DIGITAL EMC CO., LTD. FCC Class B Certification Test Report No. : DR50110205I Page 1 of 19 FCC ID: PA3SY0205HSCC2 Applicant : SeYoung Communication Co., Ltd 137-130, Damo B/D 2F #289-4 ,Yangjae-Dong, Seocho-Ku, Seoul, Korea Manufacturer : SeYoung Communication Co., Ltd 137-130, Damo B/D 2F #289-4 ,Yangjae-Dong, Seocho-Ku, Seoul, Korea Test Item : CATV Converter FCC ID PA3SY0205HSCC2 Model No. : GS-2 Test Specification : ANSI C 63.4:1992 FCC Part 15 Class B Tested Date : May 23 - 30, 2002 Issued Date : May 31, 2002 Test Result : Passed Tested by : K.T.LEE Name Signature Reviewed by : C.H.AHN Name Signature Other Aspects : Abbreviations : OK, Pass = passed , Fail = failed , N/A = not applicable This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S.Government. DIGITAL EMC CO., LTD. FCC Class B Certification Test Report No. : DR50110205I Page 2 of 19 FCC ID: PA3SY0205HSCC2 TEST SUMMARY The data collected shows that the SeYoung Communication Co., Ltd (Model NO.: GS-2) CATV converter complies with 15.107 and 15.109 of the FCC Rules. The highest emission observed, with a minimum margin to the specifications, was at 4.573MHz for conducted emissions with a margin of 3.9dB, and at 119.73MHz for radiated emissions (Pol.: Vertical, EUT Angle : 108degree , ANT. Height : 100cm)with a margin of 5.5dB. The data and results referenced in this document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities. The measurement uncertainty was calculated for all measurements listed in this test report accdg. to NIS 81 / 5 1994.”. 5.1 CONDUCTED EMISSIONS RESULT : Pass 5.2 RADIATED EMISSIONS RESULT : Pass 5.3 ANTENNA CONDUCTED POWER EMISSIONS RESULT : Pass 5.4 OUTPUT CONDUCTED LEVEL EMISSIONS RESULT : Pass 5.5 ANTENNA TRANSFER SWITCH EMISSIONS RESULT : Pass DIGITAL EMC CO., LTD. FCC Class B Certification Test Report No. : DR50110205I Page 3 of 19 FCC ID: PA3SY0205HSCC2 Contents 1. GENERAL REMARKS -------------------------------------------------------------------------------- 2. TEST SITES ----------------------------------------------------------------------------------------- 2.1 TEST FACILITIES 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS 3. GENERAL PRODUCT INFORMATION --------------------------------------------------------------- 4. TEST SET-UP AND OPERATION MODES ----------------------------------------------------------- 4.1 PRINCIPLE OF CONFIGURATION SELECTION 4.2 TEST OPERATION MODES 4.3 SUPPORT EQUIPMENT USED 5. TEST RESULTS EMISSION -------------------------------------------------------------------------- 5.1 CONDUCTED EMISSIONS ------------------------------------------------------------------------- 5.2 RADIATED EMISSIONS ---------------------------------------------------------------------------- 5.3 ANTENNA CONDUCTED POWER EMISSIONS ----------------------------------------------------- 5.4 OUTPUT CONDUCTED LEVEL EMISSIONS -------------------------------------------------------- 5.5 ANTENNA TRANSFER SWITCH EMISSIONS ------------------------------------------------------ APPENDIX APPENDIX 1 CONDUCTED MEASUREMENT GRAPH ------------------------------------------------ APPENDIX 2 OUTPUT CONDUCTED LEVEL MEASUREMENT GRAPH ---------------------------------- APPENDIX 3 ANTENNA CONDUCTED POWER MEASUREMENT GRAPH ------------------------------ LIST OF TABLES Table 1 : Conducted Emissions Test Data ------------------------------------------------------------ Table 2 : Radiated Emissions Test Data ------------------------------------------------------------- Table 