P27YH600Wireless P/T Network Camera

Network Camera User’s Guide i Table of Contents CHAPTER 1 INTRODUCTION..........................................................................................1 Overview.......................................................................................................................1 Physical Details - Network Camera..............................................................................4 Package Contents..........................................................................................................5 CHAPTER 2 BASIC SETUP...............................................................................................6 System Requirements...................................................................................................6 Installation - Network Camera.....................................................................................7 Setup using the Windows Wizard.................................................................................8 CHAPTER 3 VIEWING LIVE VIDEO.............................................................................13 Overview.....................................................................................................................13 Requirements..............................................................................................................13 Connecting to a Camera on your LAN.......................................................................13 Connecting to a Camera via the Internet...................................................................15 Viewing Live Video.....................................................................................................17 CHAPTER 4 ADVANCED VIEWING SETUP.................................................................19 Introduction................................................................................................................19 Adjusting the Video Image.........................................................................................19 Controlling User Access to the Video Stream.............................................................22 Making Video available from the Internet.................................................................23 Viewing Live Video via the Internet...........................................................................25 Motion Detection Alerts..............................................................................................27 CHAPTER 5 WEB-BASED MANAGEMENT..................................................................29 Introduction................................................................................................................29 Connecting to Network Camera.................................................................................29 Welcome Screen..........................................................................................................30 Administration Menu.................................................................................................31 System Screen.............................................................................................................32 Network Screen...........................................................................................................34 Wireless Screen...........................................................................................................36 DDNS Screen...............................................................................................................38 Video & Audio Screen................................................................................................40 Video Access Screen....................................................................................................43 User Database Screen.................................................................................................45 Pan/Tilt Screen............................................................................................................46 Motion Detection Screen.............................................................................................49 E-Mail Screen.............................................................................................................50 FTP Screen..................................................................................................................52 HTTP Screen...............................................................................................................53 Event Trigger Screen..................................................................................................54 Maintenance Screen....................................................................................................56 Status Screen...............................................................................................................58 Log Screen...................................................................................................................60 CHAPTER 6 WINDOWS MONITOR/PLAYBACK/IP RECORDER UTILITY............61 Overview.....................................................................................................................61 Installation..................................................................................................................61 System Tray Icon........................................................................................................62 Main Screen................................................................................................................62 Camera Setup.............................................................................................................63 ii Main Screen................................................................................................................67 Recording Video.........................................................................................................69 CHA…

Text truncated - open the document above for the full version.

SerComm Corporation磊 Taipei Office: 8F, No.3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. TEL: 886-2-2655-3988 FAX: 886-2-2655-3966 Chu Nan Office: 3F, No. 81, YuYi Rd., Chu-Nan, Miao-Li 350, Taiwan, R.O.C. TEL: 886-37-585-899 FAX: 886-37-585-000 Date: 2007-11-30 Federal Communications Commission Authorization and Evaluation Division FCC ID: P27YH600 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Operational Description 3. Block diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Yours, Ronnie Cheng Associate Manager / R&D Division SerComm Corporation TEL: 886-2-2655-3988 #2547 FAX: 886-2-2655-3975 E-Mail: [email protected]

SerComm Corporation磊 Taipei Office: 8F, No.3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. TEL: 886-2-2655-3988 FAX: 886-2-2655-3966 Chu Nan Office: 3F, No. 81, YuYi Rd., Chu-Nan, Miao-Li 350, Taiwan, R.O.C. TEL: 886-37-585-899 FAX: 886-37-585-000 Date: 2007-11-30 Compliance Certification Services Certification Division 47173 Benicia Street, Fremont, CA 94538 To whom it may concern: We, the undersigned, hereby authorize the Testing Division of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS Testing Division as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; SerComm Corporation磊 Taipei Office: 8F, No.3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. TEL: 886-2-2655-3988 FAX: 886-2-2655-3966 Chu Nan Office: 3F, No. 81, YuYi Rd., Chu-Nan, Miao-Li 350, Taiwan, R.O.C. TEL: 886-37-585-899 FAX: 886-37-585-000 g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Ronnie Cheng Associate Manager / R&D Division SerComm Corporation TEL: 886-2-2655-3988 #2547 FAX: 886-2-2655-3975 E-Mail: [email protected]

