P27XHC3Comcast Xfinity Low Cost Camera

i XHC3 User’s Guide Copyright 2020. All Rights Reserved. Document Version: 3.0 Version Date Changes 2.1 8 th Jul, 2021 1.Update Xfinity app setup steps 2.Correct typo and format 2.0 1 st July, 2021 Comcast made changes to images and reworded guidance 1.0 28 June, 2021 Initial Draft Table of Contents CHAPTER 1 INTRODUCTION...................................................................... 1 Overv iew ............................................................................................... 1 Physical Details .................................................................................... 2 Package Contents ................................................................................ 4 CHAPTER 2 BASIC SETUP ......................................................................... 5 Installation ............................................................................................ 5 CHAPTER 3 WALL M OUNTING .................................................................10 APPENDIX A SPECIFICATIONS.................................................................12 Te chnical Specifications .....................................................................12 Regulatory Approvals .........................................................................13 Labe l Information ................................................................................15 1 Chapter 1 Introduction Overview XHC3 is an indoor only camera that supports full HD resolution and dual band 802.11ac Wi-Fi connectivity. Features  Provides 1080p HD video quality  Supports Dual Band 2.4GHz/5GHz 802.11ac WIFI for connectivity and Bluetooth 5.0 for onboarding  Two-way audio communication capability  Provides black and white night vision via built-in IR LEDs 1 2 Physical Details Front View Figure 1: Front View Status LED Off. No power or camera is paused from software app Solid Amber. Camera is booting up. Blinking Blue. Camera is ready to pair. Solid Blue. Camera is connected to network and working normally Blinking Ambe r. Camera has trouble connecting Lens The lens is des igned to s upport full HD video and provides a wide fie ld of view Light Se nsor The light sensor is used to he lp detect daytime and nighttime trans itions to support day and night mode operation IR LEDs The two IR LEDs are used to support night mode operation. 3 Microphone The built-in microphone is designed to capture ambient sound and for bi-direction voice conversation. Rear View Figure 2: Rear View Power Input Connect the included power adapter here. Do not use other power adapters; doing so may damage the camera. Reset Button Gently press and hold this button for up to 10 sec and then release, the camera reboots and the settings are restored to factory default values. Spe aker The built-in speaker is used for voice conversation. Power Input Reset Button Speaker 4 Package Contents The following items are included in the package.  XHC3 camera x 1  Power adapter x 1  Screw/Anchor x 1  Screw diameter: 3.5mm ; Length: 25mm  Anchor inner diameter: 2.9mm ; Length: 30mm Figure 3: What’s in the Box 5 Chapter 2 Basic Setup This section provides information on how to install and setup XHC3 Installation 1. Choose a location Choose a suitable desired location anywhere inside 2. Power Up Plug the included power cable into to the camera and plug the power adapter into a standard power outlet. CAUTION: Use only the power adapter prov ided. Using a different one can result in hardware damage . Figure 4: Power Connection The status LED is solid amber during bootup. 2 6 3. Check the status LED After bootup is complete, and when camera is ready to be paired, the LED is blinking blue. 7 4. Se tup the Came ra 4.1 Download the Xfinity app from the APP store or Google Play Store. 4.2 Sign in to the app with your Xfinity credentials. 8 4.3 Se lect Add a Device, then choose the Xfinity Camera to Start installing 4.4 Follow the guidance in the APP to finish the onboarding process. You can also use the camera functions in the same APP after onboarding the camera 9 5. Mount the Came ra Place the camera in its final permanent location near a power source. For mounting on a wall, please see Chapter 3 Wall Mounting. 10 Chapter 3 Wall Mounting This section provides details for final mounting of XHC3. Ensure that the camera is setup successfully before permanently mounting it. 1. Drill the pilot hole on the mounting surface at the desired location. Note: It is suggested to use "Philips Head (PH2)" screwdriver. The diameter of the mounting hole is 6.35mm and total depth is 36.2mm. 2. Mount the included Anchor, if needed Figure 5: Installing 3 11 3. Plug the included power cable into to the camera and plug the power adapter into a standard power outlet. CAUTION: Use only the power adapter prov ided. Using a different one can result in hardware damage . Figure 8: Routing the Cable 4. Mount the camera to the surface using the included screw. Figure 9: M ounting 5. Adjust the camera to a desired position and secure it firmly. 6. Verify that the camera is working normally. 12 Appendix A Specifications Technical Specifications Came ra Dimensions H x W x D 4.24” x 2.69” x 2.05” (107.74 x 68.33 x 52.17mm) Video compression H.264 and MJPEG Operating Temperature 32F to 104F (0 C to 40 C) Storage Temperature -4F to 158F (-20 C to 70 C) Button 1 Reset Button Wireless interface Dual Band, IEEE 802.11ac, 802.11a/b/g/n, BT 5.0 Audio 1 built-in Microphone 1 built-in Speaker IR LEDs 2 LED 1 tri-color LED (Power/Network/Status) Power Adapter Input 100-240V AC Output 12V/1A DC A 13 Regulatory Approvals FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a C…

Text truncated - open the document above for the full version.

