PA8EJ309312ETHCSuper Aviator

D:\Ready_To_Convert\Doc\148684.DOC TIMCO TIMCOTIMCO TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: tei@t imcoengr.com May 9, 2001 FCC SUBJECT: ENJOY TOY & HOBBY CORP. FCCID: PA8EJ309312ETHC To Whom It May Concern: 1. Attached you will find new occupied bandwidth plots and a letter describing the changes necessary to make EUT compliant. 2. Attached is tabulated frequency stability data. 3. The modulation is Pulse modulation. 4. The EUT was re-measured per ANSI TIA/EIA 603-1992 and the data is included. 5. The power output of the EUT is 0.0005Watts ERP. 6. The emission designator should have been 8k0K1D, this will be corrected. 7. A new USER MANUAL is attached. Sincerely, Sid Sanders

A. EUT top side view B. EUT bottom side view

Sample of FCC ID Label FCC ID : PA8EJ309312ETHC

A. EUT main board component side B. EUT main board solder side C. EUT inside whole view D. EUT case inside whole view E. EUT bottom open battery case hatch view

*Remark : The transmitter is only for beginner using. To avoid causing the unnecessary confusion. The crystal is fixed. RF Exposure Safety Statements For Radio SAFETY INFORMATION Your wireless handheld portable transceiver contains a low power transmitter. When the transmitter is activated it sends out radio frequency (RF) signals. In August 1996, the Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for hand-held wireless devices. CAUTION: To maintain compliance with the FCC’ s RF exposure

ENJOY TOY & HOBBY CORP. 7F-1, NO. 29, LANE 169, KANG-NING ST., HIS-CHIH, TAIPEI HSIEN, TAIWN, R.O.C. TEL: 886-2-2692-1036; FAX: 886-2-2695-9936 EMAIL ADD: [email protected] Alignment Procedure / Tune up Instructions The transmitter is only for beginner using. To avoid causing the unnecessary confusion. The crystal is fixed.

