PCWUSET13XXSelf-Ballasted Lamp

INSTRUCTIONS ◎ THE TEXT OF THIS INSTRUCTIONS WILL BE PRINTED ON THE SURFACE OF THE INDIVIDUAL BOX AT THE TIME OF MASS PRODUCTION. 1. PRODUCT SPECIFICATION 1) COMMODITY : SELE-BALLASTED LAMP 2) MODEL NO : USET 2) MODEL NO : 2) MODEL NO : USET 2) MODEL NO : USET13XX 3) CONSUMPTION POWER : 20 W 4) INPUT VOLTAGE : AC 120 V CURRENT : 350mA 5) FREQUENCY OF INPUT LINE : 60 Hz 6) LIFE : 10,000 Hrs 2. USER’ S GUIDE ◎ ELECTRONIC BALLAST ◎ INSTANT ON, FLICKER-FREE AND LIGHT WEIGHT ◎ RELIABLE OPERATING TEMPERATURE RANGE : -10。C TO 40。 1) CAUTION ① DO NOT USE WITH DIMMING CIRCUITS, ELECTRONIC TIMERS OF PHOTOCELL DEVICE. ② DO NOT USE IN TOTALLY ENCLOSED FIXTURES,WHERE EXPOSED TO WEATHER, EMERGENCY EXIT FIXTURES OF LIGHTS. ③ NEVER DISASSEMBLE OF MODIFY THE LAMP. ④ USE ONLY 120V 60 Hz CIRCUITS. ⑤ RISK OF ELECTRIC SHOCK – USE IN DRY LOCATIONS ONLY. ⑥ DO NOT USE MORE THEN 25 LAMPS PER 20 Amp. BRANCH CIRCUIT. ⑦ INSTALL AND REMOVE LAMP FROM FIXTURE BY GRASPING THE PLASTIC BODY. 2) NOTE ① THIS PRODUCT MAY CAUSE RADIO INTERFERENCE WITH RADIOS, CORDLESS PHONES OR REMOTE CONTROL DEVICE. IF INTERFERENCE OCCURS, RELOCATED THIS PRODUCT AWAY FROM THE DEVICE OR REMOVE THIS PRODUCT OUT OF THE LINE OF SIGHT WITH THE REMOTE CONTROL RECEIVER. ② DO NOT TOUCH THE LAMP AS SOON AS TURN OFF BECAUSE IT IS VERY HOT. B BB BLOCK DIAGRAM LOCK DIAGRAMLOCK DIAGRAM LOCK DIAGRAM NAME OF APPLICANT : SK Corporation. NAME OF PRODUCT : SELF-BALLASTED LAMP MODEL NO : USET#13XX AC INPUT OUTPUT LAMP INVERTIER LINE FILTER RECTIFY (HALF WAVE)

INSTRUCTIONS ◎ THE TEXT OF THIS INSTRUCTIONS WILL BE PRINTED ON THE SURFACE OF THE INDIVIDUAL BOX AT THE TIME OF MASS PRODUCTION. 1. PRODUCT SPECIFICATI ON 1) COMMODITY : SELE-BALLASTED LAMP 2) MODEL NO : 2) MODEL NO : USET2) MODEL NO : USET 2) MODEL NO : USET13XX 3) CONSUMPTION POWER : 20 W 4) INPUT VOLTAGE : AC 120 V CURRENT : 350mA 5) FREQUENCY OF INPUT LINE : 60 Hz 6) LIFE : 10,000 Hrs 2. USER’ S GUIDE ◎ ELECTRONIC BALLAST ◎ INSTANT ON, FLICKER-FREE AND LIGHT WEIGHT ◎ RELIABLE OPERATING TEMPERATURE RANGE : -10。C TO 40。 1) CAUTION ① DO NOT USE WITH DIMMING CIRCUITS, ELECTRONIC TIMERS OF PHOTOCELL DEVICE. ② DO NOT USE IN TOTALLY ENCLOSED FIXTURES,WHERE EXPOSED TO WEATHER, EMERGENCY EXIT FIXTURES OF LIGHTS. ③ NEVER DISASSEMBLE OF MODIFY THE LAMP. ④ USE ONLY 120V 60 Hz CIRCUITS. ⑤ RISK OF ELECTRIC SHOCK – USE IN DRY LOCATIONS ONLY. ⑥ DO NOT USE MORE THEN 25 LAMPS PER 20 Amp. BRANCH CIRCUIT. ⑦ INSTALL AND REMOVE LAMP FROM FIXTURE BY GRASPING THE PLASTIC BODY. 2) NOTE ① THIS PRODUCT MAY CAUSE RADIO INTERFERENCE WITH RADIOS, CORDLESS PHONES OR REMOTE CONTROL DEVICE. IF INTERFERENCE OCCURS, RELOCATED THIS PRODUCT AWAY FROM THE DEVICE OR REMOVE THIS PRODUCT OUT OF THE LINE OF SIGHT WITH THE REMOTE CONTROL RECEIVER. ② DO NOT TOUCH THE LAMP AS SOON AS TURN OFF BECAUSE IT IS VERY HOT. B BB BLOCK DIAGRAM LOCK DIAGRAMLOCK DIAGRAM LOCK DIAGRAM NAME OF APPLICANT : SK Corporation. NAME OF PRODUCT : SELF-BALLASTED LAMP MODEL NO : USET#13XX AC INPUT OUTPUT LAMP INVERTIER LINE FILTER RECTIFY (HALF WAVE)

