Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
LL‐AF2‐ST‐SM‐RTK02 SuperTag Rechargeable User Guide LL‐AF2‐ST‐SM‐RTK02 SuperTag Rechargeable 1 Contents LL‐AF2‐ST‐SM‐RTK02 SuperTag Rechargeable 2 Device Specifications 2 Device Lifespan 2 Electrical 2 Mechanical 2 Device notification payload 2 Powering on the device and Installation 3 Frequently Asked Questions (FAQ) 5 LL‐AF2‐ST‐SM‐RTK02 SuperTag Rechargeable 2 LL‐AF2‐ST‐SM‐RTK02 SuperTag Rechargeable The LL‐AF2‐ST‐SM‐RTK02 SuperTag Rechargeable interfaces with Link Labs AirFinder User Interface (apps.airfinder.com) to provide customers with a highly accurate GPS, Wi‐Fi, Bluetooth positioning service, and accelerometer and temperature. The LL‐AF2‐ST‐SM‐RTK02 SuperTag Rechargeable is an IP67 rated device with a 5‐color LED indicator. Device Specifications Device Lifespan Up to 500 location uplinks, or 6 months, from full battery recharge depending on location type, usage, and configuration. Electrical 470mAh /3.7Vdc Li-polymer battery Micro USB for charging Mechanical Case Material: ABS Dimensions: 56.5 x 56.5 x 16.6mm Weight: 44g Operating Temperature: 0°C to +45°C Humidity: 5% - 95% RH (non-condensing) IP67 Rating Device notification payload contains GPS for outdoor positioning WiFi for outdoor positioning o Only when GPS positioning data is not available Cell Tower ID for outdoor positioning Bluetooth for indoor positioning Movement and Impact reports LL‐AF2‐ST‐SM‐RTK02 SuperTag Rechargeable 3 Powering on the device and installation The device has the multi‐function button located on the front of the device, a LED light indication located on the front of the device, and a micro USB for charging located on the bottom of the device. Please note the location of the Power Button, LED Lights, and micro USB Shipping Mode After initial programming, the device will enter a low power shipping mode. In this mode the device will perform no operation other than monitor the pushbutton. To exit shipping mode the user must press and hold the pushbutton for at least 5 seconds. After a successful exit from shipping mode the device will only re‐enter shipping mode if re‐programmed or user pushbutton sequence to re‐enter is performed. LED behavior The device has a visible multi‐colored LED used to provide user feedback about device mode and status. LL‐AF2‐ST‐SM‐RTK02 SuperTag Rechargeable 4 Shipping mode: Button hold Red LED blink Red LED solid Green LED solid White LED blink End state Button < 1 sec ‐‐ 3 sec 1 sec (if FW lock enabled) ‐‐ Shipping mode Button >= 1 sec and Button < 3 sec 1x per sec 3 sec 1 sec (if FW lock enabled) ‐‐ Shipping mode Button > 3 sec 1x per sec ‐‐ ‐‐ 5x rapid Normal operation Startup from shipping mode: blink blue LED 3 times (exit shipping mode), blink white LED 5 times (application start). Startup/reset normal: blink blue LED 3 times (bootloader), blink white LED 5 times (application start). Operation mode: 1 White blink fast during location scan Cloud sync: see cloud sync behavior Device cannot connect/constantly resetting: the blue LED will blink 3 times, then there will be a pause, and the blue LED will blink 3 more times. This behavior will continue indefinitely, without the device’s white LED blinking. This means that the device has an error. Possible cause is low battery; battery cannot handle the pulse current for LTE‐M. Cloud sync The cloud sync feature allows the user to force the device to send an uplink and check for any pending mailbox messages. When the cloud sync pushbutton sequence is performed the device will immediately send a diagnostic event count message and check downlink mailbox using the current modes network (SymBLE or LTE‐m). If a location update is in progress this will also be sent with the uplink; however, if a GPS is in progress the scan will be stopped due to potential long GPS scan times and the next