Certification Application Under Part 95, Subpart E EUT SUPER AVIATOR MODEL EJ-309 FCC ID PA8EJ309312ETHC SRT REPORT # FID0H33 PREPARED FOR ENJOY TOY & HOBBY CORP. 7F-1, NO. 29, LANE 169, KANG NING ST., HIS-CHIH, TAIPEI HSIAN, TAIWAN, R.O.C. EMI TESTING REPORT EUT:SUPER AVIATOR MODEL:EJ-309 Spectrum Research & Testing Lab. FCC ID PA8EJ309312ETHC REPORT# FID0H33 PAGE 2 OF 2 1 FCC ID:PA8EJ309312ETHC PREPARED FOR ENJOY TOY & HOBBY CORP. 7F-1, NO. 29, LANE 169, KANG NING ST., HIS-CHIH, TAIPEI HSIAN, TAIWAN, R.O.C. PREPARED BY SPECTRUM RESEARCH & TESTING LABORATORY INC. NO. 101-10 , LING 8 , SHAN-TONG LI CHUNG – LI CITY , TAOYUAN, TAIWAN , R. O. C. TABLE OF CONTENTS 1. TEST REPORT CERTIFIICATION................................................................ 4 2. TEST STATEMENT 2 . 1 TEST STATEMENT.............................................................................. 5 2 . 2 DEPARTURE FROM DOCUMENT POLICIES, PROCEDURE OR SPECIFICATIONS, TEST STATEMENT....................... 5 3. EUT MODIFICATIONS................................................................................. 6-7 4. RADIATED EMISSION TEST 4 . 1 TEST EQUIPMENT.............................................................................. 8 4 . 2 TEST PROCEDURE............................................................................. 8 4 . 3 TEST SETUP...................................................................................... 9-10 4 . 4 CONFIGURATION OF THE EUT......................................................... 11 4 . 5 EUT OPERATING CONDITION............................................................ 12 Spectrum Research & Testing Lab. FCC ID PA8EJ309312ETHC REPORT# FID0H33 PAGE 3 OF 2 1 4 . 6 EMISSION LIMITS............................................................................... 12 4 . 7 RADIATION EMISSION TEST RESULTS............................................... 13-16 5. BANDWIDTH 5 . 1 LIMIT.................................................................................................. 17 5 . 2 RESULTS.............................................................................................. 17-21 1. TEST REPORT CERTIFICATION APPLICANT ENJOY TOY & HOBBY CORP. ADDRESS 7F-1, NO. 29, LANE 169, KANG NING ST., HIS-CHIH, TAIPEI HSIAN, TAIWAN, R.O.C. EUT DESCRIPTION SUPER AVIATOR (A) POWER SUPPLY FROM BATTERY (B) MODEL EJ-309 (C) FCC ID PA8EJ309312ETHC FINAL TEST DATE 10/04/2000 MEASUREMENT PROCEDURE USED  * PART 95 SUBPART E * TEST PROCEDURE AND DATA ARE TRACEABLE TO NATIONAL OR INTERNATIONAL STANDARDS. Spectrum Research & Testing Lab. FCC ID PA8EJ309312ETHC REPORT# FID0H33 PAGE 4 OF 2 1 We hereby certify that  The measurements contained in this report were made in accordance with the procedures indicated, and the energy emitted by the equipment was found to be within the limits applicable. TESTING ENGINEER DATE Alen Chou\ SUPERVISOR DATE Jesse Ho APPROVED BY DATE Johnson Ho 2. TEST STATEMENT 2 . 1 TEST STATEMENT This letter is to explain the test condition of this project. The EUT be tested as the following status. a. The data was shown in this report reflects the worst case data for the condition as listed above. b. EUT conditions: 1. Operating frequency : 72.01MHz  72.99MHz 2. Four modes were tested : Mode 1 : 72.35MHz Mode 2 : 72.71MHz Mode 3 : 72.87MHz Mode 4 : 72.91MHz 3. Change operating frequency should change crystal. c. NVLAP logo is to be approved by management (it is according to NVLAP requirement if it need) before use. 2 . 2 DEPARTURE FROM DOCUMENT POLICIES, PROCEDURE OR SPECIFICATIONS , THE STATEMNT A . Did have any departure from document policies & procedures or from Spectrum Research & Testing Lab. FCC ID PA8EJ309312ETHC REPORT# FID0H33 PAGE 5 OF 2 1 specifications. Yes , No  .(If yes , the description as below.) B . The certificate and report shall not be reproduced except in full , without the written approval of SRT laboratory. C . The report must not be used by the client to claim product endorsement by NVLAP or any agency the government. D. This product is a prototype product. E. The effect that the results relate only to the items tested. 3. EUT MODIFICATIONS The following accessories were added to the EUT during testing No modification by SRT lab. Spectrum Research & Testing Lab. FCC ID PA8EJ309312ETHC REPORT# FID0H33 PAGE 6 OF 2 1 Spectrum Research & Testing Lab. FCC ID PA8EJ309312ETHC REPORT# FID0H33 PAGE 7 OF 2 1 4. RADIATED EMISSION TEST 4 . 1 TEST EQUIPMENT The following test equipment were used during the radiated emission test : EQIPMENT / FACILITIES SPECIFICA- TIONS MANUFACTUR - ER MODEL # / SERIAL # DATE OF CAL. & CAL. CENTER DUE DATE FINAL TEST TEST RECEIVER 9 KHz TO 2.75 MHz R & S ESVS30/ 830245/012 JULY 2000 ETC 1Y TEST RECEIVER 20 MHz TO 1000 MHz R & S ESVS30/ 841977/003 MARCH 2000 ETC 1Y√ SPECTRUM ANALYZER 100 Hz TO 1500 MHz HP 8568B/ 3019A05294 OCT. 1999 ETC 1Y SPECTRUM ANALYZER 9 KHz TO 22 GHz HP 8593E/ 3322A00670 MARCH 2000 ETC 1Y SIGNAL GENERATOR 9 KHz TO 1080 MHz ROHDE & SCHWARZ SMY01/ 841104/019 MARCH 2000 ETC 1Y√ DIPOLE ANTENNA 28 MHz TO 1000 MHz EMCO 3121C/ 9003-534 MARCH 2000 SRT 1Y DIPOLE ANTENNA 28 MHz TO 1000 MHz EMCO 3121C/ 9611-1239 AUG. 2000 SRT 1Y BI-LOG ANTENNA 26 MHz TO 2000 MHz EMCO 3142/ 9701-1124 JAN. 2000 SRT 1Y√ BI-LOG ANTENNA 26 MHz TO 2000 MHz EMCO 3142/ 9608-1073 AUG. 2000 SRT 1Y BI-LOG ANTENNA 26 MHz TO 1100 MHz EMCO 3143/ 9509-1152 AUG. 2000 SRT 1Y PRE-AMPLIFIER 0.1 MHz TO 1300 MHz HP 8447D/ 2944A08402 MARCH 2000 ETC 1Y PRE-AMPLIFIER 0.1 MHz TO 1300 MHz HP 8447D/ 2944A06412 JULY 2000 ETC 1Y HORN ANTENNA 1 GHz TO 18 GHz EMCO 3115/ 9602-4681 DEC. 1999 ETC 1Y Spectrum Research & Testing Lab. FCC ID PA8EJ309312ETHC REPORT# FID0H33 PAGE 8 OF 2 1 4 . 2 TEST PROCEDURE (1).The EUT was tested according to FCC requirement. The radiated test was performed at SRT lab’s open site. this site is on file with the FCC laboratory division, reference 31040 / SIT. (2).The EUT, peripherals were put on the turntable which…

