P2R-DEM-09279S1Engergy Saving Lamp

U SER ’ S M ANUAL

F IGURE 1 E NERGY S AVING L AMP (M/N: EL-9W/11W) G ENERAL A PPEARANCE F IGURE 2 E NERGY S AVING L AMP (M/N: TEL-9W/11W) G ENERAL A PPEARANCE F IGURE 3 E NERGY S AVING L AMP (M/N: TEL-15W/20W) G ENERAL A PPEARANCE F IGURE 4 E NERGY S AVING L AMP (M/N: TEL-25W) G ENERAL A PPEARANCE F IGURE 5 E NERGY S AVING L AMP (M/N: HLX-9W/11W) G ENERAL A PPEARANCE F IGURE 6 E NERGY S AVING L AMP (M/N: HLX-15W/20W) G ENERAL A PPEARANCE F IGURE 7 E NERGY S AVING L AMP (M/N: HLX-23W) G ENERAL A PPEARANCE

Label Drawing EL-9W 9W □□□□K 120V 60Hz 150mA NOT DIAMMABLE FCC ID: P2R-DEM-09279S1 EL-11W 11W □□□□K 120V 60Hz 180mA NOT DIAMMABLE FCC ID: P2R-DEM-09279S1 TEL-9W 9W □□□□K 120V 60Hz 150mA NOT DIAMMABLE FCC ID: P2R-DEM-09279S1 TEL-11W 11W □□□□K 120V 60Hz 180mA NOT DIAMMABLE FCC ID: P2R-DEM-09279S1 TEL-15W 15W □□□□K 120V 60Hz 250mA NOT DIAMMABLE FCC ID: P2R-DEM-09279S1 TEL-20W 20W □□□□K 120V 60Hz 330mA NOT DIAMMABLE FCC ID: P2R-DEM-09279S1 TEL-25W 25W □□□□K 120V 60Hz 440mA NOT DIAMMABLE FCC ID: P2R-DEM-09279S1 HLX-9W 9W □□□□K 120V 60Hz 150mA NOT DIAMMABLE FCC ID: P2R-DEM-09279S1 HLX-11W 11W □□□□K 120V 60Hz 180mA NOT DIAMMABLE FCC ID: P2R-DEM-09279S1 HLX-15W 15W □□□□K 120V 60Hz 250mA NOT DIAMMABLE FCC ID: P2R-DEM-09279S1 HLX-20W 20W □□□□K 120V 60Hz 330mA NOT DIAMMABLE FCC ID: P2R-DEM-09279S1 HLX-23W 25W □□□□K 120V 60Hz 380mA NOT DIAMMABLE FCC ID: P2R-DEM-09279S1

Label Location Information Refer to the below red arrow: (for example)

F IGURE 1 E NERGY S AVING L AMP (M/N: EL-9W/11W) C OVER R EMOVED F IGURE 2 E NERGY S AVING L AMP (M/N: EL-9W/11W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 3 E NERGY S AVING L AMP (M/N: EL-9W/11W) M AIN B OARD (S OLDERED S IDE ) Figure 4 E NERGY S AVING L AMP (M/N: TEL-9W/11W) C OVER R EMOVED F IGURE 5 E NERGY S AVING L AMP (M/N: TEL-9W/11W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 6 E NERGY S AVING L AMP (M/N: TEL-9W/11W) M AIN B OARD (S OLDERED S IDE ) Figure 7 E NERGY S AVING L AMP (M/N: TEL-15W/20W) C OVER R EMOVED F IGURE 8 E NERGY S AVING L AMP (M/N: TEL-15W/20W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 9 E NERGY S AVING L AMP (M/N: TEL-15W/20W) M AIN B OARD (S OLDERED S IDE ) F IGURE 10 E NERGY S AVING L AMP (M/N: TEL-25W) C OVER R EMOVED F IGURE 11 E NERGY S AVING L AMP (M/N: TEL-25W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 12 E NERGY S AVING L AMP (M/N: TEL-25W) M AIN B OARD (S OLDERED S IDE ) Figure 13 E NERGY S AVING L AMP (M/N: HLX-9W/11W) C OVER R EMOVED F IGURE 14 E NERGY S AVING L AMP (M/N: HLX-9W/11W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 15 E NERGY S AVING L AMP (M/N: HLX-9W/11W) M AIN B OARD (S OLDERED S IDE ) F IGURE 16 E NERGY S AVING L AMP (M/N: HLX-15W/20W) C OVER R EMOVED F IGURE 17 E NERGY S AVING L AMP (M/N: HLX-15W/20W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 18 E NERGY S AVING L AMP (M/N: HLX-15W/20W) M AIN B OARD (S OLDERED S IDE ) Figure 19 E NERGY S AVING L AMP (M/N: HLX-23W) C OVER R EMOVED F IGURE 20 E NERGY S AVING L AMP (M/N: HLX-23W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 21 E NERGY S AVING L AMP (M/N: HLX-23W) M AIN B OARD (S OLDERED S IDE )

