P4JTME-4M2M Terminal

Nokia 31 GSM Connectivity Terminal User’s Guide for Modem Use Issue 6 – Final Draft LEGAL INFORMATIONPart No. 9353859, Issue 1© 2002 Nokia Mobile Phones. All rights reserved.Nokia is a registered trademark of Nokia Corporation. Nokia, Nokia Connecting People and the Original Accessories logos are trademarks of Nokia Corporation and/or its affiliates.US Patent Numbers 4868846, 4969192, 5001372, 5101175, 5212834, 5230091, 5241583, 5311179, 5331638, 5331638, 5335362, 5384782, 5384782, 5390223, 5396657, 5400949, 5416435, 5442521, 5444816, 5446364, 5479476, 5487084, 5519885, 5526366, 5553125, 5557639, 5581244, 5625274, 5640395, 5664053, 5677620, 5692032, 5699406, 5699482, 5701392, 5722087, 5729534, 5729541, 5754976, 5760568, 5782646, 5805301, 5827082, 5835889, 5839101, 5844884, 5845219, 5857151, 5862178, 5870683, 5887266, 5889770, 5892475, 5898925, 5907823, 5914796, 5915440, 5917868, 5920826, 5926138, 5926769, 5930233, 5946651, 5953675, 5956625, 5956633, 5960389, 5963901, 5966374, 5966378, 5970059, 5987137, 5991716, 5991857, 6005857, 6011853, 6014573, 6026161, 6028567, 6029128, 6032034, 6038238, 6043760, 6047196, 6049796, 6055439, 6060193, 6069923, 6078820, 6081534, 6084962, 6085080, 6088746, 6094587, 6097964, 6108531, 6112099, 6115617, 6118775, 6122498, 6125281, 6128322, 6128509, 6138038, 6138091, 6144243, 6144676, 6148209, 6151507, 6163609, 6164547, 6167248, 6170073, 6185295, 6188909, 6195338, 6199035, 6201876, 6240076, 6240079, 6249584, 6266330, 6292668, 6295286, 6310609, 6324412, 6357466Includes RSA BSAFE cryptographic or security protocol software from RSA Security.The information contained in this user guide was written for Nokia 31 GSM Connectivity Terminal. Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS.” EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.EXPORT CONTROLSThis product contains commodities, technology or software exported from the United States in accordance with the Export Administration regulations. Diversion contrary to U.S. law is prohibited. ' 2002 Nokia Corporation. All rights reserved. U.S. English 3 FCC/INDUSTRY CANADA NOTICEYour terminal may cause TV or radio interference (for example, when using a terminal in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your terminal if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation i s subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.OEM LABELINGA label must be affixed to the outside of the end product into which the authorized terminal is incorporated, with a statement similar to the following: This device contains TX FCC ID: P4JTME-4" ' 2002 Nokia Corporation. All rights reserved. 4 FOR YOUR SAFETY Please read and follow these simple guidelines. Breaking these rules may be dangerous or illegal. Switch off terminal where prohibitedDo not switch the wireless terminal on when wireless device use is prohibited or when it may cause interference or danger. Be aware of interferenceAll wireless devices may get interference that could affect performance. Switch off in hospitals Follow any regulations or rules. Switch off when refuelingDo not use this wireless device at a refueling point. Do not use it near fuel or chemicals. Switch off near blastingDo not use your wireless terminal where blasting is in progress. Observe restrictions and follow any regulations or rules. ' 2002 Nokia Corporation. All rights reserved. U.S. English 5 Keep out of waterYour wireless terminal is not water-resistant. Keep it dry.Use your terminal sensiblyDo not touch the antenna unnecessarily. Use only qualified service personnelOnly qualified personnel may install or repair equipment. Use approved accessories Use only approved accessories. Do not connect incompatible products. Backup copiesRemember to make backup copies of all important data. Connecting to other devicesWhen connecting to any other device, read its user's guide for detailed safety instructions. Do not connect incompatible products. ' 2002 Nokia Corporation. All rights reserved. 6 1 Introduction The Nokia 31 is a GSM Connectivity Terminal which offers high speed wireless connections over GSM 850/1900 MHz networks. The contents of the "Complete" Terminal package include:1 Nokia 31 GSM Connectivity Terminal 2 Power supply ACW-5A 3 Data adapter RS-232 4 Data cable RS-232 5 Installation kit 6 Product note 7 Nokia 31 CD-ROM 8 Installation pad (not shown) O PERATION M ODES M2M M2M stands for "machine-to-machine, man-to-machine or machine-to-man" communication. M2M is a simple way to use wireless data transmission as a link between systems, remote devices or locations and individuals. ' 2002 Nokia Corporation. All rights reserved. U.S. English 7 The Nokia 31 terminal can be combined with the Nokia M2M Gateway to provide wireless connections (Text Messaging, USSD, GPRS, CSD) for machine-to-machine communications. This combination forms part of an application solution which can remotely monitor or control a pool of devices or to connect them with existing systems. With the Nokia 31 terminal connected to a mac…

Text truncated - open the document above for the full version.