location type will be started. The LED is used to indicate to the user the result of the mailbox check: 1 ‐ Green LED blink (5s): downlink mailbox check success with mail 2 ‐ White LED blink (5s): downlink mailbox check success no mail 3 ‐ Red LED blink (5s): downlink mailbox check failed LL‐AF2‐ST‐SM‐RTK02 SuperTag Rechargeable 5 Frequently Asked Questions (FAQ) Question Answer How do I power on the device? Device is powered on by pressing/holding the button for 5 seconds. The LED will blink blue 3 times and white 5 times to indicate it is powered up. If no LED response, then ensure the device is fully charged by connecting the USB to an appropriate power source. How do I diagnose what is going on with my device? Most of the device diagnostics can be observed from the LED light on the device. Can I power down the device? Devices do not have the ability to be powered off after the initial power on unless the batteries are removed. Can I change the configuration of the device? Device configurations can be changed by setting up an AirFinder account at apps.airfinder.com, or submitting a support ticket to https://link‐labs.zendesk.com/hc/en‐ us/requests/new?ticket_form_id=360000334931 LL‐AF2‐ST‐SM‐RTK02 SuperTag Rechargeable 6 FCC warming message: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television r…
Text truncated - open the document above for the full version.
SercommCorporation中磊電子股份有限公司 TaipeiOffice:8F,No.3-1,YuanQuSt.,NanKang,Taipei115,Taiwan,R.O.C. TEL:886-2-2655-3988FAX:886-2-2655-3966 Date:2022-06-09 FCCID:P27SMRTK02 Totheattentionof FederalCommunicationsCommission AuthorizationandEvaluationDivision PermanentConfidentialityRequest PursuanttoSections0.457and0.459oftheCommission’sRules,theApplicantherebyrequests confidentialtreatmentofinformationaccompanyingthisApplicationasoutlinedbelow: Schematics BlockDiagram OperationalDescription Partlist Tune-upProcedure Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.ThepublicdisclosureofthesemattersmightbeharmfultotheApplicantandprovide unjustifiedbenefitstoitscompetitors. TheApplicantunderstandsthatpursuanttoRule0.457,disclosureofthisApplicationandall accompanyingdocumentationwillnotbemadebeforethedateoftheGrantforthisapplication. Sincerelyyours, ----------------------------------------------- SercommCorporation NickWu/Engineer TEL:886-2-2655-3988*2556 FAX:886-2-2655-3965 E-mail:[email protected]
SercommCorporation中磊電子股份有限公司 TaipeiOffice:8F,No.3-1,YuanQuSt.,NanKang,Taipei115,Taiwan,R.O.C. TEL:886-2-2655-3988FAX:886-2-2655-3966 Date:2022-06-09 FCCID:P27SMRTK02 AUTHORIZATIONLETTER Towhomitmayconcern: We,theundersigned,herebyauthorizeAndreaHsia/SupervisorofBureauVeritasConsumer ProductsServices(H.K.)Ltd.,TaoyuanBranch(BVCPSTaoyuan)ofTaiwantoactonourbehalfinall mannersrelatingtoFCCapplicationforequipmentauthorization,includingsigningofalldocuments relatingtothesematters.AnyandallactscarriedoutbyAndreaHsia/SupervisorofBVCPSTaoyuan onourbehalfshallhavethesameeffectasactsofourown. Ifyouhaveanyquestionsregardingtheauthorization,pleasedon’thesitatetocontactus. Sincerelyyours, ----------------------------------------------- SercommCorporation NickWu/Engineer TEL:886-2-2655-3988*2556 FAX:886-2-2655-3965 E-mail:[email protected]
SercommCorporation中磊電子股份有限公司 TaipeiOffice:8F,No.3-1,YuanQuSt.,NanKang,Taipei115,Taiwan,R.O.C. TEL:886-2-2655-3988FAX:886-2-2655-3966 Date:2022-06-09 Declarationletter ToWhomItMayConcern We,SercommCorp,declarethatWi-Fi/BLEfunctionislimitedbyfirmwaretoreceivesignalonlyand thereisnomethodtoactivetransmissionfunctionaftershipping. FCCID:P27SMRTK02 ----------------------------------------------- SercommCorporation NickWu/Engineer TEL:886-2-2655-3988*2556 FAX:886-2-2655-3965 E-mail:[email protected]
Reference No.: BEIH-WTW-P22050972_ExtPho Page 1 / 3 CONSTRUCTION PHOTOS OF EUT Reference No.: BEIH-WTW-P22050972_ExtPho Page 2 / 3 Reference No.: BEIH-WTW-P22050972_ExtPho Page 3 / 3
