P9TSHF-999Universal R.F. Handsfree Holder

SpaceLink Technology Corp. 13F-6,No.75,Hsin Tai Wu Road, Sec 1, Shih-Chih, Taipei, Taiwan 7513F6. Tel : 886 2 26983668 Fax : 886 2 26983554 User Menu SHF-999 The SHF-999 is a Radio Band transmitter, it designed for cellular Phones hand free The features 1. Hand isn’t needful while answering a call. 2. Suitable for every kind of mobile phones. 3. Suitable for every kind of cars with cigarette lighter socket 4. Adjustable plug-in head. 5. Phone locks automatically when it touches the holder 6. Simple operation SpaceLink Technology Corp. 13F-6,No.75,Hsin Tai Wu Road, Sec 1, Shih-Chih, Taipei, Taiwan 7513F6. Tel : 886 2 26983668 Fax : 886 2 26983554 How to use the hand free l The unit includes an DC Power supply, Plug the Unit into the Vehicle’s Cigarette Socket l The Power Light on the bottom of the unit will illuminate to indicate the unit is operational. l Place Clip on to Cell Phone Speaker l Tighten the pivoting nut counterclockwise to secure your desired position. l Put your cell phone on the hand free holder cradle. It will automatically clamp-on when touching the button. Set your Radio Frequency to 96.1 FM Universal Design Works with all Types of Cellular Phones SpaceLink Technology Corp. 13F-6,No.75,Hsin Tai Wu Road, Sec 1, Shih-Chih, Taipei, Taiwan 7513F6. Tel : 886 2 26983668 Fax : 886 2 26983554 * Simply Plug the Unit into the Vehicle’s Cigarette Socket * Place Clip on to Cell Phone Speaker * Set your Radio to 96.1 FM * Universal Design Works with all Types of Cellular Phones SPECIFICATION POWER SUPPLY DC 12V IN TRANSMITTER FREQUENCY 96.1 MHZ TRANSMITTER POWER 1 m W CURRENT < 45 m A SpaceLink Technology Corp. 13F-6,No.75,Hsin Tai Wu Road, Sec 1, Shih-Chih, Taipei, Taiwan 7513F6. Tel : 886 2 26983668 Fax : 886 2 26983554 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two condition.(1).this device may not cause harmful interference. (2).this device must accept any interference received, including interference that may cause undesired operation Warning: Note: This equipment has been tested and found to comply with the limits for digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, used and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference in to radiate communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: l Reorient or relocate the receiving antenna l Increase the separation between the equipment and receiver. l Connect the equipment into an outlet on a circuit different form that to which the receiver in connected. l Consult the dealer or an experienced radio/TV technician for help. ’

Photo # 1 Front View / Rear View

NEUTRON EMC LAB. FCC ID : P9TSHF-999 5/18 2. Product Labeling 2-1. FCC ID label The remained portion of label statement required by FCC is attached in the user’s manual. 2-2 Location of Label on EUT 3 cm FCC ID:P9TSHF-999 1cm

Photo # 2 Unit Partially Disassembled Photo # 3 Unit Partially Disassembled 02E2064 02E2064 Photo # 4 Unit Partially Disassembled

SHF-999 SPECIFICATION The Spacelink Technology Corporation. Model: SHF-999 (referred to as the EUT in this report) is a UNIVERSAL R.F. HANDSFREE HOLDER which is used in Car. Simply Plug the Unit into the Vehicle’s Cigarette Socket. Details of technical specification for EUT, refer to the follows: (1) Transmitter Frequency Designation Operating Frequency : 96.1 MHz, 1 channel, 1 mW Max. (2) Modulation: Frequency Modulation (3) Antenna Designation: Non-User Replaceable (Fixed) (4) Power Rating : 12 Vdc Battery Operated ≤ FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two condition.(1).this device may not cause harmful interference. (2).this device must accept any interference received, including interference that may cause undesired operation Warning: Note: This equipment has been tested and found to comply with the limits for digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, used and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference in to radiate communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: l Reorient or relocate the receiving antenna l Increase the separation between the equipment and receiver. l Connect the equipment into an outlet on a circuit different form that to which the receiver in connected. l Consult the dealer or an experienced radio/TV technician for help. THE MANUFACTURER IS NOT RESPONSIBKE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.SUCH ODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. ’