SercommCorporation中磊電子股份有限公司 TaipeiOffice:8F,No.3-1,YuanQuSt.,NanKang,Taipei115,Taiwan,R.O.C. TEL:886-2-2655-3988FAX:886-2-2655-3966 Date:2021/05/24 We,SercommCorporationheredeclarethatthedevicedoesnotsupportchannel12~ 13in2.4GHzbandandanynon-USchannelsinalltheoperationalmode(s)forthe followingproduct. FCCID:P27XHC3 Ifyoushouldhaveanyquestion(s)regardingthisdeclaration,pleasedon’thesitateto contactus.Thankyou! -------------------------------------------- SercommCorporation NickWu/Engineer TEL:886-2-2655-3988*2556 FAX:886-2-2655-3965 E-mail:[email protected]

SercommCorporation中磊電子股份有限公司 TaipeiOffice:8F,No.3-1,YuanQuSt.,NanKang,Taipei115,Taiwan,R.O.C. TEL:886-2-2655-3988FAX:886-2-2655-3966 Date:2021-05-28 FCCID:P27XHC3 Totheattentionof FederalCommunicationsCommission AuthorizationandEvaluationDivision PermanentConfidentialityRequest PursuanttoSections0.457and0.459oftheCommission’sRules,theApplicantherebyrequests confidentialtreatmentofinformationaccompanyingthisApplicationasoutlinedbelow: Schematics BlockDiagram OperationalDescription SoftwareOperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.ThepublicdisclosureofthesemattersmightbeharmfultotheApplicantandprovide unjustifiedbenefitstoitscompetitors. TheApplicantunderstandsthatpursuanttoRule0.457,disclosureofthisApplicationandall accompanyingdocumentationwillnotbemadebeforethedateoftheGrantforthisapplication. Sincerelyyours, --------------------------------------------- SercommCorporation NickWu/Engineer TEL:886-2-2655-3988*2556 FAX:886-2-2655-3965 E-mail:[email protected]

SercommCorporation中磊電子股份有限公司 TaipeiOffice:8F,No.3-1,YuanQuSt.,NanKang,Taipei115,Taiwan,R.O.C. TEL:886-2-2655-3988FAX:886-2-2655-3966 Date:2021-05-28 FCCID:P27XHC3 Totheattentionof FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequest PursuanttoSections0.457and0.459ofthecommission’srules,werequestshort-termconfidential treatmentforthefollowinginformationuntil180daysaftertheGrantDateofEquipmentAuthorization inordertoensuresensitivebusinessinformationremainsconfidentialuntiltheactualmarketingof thedevice: Externalphotos TestSetupphotos User’smanual InternalPhotos Sincerelyyours, ------------------------------------------------ SercommCorporation NickWu/Engineer TEL:886-2-2655-3988*2556 FAX:886-2-2655-3965 E-mail:[email protected]

SercommCorporation中磊電子股份有限公司 TaipeiOffice:8F,No.3-1,YuanQuSt.,NanKang,Taipei115,Taiwan,R.O.C. TEL:886-2-2655-3988FAX:886-2-2655-3966 Date:2021-05-28 FCCID:P27XHC3 AUTHORIZATIONLETTER Towhomitmayconcern: We,theundersigned,herebyauthorizeAndreaHsia/SupervisorofBureauVeritasConsumer ProductsServices(H.K.)Ltd.,TaoyuanBranch(BVCPSTaoyuan)ofTaiwantoactonourbehalfinall mannersrelatingtoFCCapplicationforequipmentauthorization,includingsigningofalldocuments relatingtothesematters.AnyandallactscarriedoutbyAndreaHsia/SupervisorofBVCPSTaoyuan onourbehalfshallhavethesameeffectasactsofourown. Ifyouhaveanyquestionsregardingtheauthorization,pleasedon’thesitatetocontactus. Sincerelyyours, ----------------------------------------------------- SercommCorporation NickWu/Engineer TEL:886-2-2655-3988*2556 FAX:886-2-2655-3965 E-mail:[email protected]

