PIYB7170-03A4TLooney Tunes Bumper Car - Transmitter

O / I B7160-0720 ❺ ❹ ❷ ❸ ❶ OWNERS MANUAL Keep these instructions for future reference as they contain important information. MANUAL DEL USUARIO Recomendamos guardar estas instrucciones para futura referencia, ya que contienen información importante. GUIDE DE L’UTILISATEUR Ce mode d’emploi contient des nformations importantes. Conservez-le pour pouvoir vous y référer en cas de besoin. + O / I BATTERY INSTALLATION • COLOCACIÓN DE LAS PILAS • INSTALLATION DES PILES AA(UM-3/LR6) 2 x 1.5V d.c. 6LR61 9V d.c. QUICK TIPS • GUÍA RÁPIDA DE REFERENCIA • CONSEILS U.S.A. 90-DAY LIMITED WARRANTY TYCO® R/C PRODUCTS Mattel, Inc. warrants to the original consumer purchaser that this product will be free of defects in material and workmanship for ninety (90) days (unless specified in alternate warranties) from the date of purchase. Mattel will replace the product in the event of such a de fect within the war- ranty period.In the event of a defect covered under this warranty, first call the toll-free number listed below. Many problems can be solved in this manner. If necessary, you will be instructed to return the product, postage prepaid and insured, to the address below. Enclose your name, address, dated sales receipt, and a brief explanation of the defect. Replacement and return shipment will be free of charge.This warranty does not cover damage resulting from unauthorized modification, accident, misuse or abuse. If the product is retu rned without a dated sales receipt the product may be excluded from coverage under this warranty.Mattel’s liability for defects in material and workmanship under this warranty shall be limited to replacement, and in no event shall we be respon- sible for incidental, consequential, or contingent damages (except in those states that do not allow this exclusion or limitati on). This warranty is exclusive, and is made in lieu of any express or implied warranty. V alid only in U.S.A . This warranty gives you specific legal rights and you may have other rights, which vary from state to state. Some states do not allow the exclusion of incidental or consequential damage s, so the above exclusions or limitations may not apply to you.TOLL-FREE NUMBER: 1-888-557-TYCO (8926) (valid only in U.S.A.) Hours: 8:00 A.M. - 5:00 P.M. Eastern Time; Monday - Friday. Expect some delay in January following the holiday season. Please b e patient and keep trying the toll-free number.ADDRESS FOR RETURNS: CONSUMER RELATIONS, 636 GIRARD AVENUE, EAST AURORA, NY 14052 Mattel de México, S.A. De C.V., garantiza sus productos por un perio-do de 90 días en todas sus partes y mano de obra, a partir de la fechade entrega. Condiciones: 1.- El consumidor presentará el producto enel lugar donde lo adquirió y/o presentarlo o enviarlo a nuestro centrode servicio ubicado en Lebrija 296-a, Col. Cerro de la Estrella,Iztapalapa C.P. 09880, México, D.F. Tels: 426-44-87 y 426-44-38 2.-Durante la vigencia de esta póliza nos comprometemos a efectuar sincargo la reparación, en un plazo que no excederá de 30 días a partirde la fecha de recepción del producto en nuestro sentro de servicio, oal cambio del producto defectuoso en su caso. Así mismo cubrimosgastos que se deriven de la presenta garantía. 3.- Refacciones paraeste producto podrán ser adquiridas en nuestro centro de servicio.Esta garantía se invalida en los siguientes casos: si ha sufrido undeterioro esencial, grave o irreparable por causa del consumidor, pordaños causados por maltrato, mal uso, golpes accidentales o inten-cionales, o que el artículo se hay expuesto a elementos como agua (a excepción de que el instructivo indique otra cosa), áci-dos, fuego, intemperie, así como daños causados por baterías que sedejen dentro del juguete por largos periodos de tiempo sin uso.NOMBRE DEL CONSUMIDOR: LÍNEA DE PRODUCTO: _____________________________________SERIE: __________________________________________________MODELO: _______________________________________________NOMBRE DEL DISTRIBUIDOR: _______________________________DIRECCIÓN: _____________________________________________SELLO O FIRMA DEL DISTRIBUIDOR: _________________________FECHA DE COMPRA: ______________________________________FECHA DE ENTREGA: ______________________________________ CANADA 90-DAY LIMITED WARRANTY Mattel, Inc. warrants to the original consumer purchaser that thisproduct will be free of defects in material and workmanship for ninety(90) days (unless specified in alternate warranties) from the date ofpurchase. If defective, return the product along with proof of the dateof purchase, postage prepaid to Mattel Canada Inc., ConsumerService, 6155 Freemont Blvd., Mississauga, Ontario L5R 3W2 forreplacement with an identical toy or a similar toy of equal or greatervalue according to availability. This warranty gives you specific legalrights and you may have other rights which vary from province toprovince. This warranty does not cover damage resulting from acci-dent, misuse or abuse. V alid for products sold in Canada only. YOU MAY CALL US FREE AT 1-800-665-6288 Monday – Friday, 8:00a.m. – 5:00 p.m. EST; 5:00 a.m. – 2:00 p.m. PST. CANADA GARANTIE LIMITÉE DE 90 JOURS Mattel garantit à l’acheteur initial que le produit est couvert contre lesvices de matériau ou de fabrication pour une période de 90 jours (àmoins d’indication contraire dans d’autres garanties) à compter de ladate d’achat. Tout produit défectueux doit être retourné, accompagnéd’une preuve de la date d’achat et dûment affranchi, au Service à laclientèle de Mattel Canada Inc., 6155, Freemont Blvd., Mississauga(Ontario) L5R 3W2, où il sera remplacé par un produit identique ouun produit semblable de valeur égale ou supérieure, selon la disponi-bilité. La présente garantie procure certains droits légaux à l’acheteur,qui peut également bénéficier de droits supplémentaires qui varientd’une province à l’autre. La présente garantie ne couvre pas les dom-mages occasionnés par un accident ou un usage abusif ou inappro-prié. Va lable pour les produits v…