FCC ID: P27SMRTK02 IC:12201A-RTK02 Label Location Back Side Label Location
FCC ID: P27SMRTK02 IC:12201A-RTK02
Reference No.: BEIH-WTW-P22050972_IntPho Page 1 / 7 CONSTRUCTION PHOTOS OF EUT Reference No.: BEIH-WTW-P22050972_IntPho Page 2 / 7 Reference No.: BEIH-WTW-P22050972_IntPho Page 3 / 7 Reference No.: BEIH-WTW-P22050972_IntPho Page 4 / 7 Reference No.: BEIH-WTW-P22050972_IntPho Page 5 / 7 Reference No.: BEIH-WTW-P22050972_IntPho Page 6 / 7 Reference No.: BEIH-WTW-P22050972_IntPho Page 7 / 7
FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 1 of 9 Report No. : SFBEIH-WTW-P22050972 Issued Date : Jul. 20, 2022 FCC SAR Exclusion Report Report No. : SFBEIH-WTW-P22050972 Applicant : Sercomm Corporation Address : 8F, No. 3-1, YuanQu St., NanKang, Taipei, 115, Taiwan, R.O.C. Product Name : Airfinder Rechargeable SuperTag Brand : AirFinder, Sercomm (refer to section 2 for more details) FCC ID : P27SMRTK02 Model No. : LL-AF2-ST-SM-RTK02, SM-RTK02 (refer to section 2 for more details) FCC Rule Part : CFR §2.1093 Standards : IEEE C95.1:1992, IEC/IEEE 66209-1528:2020, KDB 865664 D01 v01r04, KDB 865664 D02 v01r02, KDB 941225 D05 v02r05 KDB 447498 D04 Interim General RF Exposure Guidance v01 Sample Received Date : Jul. 11, 2022 Date of Evaluation : Jul. 19, 2022 Lab Address : No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location : No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City, Taiwan CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch – Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Vera Huang / Specialist Approved By : Gordon Lin / Manager This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 2 of 9 Report No. : SFBEIH-WTW-P22050972 Issued Date : Jul. 20, 2022 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement Evaluation .............................................................................................................................................. 6 3.1 Maximum Target Conducted Power ............................................................................................................................. 6 3.1.1 Maximum Target Conducted Power ................................................................................................................... 6 3.1.2 Time-Avg. Power Calculation ............................................................................................................................. 6 3.1.3 Duty Cycle Calculation ....................................................................................................................................... 7 3.2 SAR Testing Exclusions ............................................................................................................................................... 8 4. Information on the Testing Laboratories ............................................................................................................................. 9 FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 3 of 9 Report No. : SFBEIH-WTW-P22050972 Issued Date : Jul. 20, 2022 Release Control Record Issue No. Reason for Change Date Issued SFBEIH-WTW-P22050972 Initial release Jul. 20, 2022 FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 4 of 9 Report No. : SFBEIH-WTW-P22050972 Issued Date : Jul. 20, 2022 1. Summary of Maximum SAR Value Equipment Class Mode Highest Reported SAR 1g (W/kg) PCB LTE 2 Not Required LTE 4 Not Required LTE 12 Not Required LTE 13 Not Required Note: 1. The SAR criteria (Head & Body: SAR-1g1.6 W/kg) for general population/uncontrolled exposure is specified in FCC 47 CFR part 2 (2.1093) and ANSI/IEEE C95.1-1992. References Guidance: IEEE C95.1:1992, FCC-19-126 FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 5 of 9 Report No. : SFBE…
Text truncated - open the document above for the full version.