Reference No.:BEIH-WTW-P21040843_ExtPho Page 1/6 CONSTRUCTION PHOTOS OF EUT Reference No.:BEIH-WTW-P21040843_ExtPho Page 2/6 Reference No.:BEIH-WTW-P21040843_ExtPho Page 3/6 Reference No.:BEIH-WTW-P21040843_ExtPho Page 4/6 Reference No.:BEIH-WTW-P21040843_ExtPho Page 5/6 Reference No.:BEIH-WTW-P21040843_ExtPho Page 6/6

Confidential Proprietary Label Location: on the bottom of the stand base

Reference No.:BEIH-WTW-P21040843 Page 1/13 CONSTRUCTION PHOTOS OF EUT Reference No.:BEIH-WTW-P21040843 Page 2/13 Antenna 2 Antenna 1 Reference No.:BEIH-WTW-P21040843 Page 3/13 Reference No.:BEIH-WTW-P21040843 Page 4/13 Reference No.:BEIH-WTW-P21040843 Page 5/13 Reference No.:BEIH-WTW-P21040843 Page 6/13 Reference No.:BEIH-WTW-P21040843 Page 7/13 Reference No.:BEIH-WTW-P21040843 Page 8/13 Reference No.:BEIH-WTW-P21040843 Page 9/13 Reference No.:BEIH-WTW-P21040843 Page 10/13 Reference No.:BEIH-WTW-P21040843 Page 11/13 Reference No.:BEIH-WTW-P21040843 Page 12/13 Reference No.:BEIH-WTW-P21040843 Page 13/13

Report No.: SABEIH-WTW-P21040843 Page No. 1 / 6 Report Format Version: 6.1.1 RF Exposure Report Report No.: SABEIH-WTW-P21040843 FCC ID: P27XHC3 Test Model: XHC3 Series Model: XHC3xxxxxxxx, SCHC3AExxxxxxxxx (the 1st x should be "blank" or "-"; the rest x could be 0 to 9, A to Z, a to z, "blank" or "-" , for marketing purpose) Received Date: Apr. 22, 2021 Test Date: May 7 to 28, 2021 Issued Date: Jun. 9, 2021 Applicant: Sercomm Corp. Address: 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan FCC Registration / Designation Number: 198487 / TW2021 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: SABEIH-WTW-P21040843 Page No. 2 / 6 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits For Maximum Permissible Exposure (MPE) ............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 2.4 Antenna Gain ...................................................................................................................................... 5 2.5 Calculation Result Of Maximum Conducted Power ............................................................................ 6 Report No.: SABEIH-WTW-P21040843 Page No. 3 / 6 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SABEIH-WTW-P21040843 Original release. Jun. 9, 2021 Report No.: SABEIH-WTW-P21040843 Page No. 4 / 6 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Comcast Xfinity Low Cost Camera Brand: Sercomm, Comcast, Xfinity Test Model: XHC3 Series Model: XHC3xxxxxxxx, SCHC3AExxxxxxxxx (the 1st x should be "blank" or "-"; the rest x could be 0 to 9, A to Z, a to z, "blank" or "-" , for marketing purpose) Sample Status: Engineering sample Applicant: Sercomm Corp. Test Date: May 7 to 28, 2021 Standards: FCC Part 2 (Section 2.1091) References Test Guidance: KDB 447498 D01 General RF Exposure Guidance v06 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s RF characteristics under the conditions specified in this report. Prepared by : , Date: Jun. 9, 2021 Annie Chang / Senior Specialist Approved by : , Date: Jun. 9, 2021 Rex Lai / Associate Technical Manager Report No.: SABEIH-WTW-P21040843 Page No. 5 / 6 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits For Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 f = Frequency in MHz ; *Plane-wave equivalent power density 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. 2.4 Antenna Gain Function Frequency (MHz) Ant 1 Peak Gain (dBi) Ant 2 Peak Gain (dBi) Antenna Type Connector WLAN 2400 2.65 2.02 Dipole IPEX WLAN 2450 2.02 2.05 WLAN 2500 2.13 2.11 WLAN 5150 4.62 4.12 WLAN 5500 4.71 4.52 WLAN 5850 4.63 4.65 BT LE 2400 2.65 - BT LE 2450 2.02 - BT LE 2500 2.13 - Note: The above Antenna information is declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laborat…

Text truncated - open the document above for the full version.

