P58KFEKHSMElectronic Energy Saving Lamp

User’s Manual This light device has been tested and found to comply with the limits for Consumer RF Lighting device, pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. 1. Use only on 120 volt, 60 hertz. 2. Never disassemble or modify-any changes could void the user’s authority to operate the device. 3. Not for use in totally enclosed fixtures. 4. Risk of electric shock-do not use where directly exposed to water. 5. This device is not intended for use with emergency exit fixtures or emergency exit lights. 6. This product could produce interference when used near a TV, radio, wireless remote control or maritime safely communications equipment or other critical navigation or communication equipment operating between 0.45-30MHz. If interference should occur, move the lamp away from the appliance a distance of three feet or more. Or, plug the lamps or the appliance into a different outlet. 7. To prevent burns, do not touch the bulb during operation or immediately after switching off. 8. Not for use with dimmers, electronic timer or photocell devices or occupancy sensor. 9. Not for use in totally enclosed recess fixtures. 10. To prevent children from touching the bulb, installed the device higher.

Block Diagram

Label Drawing SMKUOHAN 120V 60Hz FCC ID: P58KFEKHSM

Label Location Information Refer to the below red arrow: (for example)

Schematics

Schematics

Shanghai Kuohan Electronic Co., Ltd. FCC ID: P58KFEKHSM Page 1 of 29 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01102 Application for FCC Certificate On Behalf of Shanghai Kuohan Electronic Co., Ltd. Electronic Energy Saving Lamp Model No.: KFE-S11W KFE-S15W KEF-S20W KFE-S24W KFE-C24W FCC ID : P58KFEKHSM Prepared For : Shanghai Kuohan Electronic Co., Ltd. No.5 Weijie Road, Qiao Long Chun, Sun Qiao Town, Pu Dong Shanghai, China Prepared By : Audix Technology (Shanghai) Co., Ltd. 3F 34Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233 Tel: +86-21-64955500 Fax: +86-21-64955491 Report No. : ACI-F01102 Date of Test : Dec 05 - 07, 2001 Date of Report : Dec 12, 2001 Shanghai Kuohan Electronic Co., Ltd. FCC ID: P58KFEKHSM Page 2 of 29 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01102 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test ........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 5 1.3 Measurement Uncertainty .......................................................................................................... 5 2 AC POWERLINE CONDUCTED EMISSION TEST ................................................................. 6 2.1 Test Equipment........................................................................................................................... 6 2.2 Block Diagram of Test Setup ..................................................................................................... 6 2.3 Conducted Emission Limits ....................................................................................................... 6 2.4 Test Configuration ...................................................................................................................... 7 2.5 Operating Condition of EUT ...................................................................................................... 7 2.6 Test Procedures........................................................................................................................... 7 2.7 Test Results................................................................................................................................. 8 3 FIELD STRENGTH TEST ........................................................................................................... 13 3.1 Test Equipment......................................................................................................................... 13 3.2 Block Diagram of Test Setup ................................................................................................... 13 3.3 Test Configuration .................................................................................................................... 13 3.4 Operating Condition of EUT .................................................................................................... 13 3.5 Test Procedure .......................................................................................................................... 14 3.6 Test Result ................................................................................................................................ 14 Shanghai Kuohan Electronic Co., Ltd. FCC ID: P58KFEKHSM Page 3 of 29 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01102 TEST REPORT FOR FCC CERTIFICATE Applicant : Shanghai Kuohan Electronic Co., Ltd. Manufacturer : The Shanghai SanMin Electronic Plant EUT Description : Electronic Energy Saving Lamp (A) Model No.: (B) Serial No.: KFE-S11W E120511 KFE-S15W E120515 KFE-S20W E120520 KFE-S24W E120524 KFE-C24W E120624 (C) Power Supply: 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 18 CONSUMER DEVICES (2000) AND MP-5/1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 RF Lighting Device limits both conducted emissions and field strength. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Dec 05 - 07, 2001 Prepared by : Test Engineer : SUE SUN (Assistant) ADA ZOU (Engineer) Reviewer : Approved Signatory : BYRON KWO (Supervisor) ALEX CHIU (Assistant Manager) Shanghai Kuohan Electronic Co., Ltd. FCC ID: P58KFEKHSM Page 4 of 29 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01102 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description : Electronic Energy Saving Lamp Type of EUT : ; Production … Pre-product … Pro-type Model Number : KFE-S11W KFE-S15W KEF-S20W KFE-S24W KFE-C24W KFE-S24W and KFE-C24W only have different appearance. Applicant : Shanghai Kuohan Electronic Co., Ltd. No.5 Weijie Road, Qiao Nong Village Sun Qiao Town, Pu Dong Shanghai, China Manufacturer : The Shanghai SanMin Electronic Plant No.100 Qing Yun Road, Pudong, Shanghai, China M/N Apparent Power (VA) Real Power (W) KFE-S11W 20.8 10.9 KFE-S15W 26.1 14.1 KFE-S20W 32.7 19.2 KFE-S24W 42.7 23.2 KFE-C24W 38.7 22.0 Shanghai Kuohan Electronic Co., Ltd. FCC ID: P58KFEKHSM Page 5 of 29 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01102 1.2 Description of Test Facility Site Description : Sept. 17, 1998 file on (Semi-An…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test M/N: KFE-S11W M/N: KFE-S15W M/N: KFE-S20W M/N: KFE-S24W M/N: KFE-C24W 2. Field Strength Test M/N: KFE-S11W, KFE-S15W, KFE-S20W, KFE-S24W M/N: KFE-C24W
