P3G88025518Light

U SER ’ S M ANUAL Federal Communication Commission Interference Statement 1. Application Normal self ballasted compact fluorescent lamp (energy saving lamp) is one kind of new light sources which can substitute incandescent lamps The energy saving lamp can be used at home, hotel, restaurant supper market, office and many other places. 2. Characters High optical efficiency, long life and energy saving are the famous characters of electronic compact fluorescent lamps. It only needs to use 20% energy of incandescent lamp to provide same luminous flux as incandescent lamp in the same condition, So, it is a kind of excellent light source that can save the energy. 3. Technical parameter Model number Shape Operating voltage (V) Frequency (Hz) Rated power (W) Power factor Current (m A) Most Dia (mm) Most length (mm) Cap SPIRAL 11W SPIRAL 120 60 11 0.50* 180* ψ45 130 E26 SPIRAL 13W SPIRAL 120 60 13 0.50* 190* ψ45 135 E26 SPIRAL 15W SPIRAL 120 60 15 0.52* 240* ψ63 140 E26 SPIRAL 20W SPIRAL 120 60 20 0.52* 280* ψ63 147 E26 SPIRAL 23W SPIRAL 120 60 23 0.52* 0305* ψ63 150 E26 Explain:*Consult value 4. Instructions 1> Power must be cut off when installing or replacing the lamp. 2> Never use with a dimmer and do not use the lamp in constant on/off circumstance. 3> Over voltage will effect the life time of the lamp. 4> It is not good to use the lamp in bad ventilation circumstance, The fixture of the lamp can not be too close to the bulb and the fitting can not be scaled. 5> Please check the contact between the cap and the lamp holder and the voltage of the power when tube appeared to be flicker or blanking. If no problem found then replace with a new lamp. 6> Please only hold the lamp at the plastic part to install/uninstall the lamp to make sure the safety of person and to invoid crumbing the lamp.

F IGURE 1 L IGHT (M/N: S PIRAL -15W, S PIRAL -20W) G ENERAL A PPEARANCE FIGURE 2 LIGHT (M/N: SPIRAL-23W) GENERAL APPEARANCE

Label Drawing 120V/60Hz 0.18A SPIRAL-15W FCC ID: P3G88025518 120V/60Hz 0.18A SPIRAL-20W FCC ID: P3G88025518 120V/60Hz 0.18A SPIRAL-23W FCC ID: P3G88025518

Label Location Information Refer to the below red arrow: (for example)

Schematics

Yinxian Youbang Lights Making Factory FCC ID:P3G88025518 Page 1 of 21 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01090 Application for FCC Certificate On Behalf of Yinxian Youbang Lights Making Factory Light Model No.: Spiral-15W, Spiral-20W, Spiral-23W FCC ID : P3G88025518 Prepared For : Yinxian Youbang Lights Making Factory Zhongxin Main Road Fengshuigang Village Buzheng Town, Ningbo, China Prepared By : Audix Technology (Shanghai) Co., Ltd. 3 F 34 Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233 Tel: +8621-64955500 Fax: +8621-64955491 Report No. : ACI-F01090 Date of Test : Oct 24-29, 2001 Date of Report : Nov 08, 2001 Yinxian Youbang Lights Making Factory FCC ID:P3G88025518 Page 2 of 21 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01090 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test ........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 5 1.3 Measurement Uncertainty .......................................................................................................... 5 2 AC POWERLINE CONDUCTED EMISSION TEST ................................................................. 6 2.1 Test Equipment........................................................................................................................... 6 2.2 Block Diagram of Test Setup ..................................................................................................... 6 2.3 Conducted Emission Limits ....................................................................................................... 6 2.4 Test Configuration ...................................................................................................................... 7 2.5 Operating Condition of EUT ...................................................................................................... 7 2.6 Test Procedures........................................................................................................................... 7 2.7 Test Results................................................................................................................................. 8 3 FIELD STRENGTH TEST ........................................................................................................... 11 3.1 Test Equipment......................................................................................................................... 11 3.2 Block Diagram of Test Setup ................................................................................................... 11 3.3 Test Configuration .................................................................................................................... 11 3.4 Operating Condition of EUT .................................................................................................... 11 3.5 Test Procedure .......................................................................................................................... 12 3.6 Test Result ................................................................................................................................ 12 Yinxian Youbang Lights Making Factory FCC ID:P3G88025518 Page 3 of 21 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01090 TEST REPORT FOR FCC CERTIFICATE Applicant : Yinxian Youbang Lights Making Factory Manufacturer : Yinxian Youbang Lights Making Factory EUT Description : Light (A) Model No.: Spiral-15W, Spiral-20W, Spiral-23W (B) Serial No.: YB2001SP003 YB2001SP004 YB2001SP005 (C) Power Supply: 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 18 CONSUMER DEVICES (2000) AND MP-5/1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 RF Lighting Device limits both conducted emissions and field strength. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Oct 24-29, 2001 Prepared by : Test Engineer : JEENY LUO (Assistant) JIM HSU (Engineer) Reviewer : Approved Signatory : BYRON KWO (Supervisor) ALEX CHIU (Assistant Manager) Yinxian Youbang Lights Making Factory FCC ID:P3G88025518 Page 4 of 21 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01090 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description : Light Type of EUT : ; Production … Pre-product … Pro-type Model Number : Spiral-15W, Spiral-20W, Spiral-23W Applicant : Yinxian Youbang Lights Making Factory Zhongxin Main Road Fengshuigang Village Buzheng Town, Ningbo, China Manufacturer : Yinxian Youbang Lights Making Factory Zhongxin Main Road Fengshuigang Village Buzheng Town, Ningbo, China M/N A PPARENT P OWER (VA) R EAL P OWER (W) Spiral-15W 25 13.2 Spiral-20W 28.2 15.3 Spiral-23W 33 18.3 Yinxian Youbang Lights Making Factory FCC ID:P3G88025518 Page 5 of 21 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01090 1.2 Description of Test Facility Site Description : Sept. 17, 1998 file on (Semi-Anechoic Chamber) Federal Communications Commission FCC Engineering Laboratory 7435 Oakland Mills Road Columbia, MD 21046, USA Name of Firm : Audix Technology (Shanghai) Co.,…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test 2. Field strength Test