Report No.: RFBEIH-WTW-P22050972 Page No. 1 / 58 Report Format Version: 6.1.1 FCC Test Report (PART 24–Cat-M1 B2) Report No.: RFBEIH-WTW-P22050972 FCC ID: P27SMRTK02 Test Model: LL-AF2-ST-SM-RTK02 Series Model: SM-RTK02 (refer to item 3.1 for more details) Received Date: May 30, 2022 Test Date: Jun. 06 ~ Jun. 14, 2022 Issued Date: Jul. 04, 2022 Applicant: Sercomm Corporation Address: 8F, No. 3-1, YuanQu St., NanKang, Taipei Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test LoCation (1): No.19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, Taiwan Test LoCation (2): No. 70, Wenming Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) FCC Registration / Designation Number: 788550 / TW0003 281270 / TW0032 This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. . Report No.: RFBEIH-WTW-P22050972 Page No. 2 / 58 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ........................................................................................................................... 5 2 Summary of Test Results ........................................................................................................................... 6 2.1 Measurement Uncertainty ..................................................................................................................... 6 2.2 Test Site and Instruments ..................................................................................................................... 7 3 General Information ................................................................................................................................... 8 3.1 General Description of EUT .................................................................................................................. 8 3.2 Configuration of System under Test ...................................................................................................... 9 3.2.1 Description of Support Units ....................................................................................................... 9 3.3 Test Mode Applicability and Tested Channel Detail .............................................................................. 9 3.4 EUT Operating Conditions .................................................................................................................. 12 3.5 General Description of Applied Standards and references................................................................. 12 4 Test Types and Results ............................................................................................................................ 13 4.1 Output Power Measurement ............................................................................................................... 13 4.1.1 Limits of Output Power Measurement ...................................................................................... 13 4.1.2 Test Procedures ........................................................................................................................ 13 4.1.3 Test Setup ................................................................................................................................. 13 4.1.4 Test Results .............................................................................................................................. 14 4.2 Modulation Characteristics Measurement .......................................................................................... 18 4.2.1 Limits of Modulation Characteristics ......................................................................................... 18 4.2.2 Test Setup ................................................................................................................................. 18 4.2.3 Test Procedure ......................................................................................................................... 18 4.2.4 Test Results .............................................................................................................................. 18 4.3 Frequency Stability Measurement ................................…