' 2002 Nokia Corporation. All rights reserved. U.S. English 21 Note: When the AutoPIN feature is switched on with the Nokia 31 Configurator software, the PIN code is saved in the terminal’s memory and there is no need to type in the PIN code each time the terminal is powered on. U SE H YPER T ERMINAL TO CHANGE THE PIN CODE Several applications can be used to enter the PIN code into the Nokia 31 terminal. In a Windows environment, one application which can be used to enter the PIN code is HyperTerminal®. To configure and run HyperTerminal:1 From the Windows Taskbar , select Start, Programs, Accessories, Communications, HyperTerminal . Double-click the HyperTrm.exe icon. 2 In the Connection Description page, go to the Name box and type a name for the connection (for example GSM1). Click OK . ' 2002 Nokia Corporation. All rights reserved. 22 3 In the Connect To dialog box, there is a Connect using list. From that drop down list, select Direct to Com X , where "X" is the COM port number where the Nokia 31 terminal is attached. Click OK . 4 In the COM X Properties dialog box, select the Port Settings dialog box and click OK. 5 In the HyperTerminal connection window, type at and press ENTER . If the connection is successful, the program will answer OK . If you do not get an OK response, see “Troubleshooting” on page 37. ' 2002 Nokia Corporation. All rights reserved. U.S. English 23 6 Type in the AT command at+cpin="PIN" where PIN is your PIN code. 7 Press Enter . If you enter the wrong PIN code three times in a row, the code is blocked (for more details, see “Troubleshooting” on page 37). Changing the PIN codeTo protect your SIM card against unauthorized use, it is a good idea to change the PIN code supplied by your service provider. Note: The PIN code request must be set to on before you can change the PIN code using an AT command. For example, to change the PIN code from the HyperTerminal connection window: 1 Type in the following AT commandat+cpwd="sc","OLDPIN", "NEWPIN"where OLDPIN is the old PIN code and NEWPIN the new code. 2 Press Enter . The PIN code can also be changed using the Nokia 31 Configurator software. ' 2002 Nokia Corporation. All rights reserved. 24 5 Modem installation for Nokia 31 terminal Modem Setup for Nokia 31 terminal allows you to use the Nokia 31 terminal as a wireless modem for your computer. This modem functionality supports most commercially available data and fax applications as well as Internet browsers and e-mail. The setup installs PC compatible data and fax modem drivers as well as Nokia Modem Options that allows you to set parameters for data calls. Alternatively, you can use the standard modem driver installed with MS Windows.The Nokia 31 Modem Options run with Windows 98/Me/2000/XP or Windows NT 4.0 with Service Pack 5 or newer.To connect to the Internet, to send and receive e-mail or faxes or to transmit data from your PC, you must have previously installed the appropriate data and fax communications software. G ETTING S TARTED Before you install the Modem Setup for Nokia 31 terminal:• close all the applications currently running in the PC • make sure that the PIN code request in the SIM card is disabled before inserting the SIM card into the terminal. If the PIN request is activated, the PIN code can be entered with an application such as HyperTerminal (see Enter the PIN code, p. 20) • if you want to activate GPRS service, GPRS must be activated in the SIM card used with the Nokia 31 terminal and your local Internet service provider must support GPRS service. ' 2002 Nokia Corporation. All rights reserved. U.S. English 25 § M ODEM SETUP You can install the Modem Setup for Nokia 31 terminal from the Nokia 31 CD-ROM or download the latest software from www.americas.forum.nokia.com . 