PI8SG501GTS Belt Tracking System

SkyGuard 500 Superior tracking for real-time monitoring SkyGuard 500 Superior tracking for real-time monitoring © 2001 Continental Divide Robotics, Inc. All Rights Reserved Printed in USA Document version 0.2 SkyGuard version 0.1 CDR prepared this manual for use by BI customers only. All comments concerning the contents of this manual should be directed to BI’s Marketing Department, 6400 Lookout Road, Boulder, CO 80301, USA. No part of this work covered by copyright may be reproduced in any form either graphically, electronically, mechanically; including photocopying, recording, taping, or storage in an information retrieval system without prior written permission from BI. Trademarks and Patents The following are registered trademarks of BI Incorporated: • BI • BI logo • BI SkyGuard 500 Base Station • BI SkyGuard 500 Transmitter • BI SkyGuard 500 Tracking Pack 3 Contents System overview _________________________________________ 1 How reliable is SkyGuard 500? ____________________________ 6 Benefits _________________________________________________ 8 If you’re familiar with tracking ... _________________________ 9 SkyGuard 500 in action__________________________________ 11 What are the officer’s responsibilities? ____________________ 15 Training and Support ___________________________________ 16 SkyGuard 500: System Overview Offender wears transmitter and tracking pack Position information is sent from GPS satellite to the offender’s tracking pack Tracking pack communicates with cell towers, which in turn communicates with the Internet Internet Central Monitoring Station (CMS) stores information received from the base station and tracking pack Officer uses an Internet connection to monitor offenders through GTS software Base station charges tracking pack and sends information to the CMS throu gh a phone line Transmitter Tracking pack 1 System overview SkyGuard 500™ is a state-of-the-art tracking system that continuously monitors the location of offenders 24 hours a day. Using sophisticated Global Positioning Satellite (GPS) technology, SkyGuard 500 provides timely information about an offender’s location, as well as his or her compliance with established boundaries and curfews. Corrections officers can monitor offenders from multiple locations, such as home, office, or car. The SkyGuard 500 consists of five main components: !"SkyGuard 500 Central Monitoring Station (CMS) !"SkyGuard 500 Transmitter (transmitter) !"SkyGuard 500 Tracking Pack (tracking pack) !"SkyGuard 500 Base Station (base station) !"SkyGuard 500 Global Tracking System (GTS) software 2 Central Monitoring Station The SkyGuard 500 Central Monitoring Station (CMS) is the heart of the tracking system. It performs the following functions: !"Stores the SkyGuard database and processes information received from the base station and tracking pack !"Generates alerts if it detects that someone has tampered with the transmitter, base station, or tracking pack. !"Automatically reports violations in the form of an alert. For example, if an offender leaves the house outside the permitted time, the base station sends this information to the CMS, which alerts you via pager or e-mail. Transmitter The transmitter is a waterproof, battery-operated bracelet that the offender wears around the ankle or wrist. It sends a signal to the belt pack, which recognizes the proximity of the transmitter, as well as the transmitter’s identification number, tamper condition, and battery status. Transmitter features include: !"Low-power, radio-frequency transmissions !"Field-replaceable battery !"Adjustable, hypo-allergenic, replaceable strap !"Waterproof to 15 feet !"Multiple tamper and low-battery sensors !"Weighs less than four ounces 3 !"Automatic tamper reset !"Encrypted transmissions which prevent signal replication Tracking Pack The SkyGuard 500 Tracking Pack is a battery-operated unit enclosed in a shoulder bag and typically worn on the offender’s body. Although the offender is not required to wear the tracking pack, to avoid an alert from being generated, the transmitter and tracking pack must remain within 30 feet of each other at all times. The tracking pack battery lasts approximately 16 hours and must be charged at the end of every day; the battery is charged by plugging the unit into the base station. The tracking pack is capable of storing position information about the offender. Therefore, if an offender’s position cannot be continuously monitored because of inconsistent cellular coverage, the tracking pack records GPS coverage information. This information is transmitted to the CMS when the offender plugs the tracking pack into the base station at the end of the day or when the tracking pack reenters cellular range. 4 Base Station The SkyGuard 500 Base Station is the link to the offender, while he or she is at home (wearing the transmitter), and the central monitoring station The base station is installed in the offender’s home and is connected to the home phone line. The offender uses the base station to charge the tracking pack battery. When an offender returns to his home at the end of the day, he or she plugs the unit into the base station and the tracking pack battery is recharged. Additionally, the base station transmits any information stored in the tracking pack to the CMS via the phone line. Features of the SkyGuard 500 Base Station include: !"Tamper detection sensors discourage unauthorized removal !"Back up battery that operates for up to 36 hours in the event of a power failure !"Detects up to 10 transmitters at one time !"Easy-to-configure, pro-active alert notification system !"Ability to define restriction zones 5 SkyGuard 500 Global Tracking System software The SkyGuard 500 GTS software lets you track offenders by accessing the application through your Internet browser. This means you can get position updates from any computer with an Internet connection – at home, in the office, even in your car. The software provides the fo…

