P5A-CB00332.4 GHz Wireless Trackball Mouse

1 of 9 Wireless Vertical Trackball Mouse Model No: B107LR User’s Guide 2 of 9 Introduction Congratulations on your purchase of the most innovative Wireless Vertical Trackball Mouse with one additional detachable base for a different angle to find your comfortable hand position. With the naturally upright and relaxed hand position, you may use the mouse more comfortably. The trackball reduce the use of the wrist and the risk of carpal tunnel syndrome. The unique precise cursor control technology can automatically adjust the cursor speed to precisely get to your target points. It offers even more advance that will make you more productive and more comfortable. Product Features  2.4GHz (distance 6~8m), 16 Channels  The state-of-the-art sensor for best tracking performance on the trackball  Auto-Link, Plug and Play! No need to set the channel ID. Power on/off switch.  Auto-Speed technology automatically adjust your cursor speed to precisely get to the point you want.  Vertical contour design and two selectable angles make you use the mouse in a more natural and relaxed hand position.  Three DPI levels switchable: (1) Fixed 600 dpi (2) Auto-Speed 450~1200 dpi (3) Auto-Speed 600~1600 dpi  Storable Nano Receiver  2*AA Alkaline batteries included.  Mouse Dimension: 127 x 96 x 52 mm; Receiver dimension: 17.6 x 15 x 6 mm System Requirements  Microsoft Windows Vista & Windows 7 / 8 /10 or MAC OS X (Button functions may differ on a MAC).  USB Port 3 of 9 Product Functions 1 7 3 1 6 2 4 5 8 4 5 7 11 9 10 4 of 9 1. Left Button 2. Right Button 3. Scroll Wheel / Middle Button 4. Internet Explorer Forward 5. Internet Explorer Backward 6. 34mm diameter trackball 7. One RED LED indicator: a. Power ON indicator: ON for 6 seconds when Power is switched to ON. b. Low Power Indicator: Flash for 6 seconds when battery power is low. c. DPI Switch indicator: Flash once when switched to fixed 600 dpi; flash twice when switched to auto-speed 450~1200 dpi; flash three times when switched to auto-speed 600~1600 dpi 8. DPI switch button 9. Battery Cover 10. Nano Receiver 11. Power On/Off Switch 12. 10-Degree-Adding Base 12 5 of 9 Operation 1. Insert the batteries a. Lift the battery cover up. b. Insert Alkaline battery AA x 1pc. Please ensure the batteries’ polarities (+/-) match the battery compartment’s polarities. c. Close the battery cover. d. Switch the Power on-off switch on the bottom of the mouse to the ON position. e. The Low Power LED on the top case will be on for 6 seconds when the power is switched on. (ǃ) Note:  The unit offers a strong power saving management. Once the mouse accesses the sleeping mode, "to click any button of the mouse" is compulsory to wake it up. Power On/Off:  To save energy for long period of non-usage, switch the On/Off button to Off position to turn off the mouse.  Users can press the DPI button to change the resolution. The LED will flash once or twice or three times when dpi has been successfully switched. Battery cover AA battery x 1pc 6 of 9 2. Connect the receiver a. Turn on your PC. b. Plug the receiver into the USB port on PC. 3. Communication : the mouse & the receiver a. Make sure the Power On/Off Switch on the bottom of the mouse is ON. b. The mouse and receiver have been successfully linked when the cursor’s movement mimics that of the mouse. 4. Clean the trackball holder You may use a pen, through the hole at the mouse bottom, to push out the trackball and clean the trackball holder if dirt is inside. 7 of 9 5. 10-Degree Adding Base There is an additional base to add 10 degree more tilt angle for the mouse. You may select a more comfortable hand position, by using or not to use the base. Trouble Shooting 1. Make sure you have put the batteries in correction directions, and power switch is ON. 2. Make sure you have connected the receiver correctly to the computer's USB port. 3. Try another USB port, in case that your USB port is loose. 4. Replace new batteries if needed when the battery power is low. 5. If mouse performance is slow or intermittent around a wireless network, unplug the Nano receiver from the USB port and then re-insert it. To reactivate the mouse, switch it on, off and on again using the On/Off switch on the bottom of the mouse. 6. Repeat the connection procedure. You can also try moving the mouse closer to the Nano receiver. 7. For the best performance, we suggest that you place the receiver away from other electrical devices. (ǃ) Note:  The mouse, while working if encountering any interference, will automatically source out with the receiver and transfer to another free channel. During the transferring, the cursor movement may have a second delay. (ǃ) Note:  The Red LED on the mouse top is the low battery power indicator. Its 6- seconds flashing indicates that the batteries inside the mouse are needed to be replaced. 8 of 9 Battery Use Reminders 1. Remove worn-out batteries from equipment immediately and dispose of them properly. 2. Keep all batteries (used or new) out of the reach of children. 3. Never dispose of batteries in fire. 4. Do not mix old and new batteries. Do not mix alkaline, standard (Carbon-Zinc), or rechargeable (Nickel Cadmium) batteries. 5. Remove the batteries from this device if the device will not be used for a long period of time. 6. If the performance of the battery decreases substantially, it is time to replace the battery. FCC Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation if this equipment does cause harmful interfer…

Text truncated - open the document above for the full version.