Text truncated - open the document above for the full version.

1. TEST STATEMENT 2 . 1 TEST STATEMENT This letter is to explain the test condition of this project. The EUT be tested as the following status. a. The data was shown in this report reflects the worst case data for the condition as listed above. b. EUT conditions: 1. Operating frequency : 72.01MHz ― ―― ― 72.99MHz 2. Four modes were tested : Mode 1 : 72.35MHz Mode 2 : 72.71MHz Mode 3 : 72.87MHz Mode 4 : 72.91MHz 3. Change operating frequency should change crystal. c. NVLAP logo is to be approved by management (it is according to NVLAP requirement if it need) before use. Spectrum Research & Testing Lab. FCC ID： ：： ： PA8EJ309312ETHC REPORT#： ：： ： FID0H33 PAGE ： 2 OF 2 1 Temperature Test Results Temperature Deg C Frequency MHz Frequency Increment Hz Stability PPM 25 72.870 000 0.00 0.0 -30 72.870810 810.0 +11.1 -20 72.870 770 770.0 +10.6 -10 72.870 530 530.0 +7.3 0.0 72.870 410 410 +5.6 +10.0 72.870 290 290 +4.0 +20.0 72.870 170 170 +2.3 +30 72.870 040 40 +0.54 +40 72.869 870 -130 -1.8 +50 72.869 720 -280 -3.8 Frequency Stability versus Voltage Voltage VDC Frequency MHz Frequency Increment Hz Stability PPM 13.8 72.870 110 100.0 1.4 10.2 72.869 200 800.0 -11.0 15.9 72.869 080 920.0 -12.6 Spurious Emissions Measured per ANSI/TIA/EIA – 603-1992 Requirement: 56 + 10 log (Po) = 56 +10log(0.0005) = 56 – 33.0 = 23.0dBc Frequency MHz Attenuation dBc 72.35 0.0(Carrier) 36.18 -44.2 108.53 -41.3 144.73 -39.7 398.10 -38.2 542.63 -46.7 723.50 -55.3 Spectrum Research & Testing Lab. FCC ID： ：： ： PA8EJ309312ETHC REPORT#： ：： ： FID0H33 PAGE ： 3 OF 2 1

TIMCO ENGINEERING INC. 849 NW State Road 45 NEWBERRY, FLORIDA 32669 [email protected] 888.472.2424 Mr. Frank Coperich FCC SUBJECT: PA8EJ309312ETHC REFERENCE: TC99825 The pulse train is varied depending on the position of the controls. Attached is a plot of the occupied bandwidth and plots of the worse case pulse train. Thanks for your help. Sincerely, Sid Sanders