Text truncated - open the document above for the full version.

March 19, 2001 Federal Communications Commission Authorization and Evaluation Division Laboratory Division 7435 Oakland Mills Road Columbia, MD 21046 We, the undersigned, hereby authorize Intertek Testing Services to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by Intertek Testing Services on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to the applications authorized hereunder is subject to denial of benefIts, that includes FCC benefIts, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C. 853(a). Director of Operations Continental Divide Robotics, Inc. EJS.wo 5255 S. Rio Grande Street Littleton, CO 80120 303-409-2990 fax: 303-707-0754

March 19, 2001 Federal Communications Commission Authorization and Evaluation Division Laboratory Division 7435 Oakland Mills Road Columbia, MD 21046 Re: SkyGuard 500, SG501 Request for withholding from public proprietary information pursuant to an application for certification of a Skyguard 500. Dear Sir or Madam Continental Divide Robotics, Inc. re!quest that certain materials submitted with this application for certification of the Model SG501 be withheld from public disclosure. This request is made under the provision s of Section O.457(d) of the Commission's Rule and Section 552 (b) (4) of the Freedom of Information Act, Trade Secrets. : The items marked "Confidential" j::ontain detailed block diagrams, schematics diagrams, word documents, and detailed theory of operation submitted to the FCC for review with this application. The information in this envelope contains proprietary information (trade secrets) regarding the circuit operation and capabilities (specific values of components, circuit design details and system architecture), which are the result of our extensive investment in research and development. Without the disclosed information, competitivE~ organizations would take considerable more time to assess and develop a workable competitive pro,duct. As a result, we believe that disclosure of these company guarded materials would compromise~ our leading position in this market. We therefore formally request that the materials named below that are contained in this envelope be kept strictly confidential and not made available for inspection by any other party, except on a need to know basis for the sole purpose of thE~ certification process. Be:tTagBOM -3.1- 021902.pdf Mic;rosoft Word -GTS Theory of Operations.pdf Mic;rosoft Word -Intro-vO.2pdf Mic;rosoft Word -OficersGuide-vO.2.pdf Mic;rosoft Word -SysAdminGuide-draft1.pdf Production 2 BeItT AGA6.pdf Enclosed Marked CD containing the above files Director of Operations Continental Divide Robotics, Inc. EJS.wo Enclosures 5255 S. Rio Grande Street Littleton, GO 80120 303-409-2990 fax: 303-707-0754

March 19, 2001 Statement of Compliance with Ele<:tronic Serial Number (ESN) regulations The Electronic Serial Number (ESN) of the SkyGuard 500 model SG501 is set in the factory and a unique value is given to each device. The memory device storing the ESN is permanently soldered to the main circuit board. An encrypted version of the ESN is also stored in a different location in memory. Upon power up, the phone's microprocessor regenerates an encrypted version for the ESN locally using a proprietary algorithm and key known only to Sierra Wireless and compares it to the encrypted version in memory. If these values do not match, the phone is completely disabled and cannot be used in anyway. The ESN can be set only by configuration and maintenance personnel, and otherwise cannot be altered. transferred, removed, or otherwise manipulated. Any attempt to alter the ESN number or tamper with the firmware will render the phone inoperative. i 5255 S. Rio Grande Street Littleton, GO 80120 303-409-2990 fax: 303-707-0~54

