P8H-LP61SEnergy Saving Lamp

Shenzhen Lapin Lighting Technology Co., Ltd.

Click to zoom

Application Details

Equipment Class: 8CC - Part 18 Consumer Device
Date of Grant: Apr 09, 2002
Application Purpose: Original Equipment
Date of Application: Apr 09, 2002
Equipment Note: Energy Saving Lamp
Frequency Range: 0.05000000 - 0.06500000
Company: Shenzhen Lapin Lighting Technology Co., Ltd.
Country: China
