PIY97577-04A4RFAST GEAR

I. BATTERY INSTALLATION (Transmitter & Vehicle)Install 2 AA alkaline batteries with polarity (+/-) as showninside battery compartment. ❶ Steering Adjuster ❷ ON/OFF Switch II. OPERATION❶ FORWARD ❷ REVERSE ❸ LEFT TURN ❹ RIGHT TURN III. BA TTERY SAFETY INFORMATION In exceptional circumstances batteries may leak fluidsthat can cause a chemical burn injury or ruin your toy (product). To avoid battery leakage:• Non-rechargeable batteries are not to be recharged.• Rechargeable batteries are to be removed from the toy before being charged (if designed to be removable). • Rechargeable batteries are only to be charged under adult supervision (if designed to be removable). • Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries. • Do not mix old and new batteries.• Only batteries of the same or equivalent type as recommended are to be used. • Batteries are to be inserted with the correct polarity.• Exhausted batteries are to be removed from the toy.• The supply terminals are not to be short-circuited.• Dispose of battery(ies) safely.• Do not dispose of this toy in a fire. The batteries inside may explode or leak . Battery Performance Note:For best performance use regular or high-performancealkaline batteries (where disposable batteries are calledfor). If your vehicle is supplied with standard (carbon-zinc) batteries for initial use and/or demon stration purposes, we recommend replacing them with alkaline batteries when necessary. Battery life may vary depending on battery brand. IV. QUICK TIPS❶ When your vehicle starts to lose power, it may lose functions or performance. It’s time for fresh batteries. Y our vehicle’s running time may change depending on your driving style. ❷ Radio interference can make your vehicle run badly.Interference can be caused by other R/C vehiclesrunning on the same frequency; electrical wires; largebuildings; or CB radios. Try to stay away from these! ❸ Point your transmitter up - not down toward yourvehicle. If your vehicle gets too far away, it won’twork properly. ❹ Don’t drive your vehicle in sand or through water orsnow. If your vehicle does get wet, wipe with a toweland allow to dry completely. ❺ Don’t store your vehicle near heat or in directsunlight. Always turn switches OFF and remove allbatteries for storage. V. CONSUMER INFORMATION Note to Adults: To ensure that the child’s play is both safeand fun, please review all operating instructions and safetyrules with your child.Safety Tips• NEVER drive your vehicle on streets! They’re for real cars! • DO NOT pick up vehicle while in motion.• Keep fingers, hair and loose clothing away from the tires and the wheel hubs while the vehicle is switched ON. • Adult supervision is recommended when this vehicle is being operated. • To avoid accidental operation, remove all batteries when not in use. CAUTION: To prevent entanglement, keep hair away from wheels. ❷ ❶ 1.5 V d.c. x 2 ❶ ❷ ❸ ❹ Keep these instructions for future reference, as they contain important information. ENG C3132-0720 C3132-DU1EB-S1 1.5V d.c. 1.5V d.c. U.S.A. 90-DAY LIMITED WARRANTY – TYCO® R/C PRODUCTS Mattel, Inc. warrants to the original consumer purchaser that this product will be free of defects in material and workmanship for ninety (90) days (unless specified in alternate warranties) from the date of purchase. Mattel will replace the product in the event of such a defect within the warranty period.In the event of a defect covered under this warranty, first call the toll-free number listed below. Many problems can be solved in this manner. If necessary, you will be instructed to return the product, postage prepaid and insured, to the address below. Enclose your name, address, dated sales receipt, and a brief ex planation of the defect. Replacement and return shipment will be free of charge.This warranty does not cover damage resulting from unauthorized modification, accident, misuse or abuse. If the product is retu rned without a dated sales receipt the product may be excluded from coverage under this warranty.Mattel’s liability for defects in material and workmanship under this warranty shall be limited to replacement, and in no event shall we be responsible for incidental, consequential, or contingent damages (except in those states that do not allow this exclusion or limitation). This warranty is exclusive, and is made in lieu of any express or implied warranty. V alid only in U.S.A. This warranty gives you specific legal rights and you may have other rights, which vary from state to state. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusions or limitations may not apply to you.TOLL-FREE NUMBER: 1-888-557-TYCO (8926) (valid only in U.S.A.) Hours: 8:00 A.M. - 5:00 P.M. Eastern Time; Monday - Friday. Expect some delay in January following the holiday season. Please b e patient and keep trying the toll-free number. ADDRESS FOR RETURNS: CONSUMER RELATIONS, 636 GIRARD AVENUE, EAST AURORA, NY 14052 CANADA 90-DAY LIMITED WARRANTY Mattel, Inc. warrants to the original consumer purchaser that this product willbe free of defects in material and workmanship for ninety (90) days (unless specified in alternate warranties) from the date of purchase. If defective,return the product along with proof of the date of purchase, postage prepaid toMattel Canada Inc., Consumer Service, 6155 Freemont Blvd., Mississauga,Ontario L5R 3W2 for replacement with an identical toy or a similar toy of equalor greater value according to availability. This warranty gives you specific legalrights and you may have other rights which vary from province to province.This warranty does not cover damage resulting from accident, misuse or abuse.V alid for products sold in Canada only. YOU MAY CALL US FREE AT 1-800-665-6288 Monday – Friday, 8:00 a.m. –5:00 p.m. EST; 5:00 a.m. – 2:00 p.m. PST. CANADA GARANTIE LIMITÉE DE 90 JOURS Mattel garantit à l’acheteur initial que le produit est couvert contre les vices dematé…

