P6NDH-9100VDigital portable Radio

We appreciate your purchasing DH-9100 digital portable radio! We believe that the quality and function of this radio will bring you stable performance and smooth communication. As a product built to the DMR standard, DH-9100 is gifted with ergonomic design, all round digital functions and remarkable quality to refresh your experience and enable you to be responsive to critical situations. Please read this manual before use. All rights reserved to HQT. Pictures shown in this manual are for your reference only, if there is fluctuation, according to the real object, please. Hello Digital portable radios The Federal Communications Commission (FCC), with its action in General Docket 93-62, November 7, 1997, has adopted a safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated equipment. Proper operation of this radio will result in user exposure far below the Occupational Safety and Health Act (OSHA) and Federal Communications Commission limits. FCC RF EXPOSURE COMPLIANCE REQUIREMENTS FOR OCCUPATIONAL USE ONLY transmit for more than 50% of total radio use time (50% duty cycle). Transmitting more than 50% of the time can cause FCC RF exposure compliance requirements to be exceeded. This radio is NOT approved for use by the general population in an uncontrolled environment. This radio is restricted to occupational use, work related operations only where radio operator must have the knowledge to control the user’s exposure conditions for satisfying the higher exposure limit allowed for occupational use. When transmitting, hold the radio in a vertical position with its microphone 1 inch (2.5cm) away from your mouth. The radio is transmitting when the red LED on the front of the radio is illuminated. You can cause the radio to transmit by pressing the PTT bar on the radio. These are required operating configurations for meeting FCC RF exposure compliance. Failure to observe these restrictions mean violation. FCC Caution DO NOT Any Changes or modifications not expressly approved by the party responsible for compliance could void user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. More detailed product information More professional technique support More plentiful product models More optional accessories HQT serice network provides more information about on-line service of HQT two-way radio. More detailed product information To deepen your understanding of the functions of this radio. More plentiful product models. To display more plentiful product models, so that you can understand the details of these products in advance and make decisions correctly according to the requirement of work. For more details, please visit: www.hqt-tech.com.cn v On-line Service Center User manual and brochures To provide download or on-line reading of the latest user manuals and brochures in covering detailed information of two-way radios. software download To provide downloading of the latest programming software from HQT website. Your two-way radio can be connected to the computer with programming cable to manage or edit the parameters of channel frequency and other items. On-line learning To offer guidelines for detailed setting of the two-way radio. More optional accessories To provide various kinds of accessories, which can offer more comfortable operation an more remarkable performance of the radio to you. More professional technique support HQT endeavors to achieve the accuracy and completeness of this manual. As for any inaccuracies and omissions that may possibly occur, the right to interpretation is reserved to Shenzhen HQT Science & Technology Co., Ltd. The design or specification of this product is subject to be modified by Shenzhen HQT Science & Technology Co., Ltd. Without prior notice. It is prohibited to copy, transmit, excerpt and store in any retrieval system, or translated to any languages without written authorization of HQT. Statement 0102 0304 C o n t e n t s C o n t e n t s S a f e t y M a t t e r s P r o d u c t I n s p e c t i o n 04 05 05 06 07 07 08 09 03 Attaching/Removing the battery Attaching/Removing the antenna Installing/Removing the Belt Clip Installing Hand Strap Attachingthe Audio Accessory /Removing Radio Overview LED Indicator 13 Programmable Keys 14 Basic Operations 16 Calling on Digital Channel 17 Man Down (Optional) 18 18 Talk Around 18 Monitor 18 Squelch Off 19 Emergency Alarm 19 Busy Channel Lockout 19 Time-out Timer (TOT) 20 Invalid Channel Indication Squelch 20 Transmission Management 20 Optioanl Accessories 21 Care and Maintenance 22 Maintenance 23 Service and Support 24 24 Service Commitment 24 Warranty 25 Terms of Warranty 25 Appendix 09 10 11 Contents Safety Matters Product Inspection Get Acquainted Battery Information Cautions in Charging Attaching and Removing 24 Cautions Safety Matters Please read rules below. Nonobservance of these rules may cause danger or violation of law. The use this radio must comply with regulations of local government. Turn off the radio before you enter places of flammable or explosive environment. Do not replace or charge battery pack in places of flammable or explosive environment. Turn off the radio before you approach blast area and detonator area. Do not use the damaged antenna which may cause lightly burn on skin. Only qualified technician are allowed to maintain this two-way radio. Do not disassemble the radio by yourself. To avoid problems caused by electromagnetic interference or electromagnetic compatibility, please turn off the radio in places with “Wireless Communication Transmit Equipment Prohibited” mark, such as hospitals or other health care places. When taking a plane, turn off the radio if required. In a car with …

Text truncated - open the document above for the full version.