SK TECH CO., LTD. Page 1 of 2 SKT SKTOS-00148 FCC ID : PCWUSET13XX External Photographs of EUT SK TECH CO., LTD. Page 2 of 2 SKT SKTOS-00148 FCC ID : PCWUSET13XX

SK TECH CO., LTD. Page 1 of 1 SKT SKTOS-00148 FCC ID : PCWUSET13XX FCC ID Sample Label & Location Information LABELLING REQUIREMENTS PER ∫∫∫∫ ∫∫∫∫∫∫∫∫ ∫∫∫∫2.928 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. FCC ID : PCWUSET13XX

SK TECH CO., LTD. Page 1 of 1 SKT SKTOS-00148 FCC ID : PCWUSET13XX FCC ID Label Sample

SK TECH CO., LTD. Page 1 of 2 SKT SKTOS-00148 FCC ID : PCWUSET13XX Internal Photographs of EUT SK TECH CO., LTD. Page 2 of 2 SKT SKTOS-00148 FCC ID : PCWUSET13XX

SK TECH CO., LTD. Page 1 of 12 SKT SKTOS-00148 FCC ID : PCWUSET13XX Certificate of Compliance Test Report No.: SKTOS-00148 NVLAP CODE : 200220-0 Applicant: SK Corporation Applicant Address: 16-1, Gusu-Dong, Mapo-Gu, Seoul, Korea Product: SELF-BALLASTED LAMP FCC ID: PCWUSET13XX Model No.: USET13XX Receipt No.: SKE20001027-781 Date of receipt: Oct. 27, 2000 Date of Issue: Nov. 17, 2000 Testing location: SK TECH CO., LTD. 820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea Test Standards: FCC/OET MP-5 Rule Parts: FCC part 18 Equipment Class : RF lighting devices ( Consumer Equipment ) Test Result: The above mentioned product has been tested and passed. Prepared by:Y.H. Kang Tested by:K.H.Nam/Engineer Approved by: J.Y.Hyun /Lab.Manager Signature Date Signature Date Signature Date Other Aspects : Abbreviations : · OK, Pass = passed · Fail = failed · N/A = not applicable ☞ ☞☞ ☞ •This test report is not permitted to copy partly without our permission. •This test result is dependent on only equipment to be used. •This test result is based on a single evaluation of one sample of the above mentioned. •This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S Government. • We certify that this test report has been based on the measurement standards that is traceable to the national or International standards. NVLAP Lab. Code: 200220-0 SK TECH CO., LTD. Page 2 of 12 SKT SKTOS-00148 FCC ID : PCWUSET13XX 》》 》》》》 》》 Contents 《《 《《《《 《《 Contents 2 List of Tables 2 List of Figures 2 List of Photographs 2 1. General 3 2. Test Site 3 2.1 Location 3 2.2 List of Test and Measurement Instruments 4 2.3 Test Data 4 2.4 Test Environment 4 3. Description of the tested samples 5 3.1 Rating and Physical characteristics 5 3.2 Submitted documents 5 4. Measurement conditions 6 4.1 Modes of operation 6 4.2 List of Peripherals 6 4.3 Type of Used cables 6 4.4 Test Setup 6 4.5 Uncertainty 6 5. Emission Test 7 5.1 Conducted Emissions 7 5.2 Radiated Emissions 11 》 》》 》List of Tables Table 1 List of test and measurement equipment 4 Table 2 Test Data, Conducted Emissions 10 Table 3 Test Data, Radiated Emissions 12 》 》》 》List of Figures Figure 1 Spectral Diagram, LINE-PE 8 Figure 2 Spectral Diagram, Neutral-PE 9 SK TECH CO., LTD. Page 3 of 12 SKT SKTOS-00148 FCC ID : PCWUSET13XX 1. General This equipment has been shown to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by SK Tech Co., Ltd. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site SK TECH Co., Ltd. 2.1 Location 820-2, Wolmoon Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea The test site is in compliance with ANSI C63.4/1992 for measurement of radio interference. SK TECH CO., LTD. Page 4 of 12 SKT SKTOS-00148 FCC ID : PCWUSET13XX 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equipment z Conducted Emissions Kind of Equipment Type S/N Calibrated until Field Strength Meter ESHS 10 862970/019 04.2001 LISN KNW-407 M63284 07.2001 LISN ESH2-Z5 862060/029 06.2001 Conducted Cable N/A N/A 07.2001 z Radiated Emissions Kind of Equipment Type S/N Calibrated until Field Strength Meter ESVS 10 825120/013 04.2001 Spectrum Analyzer R3361A 11730187 07.2001 Amplifier 8447F 3113A05153 05.2001 Log Periodic Antenna UHALP9107 91071238 04.2001 Biconical Antenna BBA9106 N/A 04.2001 Open Site Cable N/A N/A 07.2001 Antenna Mast 5907 N/A N/A Antenna & Turntable controller 5906 91X519 N/A Amp & Receiver connection cable N/A N/A 07.2001 Amp & Spectrum connection cable N/A N/A 07.2001 50Ω Switcher MP59B M93083 07.2001 2.3 Test Date Date of Application : Oct. 27, 2000 Date of Test : Oct. 30, 2000 2.4 Test Environment See each test item’s description. SK TECH CO., LTD. Page 5 of 12 SKT SKTOS-00148 FCC ID : PCWUSET13XX 3. Description of the tested samples The EUT is Self-Ballasted Lamp. 3.1 Rating and Physical Characteristics • Consumption Power : 20W • Input Voltage : AC 120V • Frequency of input line : 60Hz 3.2 Submitted Documents N/A SK TECH CO., LTD. Page 6 of 12 SKT SKTOS-00148 FCC ID : PCWUSET13XX 4. Measurement Conditions Testing Input Voltage : AC 120V, 60Hz 4.1 Modes of Operation The EUT was in the following operation mode during all testing; After warming up time of 30 minutes, Testing in mode of Lamp on. 4.2 List of Peripherals Description Manufacturer Model Name Serial No. FCC ID None 4.3 Type of Used Cables Description Length Type of shield Manufacturer Remark None 4.4 Test Setup The test setup photographs showed the external supply connections and interfaces. 4.5 Uncertainty 1) Radiated disturbance Uc (Combined standard Uncertainty) = ±1.9dB Expanded uncertainty U = KUc K = 2 ∴ U = ±3.8dB 2) Conducted disturbance Uc = ±0.88dB U = KUc = 2xUc = ±1.8dB SK TECH CO., LTD. Page 7 of 12 SKT SKTOS-00148 FCC ID : PCWUSET13XX 5. EMISSION Test 5.1 Conducted Emissions Result: Pass The line-conducted facility is located inside a 2.0M x 3.6M x 7.2M shielded enclosure. The shielding effectiveness of the shielded room is in accordance with MIL-Std-285 or NSA 604-05. A 1m x 1.5m wooden table 40cm. high is placed 40cm. away from the vertical wall and 1.5m away from the side wall of the shielded room. Kyoritsu Model KNW-407 (10kHz-30MHz) 50ohm/50 uH Line-Impedance Stabilization Networks(LISNs) are bonded to the shielded room. The EUT is powered from the Kyoritsu LISN and the support equipment is powered from the Kyoritsu LISN. Power to the LISNs are filtered by a high-current high-insertion loss Lindgren enclosures power line filters (100dB 14kHz-10GHz). The purpose of the filter is to attenuate ambient signal interference and this filter is also bonded to the shielded enclosure. All…

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 2 SKT SKTOS-00148 FCC ID : PCWUSET13XX Test set up photos Photograph 1: Setup for Conducted Emissions SK TECH CO., LTD. Page 2 of 2 SKT SKTOS-00148 FCC ID : PCWUSET13XX Photograph 2: Setup for Radiated Emissions