March 19, 2001 IESN Protection Description The following measures have been taken to protect against fraud due to modification of the ESN or telephone software, in compliance with CF47, 22.919 ( 1) the stored ESN data in the FLASH device (which contains the information other than the ESN data) is encrypted. This ESN data is divided into four groups and interleaved with other data in the FLASH. (2) The ESN is never transferred in a readable format across wires on the print~ circuit board, nor can the ESN be read by probing the pins of any device. (3) If the NVM (or data in FLASH) is altered, then the ESN becomes invalid and the phone will not operate. (4) The FLASH device containing the main program software and encrypted ES~ data, is permanently attached t the circuit board by soldering. (5) The ESN write and change must be carried out at one of our manufacturing $ites using a dedicated interface tool using special software, and interface box, and a PC. This interface tool will not be supplied to and vendor/distributor. (6) To prevent fraudulent cloning and ensure that uniqueness of each ESN is protected, this product uses the Industry Standard Authentication Algorithm. This algorithm incorporates random challenges using shared secret data calculations to prevent cellular system fraud. 5255 S. Rio Grande Street Littleton, GO 80120 303-409-2990 fax: 303-707-0~54

March 23, 2001 Federal Communications Commission Authorization and Evaluation Division Laboratory Division 7435 Oakland Mills Road Columbia MD 21046 RE: Duplicate exhibits uploaded for PI8SG501, 13EA100350 Dear Sir or Madam: On March 16, 2001 the following documents were submitted. We are resubmitting them today to ensure that they are marked confidential. The documents being submitted today are also physically marked confidential (the ones submitted on March 16 were not marked.)Please be sure to use the ones listed below and submitted on March 23, 2001 for CDR’s application. Sincerely, Courtney Sherbourne Project Coordinator

FCC ID: PI8SG501 FCC ID: PI8SG501 FCC ID: PI8SG501 FCC ID: PI8SG501

Use only with Class 2 power source, 3.8 Amp, 12 VDC This device complies with Part 15 & 22 of the FCC rules. Operations is subject to the following two conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with Part 15 & 22 FCC rules. FCC Registration No.PI8SG501 CDR Made in U.S.A. Trade Name: SkyGuard 500 Track Pack Model No. SG-501 Patent Pending S / N 7003:

FCC ID: PI8SG501 FCC ID: PI8SG501 FCC ID: PI8SG501 FCC ID: PI8SG501 FCC ID: PI8SG501 FCC ID: PI8SG501

FCC ID: PI8SG501 FCC ID: PI8SG501 FCC ID: PI8SG501 FCC ID: PI8SG501 FCC ID: PI8SG501 FCC ID: PI8SG501

NOTES: Old Item ref Item Qty Per Description CDR Part Number OEM MFG Mfg. Part Number Qty for 250/mth 3 1 3 12pF, CER, 50V, CC0603 C1, C16, C17 Panasonic ECU-V1H120JCV 750 7 2 5 .01UF, CER, 25V, CC0603 C61, C67, C255, C260, C264 Panasonic ECJ-1VB1E103K 1250 5 3 1 3.3uF, TANT, 10V, TC3216 C66 Panasonic ECS-H0JY335R 250 8 4 4 10uF, TANT, 16V, TC6032 C70, C71, C216, C217 Kemet T494C106M016AS 1000 5 same part listed below 0 10 6 3 .47uF, CER, 25V, CC1206 C269, C270, C271 Subsitiute .82uF, 10%, X7R Panasonic ECJ-3VF1E474Z 750 9 7 4 33uF, TANT, 25V, TC6032 C118, C119, C120, C128 Kemet T494X336M025AS 1000 11 8A 0 Deleted Kemet T494X686M016AS 0 11 8B 6 330uF, TANT, 10V, TC7342 C122, C239, C249, C268, C276, C275 6032 OR 7342 Footprint Kemet T494X337K010AS 1500 13 9 0 Deleted Panasonic xxx 0 6 10 46 .1uF, CER, 16V, CC0603 C72, C177, C178, C179, C180, C181, C182, C183, C184, C185, C186, C187, C188, C189, C190, C191, C192, C193, C194, C195, C196, C197, C198, C199, C200, C201, C202, C203, C204, C205, C206, C211, C212, C213, C214, C215, C279, C280, C281, C282, C283, C284, C285, C286, C287, C288 Panasonic ECJ-1VB1C104K 11500 11 0 VALUE TBD CC0603 - layout only 0 12 3 100pf CER, 50V, CC0603 C256, C261, C265 Panasonic ECU-V1H101JCV 750 13A 3 3300pf CER, X7R, 10%, 50V, CC0603 C257, C262, C266 Panasonic Philips ECJ-1VB1H332K 06032R332K9B20D 750 13B 3 220pf CER, NPO, 5% 50V CC0603 C258, C263, C267 Panasonic Philips ECU-V1H221KCV 0603CG221J9B200 750 13C 3 1000pf CER, X7R, 5% 50V CC0603 C272, C273, C274 Panasonic Philips ECJ-1VB1H102K 06032R102K9B20D 750 16 14 2 LED, Amber, LED0603 D8, D26 Panasonic LNJ408K8ZRA 500 15 11 BAT54S/SOT D9, D10, D11, D13, D14, D15, D16, D17, D24, D27, D28 2750 16 3 MBRS130LT3, DO-214AA D21, D22, D23 May substitute SMB5817 Fairchild 750 18 17 17 Ground Point, Octagon, .032", TPG GP1, GP2, GP3, GP4, GP5, GP6, GP7, GP8, GP9, GP10, GP11, GP12, GP13, GP14, GP15, GP16, GP17 PCB Feature 4250 18 1 2 x 30, 0.8mm, JP1 AMP 177983-2 250 19 0 1 X 30, 0.5mm, flat-flex cable, vertical-entry, solder contact-plating Do not install Hirose FH12-30S-0.5SV 0 20 20 2 HEADER 15X2, 30PIN, Bottom Entry, SPE1016 J15, J2 Specialty Elect Samtec 233-1533-01 CLT-115-02-F-P-BE-A-TR 500 21 21 3 HEADER 10X2, 20PIN, SPE1013 J6, J4, J8 Specialty Elect Samtec 233-1033-01 CLT-110-02-L-P-A-TR 750 0 2 x 10, 2mm x 2mm, top-entry, 10 microinch gold, SMT with alignment pin, pick&place, tape&reel Samtec SQW-110-01-L-D-VS-A-K-R 0 22 1 1 X 20, 0.5mm, flat-flex cable, vertical-entry, solder contact-plating J7 Hirose FH12-20S-0.5SH 250 23 1 2 X 2, 2mm x 2mm, vertical-entry, solder contact-plating J9 May substitute DF11-4DP-2DS(22) Hirose DF11-4DP-2DS(52) 250 23 24 1 HEADER 10X2, 20PIN, Hdrblk_10X2_2MM_RA J11 Samtec CLT-110-02-L-D-A-P-TR 250 19 25 1 FH12-30S-0.5SH, 30PIN, FH12/30/0.5SH J13 Horizontal Hirose FH12-30S-0.5SH 250 24 26 1 CON10A, shrouded, 10PIN, CON10 J14 3M AMP 2510-6002UB 