Text truncated - open the document above for the full version.
Report No.: RFBEIH-WTW-P22050972 Page No. 30 / 58 Report Format Version: 6.1.1 4.5 Band Edge Measurement 4.5.1 Limits of Band Edge Measurement Power of any emission outside of the authorized operating frequency ranges must be attenuated below the transmitting power (P) by a factor of at least 43 + 10 log(P) dB. In the 1 MHz bands immediately outside and adjacent to the frequency block a resolution bandwidth of at least one percent of the emission bandwidth of the fundamental emission of the transmitter may be employed. 4.5.2 Test Setup 4.5.3 Test Procedures a. All measurements were done at low and high operational frequency range. b. The center frequency of spectrum is the band edge frequency and span is 1 MHz. RB of the spectrum is 15 kHz and VB of the spectrum is 51 kHz c. Record the max trace plot into the test report. Communication Simulator Spectrum Analyzer Power Splitter EUT 10 dB Attenuation Pad Report No.: RFBEIH-WTW-P22050972 Page No. 31 / 58 Report Format Version: 6.1.1 4.5.4 Test Results Cat M1 Band 2 Channel Bandwidth: 1.4 MHz Channel 18607 1 RB Channel 19193 1 RB Channel 18607 6 RB Channel 19193 6 RB Report No.: RFBEIH-WTW-P22050972 Page No. 32 / 58 Report Format Version: 6.1.1 Cat M1 Band 2 Channel Bandwidth: 3 MHz Channel 18615 1 RB Channel 19185 1 RB Channel 18615 6 RB Channel 19185 6 RB Report No.: RFBEIH-WTW-P22050972 Page No. 33 / 58 Report Format Version: 6.1.1 Cat M1 Band 2 Channel Bandwidth: 5 MHz Channel 18625 1 RB Channel 19175 1 RB Channel 18625 6 RB Channel 19175 6 RB Report No.: RFBEIH-WTW-P22050972 Page No. 34 / 58 Report Format Version: 6.1.1 Cat M1 Band 2 Channel Bandwidth: 10 MHz Channel 18650 1 RB Channel 19150 1 RB Channel 18650 6 RB Channel 19150 6 RB Report No.: RFBEIH-WTW-P22050972 Page No. 35 / 58 Report Format Version: 6.1.1 Cat M1 Band 2 Channel Bandwidth: 15 MHz Channel 18675 1 RB Channel 19125 1 RB Channel 18675 6 RB Channel 19125 6 RB Report No.: RFBEIH-WTW-P22050972 Page No. 36 / 58 Report Format Version: 6.1.1 Cat M1 Band 2 Channel Bandwidth: 20 MHz Channel 18700 1 RB Channel 19100 1 RB Channel 18700 6 RB Channel 19100 6 RB Report No.: RFBEIH-WTW-P22050972 Page No. 37 / 58 Report Format Version: 6.1.1 4.6 Peak to Average Ratio 4.6.1 Limits of Peak to Average Ratio Measurement In measuring transmissions in this band using an average power technique, the peak to-average ratio (PAR) of the transmission may not exceed 13 dB. 4.6.2 Test Setup 4.6.3 Test Procedures 1. Set resolution/measurement bandwidth ≥ signal’s occupied bandwidth; 2. Set the number of counts to a value that stabilizes the measured CCDF curve; 3. Record the maximum PAPR level associated with a probability of 0.1 %. Communication Simulator Spectrum Analyzer Power Splitter EUT 10 dB Attenuation Pad Report No.: RFBEIH-WTW-P22050972 Page No. 38 / 58 Report Format Version: 6.1.1 4.6.4 Test Results Cat M1 Band 2 Channel Bandwidth: 1.4 MHz Channel Bandwidth: 3 MHz Channel Frequency (MHz) Peak to Average Ratio (dB) Channel Frequency (MHz) Peak to Average Ratio (dB) QPSK 16QAM QPSK 16QAM 18607 1850.7 4.81 6.43 18615 1851.5 4.34 5.60 18900 1880.0 5.12 6.75 18900 1880.0 4.46 5.83 19193 1909.3 5.45 6.66 19185 1908.5 4.59 5.84 Spectrum Plot of Worst Value 1.4 MHz / 16QAM 3 MHz / 16QAM Report No.: RFBEIH-WTW-P22050972 Page No. 39 / 58 Report Format Version: 6.1.1 Cat M1 Band 2 Channel Bandwidth: 5 MHz Channel Bandwidth: 10 MHz Channel Frequency (MHz) Peak to