Schematics

KWO-LIGHT CO., LTD FCC ID: P2R-DEM-09279S1 Page 1 of 41 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01085 Application for FCC Certificate On Behalf of KWO-LIGHT CO., LTD Energy Saving Lamp Model No.: EL-9W EL-11W TEL-9W TEL-11W TEL-15W TEL-20W TEL-25W HLX-9W HLX-11W HLX-15W HLX-20W HLX-23W FCC ID: P2R-DEM-09279S1 Prepared For : KWO-LIGHT CO., LTD 2ND FL., NO.196-8, SEC 3 DAH TORNG ROAD, SHIN JYY CITY, TAIPEI HSIEN, TAIWAN, R.O.C. Prepared By : Audix Technology (Shanghai) Co., Ltd. 3 F 34 Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233 Tel: +86-21-64955500 Fax: +86-21-64955491 Report No. : ACI-F01085 Date of Test : Oct 17~18, 2001 Date of Report : Nov 08, 2001 KWO-LIGHT CO., LTD FCC ID: P2R-DEM-09279S1 Page 2 of 41 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01085 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 5 1.3 Measurement Uncertainty .......................................................................................................... 5 2 AC POWERLINE CONDUCTED EMISSION TEST ................................................................. 6 2.1 Test Equipment........................................................................................................................... 6 2.2 Block Diagram of Test Setup ..................................................................................................... 6 2.3 Conducted Emission Limits ....................................................................................................... 6 2.4 Test Configuration...................................................................................................................... 7 2.5 Operating Condition of EUT ...................................................................................................... 7 2.6 Test Procedures .......................................................................................................................... 7 2.7 Test Results ................................................................................................................................ 8 3 FIELD STRENGTH TEST ........................................................................................................... 16 3.1 Test Equipment......................................................................................................................... 16 3.2 Block Diagram of Test Setup ................................................................................................... 16 3.3 Test Configuration.................................................................................................................... 16 3.4 Operating Condition of EUT .................................................................................................... 16 3.5 Test Procedure .......................................................................................................................... 17 3.6 Test Result ................................................................................................................................ 17 KWO-LIGHT CO., LTD FCC ID: P2R-DEM-09279S1 Page 3 of 41 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01085 TEST REPORT FOR FCC CERTIFICATE Applicant : KWO-LIGHT CO., LTD Manufacturer #1 : DONG GUAN K-LIGHT LIGHTING CO., LTD Manufacturer #2 : SHANGHAI ANHUA ELECTRIC APPLIANCES CO., LTD EUT Description : Energy Saving Lamp (A) Model No.: EL-9W EL-11W TEL-9W TEL-11W TEL-15W TEL-20W TEL-25W HLX-9W HLX-11W HLX-15W HLX-20W HLX-23W (B) Serial No.: SC1108E-01 SC1108E-03 SC1108T-01 SC1108T-03 SC1108T-05 SC1108T-07 SC1108T-09 SC1108H-01 SC1108H-03 SC1108H-05 SC1108H-07 SC1108H-09 (C) Power Supply: 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 18 CONSUMER DEVICES (2000) AND MP-5/1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 RF Lighting Device limits both conducted emissions and field strength. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Oct 17~18, 2001 Prepared by : Test Engineer : STELLA TANG (Assistant) SAMMY CHEN (Engineer) Reviewer : Approved Signatory : BYRON KWO (Supervisor) ALEX CHIU (Assistant Manager) KWO-LIGHT CO., LTD FCC ID: P2R-DEM-09279S1 Page 4 of 41 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01085 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description : Energy Saving Lamp Type of EUT : ; Production … Pre-product … Pro-type Model Number : EL-9W, EL-11W, TEL-9W, TEL-11W, TEL-15W, TEL-20W, TEL-25W, HLX-9W, HLX-11W, HLX-15W, HLX-20W, HLX-23W (All the above models have been tested. In this report, only the data of EL-9W, EL-11W, TEL-9W, TEL-15W, TEL-25W, HLX-9W, HLX-15W, HLX-23W are reported.) Applicant : KWO-LIGHT CO., LTD 2ND FL., NO.196-8, SEC 3 DAH TORNG ROAD, SHIN JYY CITY, TAIPEI HSIEN, TAIWAN, R.O.C. Manufacturer #1 : DONG GUAN K-LIGHT LIGHTING CO., LTD No.12, Zhen Xin North Sec.2, Za Kou Ind. Area, Dao Jiao Town, Dong Guan Dity, Guang Dong Province, China Manufactu…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test SIDE VIEW (M/N: EL 9W/11W) SIDE VIEW (M/N: TEL 9W/11W/15W/20W/25W) S IDE VIEW (M/N: HLX 9W/11W/15W/20W/23W) 2. Field strength Test (M/N: EL 9W/11W) (M/N: TEL 9W/11W/15W/20W/25W) (M/N: HLX 9W/11W/15W/20W/23W)
