Date:2013-8-29 FCC ID: P3SM73A Subject: Ad Hoc Mode Function Declaration To Whom it may concern, This device is acting as slave and operating in the 2.4 GHz (2412 – 2462 MHz) band. Ad Hoc function is supported but not able to operate on non-US frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Yours sincerely, Signatory Signature Name: Erbing Zhang Title: Product Director Tel: 008675526639997

China Greatwall Computer Shenzhen Co.,Ltd. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2013-8-29 SUBJECT: FCC Application for (FCC ID: P3SM73A) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Signature Name: Erbing Zhang Title: Product Director Tel: 008675526639997

China Greatwall Computer Shenzhen Co.,Ltd. Model Difference FCC ID: P3SM73A Model : M73A, D2-7***_**(The first, second and third symbol * in type designation can be any alphanumeric character or blank and denote different client or different sales area. The fourth and the fifth symbol * in type deisgnation can be any alphanumeric character or blank and denote different colour of enclosure.) All the models are the same circuit and RF module, except the mode names. Regards, Client’s signature Signature Name: Erbing Zhang Title: Product Director Address: Greatwall Computer Bldg,Kefa Road,Nanshan District,Shenzhen,Guangdong.PRC

China Greatwall Computer Shenzhen Co.,Ltd. SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 China Greatwall Computer Shenzhen Co.,Ltd. SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 3.0 2013/8/29 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, China Greatwall Computer Shenzhen Co.,Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： Tablet PC Trade Name： GreatWall, Digital2 Model Name： M73A Serial Model： D2-7***_**(The first, second and third symbol * in type designation can be any alphanumeric character or blank and denote different client or different sales area. The fourth and the fifth symbol * in type deisgnation can be any alphanumeric character or blank and denote different colour of enclosure.) FCC ID : P3SM73A We affirm that between SIEMIC and China Greatwall Computer Shenzhen Co.,Ltd. , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature Name: Erbing Zhang Title: Product Director China Greatwall Computer Shenzhen Co.,Ltd. SCS-F18: Project and Product Certification Representative Authorization Letter Page 3 of 3 Rev 3.0 Address: Greatwall Computer Bldg,Kefa Road,Nanshan District,Shenzhen,Guangdong.PRC

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 China Greatwall Computer Shenzhen Co.,Ltd. 2013-8-29 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: P3SM73A We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Name: Erbing Zhang Title: Product Director Address: Greatwall Computer Bldg,Kefa Road,Nanshan District,Shenzhen,Guangdong. PRC

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

FCC ID LABELING AND LOCATION FCC ID Label Tablet PC Model NO.：M73A Input Rating：DC 5V/ 1500mA （Charging by Adapter） Battery:3.7V/ 2350mAh FCC ID: P3SM73A China Greatwall Computer Shenzhen Co.,Ltd. Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 ANT Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10 Photo 11 Photo 12

RF EXPOSURE EVALUATION METHOD FCC ID：P3SM73A SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Maximum measured transmitter power. Frequency Maximum Conducted Output Power(PK) Maximum Conducted Output Power(AV) (MHz) (dBm) (dBm) 2412 12.45 9.53 Remark: The best case gain of the antenna is 1.0dBi. 0.85dBi logarithmic terms convert to numeric result is nearly 1.26 9.53dbm=8.97mW [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 8.97/5*√2.412=2.61≤3.0 Threshold at which no SAR required is 10mw and ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required.

FCC RADIO TEST REPORT FCC ID: P3SM73A Product： Tablet PC Trade Name： GreatWall, Digital2 Model Name： M73A Serial Model： D2-7***_**(The first, second and third symbol * in type designation can be any alphanumeric character or blank and denote different client or different sales area. The fourth and the fifth symbol * in type deisgnation can be any alphanumeric character or blank and denote different colour of enclosure.) Report No.： NTEK-2013NT0730765F Prepared for China Greatwall Computer Shenzhen Co.,Ltd. Greatwall Computer Bldg,Kefa Road,Nanshan District,Shenzhen,Guangdong.PRC Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 65 Report No.: NTEK-2013NT0730765F TEST RESULT CERTIFICATION Applicant’s name........ China Greatwall Computer Shenzhen Co.,Ltd. Address ........................ Greatwall Computer Bldg,Kefa Road,Nanshan District,Shenzhen,Guangdong.PRC Manufacture's Name... China Greatwall Computer Shenzhen Co.,Ltd. Address ........................ Greatwall Computer Bldg,Kefa Road,Nanshan District,Shenzhen,Guangdong.PRC Factory’s name........... China Great-Wall Computer Shenzhen Co., Ltd.Shiyan Branch Address ........................ Great-Wall Computer Industry Park,Baoshi East Rd.Shiyan County,Bao’an,Shenzhen,P.R.China Product description Product name .................Tablet PC Model and/or type reference ..................... M73A Serial Model .................... D2-7***_**(The first, second and third symbol * in type designation can be any alphanumeric character or blank and denote different client or different sales area. The fourth and the fifth symbol * in type deisgnation can be any alphanumeric character or blank and denote different colour of enclosure.) Standards.................... FCC Part15.247 Test procedure ................ ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test...................................... Date (s) of performance of tests ....... 10 Aug. 2013 ~22 Aug. 2013 Date of Issue..................................... 23 Aug. 2013 Test Result......................................... Pass Testing Engineer : (Apple Huang) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 65 Report No.: NTEK-2013NT0730765F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 4 . POWER SPECTRAL DENSITY TEST 36 4.1 APPLIED PROCEDURES / LIMIT 36 4.1.1 TEST PROCEDURE 36 4.1.2 DEVIATION FROM STANDARD 36 4.1.3 TEST SETUP 36 4.1.4 EUT OPERATION CONDITIONS 36 4.1.5 TEST RESULTS 37 5 . BANDWIDTH TEST 45 5.1 APPLIED PROCEDURES / LIMIT 45 5.1.1 TEST PROCEDURE 45 Page 4 of 65 Report No.: NTEK-2013NT0730765F Table of Contents Page 5.1.2 EUT OPERATION CONDITIONS 45 5.1.3 TEST RESULTS 46 6 . PEAK OUTPUT POWER TEST 54 6.1 APPLIED PROCEDURES / LIMIT 54 6.1.1 TEST PROCEDURE 54 6.1.2 DEVIATION FROM STANDARD 54 6.1.3 TEST SETUP 54 6.1.4 EUT OPERATION CONDITIONS 54 6.1.5 TEST RESULTS 55 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 56 7.1 DEVIATION FROM STANDARD 56 7.2 TEST SETUP 56 7.3 EUT OPERATION CONDITIONS 56 7.4 TEST RESULTS 57 8 . ANTENNA REQUIREMENT 63 8.1 STANDARD REQUIREMENT 63 8.2 EUT ANTENNA 63 9 . EUT TEST PHOTO 64 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 65 Report No.: NTEK-2013NT0730765F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 65 Report No.: NTEK-2013NT0730765F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 65 Report No.: NTEK-2013NT0730765F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT…