1 From the CD-ROM main menu, click Install Software. 2 Click Install Modem Setup for Nokia 31 GSM Connectivity Terminal. 3 Click Install and fo llow th e instructions on the screen. OR 1 Open the downloaded Modem Setup for Nokia 31 terminal exe-files and save the files in a chosen location 2 Run the Setup . Be prepared to connect your Nokia 31 terminal to the PC when prompted to do so.The Nokia 31 data and fax modem drivers will be installed automatically during the setup. You can change data call settings even when your phone is not connected to the computer. Please refer to the Nokia Modem Options Help for information on how to set these options. ' 2002 Nokia Corporation. All rights reserved. 26 C ONFIGURE N OKIA M ODEM O PTIONS In order to use the Nokia 31 terminal as a wireless modem, Nokia Modem Options must be configured for your PC. These options define the modem to be used, the connection type, GSM connection speed kbits/s and the GPRS access point. For example, to set the Installed Nokia Modems using MS Windows 2000: 1 Go to the Taskbar, Start button and select Settings . Select the Control Panel . 2 In the Control Panel , select Nokia Modem Options . 3 Select Nokia 31 (cable) from the Installed Nokia Modems menu. If you have a CSD connection from your provider, you will be limited to a connection speed of 9.6 or 14.4 kbts/s.If you have a GPRS connection from your Internet service provider, you must specify a GPRS access point for the terminal. This access point is provided by the Internet service provider who provides the SIM card used in the Nokia 31 terminal. 4 When the Nokia Modem Options settings are determined select Apply and then select OK

' 2002 Nokia Corporation. All rights reserved. U.S. English 27 C REATE NEW DIAL - UP CONNECTION After you have installed the modem driver required by your system, you can select the Nokia 31 terminal as your modem and start using it through a communications software application. For example, MS Windows 95/98/2000/NT 4.0 includes communications applications such as Dial-Up Networking and HyperTerminal. For set-up assistance, please refer to the user manuals for the software you are using.When using Dial-Up Networking with Windows 2000, a new dial-up connection must be specified for each type of connection. The following steps apply equally to GPRS or CSD dial-up connections.1 In the Windows Taskbar , go to the Start button and press Settings . 2 Select Control Panel and Network and press Dial-up Connections . 3 Select Make New Connection . 4 In the Welcome to the Network Connection Wizard window, press Next . 5 Select Dial-up to the Internet in the Network Connection Wizard window and press Next . ' 2002 Nokia Corporation. All rights reserved. 28 6 In the Internet Connection Wizard windows, select I want to set up my Internet connection manually, or I want to connect through a local area network (LAN) . Press Next. 7 Select I Connect through a phone line and a modem and press Next. If your PC has more than one modem driver installed, the Choose Modem window will appear. You can then select Nokia 31 (cable) and press Next . ' 2002 Nokia Corporation. All rights reserved. U.S. English 29 GPRS connection1 Type in the telephone number for your GPRS connection. The telephone number for the GPRS connection is provided by your Internet service provider. For more information on this number, please contact your service provider. Leave the Use area code and dialing rules box unchecked. 2 Press Next .