ARESON Technology Corp. Address: 11F., No.646, Sec. 5, Chongxin Rd., Sanchong dist, New Taipei City 24158, Taiwan Tel.:886-2-2999 0505 Fax:886-2-2999 0606 E-mail: [email protected] QA-FR-170-B FCC Authorization Date: 2020-11-12 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, ARESON Technology Corp. , hereby authorize Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratory Corporation on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Jane Chang Product Manager

ARESON Technology Corp. Address: 11F., No.646, Sec. 5, Chongxin Rd., Sanchong dist, New Taipei City 24158, Taiwan Tel.:886-2-2999 0505 Fax:886-2-2999 0606 E-mail: [email protected] FCC Confidential Authorization Date: 2020-11-12 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: P5A-CB0033 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, ARESON Technology Corp., hereby requests long-term confidential treatment of information accompanying this application as outlined below: • Block Diagram • Schematics • Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature: Jane Chang Product Manager

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ201019003-RF Page 1 of 5 EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ201019003-RF Page 2 of 5 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ201019003-RF Page 3 of 5 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ201019003-RF Page 4 of 5 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ201019003-RF Page 5 of 5

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ201019003-RF EXHIBIT A - FCC ID LABEL AND LOCATION FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ201019003-RF Page 1 of 8 EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ201019003-RF Page 2 of 8 Antenna Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ201019003-RF Page 3 of 8 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ201019003-RF Page 4 of 8 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ201019003-RF Page 5 of 8 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ201019003-RF Page 6 of 8 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ201019003-RF Page 7 of 8 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ201019003-RF Page 8 of 8

Note: This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “★”. BACL is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. FCC PART 15.249 TEST REPORT For ARESON Technology Corp. 11F., No.646, Sec. 5, Chongxin Rd., Sanchong District, New Taipei City 24158, Taiwan (R.O.C.) FCC ID: P5A-CB0033 Report Type: Original Report Product Type: 2.4GHz Wireless Trackball Mouse Report Number: RSZ201019003-00 Report Date: 2020-11-04 Reviewed By: Jimmy Xiao RF Engineer Prepared By: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F., West Wing, Third Phase of Wanli Industrial Building, Shihua Road, Futian Free Trade Zone, Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ201019003-00 FCC Part 15.249 Page 2 of 21 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 3 OBJECTIVE ................................................................................................................................................................... 3 TEST METHODOLOGY .................................................................................................................................................. 3 MEASUREMENT UNCERTAINTY .................................................................................................................................... 4 TEST FACILITY ............................................................................................................................................................. 4 SYSTEM TEST CONFIGURATION .......................................................................................................................... 5 JUSTIFICATION ............................................................................................................................................................. 5 EUT EXERCISE SOFTWARE .......................................................................................................................................... 5 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 5 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 5 SUPPORT CABLE DESCRIPTIONS ................................................................................................................................... 5 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 6 SUMMARY OF TEST RESULTS ............................................................................................................................... 7 TEST EQUIPMENT LIST ........................................................................................................................................... 8 FCC§15.203 - ANTENNA REQUIREMENT .............................................................................................................. 9 APPLICABLE STANDARD .............................................................................................................................................. 9 ANTENNA CONNECTOR CONSTRUCTION ...................................................................................................................... 9 FCC§15.205, §15.209 & §15.249(D) - RADIATED EMISSIONS ............................................................................ 10 APPLICABLE STANDARD ............................................................................................................................................ 10 TEST EQUIPMENT SETUP ............................................................................................................................................ 10 EUT SETUP ................................................................................................................................................................ 11 TEST PROCEDURE ...................................................................................................................................................... 12 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................. 12 TEST DATA ................................................................................................................................................................ 12 FCC§15.215(C) - 20DB EMISSION BANDWIDTH ................................................................................................ 19 APPLICABLE STANDARD ............................................................................................................................................ 19 TEST PROCEDURE ...................................................................................................................................................... 19 TEST DATA .......................................................................................…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Radiated Emissions View (Below 1 GHz) Radiated Emissions View (Above 1 GHz)