Text truncated - open the document above for the full version.

TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AE016625-001 Date : 2004 September 17 Application No.: LE210451(2) Applicant : Mattel Asia Pacific Sourcing Ltd. 13/F., South Tower, World Finance Centre, Harbour City, Tsim Sha Tsui, Kowloon, Hong Kong. Sample Description : One(1) submitted sample stated to be Fast Gear of Model No. C3132 Rating : 2 x 1.5V AA size battery No. of sample(s) : Three (3) piece(s) *** Date Received : 2004 August 26. Test Period : 2004 August 26 – 2004 September 15. Test Requested : FCC Part 15 Certification Test Method : FCC Rules and Regulations Part 15 – Dec 2003 ANSI C63.4 – 2001 Test Result : See attached sheet(s) from page 2 to 11. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart B. For and on behalf of CMA Testing and Certification Laboratories Authorized Signature : Page 1 of 11 Danny Chui EMC Engineer - EL. Division FCC ID : PIY97577-04A4R TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AE016625-001 Date : 2004 September 17 Table of Contents 1 General Information........................................................................................................................ 3 1.1 General Description.................................................................................................................. 3 1.2 Related Submittal Grants.......................................................................................................... 3 1.3 Location of the test site............................................................................................................. 4 1.4 List of measuring equipment..................................................................................................... 5 2 Description of the radiated emission test........................................................................................... 6 2.1 Test Procedure......................................................................................................................... 6 2.2 Test Result...............................................................................................................................6 2.3 Radiated Emission Measurement Data....................................................................................... 7 3 Description of the Line-conducted Test............................................................................................ 8 3.1 Test Procedure......................................................................................................................... 8 3.2 Test Result...............................................................................................................................8 3.3 Graph and Table of Conducted Emission Measurement Data....................................................... 8 4 Photograph..................................................................................................................................... 9 4.1 Photographs of the Test Setup for Radiated Emission and Conduction Emission........................... 9 4.2 Photographs of the External and Internal Configurations of the EUT........................................... 9 5 Supplementary document............................................................................................................... 10 5.1 Bandwidth............................................................................................................................. 10 6 Appendices...............................................................................................................................11 Page 2 of 11 FCC ID : PIY97577-04A4R TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AE016625-001 Date : 2004 September 17 1 General Information 1.1 General Description The equipment under test (EUT) is a super regenerative receiver for Fast Gear. Operating at 49.860 MHz which is controlled by a LRC circuit. The EUT is powered by 2 x 1.5V “AA” size battery and it has a internal antenna. When it received a forward and backward signal, it will go forward or backward. When it received a turn left or turn right signal, it will go left or right. The brief circuit description is listed as follows : - Q1 and associated circuit act as super regenerative circuit. - U1 and associated circuit act as decoder. - Q2, Q3 and associated circuit act as voltage adjust. - Q4~Q9 and associated circuit act as motor drive circuit for M2. - Q10~Q15 and associated circuit act as motor drive circuit for M1. 1.2 Related Submittal Grants This is a single application for certification of a receiver. Page 3 of 11 FCC ID : PIY97577-04A4R TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AE016625-001 Date : 2004 September 17 1.3 Location of the test site Radiated emissions measurements are investigate…