3 : Antenna Conducted power Emissions Test Data ----------------------------------------- Table 4 : Output Conducted level Emissions Test Data ---------------------------------------------- Table 5 : Antenna Transfer Switch Emissions Test Data --------------------------------------------- 4 4 5 6 7-16 7-8 9-10 11-12 13-14 15-16 17 18 19 8 10 12 14 16 DIGITAL EMC CO., LTD. FCC Class B Certification Test Report No. : DR50110205I Page 4 of 19 FCC ID: PA3SY0205HSCC2 1. General Remarks This Report describes the emission characteristics of the tested product. If the product will be used with additional equipment other than those mentioned in this report or if the tested product will be used against the manufacture's specifications, the compliance with the relevant standards for the system has to be ensured. 2. Test Facility 2.1 Test Laboratory Quality control in the testing laboratory is implemented as per ISO/IEC 17025, which is the “General requirements for the competents of calibration and testing laboratory”. This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200559-0. DIGITAL EMC CO., LTD. Address : 683-2, Yubang-Dong, Yongin-Si, Kunggi-Do, Korea. 449-080 http://www.digitalemc.com E-mail : [email protected] Tel: +82-31-321-2664 Fax: +82-31-321-1664 2.2 Measurement Instruments Refer to each item. DIGITAL EMC CO., LTD. FCC Class B Certification Test Report No. : DR50110205I Page 5 of 19 FCC ID: PA3SY0205HSCC2 3. General Product Information PA3SY0205HSCC2 Kind of Equipment : CATV converter FCC ID : PA3SY0205HSCC2 Model Number : GS-2 Serial No. : 030502A RF INPUT/OUTPUT : Input Bandwidth :54MHz~800MHz RF Impedance: 75 Tuner(s)/RF Modulator(s) :SAMSUNG(TSDC-PA13E RF Frequency :60MHz~72MHz RF output Channels :Ch3 or Ch4(Switch selectable) Audio/Video : List of Each OSC or X-tal Freq(1MHz) :12.0MHz Channels :125channels Video signal:EIA Standard NTSC Color Audio signal:BTSC Stereo Power : Power Requirement:AC120V/60Hz Power Consumption : 12W max Mechanical :A/V Cables : Unshielded Power Cord : Unshielded Chassis Type :Metal Dimension(W*H*D) : 298*204*64 Weight : 1.3kg Tested Power Supply : 1 phase 120Vac 60Hz Applicant : SeYoung Communication Co., Ltd Manufacturer : SeYo…

Text truncated - open the document above for the full version.

DIGITAL EMC CO., LTD. FCC Class B Certification Test Report No. : DR50110205I PHOTOGRAPHS Page 1 of 6 FCC ID: PA3SY0205HSCC2 MODEL NO.: GS-2 1. Test setup photograph for Conducted Emission 2. Test setup photograph for Radiated Emission 3. Antenna Conducted Power Emissions 4. Output Conducted level Emissions. 5. Antenna Transfer Switch Emissions DIGITAL EMC CO., LTD. FCC Class B Certification Test Report No. : DR50110205I PHOTOGRAPHS Page 2 of 6 FCC ID: PA3SY0205HSCC2 Test setup photograph for Conducted Emission DIGITAL EMC CO., LTD. FCC Class B Certification Test Report No. : DR50110205I PHOTOGRAPHS Page 3 of 6 FCC ID: PA3SY0205HSCC2 Test setup photograph for Radiated Emission DIGITAL EMC CO., LTD. FCC Class B Certification Test Report No. : DR50110205I PHOTOGRAPHS Page 4 of 6 FCC ID: PA3SY0205HSCC2 Test setup photograph for Antenna Conducted Power Emissions DIGITAL EMC CO., LTD. FCC Class B Certification Test Report No. : DR50110205I PHOTOGRAPHS Page 5 of 6 FCC ID: PA3SY0205HSCC2 Test setup photograph for Output Conducted level Emissions. DIGITAL EMC CO., LTD. FCC Class B Certification Test Report No. : DR50110205I PHOTOGRAPHS Page 6 of 6 FCC ID: PA3SY0205HSCC2 Test setup photograph for Antenna Transfer Switch Emissions.
