PFDCL-2200XPWireless Phone

EXHIBIT C User Manual TABLE OF CONTENTS IMPORTANT SAFTY INSTRUCTIONS LOCATION AND DISCRIPTION OF CONTROLS Base unit(Desk-top) Base unit(Wall-mount) Handset Charger stand INSTALLATION Base unit Handset Charger stand Batteries LCD DISPLAY & MESSAGE OPERATION Turn ON/OFF Making calls Answering calls Last number redial Speed dial mode Call Transfer Intercom Group paging Transmitting (TX) power control Volume control Voice scramble Free channel scan on handset Talking time control Handset microphone sensitivity adjustment PABX (multi-base) operation PPOGRAMING INSTRUCTION Introduction Base unit Handset DISA AND DIGITAL ANSWERING MACHINE Introduction Outgoing messages DISA operation Voice mail operation Listen to Message and Delete Message Memo Message Option Important TIPS FOR OPERATION PROBLEM 1 2 3 4 5 6 7 7 8 9~10 11 11 11 11 12 12 13 13 13 13 13 14 14 14 14 15 16 17 18 18 19 20 20 21 21 22 Thank you for purchasing “Voyager” Cordless Telephone System. To ensure that you enjoy the full capacities of this product, please read this user’s manual before operating. IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. Read and follow all instructions carefully. 2. Follow all warning and instructions on the product. 3. Unplug this product from the host telephone equipment before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 4. Do not use this product near water. 5. Do not place this product on top of metal surface or an unstable cart, stand, or table. 6. Do not allow anything to rest on the power cords. Do not locate this product where the cords will be abused by person’s walking on them. 7. Do not use this product in the vicinity of gas leak or any explosive fumes. To report such a hazardous condition, use a telephone away from the area in question. 8. Do not place this product near or over a radiator or heat source. 9. This product should only be operated with the Mains Power Unit supplied. 10. Do not overload the Mains wall outlets and extension cords as this can result in a risk of fire or electric shock. 11. Do not open this product. No user serviceable parts are inside. Take it to a qualified serviceman when service or repair work is required. Opening the product may expose yourself to dangerous voltage or other risks. Incorrect reassemble may result in electric shock when the product is subsequently used. 12. Never spill liquid on the product or push object of any kind through its ventilation slots. 13. Avoid using this product during an electrical storm. There may be a remote risk of electrical shock from lighting. 14. Use only the recommended by the manufacturer and only with the equipment provided by the manufacture. Do not break open batteries or bum them. Dispose of batteries safely. Batteries contain materials that are hazardous to persons and the environment. 1 CONTROL PANEL INDICATION Base unit (Desk-top) 1. Fixed antenna 2. Telephone jack 3. CO Line jack 4. DC power jack 5. Speaker 6. LCD Display 7. “OK”: OK(Confirm/Send) key 8. “HOLD” key 9. “C”: C(Clear/End) key 10. Dialing keys 11. Function keys MENU: Function select key F’SH: Flash key /Back space while dialing R/P: Redial/Pause key INT: Intercom key CID: Caller ID operation /Store and recall speed dial number. DAM: Digital answering Machine operation : Volume & select up key Volume & select down key 12. Microphone 13. Charging contact point (for charge handset) 2 Base unit (Wall-mount) 1. Fixed antenna 2. Telephone jack 3. CO. Line jack 4. Line slot 5. DC power jack 6. Connecting slot 7. Speaker 8. Display 9. “C“: C(Clear/End) key 10. Hold key 11. “OK”: OK(Confirm/Send) key 12. Dialing keys 13. Function keys MENU: Function select key F’SH: Flash key / back space While dialing R/P: Redial/Pause key INT: Intercom key CID: Caller ID operation/ Store And recall speed dial Number. DAM: Digital answering Machine : Volume & select up key Volume & select down key 14. Microphone 3 Handset 1. Fixed antenna 2. Speaker 3. LCD Display 4. Function keys OK: OK(Confirm/Send) key CO / SCN: CO key at Standby/Scan clear channel while talking C: Clear (End) key DAM / F’SH: Flash key / Back space while dialing / DAM view function at standby MIC / HOLD: Hold key/ Microphone sensitivity adjustment at standby INT: Intercom key SCR / MENU: Voice scramble operation / Function key MEMO: Store key R/P: Redial/Pause key : Volume & select up key Volume & select down key 5. Dialing keys 6. Microphone 7. Releasing latch 8. Battery charging contact point 9. Ringer 10. Audio jack 11. Battery pack *CO: for wireless PBX operation, please refer to operation section. 4 Charger Stand 1. Power indicator 2. Handset charging indicator (front slot) 3. Battery charging indicator (rear slot) 4. Charging cradle for handset 5. Charging slot for spare battery 6. DC power jack 7. Discharge button 8. Discharge indicator 5 INSTALLATION BASE UNIT 1. Gently rotate the flexible base antenna until it is positioned vertically. Note: Incorrect installation of the antennas will affect the communication range. 2. Connect the telephone line cord supplied. Plug one end into the RJ11 jack marked "LINE" at the back of the base unit and the other end into the power outlet. 3. Connect the Mains Power adapter supplied. Plug one end of the adapter into the 120/230V AC power socket and insert its mini-plug into the DC power socket at the back of the base unit. The base unit will show “STBY ICM”(standby) on LCD display when power is connected. Note: Use only the adapter supplied. Use of any other adapter could cause serious damage to the base unit 4. The system is preset for Tone dialing. Changing to Pulse dialing can be adjusted in some countries – refer to “Programming Instruction”. 5. It is allowed to connect a telephone to the base by connecting a line cord into the “TEL” jack. (Telephone se…

Text truncated - open the document above for the full version.