' 2002 Nokia Corporation. All rights reserved. 30 CSD connection1 Type in the telephone number for your CSD connection. The telephone number for the CSD connection is provided by your Internet service provider. For more information contact your Internet service provider. Be certain to check the Use area code and dialing rules box. 2 Press Next. Enter user name and password 1 Enter your username and password for the Internet access. If you do not have a username and password from your Internet service provider, you may will not be able to connect to the Internet. 2 Press Next. ' 2002 Nokia Corporation. All rights reserved. U.S. English 31 Name your connection1 Type the Connection name for your new dial-up connection e.g. Nokia 31 2 Press Next. Set up your Internet mail account . You should now be able to set up a Internet mail account. For more information, contact your Internet service provider.If you do not want to set up your Internet mail account at this time, select "No" and press Next. ' 2002 Nokia Corporation. All rights reserved. 32 A DDITIONAL SETTINGS I The Nokia 31 terminal requires that you make some additional settings before the dial-up connection process finished. Therefore do not check the box To connect to the Internet immediately, click Finish . Press Finish. S ETTINGS FOR DIAL - UP CONNECTION To finish setting up the modem connection, some additional settings for the Nokia 31 terminal must be defined. These settings apply for both GPRS and CSD connections.1 Go to the Taskbar and select Start , Settings and Control Panel . Select Network and Dial-up Connections . 2 Select the new dial-up connection you created (e.g. Nokia 31) and click on the icon to open

' 2002 Nokia Corporation. All rights reserved. U.S. English 33 the menu. 3 Select Properties from the drop down menu. Set propertiesIn the dial-up connection Properties (e.g. Nokia 31 Properties) window, select the Networking tab. Press Settings. ' 2002 Nokia Corporation. All rights reserved. 34 1 Make certain that the Enable software compression in the PPP Settings window is unchecked . 2 Press OK. 3 Back under the Networking tab, click on the Properties button for I nternet Protocol (TCP/ IP) .I 4 Complete these fields with the information provided by your Internet service provider. 5 Click on the Advanced tab. ' 2002 Nokia Corporation. All rights reserved. U.S. English 35 6 In the Advanced TCP/IP Settings window, make certain that the Use IP header compression box is not checked . Note: Advanced TCP/IP Settings are Internet service provider dependent. For more information, please contact your Internet service provider. 7 Press OK 8 In the Dial-up connection Properties (e.g. Nokia 31 Properties) Networking window press OK. C ONNECTING TO THE I NTERNET If properly configured, your Nokia 31 GSM Connectivity Terminal should now be ready to make an the Internet connection. Go to the Taskbar and select Start , Settings and Control Panel . Select Network and Dial-up Connections . Double-click the new connection icon (e.g. Nokia 31).1 Enter your Internet access username and password. For more information, contact your Internet service provider. ' 2002 Nokia Corporation. All rights reserved. 36 2 When you have successfully connected to the Internet, the Connection Complete window will appear into your PC screen. U NINSTALLING M ODEM SETUP FOR N OKIA 31 1 Click the Start button, point to Settings , and click Control Panel . 2 Double-click Add/Remove Programs . 3 In the Install/Uninstall tab, select Modem Setup for Nokia 31 from the list of software that can be removed. 4 Click Add/Remove . 5 Follow the instructions on the screen until the program files are removed. ' 2002 Nokia Corporation. All rights reserved. U.S. English 37 6 Troubleshooting If you are experiencing problems with the Nokia 31 terminal, check the following:1 Confirm that the data cable is firmly connected to the Nokia 31 terminal and to the PC (or other compatible device). 2 Confirm that the power supply is firmly connected to the Nokia 31 terminal and to an AC wall outlet. 3 Disconnect the power supply from the AC wall outlet and verify that the SIM card is installed properly. P OOR RECEPTION If there are problems with reception, for example, interruptions in the service, the signal may be too weak. The signal strength is indicated at startup by the LED indicators on the front of the Nokia 31 terminal (see Signal Strength, p. 17).To check the strength using the HyperTerminal application, start the software and enter the AT command sequence: at+csq . The response is +csq: <rssi>, 99 . The parameters for <rssi> are from 0 through 31 at 2 dBm intervals: 0 ... 6 -101 dBm or less -> Unacceptable coverage 7 ... 11 -100 dBm ... -91 dBm -> Weak coverage 12 ... 16 -90 dBm ... -81 dBm -> Moderate coverage ' 2002 Nokia Corporation. All rights reserved. 