Text truncated - open the document above for the full version.

Block Diagram of Looney Tunes Bumper Car (TX) B7170 Encode Q3 & Q4 RF C7 & Q1 Power Supply 9V Battery OSC Y1 49.860MHz & Q2

  THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. B7170 BOBBIN BUMPERS TAZ ñ CANADA 210

Looney Tunes Bumper Car B7170 49.860MHz Transmitter Operational Description Looney Tunes Bumper Car radio control transmitter is a low powered, hand held unit for controlling the movement of the RC car. It is powered by a 9V battery and is designed to operated on a single fixed frequency in the 49.82-49.90 MHz band. The RF link (control method) of TX is established by generating a square wave at a regular frequency (there is only one key – SW1 on the transmitter). This wave will be integrated with a carrier signal that later interpreted by receiver decoder for the car controlling. The controller has 3 main parts, an encoder for wave generation, an oscillator and an RF amplifier. Whenever the key is pressed (SW1), a square wave will be generated through Q3 and Q4 from the 9V battery. At the same time, this wave will be received by Q1 through R3. T1 and Q2 is a crystal control oscillation circuit generating the carrier signal and the power is applied when SW1 is pressed. It outputs to RF amplifier via C7. Q1 is a RF amplifier and it receives signal from oscillator (RF frequency) and modulating pulse from encoder. A band pass filter is placed between the amplifier and antenna to reduce upper harmonic & spurious emission. All tuning and verifications are performed by the manufacturer and there are no adjustments which can be made by the user. No external ground is required or used with this transmitter. (End of document.)