EXHIBIT E Block Diagram

List of Exhibit EXHIBIT A Sample Label EXHIBIT B Test Report EXHIBIT C User Manual EXHIBIT D Circuit Diagram EXHIBIT E Block Diagram EXHIBIT F Photographs of EUT EXHIBIT A Sample Label LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID : PFDCL-2200XP Model No.: CL-2200XP LABEL Size: 45 X20 mm LABEL Position: LABEL LABEL

EXHIBIT F Photographs of EUT

EXHIBIT D Circuit Diagram

EXHIBIT B Test Report Test Report --------------------------------------------------------------------------------- 1/41 Report No.: AA115085, Wireless Phone, FCC Part 15 Class B Test date: 12/13/2000, Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 MEASUREMENT REPORT of WIRELESS PHONE Applicant : ANCO Communication & Electronics Co. Model No. : CL-2200XP EUT : Wireless Phone FCC ID : PFDCL-2200XP Report No. : AA115085 Test by : Training Research Co., Ltd. TEL : 886-2-26935155 FAX : 886-2-26934440 2, Lane 194, Huan-Ho Street, Hsichih, Taipei Hsien 221, Taiwan, R.O.C. Test Report --------------------------------------------------------------------------------- 3/41 Report No.: AA115085, Wireless Phone, FCC Part 15 Class B Test date: 12/13/2000, Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 Tables of Contents I. GENERAL 1.1 Introduction ...................................................................................................................... 5 1.2 Description of EUT ........................................................................................................... 5 1.3 Description of Support Equipment ..................................................................................... 5 1.4 Configuration of System Under Test .................................................................................. 6 1.5 Test Procedure ................................................................................................................. 6 1.6 Location of the Test Site .................................................................................................... 6 1.7 General Test Condition ...................................................................................................... 7 II. Conducted Emissions Measurements 2.1 Test Condition & Setup .................................................................................................... 8 2.2 List of Test Instruments ..................................................................................................... 8 2.3 Test Configuration ............................................................................................................ 9 2.4 Test Result of Conducted Emissions ................................................................................. 12 III. Radiated Emissions Measurements 3.1 Test Condition & Setup ................................................................................................... 16 3.2 List of Test Instruments .................................................................................................... 17 3.3 Test Instruments Configuration ......................................................................................... 18 3.4 Test Result of Radiated Emissions .................................................................................... 20 3.5 Test Result of Spurious Radiated Emissions ...................................................................... 21 IV. Verify Frequencies and Channels .................................................................................... 37 TABLES Table 1 Power Line Conducted Emissions [Channel 1].......................................................... 12 Table 2 Power Line Conducted Emissions [Channel 68]........................................................ 13 Table 3 Power Line Conducted Emissions [Linking].............................................................. 14 Table 4 Open Field Fundamental Emissions ........................................................................ 19 Test Report --------------------------------------------------------------------------------- 4/41 Report No.: AA115085, Wireless Phone, FCC Part 15 Class B Test date: 12/13/2000, Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 Table 5 Open Field Radiated Emissions [Base Channel 01 Horizontal 30MHz 1GHz].................................................... 20 Table 6 Open Field Radiated Emissions [Base Channel 01 Horizontal 1GHz 18GHz] ................................................... 21 Table 7 Open Field Radiated Emissions [Base Channel 01 Vertical 30MHz 1GHz] ...................................................... 22 Table 8 Open Field Radiated Emissions [Base Channel 01 Vertical 1GHz 18GHz] ...................................................... 23 Table 9 Open Field Radiated Emissions [Base Channel 68 Horizontal 30MHz 1GHz] .................................................. 24 Table 10 Open Field Radiated Emissions [Base Channel 68 Horizontal 1GHz 18GHz] ................................................... 25 Table 11 Open Field Radiated Emissions [Base Channel 68 Vertical 30MHz 1GHz]........................................................ 26 Table 12 Open Field Radiated Emissions [Base Channel 68 Vertical 1GHz 18GHz] ...................................................... 27 Table 13 Open Field Radiated Emissions [Handset Channel 01 Horizontal 30MHz 1GHz]............................................... 28 Table 14 Open Field Radiated Emissions [Handset Channel 01 Horizontal 1GHz 18GHz]................................................ 29 Table 15 Open Field Radiated Emissions [Handset Channel 01 Vertical 30MHz 1GHz]................................................... 30 Table 16 Open Field Radiated Emissions [Handset Channel 01 Vertical 1GHz 18GHz]................................................... 31 Table 17 Open Field Radiated Emissions [Handset Channel 68 Horizontal 30MHz 1GHz]............................................... 32 Table 18 Open Field Radiated Emissions [Handset Channel 68 Horizontal 1GHz 18GHz]................................................ 33 Table 19 Open Field Radiated Emissions [Handset Channel 68 Vertical 30MHz 1GHz]................................................... 34 Table 20 Open Field Radiated Emissions [Handset Channel 68 Vertical 1GHz 18GHz]................................................... 35 Appen…

Text truncated - open the document above for the full version.
