PE8YK9120K2.4GHz wireless CCD Camera & Portable DVR

PORTABLE SECURITY RECORDER KIT USER MANUAL CONTENTS 1. SAFETY PRECAUTIONS........................................................................................................2 2. FEATURES................................................................................................................................. 3 3. PACKING LIST.........................................................................................................................4 4. NAME AND FUNCTION OF EACH PART...........................................................................5 4.1 MPEG4 DVR - FRONT VIEW....................................................................................................5 4.2 MPEG4 DVR – SIDE VIEW....................................................................................................6 4.3 IR CAMERA – FRONT VIEW.....................................................................................................7 4.4 IR CAMERA – BACK VIEW......................................................................................................7 5. CONFIGURATION...................................................................................................................8 6. OPERATION..............................................................................................................................9 6.1 POWER ON..............................................................................................................................9 6.2 LIVE MODE.............................................................................................................................9 6.3 RECORD MODE.....................................................................................................................10 6.4 PLAYBACK MODE..................................................................................................................11 6.5 PC PLAYBACK.......................................................................................................................13 6.6 CF CARD MAINTENANCE......................................................................................................13 6.7 HOW TO DOWNLOAD THE UPDATE SOFTWARE.......................................................................13 7. MENU SETUP..........................................................................................................................14 7.1 MAIN MENU..........................................................................................................................14 7.2 DATE/TIME............................................................................................................................14 7.3 MOTION DETECTION.............................................................................................................15 7.4 RECORD SETUP.....................................................................................................................16 7.5 CF CARD FUNCTION.............................................................................................................17 7.6 SYSTEM STAT U S DISPLAY......................................................................................................17 7.7 POWER ON SETUP.................................................................................................................18 7.8 RETURN TO FACTORY DEFAULT VALUE.................................................................................18 8. SPECIFICATION....................................................................................................................19 8.1 WIRELESS MPEG4 DVR......................................................................................................19 8.2 WIRELESS IR CAMERA..........................................................................................................20 9. TROUBLESHOOTING..........................................................................................................21 The author assumes no responsibility for any errors or omissions that may appear in this document nor does it make a commitment to update the information herein. 1 2005/07/12, Ver.: 1.0, P/N: 040099/1 1. SAFETY PRECAUTIONS WARNING: The lightning flash with an arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of un-insulated “dangerous voltage”. CAUTION: The exclamation point within an equilateral triangle is intended to alert the user to presence of important operating and maintenance. Do not Plug and unplug the power cord, it may result product malfunction. Do not install the product in an environment where the humidity is high. Unless the product is waterproof or weatherproof, otherwise poor image quality may occur. Do not drop the product or subject them to physical shocks. Except for vandal-proof or shockproof product, otherwise malfunctions may occur. Never keep the product to direct strong light. It can damage the product. Do not spill liquid of any kind on the product. If it gets wet, wipe it dry immediately. Alcohol or beverage can contain minerals that corrode the electronic components. Do not install the product in extreme temperature conditions. Use the camera under conditions where temperatures are between 0∘C (32∘ F ) ~ 4 5∘C.(113∘ F ) . Be especially careful to provide ventilation when operating under high temperatures. Do not replace or remove the antenna at will. It can damage the product. 2 2. FEATURES z The kit includes one MPEG4 DVR and one camera both build in 2.4 GHz wireless modules. The effective wireless transmission range of audio/video signal up to 50 M in open area. z The camera builds in IR LED whose effective lighting distance is around 5 M. The video image is distinguishable even at dark place. z The portable DVR builds in 2.5” Color TFT-LCD panel, speaker, and 4xAA battery power supply. There is no limitation for the place you can see the video and hear the voice wireless transmitted from…
