Compliance Certification Services Inc. Report No.: T130916D11 Date of Issue: November 05, 2013 Page 1 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. APPENDIX I RADIO FREQUENCY EXPOSURE LIMIT According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter. EUT Specification EUT Wireless Network Camera Model Number RC832xxxxxxxxx(x=0 to 9, A to Z, blank or “-“ for marking purpose) Frequency band (Operating) 802.11b/g/n HT20: 2.412GHz ~ 2.462GHz 802.11n HT40: 2.422GHz ~ 2.452GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna Specification Parts Number: Ant0: Gain: Ant1: Gain: Parts Number: Ant0: Gain: Ant1: Gain: 2.62 dBi ALA120-221025-055800 3.54 dBi ALA120-221025-080800 4.31 dBi Type A (PIFA) Type B (PIFA) ALA130-051021-035850 3.04 dBi ALA130-051021-075850 Max. output power IEEE 802.11b Mode: 19.50 dBm(0.089 W) IEEE 802.11g Mode: 18.50 dBm(0.071 W) IEEE 802.11n HT 20 Mode: 18.50 dBm(0.071 W) IEEE 802.11n HT 40 Mode: 18.50 dBm(0.071 W) Evaluation applied MPE Evaluation* SAR Evaluation N/A Compliance Certification Services Inc. Report No.: T130916D11 Date of Issue: November 05, 2013 Page 2 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TEST RESULTS No non-compliance noted. Calculation Given d G P E    30 & 377 2 E S  Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 377 30 d G P S    Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields     2 2 0796 . 0 100 / 377 1000 / 30 d G P d G P S        Equation 1 Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Compliance Certification Services Inc. Report No.: T130916D11 Date of Issue: November 05, 2013 Page 3 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Maximum Permissible Exposure Substituting the MPE safe distance using d = 20 cm into Equation 1: G P S    000199 . 0 Where P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 IEEE 802.11b mode: Ch. Frq.(MHz) P (mW) Gain (num.) D (cm) Power density in mW / cm 2 Limit (mW/cm2) 6 2437 89 4.31 20 0.0763 1 IEEE 802.11g mode: Ch. Frq.(MHz) P (mW) Gain (num.) D (cm) Power density in mW / cm 2 Limit (mW/cm2) 6 2437 71 4.31 20 0.0609 1 IEEE 802.11n HT20 mode: Ch. Frq.(MHz) P (mW) Gain (num.) D (cm) Power density in mW / cm 2 Limit (mW/cm2) 11 2462 71 4.31 20 0.0609 1 IEEE 802.11n HT40 mode: Ch. Frq.(MHz) P (mW) Gain (num.) D (cm) Power density in mW / cm 2 Limit (mW/cm2) 3 2422 71 4.3 20 0.0608 1

Compliance Certification Services Inc. Report No.: T130916D11-RP1 FCC ID: P27RC8321 Date of Issue: October 24, 2013 Page 1 / 95 Rev.00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Wireless Network Camera Model: RC832xxxxxxxxx (x=0 to 9, A to Z, blank or “-“ for marking purpose) Trade Name: SerComm; AT&T; iControl; ADT Issued to SerComm Corporation 8F, No.3-1,YuanQuSt., NanKang,Taipei115,Taiwan, R.O.C. Issued by Compliance Certification Services Inc. No.81-1, Lane 210, Bade 2nd Rd., Lujhu Township, Taoyuan County 33841, Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 http://www.ccsrf.com [email protected] Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NIST or any government agencies. The test results in the report only apply to the tested sample. Compliance Certification Services Inc. Report No.: T130916D11-RP1 FCC ID: P27RC8321 Date of Issue: October 24, 2013 Page 2 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 October 24, 2013 Initial Issue All Angel Hu Compliance Certification Services Inc. Report No.: T130916D11-RP1 FCC ID: P27RC8321 Date of Issue: October 24, 2013 Page 3 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION ...........................................................................................4 2. EUT DESCRIPTION................................................................................................................5 3. TEST METHODOLOGY..........................................................................................................6 3.1 EUT CONFIGURATION .....................................................................................................6 3.2 EUT EXERCISE .................................................................................................................6 3.3 GENERAL TEST PROCEDURES......................................................................................6 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ..........................................7 3.5 DESCRIPTION OF TEST MODES.....................................................................................8 4. INSTRUMENT CALIBRATION ...............................................................................................9 4.1 MEASURING INSTRUMENT CALIBRATION ....................................................................9 4.2 MEASUREMENT EQUIPMENT USED ..............................................................................9 4.3 MEASUREMENT UNCERTAINTY...................................................................................10 5. FACILITIES AND ACCREDITATIONS .................................................................................11 5.1 FACILTIES .......................................................................................................................11 5.2 EQUIPMENT....................................................................................................................11 5.3 TABLE OF ACCREDITATIONS AND LISTINGS..............................................................12 6. SETUP OF EQUIPMENT UNDER TEST ..............................................................................13 6.1 SETUP CONFIGURATION OF EUT ................................................................................13 6.2 SUPPORT EQUIPMENT..................................................................................................13 7. FCC PART 15.247 REQUIREMENTS ..................................................................................14 7.1 6 DB BANDWIDTH ............................................................................................................14 7.2 PEAK POWER .................................................................................................................25 7.3 AVERAGE POWER .........................................................................................................27 7.4 BAND EDGES MEASUREMENT .....................................................................................29 7.5 PEAK POWER SPECTRAL DENSITY .............................................................................46 7.6 SPURIOUS EMISSIONS..................................................................................................57 7.7 POWERLINE CONDUCTED EMISSIONS .......................................................................89 APPENDIX I PHOTOGRAPHS OF TEST SETUP ......................................................................92 APPENDIX I PHOTOGRAPHS OF TEST SETUP ......................................................................92 Compliance Certification Services Inc. Report No.: T130916D11-RP1 FCC ID: P27RC8321 Date of Issue: October 24, 2013 Page 4 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1. TEST RESULT CERTIFICATION Applicant: SerComm Corporation 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Manufacturer: SerComm Corporation 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Equipment Under Test: Wireless Network Camera Trade Name: SerComm; AT&T; iControl; ADT Model: RC832xxxxxxxxx (x=0 to 9, A to Z, blank or “-“ for marking purpose) Date of Test: October 3 ~ 22, 2013 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. Th…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: T130916D11-RP1 FCC ID: P27RC8321 Date of Issue: October 24, 2013 Page 92 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. APPENDIX I PHOTOGRAPHS OF TEST SETUP Radiated Emission Set up Photos Below 1GHz Compliance Certification Services Inc. Report No.: T130916D11-RP1 FCC ID: P27RC8321 Date of Issue: October 24, 2013 Page 93 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Above 1GHz Compliance Certification Services Inc. Report No.: T130916D11-RP1 FCC ID: P27RC8321 Date of Issue: October 24, 2013 Page 94 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Conducted Emission Setup Photos Compliance Certification Services Inc. Report No.: T130916D11-RP1 FCC ID: P27RC8321 Date of Issue: October 24, 2013 Page 95 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Powerline Conducted Emissions Setup Photos
