USECO: Unitron 7 Installation and Operation Manual, rev. 12/01 Unitron 7 manual.msw 1 _________________________UNITRON 7 TM RETHERM SYSTEM _________INSTALLATION AND OPERATION MANUAL (continued) 9. No Liability for Consequential Damages. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL USECO OR ITS SUPPLIERS BE LIABLE FOR ANY SPECIAL, INCIDENTIAL, INDIRECT OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS, LOSS OF BUSINESS SUPPLIES, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR ANY OTHER PECUNIARY LOSS) ARISING OUT OF THE USE OF OR INABILITY TO USE THE SOFTWARE PRODUCT, EVEN IF USECO HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES AND JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU. 10. Severability. The illegality, invalidity or unenforceability of any one or more of the provisions of this EULA shall not affect the remaining portions of this EULA which shall continue in full force and effect for the full term hereof. YOU AGREE THAT THIS EULA IS THE COMPLETE AND EXCLUSIVE STATEMENT OF THE AGREEMENT BETWEEN YOU AND USECO INVOLVING THE SOFTWARE PRODUCT AND THAT THE PROVISIONS OF THIS EULA SUPERSEDE ANY PROPOSAL, INVOICE TERMS OR PRIOR WRITTEN COMMUNICATIONS BETWEEN YOU AND USECO RELATING TO OR INVOLVING THE SOFTWARE PRODUCT. FCC REQUIREMENTS Compliance Information: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an output on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. 2 USECO: Unitron 7 Installation and Operation Manual, rev. 12/01 Unitron 7 manual.msw UNITRON 7 TM RETHERM SYSTEM_________________________ INSTALLATION AND OPERATION MANUAL_________________ WIRING DIAGRAM

USECO WIRELESS TRANSCEIVER RS-485 IN/OUT TTL / 3.3V TX DATA 9.6KHZ 3.3V / TTL RX DATA RS-485 INTERFACE RF TRANSCEIVER +3.3VDC OUT+5VDC+17VDC IN +5V REGULATOR+3.3V REGULATOR 916.5 MHZ RF MONOLITHICS TR1000 (SEE DATA SHEET FOR INTERNAL CIRCUITRY) TX/RX CONTROL 0.75 MW OUTPUT 9.6 KHZ 9.6 KHZ FROM SERIAL UART URF-001 SGR 1234 A B C D 4321 D C B A Title NumberRevisionSize Letter Date:24-Apr-2002Sheet of File:E:\1PROJ\1USECO\P78Z8\PCB\P78BLK.SCHDrawn By: 120VAC 60HZ IN POWER SUPPLY CPU SECTION Z86E4412FSC 8 MHZ 1.8432 MHZ 4.9152 MHZ RS-485 INTERFACE TL16C550CIPT UART 1.8432 MHZ MODEM INTERFACE TL16C550CIPT UART 2400 BAUD MODEM SI2400 / SI3015 ADDR BUS DATA BUS RJ-11 TELEPHONE JACK TTL SERIAL RS-485 SERIAL915 MHZ RF TRANCEIVER SEE SEPARATE PAGE FOR INTERNAL DIAGRAM 9.6 KHZ 9.6 KHZ 2 MHZ USECO WIRELESS MODEM INTERFACE USE-012-BLK SGR +5VDC +17VDC +17VDC+5VDC +5VDC+5VDC

Authorized Agent: Radiometrics Midwest Corporation (815) 293-0772 – [email protected] External EUT Photographs Equipment Tested (Company, Model) FCC ID: United Service Equipment Co., Unitron P7M-UNITRON

Authorized Agent: Radiometrics Midwest Corporation (815) 293-0772 – [email protected] ID Label/Location Equipment Tested (Company, Model) FCC ID: United Service Equipment Co., Unitron P7M-UNITRON NOTES: Adhesive to be permanent

Authorized Agent: Radiometrics Midwest Corporation (815) 293-0772 – [email protected] Internal EUT Photographs Equipment Tested (Company, Model) FCC ID: United Service Equipment Co., Unitron P7M-UNITRON RF PCB RF PCB and case Authorized Agent: Radiometrics Midwest Corporation (815) 293-0772 – [email protected] Full system; Case open Processor and Modem PCB Processor and Modem PCB

Radiometrics Midwest Corporation (815) 293-0772 – [email protected] OPERATIONAL DESCRIPTION Equipment Tested (Company, Model) FCC ID: United Service Equipment Co., Unitron P7M-UNITRON The Unitron Central Monitoring System is a two-way communications package that monitors the operational status of the Unitron 5 modules or Unitron 7 carts. It affords the user the option to program the individual Unitron Modules or cart from a central location. Observaton and supervision of the Unitron Modules or cart can be performed from a supervisor’s offcie instead of having to inspect the individual modules or carts throughout the facility for operational compliance. The Unitron Monitoring System includes Pentium Computer, Monitor, Printer, Montoring System Software, and Modem(s). The customer is to furnish the telephone line(s), and pager(s) to interact with the system. The output power and modulation technique is .75 milliwatt. The system uses a Rf signal for transmission. The device is in compliance as specified by FCC Title 17 Parts 2 & 15. Transmission is in the 916.5MHz in the North Ameericaon ISM Band, using ook modulation(on off keyed) using a digital signal.