Lucy Tsai 附件可能包含會破壞電腦的病毒，因此可能無法正常顯示。 Dear Lucy, Plz see my reply, thank you. Best Regards, Amanda Hi Gina, Please address following issues. Q#1: Please provide RF module's schematics and block diagram. Ans: Please see the RF module's schematics and block diagram as attachment. Q#2: Please provide a RF module photo without the metal shielding. Ans: Please see the revised Internal Photos as attachment. Best Regards, Lucy Tsai The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. "Lucy Tsai" <[email protected]> 2007/12/17 02:27 AM 收件人： "application" <[email protected]> 副本抄送： 主旨： FW: SerComm Corporation, FCC ID: P27YH600, Assessment NO.: AN07T7433, Notice#1 寄件者: gina.lo 代理 application寄件日期: 2007/12/18 [星期二] 上午 12:14 收件者: Lucy Tsai 副本: 主旨: Re:FW: SerComm Corporation, FCC ID: P27YH600, Assessment NO.: AN07T7433, Notice#1 附件: RC8030 Schematic for Module.pdf (136KB) RC8030 Block Diagram for Module.pdf (44KB) RC8030 Internal Photos Revised 1218.pdf (3MB)

Compliance Certification Services Inc. Report No.: 70828207 Date of Issue: December 13, 2007 Page 1 Total Page: 12 Rev. 00 EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: 70828207 Date of Issue: December 13, 2007 Page 2 Rev. 00 Compliance Certification Services Inc. Report No.: 70828207 Date of Issue: December 13, 2007 Page 3 Rev.00 Compliance Certification Services Inc. Report No.: 70828207 Date of Issue: December 13, 2007 Page 4 Rev.00 Compliance Certification Services Inc. Report No.: 70828207 Date of Issue: December 13, 2007 Page 5 Rev.00 Compliance Certification Services Inc. Report No.: 70828207 Date of Issue: December 13, 2007 Page 6 Rev.00 Model: MU12-2050200-A1 Model: SA110C-05-I

Compliance Certification Services Inc. Report No.: 70828207 Date of Issue: December 13, 2007 Page 7 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: 70828207 Date of Issue: December 13, 2007 Page 8 Rev.00 Compliance Certification Services Inc. Report No.: 70828207 Date of Issue: December 13, 2007 Page 9 Rev.00 Compliance Certification Services Inc. Report No.: 70828207 Date of Issue: December 13, 2007 Page 10 Rev.00 Compliance Certification Services Inc. Report No.: 70828207 Date of Issue: December 13, 2007 Page 11 Rev.00 Compliance Certification Services Inc. Report No.: 70828207 Date of Issue: December 13, 2007 Page 12 Rev.00 Compliance Certification Services Inc. Report No.: 70828207 Date of Issue: December 13, 2007 Page 13 Rev.00

Specification 1. Electrical Properties : 1.1 Frequency Range.................. 1.2 Impedance ..................... ... 1.3 VSWR .............................. 1.4 Return Loss........................ 1.5 Radiation ........................... 1.6 Gain..................................1.8dBi typ. 1.7 Polarization..................... ...Linear Vertical 1.8 Admitted Power.................. 1.9 Cable.............................. ...RG-178 Coaxial Cable 1.10 Connector........................ ...SMA Plug Reverse 2. Physical Properties : 2.1 Antenna Cover................ ... TPE 2.2 Antenna Base................ ... ...PC 2.3 Antenna Base................ ... ...PBT 2.4 Operating Temp. ............... ...-10 ~ +60 2.5 Storage Temp. .................. ...-10 ~ +70 2.6 Color .............................. Cool Gray RF Antenna Cable Assembly Omni-directional 1W 2.4GHz ~ 2.5GHz 50Ω Nominal 1.92 :1Max. -10 dB Max. 1 RF Antenna Assembly P/NO:C147- 510356-A (SSR- 71105) SPEC:2.4~2.5GHz 2007/4/14 3 RF Antenna Assembly P/NO:C147-510356-A SPEC:2.4~2.5GHz NO:SSR-71 105 2007.4.14 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20 -10 0 dB Far-field amplitude of C147-510356-A (SSR-71105) -V.nsi 2.400000 GHz 2.450000 GHz 2.500000 GHz 4 RF Antenna Assembly P/NO:C147-510356-A SPEC:2.4~2.5GHz NO:SSR-71 105 2007.4.14 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20 -10 0 dB Far-field amplitude of C147-510356-A (SSR-71105) -H.nsi 2.400000 GHz 2.450000 GHz 2.500000 GHz 5