147102-5 250 26 28 1 Ferite Bead, LC1206 L3 Panasonic EXC-CL3216U 250 27A 1 47uH 20% L8 Sumida CDRH125-470 250 Page 1 of 3 2/19/01 Old Item ref Item Qty Per Description CDR Part Number OEM MFG Mfg. Part Number Qty for 250/mth 27B 1 100uH 20% L9 Sumida CDRH125-101 250 27C 1 15uH 20% L10 Sumida CDRH-127-150MC 250 27 29 1 000-00000, FR4, .062 thick PCB1 PCB Vendor TBD 250 30 2 MMBTA63L Q1, Q2 Fairchild MMBTA63L 500 28 31 0 FDC6303N, Super SOT 6 Fairchild FDC6303N 0 32 8 MMBT3904/SOT Q8, Q9, Q10, Q11, Q12, Q13, Q14, Q19 Fairchild MMBT3904 2000 30 33 10 10K, 5%, 1/16W, RP4_0805 RP1, RP2, RP3, RP5, RP13, RP17, RP18, RP19, RP20, RP40 Panasonic EXB-V8V103JV 2500 72 34 14 100K, 5%, 1/16w, RP4_0805 RP15, RP28, RP29, RP30, RP31, RP32, RP34, RP36, RP37, RP38, RP39, RP41, RP43, RP44 Panasonic EXB-V8V104JV 3500 35 1 100 Ohm, 5%, 1/16W, RP4_0805 RP16 Panasonic EXB-V8V101JV 250 36 6 3.3K, 5%, 1/16W, RP4_0805 RP22, RP25, RP26, RP33, RP35, RP45 Panasonic EXB-V8V332JV 1500 37 0 0 31 38 4 10K, 1%, 1/16W, RC0603 R118, R122, R127, R132 Panasonic ERJ-3GSYJ103 1000 32 39 2 22, 5%, 1/16W, RC0603 R6, R2 Panasonic ERJ-3GSYJ220 500 40 17 10K, 5%, 1/16W, RC0603 R3, R7, R8, R9, R12, R14, R15, R18, R21, R23, R25, R26, R31, R38, R95, R96, R97 4250 33 41 5 0 Ohm, 5%. 1/16W, RC0603 R5, R16, R17, R22, R141 Panasonic ERJ-3GSYJ000 1250 34 42 1 1M, 5%, 1/16W, RC0603 R40 Panasonic ERJ-3GSYJ105 250 35 43 2 VT90N4, Radial R60, R62 Move R60 to Secondary side PerkinElmer VT90N4 500 37 44A 10 1K, 5%, 1/16W, RC0603 R109, R111, R112, R113, R114, R115, R116, R129, R124, R134 Panasonic ERJ-3GSYJ102 2500 44B 0 1K, 1%, 1/16W, RC0603 Panasonic ERJ-3EKF1003 0 38 45 3 100K, 5%, 1/16W, RC0603 R69, R140, R142 Panasonic ERJ-3GSYJ104 750 39 46 0 0.075, 5%, 1W RC26114 Ohmite RW1S0BARR075F 0 40 47 1 200K, 1%, 1/16W, RC0603 R119 Panasonic ERJ-3EKF2003 250 73 48 0 64.9K, 1%, 1/16w, 0603 0 43 49 0 221K, 1%, 1/16W, RC0603 Panasonic ERJ-3EKF2213 0 74 50 0 115K, 1%, 1/16w, 0603 0 75 51 0 3.48K, 1%, 1/16w, 0603 0 76 52 0 3.16K, 1%, 1/16w, 0603 0 53A 1 19.6K, 1%, 1/16W, 0603 R121 Panasonic ERJ-3EKF1962 250 53B 4 0.10, 1%, 1206 R133, R123, R128, R139 Vishay-Dale WSL1206 R10 1% R86 1000 53C 3 866 Ohm, 1%, 1/16W, 0603 R125, R130, R135 Panasonic ERJ-3EKF8660 750 53D 2 33.2K, 1%, 1/16W, 0603 R131, R126 Panasonic ERJ-3EKF3322 500 53E 1 365K, 1%, 1/16W, 0603 R120 Panasonic ERJ-3EKF3653 250 44 54 1 SW PUSHBUTTON, N.O. mom, ESE2101BT S1 Panasonic ESE-2101BT 250 46 55 37 Test Point, Round, .032", TP TP1, TP2, TP3, TP4, TP5, TP6, TP7, TP8, TP9, TP10, TP11, TP12, TP13, TP14, TP15, TP16, TP17, TP18, TP19, TP21, TP22, TP23, TP24, TP26, TP27, TP28, TP29, TP30, TP31, TP32, TP33, TP36, TP37, TP38, TP39, TP40, TP41 PCB Feature 9250 47 56 1 TMS320LC548, DSP, TQFP144 U1 Texas Instrumen t TMS320BLC548PGE-66 250 48 57 2 Generic Flash 48, TSOP48 U4, U2 Intel TE38F400B3T-110 500 49 58 1 CY62126V-70ZC, TSOP44F CY62126VL-70ZC, CY62126VLL-70ZC, CY62127V-70ZC, CY62127VL-70ZC, or CY62127VLL-70ZC KM616V4000C, TSOP44F U3 Cypress CY62126V-70ZC 250 53 59 1 DS1832, SO8NB U8 Dallas Semi DS1832 SOIC 250 79 60 1 XCR3256XL-10PQ208C U24 Xilinx 250 6…