Electromagnetic Compatibility Test Report Tests Performed on a United Service Equipment Co. Transmitter, Model Unitron Radiometrics Document RP-4696 Product Detail: FCC ID: P7M-UNITRON Equipment type: 916.5 MHz; Low-Power Transmitter Test Standards: US CFR Title 47, Chapter I, FCC Part 15 Subpart C FCC Part 15 CFR Title 47: 2001 This report concerns: Original Grant for Certification FCC Part 15.249 Tests Performed For: Test Facility: United Service Equipment Co. 1152 Park Ave Murfreesboro, TN 37129 Phone: 615-893-8432 Radiometrics Midwest Corporation 12 East Devonwood Romeoville, IL 60446 Phone: (815) 293-0772 e-mail: [email protected] Test Date(s): (Month-Day-Year) January 22 and 23, 2002 Document RP-4696 Revisions: Rev. Issue Date Affected Pages Revised By Authorized Signature for Revision 0 February 25, 2002 1 March 20, 2002 All Joseph Strzelecki 2 May 7, 2002 All Joseph Strzelecki RADIOMETRICS MIDWEST CORPORATION - EMC Test Report Equipment Tested (Company, Model, Product Name): Document No.: Page: United Service Equipment Co., Unitron, Transmitter RP-4696 Rev. 1 2 of 13 Table of Contents 1 ADMINISTRATIVE DATA........................................................................................................................3 2 TEST SUMMARY AND RESULTS.........................................................................................................3 3 EQUIPMENT UNDER TEST (EUT) DETAILS.......................................................................................4 3.1 EUT Description..............................................................................................................................4 3.2 Related Submittals..........................................................................................................................4 4 TESTED SYSTEM DETAILS.................................................................................................................4 4.1 Tested System Configuration and Operating Mode........................................................................4 4.2 Special Accessories........................................................................................................................5 4.3 Equipment Modifications..................................................................................................................5 5 TEST SPECIFICATIONS AND RELATED DOCUMENTS....................................................................5 6 RADIOMETRICS’ TEST FACILITIES.....................................................................................................5 7 DEVIATIONS AND EXCLUSIONS FROM THE TEST SPECIFICATIONS............................................6 8 TEST PROCEDURES...........................................................................................................................6 8.1 Radiated RF Emissions Measurement Procedures.......................................................................6 8.1.1 Field Strength Calculation.........................................................................................................7 8.1.2 Conducted Emission Measurement Procedures.....................................................................7 9 CERTIFICATION....................................................................................................................................8 10 TEST EQUIPMENT TABLE.................................................................................................................8 11 TEST SETUP DOCUMENTATION......................................................................................................9 Figure 1. Configuration of Tested System.............................................................................................9 12 OCCUPIED BANDWIDTH DATA.......................................................................................................10 Figure 2. Occupied Bandwidth Plot.....................................................................................................10 13 DETAILED TEST RESULTS.............................................................................................................11 13.1 Radiated Emissions Test Results...............................................................................................11 13.2 Conducted Emission Test Results.............................................................................................12 Notice: This report must not be reproduced (except in full) without the written approval of Radiometrics Midwest Corporation. RADIOMETRICS MIDWEST CORPORATION - EMC Test Report Equipment Tested (Company, Model, Product Name): Document No.: Page: United Service Equipment Co., Unitron, Transmitter RP-4696 Rev. 1 3 of 13 1 ADMINISTRATIVE DATA Equipment Under Test: A United Service Equipment Co., Transmitter Model: Unitron, Serial Number: None This will be referred to as the EUT in this Report Date EUT Received at Radiometrics: (Month-Day-Year) Test Date(s): (Month-Day-Year) December 11, 2001 January 22 and 23, 2002 Test Report Written By: Test Witnessed By: Ron Lazarowicz EMC Technician none Radiometrics’ Personnel Responsible for Test: Test Report Approved By Joseph Strzelecki Senior EMC Engineer NARTE EMC-000877-NE Chris W. Carlson Director of Engineering NARTE EMC-000921-NE 2 TEST SUMMARY AND RESULTS The EUT (Equipment Under Test) is a Transmitter, Model Unitron, manufactured by United Service Equipment Co. The detailed test results are presented in a separate section. The following is a summary of the test results. Emissions Tests Results Environmental Phenomena Frequency Range Basic Standard Test Result RF Radiated Emissions 30 - 9200 MHz FCC Part 15 Pass Conducted Emissions, AC Mains 0.45 - 30 MHz FCC Part 15 Pass Occupied Bandwidth Test 916.5 MHz FCC Part 15 Pass RADIOMETRICS MIDWEST CORPORATION - EMC Test Report Equipment Tested (Company, Model, Product Name): Document No.: Page: United Service Equipment Co., Unitron, Tran…

Text truncated - open the document above for the full version.

Authorized Agent: Radiometrics Midwest Corporation (815) 293-0772 – [email protected] Test Setup Photograph Equipment Tested (Company, Model) FCC ID: United Service Equipment Co., Unitron P7M-Unitron Photograph of Radiated Emissions Test Setup The dates on the photos are incorrect. They should be 1/22/02 for the Radiated and 1/23/02 for the Conducted emissions test. Photograph of Conducted Emissions Test Setup Authorized Agent: Radiometrics Midwest Corporation (815) 293-0772 – [email protected]
