P85KFEFANGTable Lamp

User’s Manual This light device has been tested and found to comply with the limits for Consumer RF Lighting device, pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with is no guarantee that interference will not occur in a particular installation. 1. Use only on 120 volt, 60 hertz. 2. Never disassemble or modify-any changes could void the user’s authority to operate the device. 3. Not for use in totally enclosed fixtures. 4. Risk of electric shock-do not use where directly exposed to water. 5. This device is not intended for use with emergency exit fixtures or emergency exit lights. 6. This product could produce interference when used near a TV, radio, wireless remote control or maritime safely communications equipment or other critical navigation or communication equipment operating between 0.45-30MHz. If interference should occur, move the lamp away from the appliance a distance of three feet or more. Or, plug the lamps or the appliance different outlet. 7. To prevent burns, do not touch the bulb during operation or immediately after switching off. 8. Not for use with dimmers, electronic timer or photocell devices or occupancy sensor. 9. Not for use in totally enclosed recess fixtures. 10. To prevent children from touching the bulb, installed the device higher.

F IGURE 1 T ABLE LAMP (M/N: NO921) G ENERAL A PPEARANCE F IGURE 2 TABLE LAMP (M/N: NO922) G ENERAL A PPEARANCE EUT: Table Lamp M/N: No922 EUT: Table Lamp M /N: No9 21 F IGURE 3 T ABLE LAMP (M/N: NO921) G ENERAL A PPEARANCE (W ITHOUT C OVER ) FIGURE 4 T ABLE L AMP (M/N: N O 922) GENERAL APPEARANCE (WITHOUT COVER) EUT: Table Lamp M/N: No921 EUT: Table Lamp M/N: No922

Label Drawing Fang’s Far East Corp. 120V 60Hz FCC ID: P85KFEFANG

Label Location Information Refer to the below red arrow: (for example) EUT: Table Lamp M /N: No9 21 Fang’s Far East Corp. 120V 60Hz FCC ID:

F IGURE 1 T ABLE LAMP (M/N: NO921) G ENERAL A PPEARANCE (B ALLAST M/N KFE-C22W) F IGURE 2 TABLE LAMP (M/N: NO921) COVER REMOVED#1 (BALLAST M/N KFE-C22W) EUT: Table Lamp M/N: No921 EUT: Table Lamp M/N: No921 F IGURE 3 T ABLE L AMP (M/N: N O 921) C OVER REMOVED#2 (BALLAST M/N KFE-C22W) EUT: Table Lamp M/N: No921 F IGURE 4 T ABLE LAMP (M/N: NO921) M AIN B OARD : C OMPONENT S IDE (B ALLAST M/N KFE-C22W) F IGURE 5 TABLE LAMP (M/N: NO921) M AIN B OARD : S OLDERED S IDE (B ALLAST M/N KFE-C22W) EUT: Table Lamp M/N: No921 EUT: Table Lamp M/N: No921

Schematics

Fang's Far East Corp (B.U.I.) Ltd FCC ID: P85KFEFANG Page 1 of 12 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F02010 Application for FCC Certificate On Behalf of Fang's Far East Corp (B.U.I.) Ltd Table Lamp Model No.: No921 No922 FCC ID : P85KFEFANG Prepared For : Fang's Far East Corp (B.U.I.) Ltd 5F-2, No. 1-93, Wu-Chuan Road, Taichung, Taiwan Prepared By : Audix Technology (Shanghai) Co., Ltd. 3F 34Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233 Tel: +86-21-64955500 Fax: +86-21-64955491 Report No. : ACI-F02010 Date of Test : Feb 5, 2002 Date of Report : Feb 22, 2002 Fang's Far East Corp (B.U.I.) Ltd FCC ID: P85KFEFANG Page 2 of 12 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F02010 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 D ESCRIPTION OF E QUIPMENT U NDER T EST ................................................................................. 4 1.2 DESCRIPTION OF TEST FACILITY.................................................................................................. 4 1.3 M EASUREMENT UNCERTAINTY.................................................................................................... 4 2 AC POWERLINE CONDUCTED EMISSION TEST ................................................................. 5 2.1 T EST E QUIPMENT ........................................................................................................................ 5 2.2 B LOCK D IAGRAM OF T EST S ETUP ................................................................................................ 5 2.3 C ONDUCTED EMISSION LIMITS.................................................................................................... 5 2.4 TEST CONFIGURATION................................................................................................................. 6 2.5 T EST PROCEDURES...................................................................................................................... 6 2.6 OPERATING CONDITION OF EUT ................................................................................................. 6 2.7 T EST R ESULTS ............................................................................................................................. 7 3 FIELD STRENGTH TEST .............................................................................................................8 3.1 T EST E QUIPMENT ........................................................................................................................ 8 3.2 BLOCK DIAGRAM OF TEST SETUP................................................................................................ 8 3.3 T EST C ONFIGURATION ................................................................................................................. 8 3.4 O PERATING CONDITION OF EUT ................................................................................................. 8 3.5 T EST P ROCEDURE ........................................................................................................................ 9 3.6 T EST R ESULT ...............................................................................................................................9 Fang's Far East Corp (B.U.I.) Ltd FCC ID: P85KFEFANG Page 3 of 12 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F02010 TEST REPORT FOR FCC CERTIFICATE Applicant : Fang's Far East Corp (B.U.I.) Ltd Manufacturer : Kuo Han Electronic Co., Ltd EUT Description : Table Lamp (A) Model No.: No921, No922 (B) Serial No.: E01501 (C) Power Supply: 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 18 CONSUMER DEVICES (2000) AND MP-5/1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 RF Lighting Device limits both conducted emissions and field strength. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Feb 5, 2002 Prepared by : Test Engineer : SUE SUN (Assistant) LORENZO CHEN (Engineer) Reviewer : Approved Signatory : BYRON KWO (Supervisor) ALEX CHIU (Assistant Manager) Fang's Far East Corp (B.U.I.) Ltd FCC ID: P85KFEFANG Page 4 of 12 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F02010 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description : Table Lamp (with ballast M/N KFE-C22W) Type of EUT : ; Production … Pre-product … Pro-type Model Number : No921, No922 The above two models are with the same ballast (M/N: KFE-C22W), only the lampbase are different. So only the test data of No921 has been recorded in this report. Applicant : Fang's Far East Corp (B.U.I.) Ltd 5F-2, No.1-93, Wu-Chuan Road, Taichung, Taiwan Manufacturer : Kuohan Electronic Co., Ltd No.5 Weijie Road, Qiao Long Chun, Shun Qiao Zheng, Pudong, Shanghai M/N Apparent Power (VA) Real Power (W) No921 38.1 19.7 1.2 Description of Test Facility Site Description : Sept. 17, 1998 file on (Semi-Anechoic Chamber) Federal Communications Commission FCC Engineering Laboratory 7435 Oakland Mills Road Columbia, MD 21046, USA Name of Firm : Audix Technology (Shanghai) Co., Ltd. Site Location : 3 F 34 Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233 NVLAP Lab Code : 200371-0 1.3 Measurement Uncertainty Conducted Emission Uncertainty : U = ± 2.66 dB Fang's Far East …

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test M/N: NO921 2. Field Strength Test M/N: N O921 EUT: Table Lamp M /N: No9 21