Shenzhen HQT Science&Technology Co.,Ltd Add:5/F,East of Building M-8,Central Zone,Hi-tech Industrial Part,Nanshan District, Shenzhen,China Tel:+86-0755-86028800 Fax:+86-0755-86028872 Date:2015-10-23 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Normal Frequencies Justification Dear Sir/Madam, The Radio with FCC ID: P6NDH-9100V was designed to operate in the frequency bands 136~174MHz To aid equipment authorization in other countries which accept the United States FCC Grant for Certification, Shenzhen HQT Science&Technology Co., Ltd. is requesting that the FCC lists the frequencies 136~174MHz, under FCC Rule Part 90 on the FCC Grant. Shenzhen HQT Science&Technology Co., Ltd. Attests that the radio will not be marketed to USA users with the frequency band which is not allowed by the rule part 90.Per the FCC’s KDB634817 guidance, as an alternative to listing the exact frequencies, we acknowledge that it’s a violation of the FCC Rules if this device operates on unauthorized frequencies.Also, equipment programming is the responsibility of Authorized Service Personnel, the radio complies with 47 CFR Part 90.203(e), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. Per the FCC’s KDB634817 guidance, as an alternative to listing the exact frequencies, We acknowledge that it’s a violation of the FCC Rules if this Device operates on unauthorized frequencies. Frequency Range(MHz) FCC rule part 136-150.8MHz Federal 150.8-152.855MHz Part 90 152.855-154MHz Part 90 154-156.2475MHz Part 90 157.1875-157.45MHz Part 90 157.45-161.575MHz Part 90 161.755-161.9625MHz Part 90 162.0375-173.2MHz Part 90 173.2-173.4MHz Part 90 173.4-174MHz Federal Shenzhen HQT Science&Technology Co.,Ltd Add:5/F,East of Building M-8,Central Zone,Hi-tech Industrial Part,Nanshan District, Shenzhen,China Tel:+86-0755-86028800 Fax:+86-0755-86028872 Sincerely Yours, Printed Name: Qian Chen Signature: Title: Manager

Shenzhen HQT Science&Technology Co.,Ltd. Add:5/F,East of Building M-8,Central Zone,Hi-tech Industrial Park,Nanshan District, Shenzhen,China Tel:+86-0755-86028800 Fax:+86-0755-86028872 FCC Confidential Authorization (2015-10-26) FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: P6NDH-9100V In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, (Shenzhen HQT Science&Technology Co.,Ltd.)hereby requests long-term confidential treatment of information accompanying this ap plication as outlined below: • Block Diagram • Schematics • Operation Description • Parts List/Tune up procedure (for licensed devices) The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Printed Name：Qian Chen Signature: Title: Manager

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT – Front View EUT – Rear View EUT – Top View EUT – Bottom View EUT – Left Side View EUT – Right Side View EUT – Clip View EUT – Earphone View

EXHIBIT A - FCC ID LABELING AND LOCATION FCC ID Label Proposed FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925) Label here

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS EUT – Cover off View 1 EUT – Cover off View 2 EUT –Cover off View 3 EUT –Cover off View 4 EUT – Main Board 1 Top View EUT – Main Board 1 Top Shielding off View EUT – Main Board 1 Bottom View 1 EUT – Main Board 1 Bottom View 2 EUT – Main Board 1 Bottom View 3 EUT – Main Board 1 Bottom Shielding off View EUT – Main Board 2 Top View EUT – Main Board 2 Bottom View EUT – Antenna View 1 EUT – Antenna View 2 EUT – Battery Front View EUT – Battery Rear View