Text truncated - open the document above for the full version.

64K x 16 Static RAM CY62127V Cypress Semiconductor Corporation •3901 North First Street•San Jose•CA 95134•408-943-2600 June 2, 1999 Features • 2.7V–3.6V operation • CMOS for optimum speed/power • Low active power (70 ns) — 198 mW (max.) (55 mA) • Low standby power (70 ns, LL version) —54 μ W (max.) (15 μ A) • Automatic power-down when deselected — Power down either with CE or BHE and BLE HIGH • Independent control of Upper and Lower Bytes • Available in 44-pin TSOP II (forward) Functional Description The CY62127V is a high-performance CMOS Static RAM or- ganized as 65,536 words by 16 bits. This device has an auto- matic power-down feature that significantly reduces power consumption by 99% when deselected. The device enters power-down mode when CE is HIGH or when CE is LOW and both BLE and BHE are HIGH. Writing to the device is accomplished by taking Chip Enable (CE ) and Write Enable (WE) inputs LOW. If Byte Low Enable (BLE ) is LOW, then data from I/O pins (I/O 1 through I/O 8 ), is written into the location specified on the address pins (A 0 through A 15 ). If Byte High Enable (BHE) is LOW, then data from I/O pins (I/O 9 through I/O 16 ) is written into the location specified on the address pins (A 0 through A 15 ). Reading from the device is accomplished by taking Chip Enable (CE ) and Output Enable (OE) LOW while forcing the Write Enable (WE ) HIGH. If Byte Low Enable (BLE) is LOW, then data from the memory location specified by the address pins will appear on I/O 1 to I/O 8 . If Byte High Enable (BHE) is LOW, then data from memory will appear on I/O 9 to I/O 16 . See the truth table at the back of this datasheet for a complete description of read and write modes. The input/output pins (I/O 1 through I/O 16 ) are placed in a high-impedance state when the device is deselected (CE HIGH), the outputs are disabled (OE HIGH), the BHE and BLE are disabled (BHE, BLE HIGH), or during a write operation (CE LOW, and WE LOW). The CY62127V is available in standard 44-pin TSOP Type II (forward pinout) and mini-BGA packages. Logic Block Diagram Pin Configurations 64K x 16 RAM Array I/O 1 –I/O 8 ROW DECODER A 10 A 9 A 7 A 6 A 3 A 0 COLUMN DECODER A 5 A 8 A 13 A 14 A 15 1024 X 1024 SENSE AMPS DATA IN DRIVERS OE A 2 A 1 I/O 9 –I/O 16 CE WE BLE BHE A 4 A 11 A 12 62127V–162127V–2 WE 1 2 3 4 5 6 7 8 9 10 11 14 31 32 36 35 34 33 37 40 39 38 Top View TSOP II (Forward) 12 13 41 44 43 42 16 15 29 30 V CC A 15 A 14 A 13 A 12 NC A 4 A 3 OE V SS A 5 I/O 16 A 2 CE I/O 3 I/O 1 I/O 2 BHE NC A 1 A 0 18 17 20 19 I/O 4 27 28 25 26 22 21 23 24 NC V SS I/O 7 I/O 5 I/O 6 I/O 8 A 6 A 7 BLE V CC I/O 15 I/O 14 I/O 13 I/O 12 I/O 11 I/O 10 I/O 9 A 8 A 9 A 10 A 11 CY62127V 2 Maximum Ratings (Above which the useful life may be impaired. For user guide- lines, not tested.) Storage Temperature .................................–65°C to +150°C Ambient Temperature with Power Applied .............................................