38 For example, the response +csq: 31, 99 means that the signal strength is excellent. If the signal is weaker than -91 dBm (the <rssi> parameter is 11 or less), move the Nokia 31 terminal to another location. You may need to install an external antenna to improve the reception. (For more information on external antenna installation, please see www. americas.forum.nokia.com .) B LOCKED PIN CODE If you enter the wrong PIN code three times in a row, the code will be blocked (L.E.D. indicators 1 and 2 will blink red). To unblock the PIN code, you must enter your Personal Unblocking Key (PUK) code. Unblock using HyperTerminal applicationTo do this in the HyperTerminal application:1 Type the AT command at+cpin? and press Enter . If the PUK code is required, the response is +cpin: SIM PUK . 2 Enter the PUK code via the command at+cpin=PUK, PIN where PUK is your PUK code and PIN is your old or new PIN code. Press Enter . 17 ... 31 -80 dBm or greater -> Good coverage 99 Not known or not detectable ' 2002 Nokia Corporation. All rights reserved. U.S. English 39 N O CONNECTION If you do not get an OK response when you press Enter in the HyperTerminal connection window, verify that the port settings are correct. Modem driverCheck that no other device uses the same COM port with your PC to which you have connected the Nokia 31 terminal. If you wish to see the log file to check what the Nokia 31 terminal has responded to the AT commands, you can find the file named Modem_Nokia30.txt on your PC in the WINNT or Windows folder. If the log file is not found:1 (In Windows 2000) Select Control Panel > Phone and Modem options > Modems > Nokia 31 > Properties > Diagnostics. 2 In the Logging section, select Append to Log . If you are unable to to create the Internet connection • Check the Nokia Modem Options settings are correct. • Check New Dial-up Connection settings are correct. • Contact your Internet service provider. ' 2002 Nokia Corporation. All rights reserved. 40 7 CARE AND MAINTENANCE Your Nokia 31 terminal is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you fulfill your warranty obligations and allow you to enjoy this product for many years.• Keep the terminal and all its parts and accessories out of the reach of small children. • Keep the terminal dry. Precipitation, humidity and all types of liquids or moisture contain minerals that will corrode electronic circuits. • Do not use or store the terminal in dusty, dirty areas. Its moving parts can be damaged. • Do not store the terminal in hot areas. High temperatures can shorten the life of electronic devices, damage batteries, and warp or melt certain plastics. • Do not store the terminal in cold areas. When it warms up (to its normal temperature), moisture can form inside which could…

Text truncated - open the document above for the full version.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 June 27, 2002 RE: FCC ID: P4JTME-4 Attention: Paivi Leinonen I have a few comments on this Application. 1 The FCC ID label must have the FCC ID number on the sample label. While the number is given on a second page, in the label drawing itself the number is missing. Please provide a label with the number on the label. 2 This is also a Computer peripheral device connected to a computer. As such, it is subject to the label requirements of Part 15. The device also appears to be large enough to accommodate the two-condition statement required by 15.19 on the device. Please provide the appropriate label containing all necessary information in accordance with 15.19(a)(3) and 2.925. 3 The Part 22 section of test report is incorrect. Part 22 test data for the 800MHz lists paragraphs of Part 24 as the test sections (see starting page 65 of report). Please correct the report to reflect the proper CFR 47 Parts and the proper test sections. 4 The manual and report mentions the use of an external antenna. The device does not appear to have been tested with this option, but only with the internal antenna (see setup photos). It is not apparent if this external antenna has a higher gain than the internal antenna or not. Please provide test data for this external antenna type. This includes RF exposure calculations if the external gain is higher than the internal antenna gain specified. Alternately, please provide evidence and justification as to why testing of the external antenna was not performed. 5 The FCC requires that separate test setup photos be provided at the time of grant and data upload. Please provide a separate exhibit showing the test setup photos by themselves. 6 This is a Part 15 digital device as well. Please provide a manual with the proper Part 15 statements in accordance with 15.19, 15.21 and 15.105 Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