Compliance Certification Services Inc. Report No.: 70828207-RP1 FCC ID: P27YH600 Date of Issue: December 13, 2007 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 59 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Wireless P/T Network Camera Model: RC8030, ICA-551W, WCS-0020 Trade Name: SerComm Issued to SerComm Corporation 8F, No.3-1, YuanQu St., NanKang, Taipei 115, Taiwan, R.O.C. Issued by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. http://www.ccsemc.com.tw [email protected] Compliance Certification Services Inc. Report No.: 70828207-RP1 FCC ID: P27YH600 Date of Issue: December 13, 2007 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION....................................................................................................3 2. EUT DESCRIPTION ...........................................................................................................................4 3. TEST METHODOLOGY ....................................................................................................................5 3.1 EUT CONFIGURATION........................................................................................................................5 3.2 EUT EXERCISE....................................................................................................................................5 3.3 GENERAL TEST PROCEDURES.............................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS........................................................6 3.5 DESCRIPTION OF TEST MODES...........................................................................................................7 4. INSTRUMENT CALIBRATION........................................................................................................8 4.1 MEASURING INSTRUMENT CALIBRATION......................................................................................8 4.2 MEASUREMENT EQUIPMENT USED.........................................................................................8 5. FACILITIES AND ACCREDITATIONS ..........................................................................................9 5.1 FACILITIES .........................................................................................................................................9 5.2 EQUIPMENT........................................................................................................................................9 5.3 TABLE OF ACCREDITATIONS AND LISTINGS.....................................................................................10 6. SETUP OF EQUIPMENT UNDER TEST .......................................................................................11 6.1 SETUP CONFIGURATION OF EUT.......................................................................................................11 6.2 SUPPORT EQUIPMENT ...............................................................................................................11 7. FCC PART 15.247 REQUIREMENTS.............................................................................................12 7.1 6DB BANDWIDTH.............................................................................................................................12 7.2 PEAK POWER....................................................................................................................................16 7.3 AVERAGE POWER............................................................................................................................20 7.4 BAND EDGES MEASUREMENT ................................................................................................24 7.5 PEAK POWER SPECTRAL DENSITY....................................................................................................33 7.6 SPURIOUS EMISSIONS ................................................................................................................38 7.7 POWERLINE CONDUCTED EMISSIONS...............................................................................................52 APPENDIX I RADIO FREQUENCY EXPOSURE ...............................................................................55 APPENDIX II PHOTOGRAPHS OF TEST SETUP .............................................................................57 Compliance Certification Services Inc. Report No.: 70828207-RP1 FCC ID: P27YH600 Date of Issue: December 13, 2007 Page 4 Rev. 00 2. EUT DESCRIPTION Product Wireless P/T Network Camera Trade Name SerComm Model Number RC8030, ICA-551W, WCS-0020 Model Discrepancy All the specification and layout are identical except they come with different model numbers for marketing purpose. Power Adapter 1. LEADER / MU12-2050200-A1 I/P: AC 100-240V, 0.5A, 50-60Hz O/P: DC 5.0V, 2.0A 2. SINO-AMERICAN / SA110C-05-I I/P: AC 100-240V, 0.3A, 50-60Hz O/P: DC 5V, 2A Frequency Range 2412 ~ 2462 MHz Transmit Power IEEE 802.11b: 22.19 dBm IEEE 802.11g: 19.98 dBm Modulation Technique IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: DSSS (CCK, DQPSK, DBPSK) + OFDM (QPSK, BPSK, 16-QAM, 64-QAM) Transmit Data Rate IEEE 802.11b: 11, 5.5, 2, 1 Mbps IEEE 802.11g: 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 Mbps Number of Channels 11 Channels Antenna Specification Gain: 1.8 dBi Antenna Designation Dipole Antenna Remark: 1. The sample selected for test was production product and was provided by manufacturer. 2. This submittal(s) (test report) is intended for FCC ID: P27YH600 filing to comply with Section 15.207, 15.209 and 15.247 of the FCC Part 15, Subpart C Rules. Compliance Certification S…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 70828207-RP1 FCC ID: P27YH600 Date of Issue: December 13, 2007 Page 57 Rev. 00 APPENDIX II PHOTOGRAPHS OF TEST SETUP CONDUCTED EMISSIONS SETUP PHOTOS Compliance Certification Services Inc. Report No.: 70828207-RP1 FCC ID: P27YH600 Date of Issue: December 13, 2007 Page 58 Rev. 00 RADIATED EMISSIONS SETUP PHOTOS Compliance Certification Services Inc. Report No.: 70828207-RP1 FCC ID: P27YH600 Date of Issue: December 13, 2007 Page 59 Rev. 00 POWERLINE CONDUCTED EMISSIONS SETUP PHOTOS