–55°C to +125°C Supply Voltage on V CC to Relative GND [1] ....–0.5V to +4.6V DC Voltage Applied to Outputs in High Z State [1] ....................................–0.5V to V CC + 0.5V DC Input Voltage [1] .................................–0.5V to V CC + 0.5V Current into Outputs (LOW)......................................... 20 mA Static Discharge Voltage .......................................... >2001V (per MIL-STD-883, Method 3015) Latch-Up Current .................................................... >200 mA Notes: 1.V IL (min.) = –2.0V for pulse durations of less than 20 ns. 2.T A is the “Instant On” case temperature. Pin Configurations (continued) Mini-BGA Selection Guide 62127V-5562127V-70Units Maximum Access Time5570ns Maximum Operating Current5555mA Maximum CMOS Standby CurrentCom’lStd0.30.3mA L5050μA LL1515μA Ind’lLL3030μA Shaded areas contain preliminary information. WE V CC A 11 A 10 NC A 6 A 0 A 3 CE I/O 11 I/O 9 I/O 10 A 4 A 5 I/O 12 I/O 14 I/O 13 I/O 15 I/O 16 V SS A 9 A 8 OE V SS A 7 I/O 1 BHE NC NC A 2 A 1 BLE V CC I/O 3 I/O 2 I/O 4 I/O 5 I/O 6 I/O 7 I/O 8 A 15 A 14 A 13 A 12 NC NC NC NC 62127V–3 3 2 65 4 1 D E B A C F G H Operating Range Range Ambient Temperature [2] V CC Commercial0°C to +70°C2.7V–3.6V Industrial–40°C to +85°C2.7V–3.6V CY62127V 3 Electrical Characteristics Over the Operating Range 62127V–55, 70 ParameterDescriptionTest ConditionsMin.Typ. [3] Max.Unit V OH Output HIGH VoltageV CC = Min., I OH = –1.0 mA2.2V V OL Output LOW VoltageV CC = Min., I OL = 2.1 mA0.4V V IH Input HIGH Voltage2.0V CC + 0.3 V V IL Input LOW Voltage [1] –0.30.4V I IX Input Load CurrentGND ≤ V I ≤ V CC –1+1 μA I OZ Output Leakage CurrentGND ≤ V I ≤ V CC , Output Disabled –1+1 μA I CC V CC Operating Supply Current V CC = Max., I OUT = 0 mA, f = f MAX = 1/t RC 55mA I SB1 Automatic CE Power-Down Current —TTL Inputs Max. V CC , CE ≥ V IH V IN ≥ V IH or V IN ≤ V IL , f = f MAX 2mA I SB2 Automatic CE Power-Down Current —CMOS Inputs Max. V CC , CE ≥ V CC – 0.3V, V IN ≥ V CC – 0.3V, or V IN ≤ 0.3V, f=0 Std0.3mA L50 μA Com’lLL0.515 μA IndLL0.530 μA Capacitance [4] ParameterDescriptionTest ConditionsMax.Unit C IN Input CapacitanceT A = 25°C, f = 1 MHz, V CC = 3.3V 9pF C OUT Output Capacitance9pF AC Test Loads and Waveforms Notes: 3.Typical specifications are the mean values measured over a large sample size across normal production process variations and are taken at nominal conditions (T A = 25 ° C, V CC =3.0V). Parameters are guaranteed by design and characterization, and not 100% tested. 4.Tested initially and after any design or process changes that may affect these parameters. 62127V-4 90% 10% 3.0V GND 90% 10% ALL INPUT PULSES 3.0V OUTPUT 30 pF INCLUDING JIG AND SCOPE 3.0V OUTPUT 5 pF INCLUDING JIG AND SCOPE (a) (b) <3 ns<3 ns OUTPUT R1 1076 ΩΩ R2 1262 Ω R2 581 Ω Equivalent to: THÉVENIN EQUIVALENT 1.62V R1 1076 1262 Ω CY62127V 4 Switching Characteristics [5] Over the Operating Range 62127V–5562127V–70 ParameterDescriptionMin.Max.Min.Max.Unit READ CYCLE t RC Read Cycle Time5570ns t AA Address to Data Valid557…