CONFIDENTIAL 1 (1) 26 August 2002 RE: Nokia Corporation FCC ID: P4JTME-4 1. The FCC ID label must have the FCC ID number on the sample label. While the number is given on a second page, in the label drawing itself the number is missing. Please provide a label with the number on the label. A new label drawing has been prepared to show FCC ID. 2. This is also a Computer peripheral device connected to a computer. As such, it is subject to the label requirements of Part 15. The device also appears to be large enough to accommodate the two-condition statement required by 15.19 on the device. Please provide the appropriate label containing all necessary information in accordance with 15.19(a)(3) and 2.925. Per 15.19(a)(5) this notification is added into user guide since this device is too small to have this text included. 3. The Part 22 section of test report is incorrect. Part 22 test data for the 800MHz lists paragraphs of Part 24 as the test sections (see starting page 65 of report). Please correct the report to reflect the proper CFR 47 Parts and the proper test sections. Revised test reports have been uploaded as a new exhibit. 4. The manual and report mentions the use of an external antenna. The device does not appear to have been tested with this option, but only with the internal antenna (see setup photos). It is not apparent if this external antenna has a higher gain than the internal antenna or not. Please provide test data for this external antenna type. This includes RF exposure calculations if the external gain is higher than the internal antenna gain specified. Alternately, please provide evidence and justification as to why testing of the external antenna was not performed. Unfortunately there is no external antenna available from Nokia to be attached into this product. Users are notified that in order to fulfill FCC RF exposure limits, an external antenna with no more tha 3dBi gain may be attached into this device. RF performance was measured also conducted to prove compliance when external antenna is used. In this sense this should not differ too much from conventional cellular phone with an external antenna connector. 5. The FCC requires that separate test setup photos be provided at the time of grant and data upload. Please provide a separate exhibit showing the test setup photos by themselves. Done. 6. This is a Part 15 digital device as well. Please provide a manual with the proper Part 15 statements in accordance with 15.19, 15.21 and 15.105 Updated User Guide have been uploaded as a new exhibit. CONFIDENTIAL 1 (2) 16 September 2002 RE: Nokia Corporation FCC ID: P4JTME-4 1) The statement in the manual "This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference." does not meet the requirements of 15.19 for computer peripherals. The label or the manual if the device is too small, must bear the following statement verbatim "This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation." Please provide a manual with this statement contained in it. Statement has been added to User Guide and new User Guide has been uploaded to your server in five parts. 2) Your device has an antenna terminal and is used for Part 24, this means the FCC wants to see min and max power levels tested for conducted antenna terminal data. Please specify if the device is 'autoranging' power levels. If it is, please provide low power level antenna conducted data. The mobile was set up for min. output power with pseudo random data modulation. Frequency (MHz) Power step Average Output Power (dBm) 824.2 19 4.30 836.6 19 4.69 848.8 19 4.44 Measurement uncertainty ± 0.5 Frequency (MHz) Power step Average Output Power (dBm) 1850.2 15 1.47 1880.0 15 1.67 1909.8 15 0.56 Measurement uncertainty ± 0.5 Instruments SN Cal. Due to R&S CMU200 838392/064 04/03 CONFIDENTIAL 2 (2) 16 September 2002 3) The new label does not indicate which FCC route was taken for the computer peripheral part. If DoC was done, then the correct FCC DoC logo must appear on the label. If the device is certified to Part 15 then a second application with all pertinent Part 15 information in coincidence with the part 24 applicaion must be provided. If the DoC route was taken then Part 15 testing must be performed by an accredited laboratory and the device must be marked with the appropriate DoC label/logo. Please provide a correct label showing either the Part 15 DoC information. See CFR47 Parts 2.948d, 2.906, 2.1072, 2.1077, and 15.19b. Declaration of Conformity testing will be done before beginning of marketing this device and appropriate DoC label/logo will be added to product’s type label. 4) The updated users guide has not been uploaded as mentioned in the correspondence. User Guide has been uploaded to your server in five parts.

Subject: Re: P4JTME-4 INFORMATION Date: Wed, 28 Aug 2002 19:02:14 -0700 From: Dennis Ward <[email protected]> Reply-To: [email protected] Organization: dt Associates To: [email protected] Hi Paivi Almost there. However, the following must be addressed: 1 The statement in the manual "This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference." does not meet the requirements of 15.19 for computer peripherals. The label or the manual if the device is too small, must bear the following statement verbatim "This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation." Please provide a manual with this statement contained in it. 2 Your device has an antenna terminal and is used for Part 24, this means the FCC wants to see min and max power levels tested for conducted antenna terminal data. Please specify if the device is 'autoranging' power levels. If it is, please provide low power level antenna conducted data. 3 The new label do…

Text truncated - open the document above for the full version.