Average Ratio (dB) Channel Frequency (MHz) Peak to Average Ratio (dB) QPSK 16QAM QPSK 16QAM 18625 1852.5 4.69 5.19 18650 1855.0 4.72 4.72 18900 1880.0 4.78 5.01 18900 1880.0 4.87 5.10 19175 1907.5 4.91 5.21 19150 1905.0 4.92 5.23 Spectrum Plot of Worst Value 5 MHz / 16QAM 10 MHz / 16QAM Report No.: RFBEIH-WTW-P22050972 Page No. 40 / 58 Report Format Version: 6.1.1 Cat M1 Band 2 Channel Bandwidth: 15 MHz Channel Bandwidth: 20 MHz Channel Frequency (MHz) Peak to Average Ratio (dB) Channel Frequency (MHz) Peak to Average Ratio (dB) QPSK 16QAM QPSK 16QAM 18675 1857.5 4.67 5.02 18700 1860.0 4.66 5.13 18900 1880.0 4.72 5.22 18900 1880.0 4.73 5.11 19125 1902.5 5.04 5.29 19100 1900.0 4.80 5.06 Spectrum Plot of Worst Value 15 MHz / 16QAM 20 MHz / 16QAM Report No.: RFBEIH-WTW-P22050972 Page No. 41 / 58 Report Format Version: 6.1.1 4.7 Conducted Spurious Emissions 4.7.1 Limits of Conducted Spurious Emissions Measurement The power of any emission outside of the authorized operating frequency ranges must be attenuated below the transmitting power (P) by a factor of at least 43 + 10 log(P) dB. The emission limit equal to -13 dBm. 4.7.2 Test Setup 4.7.3 Test Procedure a. The EUT makes a phone call to the communication simulator. All measurements were done at low, middle and high operational frequency range. b. Measuring frequency range is from 9 kHz to 1 GHz. 10 dB attenuation pad is connected with spectrum. RBW = 1 MHz and VBW = 3 MHz is used for conducted emission measurement. c. Measuring frequency range is from 1 GHz to 20 GHz. 10 dB attenuation pad is connected with spectrum. RBW = 1 MHz and VBW = 3 MHz is used for conducted emission measurement. Communication Simulator Spectrum Analyzer Power Splitter EUT 10 dB Attenuation Pad Report No.: RFBEIH-WTW-P22050972 Page No. 42 / 58 Report Format Version: 6.1.1 4.7.4 Test Results Cat M1 Band 2 Channel Bandwidth: 1.4 MHz Channel 18607 Frequency Range: 9 kHz ~ 1 GHz Frequency Range: 1 GHz ~ 20 GHz Channel 18900 Frequency Range: 9 kHz ~ 1 GHz Frequency Range: 1 GHz ~ 20 GHz Channel 19193 Frequency Range: 9 kHz ~ 1 GHz Frequency Range: 1 GHz ~ 20 GHz Note: The signal over the limit in 9 kHz is from spectrum analyzer. Report No.: RFBEIH-WTW-P22050972 Page No. 43 / 58 Report Format Version: 6.1.1 Cat M1 Band 2 Channel Bandwidth: 3 MHz Channel 18615 Frequency Range: 9 kHz ~ 1 GHz Frequency Range: 1 GHz ~ 20 GHz Channel 18900 Frequency Range: 9 kHz ~ 1 GHz Frequency Range: 1 GHz ~ 20 GHz Channel 19185 Frequency Range: 9 kHz ~ 1 GHz Frequency Range: 1 GHz ~ 20 GHz Note: The signal over the limit in 9 kHz is from s…
Text truncated - open the document above for the full version.
Report No.: RFBEIH-WTW-P22050972-1 Page No. 1 / 98 Report Format Version: 6.1.1 FCC Test Report (PART 27–Cat-M1 B4, 12, 13) Report No.: RFBEIH-WTW-P22050972-1 FCC ID: P27SMRTK02 Test Model: LL-AF2-ST-SM-RTK02 Series Model: SM-RTK02 (refer to item 3.1 for more details) Received Date: May 30, 2022 Test Date: Jun. 06 ~ Jun. 14, 2022 Issued Date: Jul. 04, 2022 Applicant: Sercomm Corporation Address: 8F, No. 3-1, YuanQu St., NanKang, Taipei Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location (1): No.19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, Taiwan Test Location (2): No. 70, Wenming Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) FCC Registration / Designation Number: 788550 / TW0003 281270 / TW0032 This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: RFBEIH-WTW-P22050972-1 Page No. 2 / 98 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ........................................................................................................................... 5 2 Summary of Test Results .…
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 36 | 27 | 782 MHz - 782 MHz | 88.00 mW | 1M08D7W | 0.005 ppm |