Text truncated - open the document above for the full version.

1 of 7112099 FEATURES
Halts and restarts an out-of-control microprocessor
Holds microprocessor in check during power transients
Automatically restarts microprocessor after power failure
Monitors pushbutton for external override
Accurate 10% or 20% microprocessor power monitoring
Eliminates need for discrete components
20% tolerance for use with 3.0-volt systems
Pin-compatible with the DS1232
Low cost 8-pin DIP, 8-pin SOIC, and space saving μ-SOP packages available
Industrial temperature range of -40°C to +85°C PIN ASSIGNMENT PIN DESCRIPTION PBRST - Pushbutton Reset Input TD - Time Delay Set TOL - Selects 10% or 20% V CC Detect GND - Ground RST - Active High Reset Output RST - Active Low Reset Output ST - Strobe Input V CC - Power Supply DESCRIPTION The DS1832 3.3-Volt MicroMonitor monitors three vital conditions for a microprocessor: power supply, software execution, and external override. First, a precision temperature-compensated reference and comparator circuit monitor the status of V CC . When an out-of-tolerance condition occurs, an internal power-fail signal is generated which forces the resets to an active state. When V CC returns to an in-tolerance condition, the reset signals are kept in the active state for a minimum of 250 ms to allow the power supply and processor to stabilize. DS1832 3.3-Volt MicroMonitor Chip www.dalsemi.com DS1832 8-Pin DIP (300-mil) See Mech. Drawings Section PBRST TD TOL GND V CC ST RST RST 1 2 3 4 8 7 6 5 DS1832S 8-Pin SOIC (150-mil) See Mech. Drawings Section 1 2 3 4 8 7 6 5 PBRST TD TOL GND V CC ST RST RST DS1832μ 8-Pin μ-SOP (118-mil) See Mech. Drawings Section PBRST TD TOL GND V CC ST RST RST 1 2 3 4 8 7 6 5 DS1832 2 of 7 The second function the DS1832 performs is pushbutton reset control. The DS1832 debounces the pushbutton input and guarantees an active reset pulse width of 250 ms minimum. The third function is a watchdog timer. The DS1832 has an internal timer that forces the reset signals to the active state if the strobe input is not driven low prior to timeout. The watchdog timer function can be set to operate on timeout settings of approximately 150 ms, 600 ms, or 1.2 seconds. OPERATION - POWER MONITOR The DS1832 detects out-of-tolerance power supply conditions and warns a processor-based system of impending power failure. When V CC falls below a preset level as defined by TOL, the V CC comparator outputs the signals RST and RST. When TOL is connected to ground, the RST and RST signals become active as V CC falls below 2.98 volts. When TOL is connected to V CC , the RST and RST signals become active as V CC falls below 2.64 volts. The RST and RST are excellent control signals for a microprocessor, as processing is stopped at the last possible moments of valid V CC . On power-up, RST and RST are kept active for a minimum of 250 ms to allow the power supply and processor to stabilize. OPERATION - PUSHBUTTON RESET The DS1832 provides an input pin for direct connection to a pushbutton reset (see Figure 2). The pushbutton reset input requires an active low signal. Internally, this input is debounced and timed such that RST and RST signals of at least 250 ms minimum are generated. The 250 ms delay commences as the pushbutton reset input is released from the low level. OPERATION - WATCHDOG TIMER The watchdog timer function forces RST and RST signals active when the ST input is not clocked within the predetermined time period. The timeout period is determined by the condition of the TD pin. If TD is connected to ground the minimum watchdog timeout would be 62.5 ms, TD floating would yield a minimum timeout of 250 ms, and TD connected to V CC would provide a timeout of 500 ms minimum. Timeout of the watchdog starts when RST and RST become inactive. If a high-to-low transition occurs on the ST input pin prior to timeout, the watchdog timer is reset and begins to timeout again. If the watchdog timer is allowed to timeout, then the RST and RST signals are driven active for a minimum of 250 ms. The ST input can be derived from many microprocessor outputs. The most typical signals used are the microprocessor address signals, data signals or control signals. When the microprocessor functions normally, these signals would, as a matter of routine, cause the watchdog to be reset prior to timeout. To guarantee that the watchdog timer does not timeout, a high-to-low transition must occur at or less than the minimum times shown in Table 1. A typical circuit example is shown in Figure 4. The DS1832 watchdog function cannot be disabled. The watchdog strobe input must be strobed to avoid a watchdog timeout and reset. DS1832 3 of 7 MICROMONITOR BLOCK DIAGRAM Figure 1 PUSHBUTTON RESET Figure 2 TIMING DIAGRAM: PUSHBUTTON RESET Figure 3 DS1832 4 of 7 WATCHDOG TIMER Figure 4 WATCHDOG TIMEOUTS Table 1 TIMEOUT TDMINTYPMAX GND62.5 ms150 ms250 ms Float250 ms600 ms1000 ms V CC 500 ms1200 ms2000 ms TIMING DIAGRAM: STROBE INPUT Figure 5 TIMING DIAGRAM: POWER DOWN Figure 6 DS1832 5 of 7 TIMING DIAGRAM: POWER-UP Figure 7 RSTVALID TO 0 VOLTS V CC Figure 8 OUTPUT VALID CONDITIONS The RST output uses a push-pull output which can maintain a valid output down to 0.8 volts V CC . To sink current below 0.8 volts a resistor c…

Text truncated - open the document above for the full version.