NEUTRON EMC LAB. FCC ID : P9TSHF-999 1/18 MEASUREMENT/TECHNICAL REPORT APPLICANT:Spacelink Technology Corporation MODEL NO.:SHF-999 FCC ID:P9TSHF-999 This report concerns ( check one ) : Original Grant ̧ Class II Change Equipment type: UNIVERSAL R.F. HANDSFREE HOLDER Deferred grant requested per 47CFR 0.457(d)(1)(ii)? Yes No ̧ If yes, defer until: (date) We, the undersigned, agree to notify the Commission by (date) / / of the intended date of announce ment of the product so that the grant can be issued on that date. Transiyion Rules Request per 15.37? Yes No ̧ If no, assumed Part 15, Subpart B for unintentional radiator the new 47 CFR (10-1-90 Edition) provision. Report Prepared by Testing House : Neutron Engineering Inc. for Company :Spacelink Technology Corporation Name Address :No. 75, 13F-6, Sec. 1, Hsin Tai Wu Rd., Shih-Chih City, Taipei Hsien, Taiwan, R.O.C. Applicant Signature : Mark Hu / Marketing Director NEUTRON EMC LAB. FCC ID : P9TSHF-999 2/18 CERTIFICATION We hereby certify that: The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (1992) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15, Subpart C. Prepared by :Carol Chen Reviewed by :Vincent Su Approved by :George Yao Issued Date :Mar. 12, 2002 Report No. :NEI-FCCB-02019 Company Stamp : NEUTRON ENGINEERING INC. No. 132-1, Lane 329, Sec. 2, Palain Rd., Shijr Jen, Taipei, Taiwan TEL(02) 2646-5426 FAX(02) 2646-6815 NEUTRON EMC LAB. FCC ID : P9TSHF-999 3/18 Table of Contents 1.General Information...................................................................................................................... 1-1 Product Description................................................................................................................4 1-2 Related Submittal(s)/Grant(s)..................................................................................................4 1-3 Test Methodology...................................................................................................................4 1-4 Test Facility............................................................................................................................4 2.Product Labeling............................................................................................................................ Figure 2-1 FCC ID Label...............................................................................................................5 Figure 2-2 Location of Label on EUT.........................................................................................5 3.System Test Configuration............................................................................................................ 3-1 EUT Configuration.................................................................................................................6 3-2 EUT Exercise.........................................................................................................................6 3-3 Test Procedure.......................................................................................................................6 3-4 Limitation..............................................................................................................................7 3-5 Special Accessories................................................................................................................7 3-6 Equipment Modifications......................................................................................................7 3-7 Test Set-UP............................................................................................................................8 3-8 Test Equipment........................................................................................................................9 4.Block10 5.Radiated Measurement Photos................................................................................................. Figure 5-1 Radiated Emission ....................................................................................................... 11 6.Radiated Emission Datas .............................................................................................................. 6-1 Reaiated Emission Data...........................................................................................................12 6-2 Field Strength Calculation.......................................................................................................13 6-3 Bandwidth Measurement15 6-4 Emission drawing between 86 and 110 MHz16 7.Attachment Photos of Tested EUT....................................................................................................................17 User Manual.................................................................................................................................18 NEUTRON EMC LAB. FCC ID : P9TSHF-999 4/18 1. GENERAL INFORMATION 1-1. Product Description The Spacelink Technology Corporation. Model: SHF-999 (referred to as the EUT in this report) is a UNIVERSAL R.F. HANDSFREE HOLDER which is used in Car. Simply Plug the Unit into the Vehicle’s Cigarette Socket. Details of technical specification for EUT, refer to the follows: (1) Transmitter Frequency Designation Operating Frequency : 96.1 MHz, 1 channel, 1 mW Max. (2) Modulation: Frequency Modulation (3) Antenna Designation: Non-User Replaceable (Fixed) (4) Power Rating : 12 Vdc A more detailed and/or technical description of EUT is attached in User’s Manual. 1-2. Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended for FCC ID: P9TSHF-999 filing to comply with Section 15.239 of the FCC Part 15, Subpart C Rules. The composite system(including receiver and transmitter) in compliance with Subpart B is authorized …

Text truncated - open the document above for the full version.

NEUTRON ENGINEERING INC. Data#: 2File#: 02E2064.EMIDate: 2002-02-18 Time: 13:41:12 Level (dBuV) 80 40 0 9597 Frequency (MHz)OS02 95969697 Trace:Ref Trace: 1 1 2 3 4 5 Limit : Probe: Operator : James Chiu Project code: 02E2064 E.U.T. : UNIVERSAL R.F HANDSFREE HOLDER Model No. : SHF-999 Test mode : N/A Temp/RH : 25/55 Memo : SR02

NEUTRON EMC LAB. FCC ID : P9TSHF-999 11/18 5-1. Radiated Measurement Photos