1234 A B C D 4321 D C B A Title NumberRevisionSize A4 Date:5-Mar-2003 Sheet of File:E:\productor\looney\TX\TX.DdbDrawn By: C9 0.033UF C10 0.033UF R5 4.7K R6 27K R8 27K R9 4.7K R2 100R C7 22P C8 22P C6 100P R3 18K R1 100R C4 10NF L1 1UH C3 22P C2 82P T1 11.5T C1 2P ANT B1 9V SW1 C5 0.01UFR11 150K Y1 49.860MHz L2 1uH Q3 2SC1623 Q4 2SC1623 Q1 2SC2712 Q2 2SC2712 R7 18K L3 1.0uH

TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1401-3, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AD002702-1 Date : 2003 April 08 Client : Mattel Asia Pacific Sourcing Limited 13/F., South Tower, World Finance Centre, Harbour City, Tsim Sha Tsui, Kowloon, Hong Kong. Sample Description : One(1) submitted sample stated to be Looney Tunes Bumper Car of Model No. B7170 . Rating : 1 x 9 V size battery No. of sample(s) : Two(2) pieces *** Date Received : 2003 February 22. Test Period : 2003 February 22 – 2003 February 26. Test Requested : FCC Part 15 Certification Test Method : FCC Rules and Regulations Part 15 – May 2002 ANSI C63.4 – 1992 Test Result : See attached sheet(s) from page 2 to 10. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart C. For and on behalf of CMA Testing and Certification Laboratories Authorized Signature : Page 1 of 10 Danny Chui EMC Engineer - EL. Division FCC ID : PIYB7170-03A4T TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1401-3, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AD002702-1 Date : 2003 April 08 Table of Contents 1 General Information........................................................................................................................ 3 1.1 General Description.................................................................................................................. 3 1.2 Related Submittal Grants.......................................................................................................... 3 1.3 Location of the test site............................................................................................................. 4 1.4 List of measuring equipment..................................................................................................... 5 2 Description of the radiated emission test.......................................................................................... 6 2.1 Test Procedure......................................................................................................................... 6 2.2 Test Result............................................................................................................................... 6 2.3 Radiated Emission Measurement Data....................................................................................... 7 3 Description of the Line-conducted Test............................................................................................ 8 3.1 Test Procedure......................................................................................................................... 8 3.2 Test Result............................................................................................................................... 8 3.3 Graph and Table of Conducted Emission Measurement Data...................................................... 8 4 Photograph..................................................................................................................................... 9 4.1 Photographs of the Test Setup for Radiated Emission and Conduction Emission.......................... 9 4.2 Photographs of the External and Internal Configurations of the EUT........................................... 9 5 Supplementary document................................................................................................................. 9 5.1 Bandwidth............................................................................................................................... 9 6 Appendices.................................................................................................................................... 10 Page 2 of 10 FCC ID : PIYB7170-03A4T TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1401-3, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AD002702-1 Date : 2003 April 08 1 General Information 1.1 General Description The equipment under test (EUT) is a transmitter for Looney Tunes Bumper Car operating at 49.860 MHz which is controlled by a crystal. The EUT is powered by a 9 V battery. There is a key (SWI) on the EUT to control the car moving forward. The brief circuit description is saved with filename : OpDec.pdf 1.2 Related Submittal Grants This is a single application for certification of a transmitter. The receiver for this transmitter is authorized by Certification procedure. Page 3 of 10 FCC ID : PIYB7170-03A4T TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1401-3, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AD002702-1 Date : 2003 April 08 1.3 Location of the test site Radiated emissions measurements are investigated and taken pursuant to the procedures of ANSI C63.4 – 1992. An Open Area Testing Site is set up for investigation and located at : Top of the Roof, Yan Hing Centre, 9 – 13 Wong Chuk Yeung Street, Fo Tan, Shatin, New Territories, Hong Kong. Conducted emissions measurements are investigated and also taken pursuant to the procedures of ANSI C63.4 – 1992. A double shielded …

Text truncated - open the document above for the full version.
