.99 -2.71 35.28 Ave 74 54 -18.72 220 1.2 2499.39 V 60.19 -2.70 57.49 Peak 74 54 -16.51 198 1.0 2500.00 V 48.70 -2.70 46.00 Ave 74 54 -8.00 198 1.0 Notes: 1. Result = Meter Reading + Factor 2. Factor = Antenna Factor + Cable Loss – Amplifier 3. The resolution bandwidth of test receiver/spectrum analyzer is 1 MHz and video bandwidth is 3 MHz for Peak detection at frequency above 1GHz. 4. The resolution bandwidth of test receiver/spectrum analyzer is 1MHz and video bandwidth is 10Hz for Average detection at frequency above 1GHz Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 95 of 106 FCC Test Report: FI07120302-A Modulation Standard: IEEE 802.11Draft n, 20MHz (6.5Mbps) Test Date: Dec. 27, 2007 Temperature: 22 Humidity: 65% Atmospheric pressure: 1030 hPa a) Channel 1 Limit@3m (dBuV/m) Frequency (MHz) Ant-Pol H/V Meter Reading Corrected Factor Result (dBuV/m) Remark Peak Ave. Margin (dB) Table (Deg.) Ant High (m) 2358.65 H 51.77 -3.21 48.56 Peak 74 54 -25.44 220 1.2 2368.55 H 39.60 -3.17 36.43 Ave 74 54 -17.57 220 1.2 2389.97 V 66.47 -3.10 63.37 Peak 74 54 -10.63 198 1.0 2389.97 V 53.83 -3.10 50.74 Ave 74 54 -3.26 198 1.0 b) Channel 11 Limit@3m (dBuV/m) Frequency (MHz) Ant-Pol H/V Meter Reading Corrected Factor Result (dBuV/m) Remark Peak Ave. Margin (dB) Table (Deg.) Ant High (m) 2483.55 H 49.48 -2.76 46.73 Peak 74 54 -27.27 220 1.2 2496.47 H 37.99 -2.71 35.27 Ave 74 54 -18.73 220 1.2 2498.25 V 60.07 -2.71 57.36 Peak 74 54 -16.64 198 1.0 2500.00 V 48.47 -2.70 45.77 Ave 74 54 -8.23 198 1.0 Modulation Standard: IEEE 802.11Draft n, 40MHz (13.5Mbps) Test Date: Dec. 27, 2007 Temperature: 22 Humidity: 65% Atmospheric pressure: 1030 hPa a) Channel 3 Limit@3m (dBuV/m) Frequency (MHz) Ant-Pol H/V Meter Reading Corrected Factor Result (dBuV/m) Remark Peak Ave. Margin (dB) Table (Deg.) Ant High (m) 2389.97 H 51.76 -3.10 48.66 Peak 74 54 -25.34 220 1.2 2386.70 H 39.77 -3.11 36.66 Ave 74 54 -17.34 220 1.2 2386.40 V 66.27 -3.11 63.16 Peak…

Text truncated - open the document above for the full version.

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 20 of 106 FCC Test Report: FI07120302-A 4.6 Test Photographs Front View Rear View Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Jan. 09, 2008 60 of 106 FCC Test Report: FI07120302-A 5.6 Test Photographs Front View Rear View
