P27SZDWS02ZigBee Door / Window Sensor

SerComm Corporation中磊電子股份有限公司 Taipei Office: 8F, No.3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. TEL: 886-2-2655-3988 FAX: 886-2-2655-3966 Chu Nan Office: 3F, No. 81, YuYi Rd., Chu-Nan, Miao-Li 350, Taiwan, R.O.C. TEL: 886-37-585-899 FAX: 886-37-585-000 Date：July 17, 2012 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: P27SZDWS02 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, SerComm Corporation hereby requests permanent confidential treatment of information accompanying this application as outlined below: Common exhibits for which confidentiality is requested are: Schematics Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Your Sincerely, Ronnie Cheng Associate Manager / R&D Division SerComm Corporation TEL: 886-2-2655-3988#2547 FAX: 886-2-2655-7379 E-Mail: [email protected]

Report No: T120628D02 Page 1 / 4 Rev.00 EXTERNAL PHOTOGRAPHS OF EUT

2 Chapter 2 Device Description This Chapter provides device description for the ZigBee Door/Window Sensor. Components 2 3 Installation Guide Main Body: 4 Magnet: 5 The mgnet shall be fixed to close to the specific area, and the distance from sensor shall not be over 1.27cm (0.5 inch) 6 Preparing the Sensor for Installation The Sensor & Magnet contact can be mounted vertically or horizontally but note that the Magnet contact must be aligned (on the same side) as the alignment marks on the Sensor.

Report No: T120628D02 Page 2 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Report No: T120628D02 Page 3 Rev.00 Report No: T120628D02 Page 4 Rev.00 Antenna

Report No: T120628D02-RP1 FCC ID: P27SZDWS02 Date of Issue: July 17, 2012 Page 1 / 31 Rev.00 FCC 47 CFR PART 15 Subpart C TEST REPORT For ZigBee Door Windows Sensor Model SZ-DWS02xxxxxxxx (x = 0~9, A~Z, Blank or any Character) Trade Name: SerComm Issued to SerComm Corporation 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Issued by Compliance Certification Services Inc. No.81-1, Lane 210, Bade 2nd Rd., Lujhu Township, Taoyuan County 33841,Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 http://www.ccsrf.com [email protected] Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NIST or any government agencies. The test results in the report only apply to the tested sample. Report No: T120628D02-RP1 FCC ID: P27SZDWS02 Date of Issue: July 17, 2012 Page 2 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 July 17, 2012 Initial Issue ALL Jill Shiau Report No: T120628D02-RP1 FCC ID: P27SZDWS02 Date of Issue: July 17, 2012 Page 3 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION..................................................................................... 4 2. EUT DESCRIPTION ......................................................................................................... 5 3. TEST METHODOLOGY ................................................................................................... 6 3.1 EUT CONFIGURATION............................................................................................... 6 3.2 EUT EXERCISE........................................................................................................... 6 3.3 GENERAL TEST PROCEDURES ............................................................................... 6 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS .................................... 7 3.5 DESCRIPTION OF TEST MODES .............................................................................. 7 4. INSTRUMENT CALIBRATION......................................................................................... 8 4.1 MEASURING INSTRUMENT CALIBRATION .............................................................. 8 4.2 MEASUREMENT EQUIPMENT USED ........................................................................ 8 4.3 MEASUREMENT UNCERTAINTY .............................................................................. 9 5. FACILITIES AND ACCREDITATIONS........................................................................... 10 5.1 FACILITIES................................................................................................................ 10 5.2 EQUIPMENT ............................................................................................................. 10 5.3 TABLE OF ACCREDITATIONS AND LISTINGS ....................................................... 11 6. SETUP OF EQUIPMENT UNDER TEST........................................................................ 12 6.1 SETUP CONFIGURATION OF EUT .......................................................................... 12 6.2 SUPPORT EQUIPMENT ........................................................................................... 12 7. FCC PART 15.249 REQUIREMENTS ............................................................................ 13 7.1 20 DB BANDWIDTH.................................................................................................... 13 7.2 BAND EDGES MEASUREMENT............................................................................... 16 7.3 SPURIOUS EMISSION.............................................................................................. 21 7.4 POWERLINE CONDUCTED EMISSIONS................................................................. 28 8. APPENDIX 1 PHOTOGRAPHS OF TEST SETUP ........................................................ 30 Report No: T120628D02-RP1 FCC ID: P27SZDWS02 Date of Issue: July 17, 2012 Page 4 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1. TEST RESULT CERTIFICATION Applicant: SerComm Corporation 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Manufacturer: SerComm Corporation 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Equipment Under Test: ZigBee Door Windows Sensor Trade Name: SerComm Model: SZ-DWS02xxxxxxxx (x = 0~9, A~Z, Blank or any Character) Date of Test: July 12 ~ 13, 2012 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements emission limits of FCC Rules Part 15.207, 15.209 and 15.249. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Stan Lin Section Manager Jill Shiau Section Manager Report No: T120628D02-RP1 FCC ID: P27SZDWS02 Date of Issue: July 17, 2012 Page 5 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2. EUT DESCRIPTION Product ZigBee Door Windows Sensor Model SZ-DWS02xxxxxxxx (x = 0~9, A~Z, Blank or any Character) Brand Ser…

Text truncated - open the document above for the full version.

Report No: T120628D02-RP1 FCC ID: P27SZDWS02 Date of Issue: July 17, 2012 Page 30 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 8. APPENDIX 1 PHOTOGRAPHS OF TEST SETUP Radiated Emission Set up Photos Below 1GHz Report No: T120628D02-RP1 FCC ID: P27SZDWS02 Date of Issue: July 17, 2012 Page 31 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Above 1GHz