Report No.: RFBEIH-WTW-P21040843-1 Page No. 1 / 36 Report Format Version: 6.1.1 FCC Test Report (BT LE) Report No.: RFBEIH-WTW-P21040843-1 FCC ID: P27XHC3 Test Model: XHC3 Series Model: XHC3xxxxxxxx, SCHC3AExxxxxxxxx (the 1st x should be "blank" or "-"; the rest x could be 0 to 9, A to Z, a to z, "blank" or "-" , for marketing purpose) Received Date: Apr. 22, 2021 Test Date: May 11 to 22, 2021 Issued Date: Jun. 9, 2021 Applicant: Sercomm Corp. Address: 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan FCC Registration / Designation Number: 198487 / TW2021 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: RFBEIH-WTW-P21040843-1 Page No. 2 / 36 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................... 8 3.2.1 Test Mode Applicability and Tested Channel Detail ............................................................................. 9 3.3 Duty Cycle of Test Signal .................................................................................................................. 10 3.4 Description of Support Units .............................................................................................................. 11 3.4.1 Configuration of System under Test ................................................................................................... 11 3.5 General Description of Applied Standards and references ................................................................ 11 4 Test Types and Results ...................................................................................................................... 12 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 12 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 12 4.1.2 Test Instruments ................................................................................................................................ 13 4.1.3 Test Procedures ................................................................................................................................. 14 4.1.4 Deviation from Test Standard ............................................................................................................ 14 4.1.5 Test Setup .......................................................................................................................................... 15 4.1.6 EUT Operating Conditions ................................................................................................................. 16 4.1.7 Test Results ....................................................................................................................................... 17 4.2 Conducted Emission Measurement .................................................................................................. 22 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 22 4.2.2 Test Instruments ................................................................................................................................ 22 4.2.3 Test Procedures ................................................................................................................................. 23 4.2.4 Deviation from Test Standard .....................................…

Text truncated - open the document above for the full version.

Report No.: RFBEIH-WTW-P21040843 Page No. 1 / 58 Report Format Version: 6.1.2 FCC Test Report Report No.: RFBEIH-WTW-P21040843 FCC ID: P27XHC3 Test Model: XHC3 Series Model: XHC3xxxxxxxx, SCHC3AExxxxxxxxx (the 1st x should be "blank" or "-"; the rest x could be 0 to 9, A to Z, a to z, "blank" or "-" , for marketing purpose) Received Date: Apr. 22, 2021 Test Date: May 7 to 28, 2021 Issued Date: Jun. 9, 2021 Applicant: Sercomm Corp. Address: 8F, No. 3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan FCC Registration / Designation Number: 198487 / TW2021 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: RFBEIH-WTW-P21040843 Page No. 2 / 58 Report Format Version: 6.1.2 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................... 9 3.2.1 Test Mode Applicability and Tested Channel Detail ........................................................................... 10 3.3 Duty Cycle of Test Signal .................................................................................................................. 12 3.4 Description of Support Units ............................................................................................................. 13 3.4.1 Configuration of System under Test .................................................................................................. 13 3.5 General Description of Applied Standards and references ............................................................... 13 4 Test Types and Results ...................................................................................................................... 14 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 14 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 14 4.1.2 Test Instruments ................................................................................................................................ 15 4.1.3 Test Procedures ................................................................................................................................. 16 4.1.4 Deviation from Test Standard ............................................................................................................ 16 4.1.5 Test Setup .......................................................................................................................................... 17 4.1.6 EUT Operating Conditions ................................................................................................................. 18 4.1.7 Test Results ....................................................................................................................................... 19 4.2 Conducted Emission Measurement .................................................................................................. 33 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 33 4.2.2 Test Instruments ................................................................................................................................ 33 4.2.3 Test Procedures ................................................................................................................................. 34 4.2.4 Deviation from Test Standard ........................................................…

Text truncated - open the document above for the full version.

Reference No.: RFBEIH-WTW-P21040843 Page No. 1 / 4 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Reference No.: RFBEIH-WTW-P21040843 Page No. 2 / 4 RADIATED EMISSION TEST <Frequency Range below 1GHz> Reference No.: RFBEIH-WTW-P21040843 Page No. 3 / 4 RADIATED EMISSION TEST <Frequency Range above 1GHz> Reference No.: RFBEIH-WTW-P21040843 Page No. 4 / 4 DFS TEST Set UUT as Client without radar detection mode (Radar injected into Master) Master Radar ( Radiated ) UUT Receiver Antenna to S.A.