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. SAR EVALUATION REPORT For Shenzhen HQT Science&Technology Co., Ltd. 5/F, East of Building M-8, Central Zone, Hi-tech Industrial Park, Nanshan District, Shenzhen, China FCC ID:P6NDH-9100V Report Type: Original report Product Type: Digital portable Radio Test Engineer: Terry XiaHou Report Number: RSZ150723552-20 Report Date: 2015-09-19 Reviewed By: Bell Hu SAR Engineer Prepared By: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F, the 3rd Phase of WanLi Industrial Building, ShiHua Road, FuTian Free Trade Zone Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No: RSZ150723552-20 SAR Evaluation Report 2 of 62 Attestation of Test Results EUT Information Company Name Shenzhen HQT Science&Technology Co., Ltd. EUT Description Digital portable Radio FCC ID P6NDH-9100V Model Number DH-9100 Test Date 2015-09-15 TX Frequency (MHz) Modulati on Max. SAR Level(s) Reported (1g-SAR) Limit (W/Kg) 136-174MHz Digital 12.5kHz Face up: 0.236W/kg(Corrected by multiplying 50%) Body-Back: 0.325 W/kg (Corrected by multiplying 50%) 8.0 Analog 12.5kHz Face up: 0.351 W/kg (Corrected by multiplying 50%) Body worn: 0.459 W/kg (Corrected by multiplying 50%) Applicable Standards ANSI / IEEE C95.1: 2005 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fileds,3 kHz to 300 GHz. ANSI / IEEE C95.3: 2002 IEEE Recommended Practice for Measurements and Computations of Radio Frequency Electromagnetic Fields With Respect to Human Exposure to SuchFields,100 kHz—300 GHz. IEC 62209-2:2010 Human exposure to radio frequency fields from hand-held and body-mounted wireless communication devices – Human models, instrumentation, and procedures – Part 2: Procedure to determine the specific absorption rate (SAR) for wireless communication devices used in close proximity to the human body (frequenc y range of 30 MHz to 6 GHz) IEEE1528:2013 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques KDB procedures KDB 447498 D01 v05r02: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. KDB 865664 D01v01r03: SAR measurement 100 MHz to 6 GHz . KDB 643646D01 v01r01: SAR test Reduction Considerations for Occupational PTT Radios. KDB Inquiry: Tracking Number 316436 for SAR VHF system validation. Note: This wireless device has been shown to be capable of compliance for localized specific absorption rate SAR For Occupational /Controlled Exposure Environment limits specified in ANSI/IEEE Standards and have been tested in accordance with the measurement procedures specified in IEEE 1528-2013 and RF exposure KDB procedures. The results and statements contained in this report pertain only to the device(s) evaluated. Bay Area Compliance Laboratories Corp. (Shenzhen) Report No: RSZ150723552-20 SAR Evaluation Report 3 of 62 TABLE OF CONTENTS DOCUMENT REVISION HISTORY ......................................................................................................................... 4 EUT DESCRIPTION .................................................................................................................................................... 5 TECHNICAL SPECIFICATION ......................................................................................................................................... 5 REFERENCE, STANDARDS, AND GUILDELINES ............................................................................................... 6 SAR LIMITS ................................................................................................................................................................. 7 FACILITIES .................................................................................................................................................................. 8 DESCRIPTION OF TEST SYSTEM .......................................................................................................................... 9 EQUIPMENT LIST AND CALIBRATION ............................................................................................................. 16 EQUIPMENTS LIST & CALIBRATION INFORMATION .................................................................................................... 16 SAR MEASUREMENT SYSTEM VALIDATION AND VERIFICATION .......................................................... 17 LIQUID VERIFICATION ............................................................................................................................................... 17 SYSTEM ACCURACY VALIDATION AND VERIFICATION .............................................................................................. 19 SAR SYSTEM VERIFICATION DATA .................................................................................................................. 20 EUT TEST STRATEGY AND METHODOLOGY ................................................................................................. 24 TEST POSITIONS FOR DEVICE OPERATING NEXT TO A PERSON’S EAR........................................................................ 24 TEST POSITIONS FOR BODY-WORN AND OTHER CONFIGURATIONS .............................................................................. 25 FOR EUT POSITIONING PROCEDURES ........................................................................................................................ 25 SAR EVALUATION PROCEDURE ................................................................................................................................. 26 TEST METHODOLOGY ........................................…

Text truncated - open the document above for the full version.

Note: This test report is prepared for the customer shown above and for the equipment described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. FCC PART 90 TEST REPORT For Shenzhen HQT Science&Technology Co., Ltd. 5/F, East of Building M-8, Central Zone, Hi-tech Industrial Park, Nanshan District, Shenzhen,China FCC ID: P6NDH-9100V Report Type: Original Report Product Type: Digital portable Radio Test En gineer: David Lee Re port Number: RSZ150723550-00 Re port Date: 2015-10-19 Reviewed B y: Jimmy Xiao RF Engineer Prepared By: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F, the 3rd Phase of WanLi Industrial Building, ShiHua Road, FuTian Free Trade Zone Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ150723550-00 FCC PART 90 Page 2 of 31 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 4 TEST METHODOLOGY .................................................................................................................................................. 4 TEST FACILITY ............................................................................................................................................................. 4 SYSTEM TEST CONFIGURATION .......................................................................................................................... 5 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 5 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 5 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 5 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 5 SUMMARY OF TEST RESULTS ............................................................................................................................... 6 FCC §1.1307(b) & §2.1093 - RF EXPOSURE ............................................................................................................. 7 APPLICABLE STANDARD .............................................................................................................................................. 7 FCC §2.1046 & §90.205 - RF OUTPUT POWER ....................................................................................................... 8 APPLICABLE STANDARD .............................................................................................................................................. 8 TEST PROCEDURE ........................................................................................................................................................ 8 TEST EQUIPMENT LIST AND DETAILS ........................................................................................................................... 8 TEST DATA .................................................................................................................................................................. 8 FCC §2.1047 & §90.207 - MODULATION CHARACTERISTIC .......................................................................... 10 APPLICABLE STANDARD ............................................................................................................................................ 10 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 10 TEST PROCEDURE ...................................................................................................................................................... 10 TEST DATA ................................................................................................................................................................ 10 FCC §2.1049 & §90.209 & §90.210 – OCCUPIED BANDWIDTH & EMISSION MASK ................................... 15 APPLICABLE STANDARD ............................................................................................................................................ 15 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 16 TEST PROCEDURE ...................................................................................................................................................... 16 TEST DATA ................................................................................................................................................................ 16 FCC §2.1051 & §90.210 - SPURIOUS EMISSIONS AT ANTENNA TERMINALS ............................................ 21 APPLICABLE STANDARD ............................................................................................................................................ 21 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 22 TEST PROCEDUR…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Transmitting Radiated Emissions View (Below 1 GHz) Transmitting Radiated Emissions View (Above 1 GHz)
