27.145MHz transmitter operational description of 1:32 Lightning McQueen The transmitter send out 27.100MHz ~27.180MHz signal of high frequency to control the car move ,which supply voltage is 3.0volts with two batteries (size AA). Please consult with added block diagram and schematic . When the user push the metal sheet of TX ,the high voltage signal enters into R5,R6,R7,R8 . The signal is generated by C9,C10,Q3,Q4 and sent thought R3 .T2,C13,C15,C12 makes up of oscillator ,The frequency is 27.145MHz ,which generated base oscillatory signal .The signal of forward was enlarged by Q1,it come by T1,C2,C3,L1,C1 and fixed 27.145MHz of high frequency, is sent out. All tuning and verifications are performed by the manufacturer and there are no adjustment which can be made by the user .No external ground is required or used with this transmitter . PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

TEST REPORT Report No. : AG000071-001 Date : 2006 January 06 Page 1 of 11 FCC ID: PIYH6948-05A2T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Application No. : LF219594(8) Client : Mattel Asia Pacific Sourcing Limited 13/F., South Tower, World Finance Centre, Harbour City, Tsimshatsui, Kowloon, Hong Kong. Sample Description : One(1) submitted sample(s) stated to be Lighting McQueen of Model No. H6948 Rating : 2 x 1.5V AA size battery No. of submitted sample : Two (2) piece(s) Date Received : 2005 December 28 Test Period : 2005 December 28 – 2006 January 06 Test Requested : FCC Part 15 Certification. Test Method : FCC Rules and Regulations Part 15 – July 2004 ANSI C63.4 – 2003 Test Result : See attached sheet(s) from page 2 to 11. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart C. For and on behalf of CMA Industrial Development Foundation Limited Authorized Signature : ____________________________________________________ Danny Chui EMC Engineer - EL. Division TEST REPORT Report No. : AG000071-001 Date : 2006 January 06 Page 2 of 11 FCC ID: PIYH6948-05A2T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Table of Contents 1 General Information............................................................................................................................. 3 1.1 General Description ..................................................................................................................... 3 1.2 Location of the test site ................................................................................................................ 4 1.3 List of measuring equipment........................................................................................................ 5 2 Description of the radiated emission test ............................................................................................. 6 2.1 Test Procedure ............................................................................................................................. 6 2.2 Test Result ................................................................................................................................... 6 2.3 Radiated Emission Measurement Data ........................................................................................ 7 3 Description of the Line-conducted Test............................................................................................... 8 3.1 Test Procedure ............................................................................................................................. 8 3.2 Test Result ................................................................................................................................... 8 3.3 Graph and Table of Conducted Emission Measurement Data ..................................................... 8 4 Photograph ........................................................................................................................................... 9 4.1 Photographs of the Test Setup for Radiated Emission and Conduction Emission....................... 9 4.2 Photographs of the External and Internal Configurations of the EUT......................................... 9 5 Supplementary document................................................................................................................... 10 5.1 Bandwidth .................................................................................................................................. 10 5.2 Duty cycle .................................................................................................................................. 10 5.3 Transmission time ...................................................................................................................... 10 6 Appendices......................................................................................................................................... 11 TEST REPORT Report No. : AG000071-001 Date : 2006 January 06 Page 3 of 11 FCC ID: PIYH6948-05A2T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Test Result : 1 General Information 1.1 General Description The equipment under test (EUT) is a transmitter for Lighting McQueen. Operating at 27.145MHz which is controlled by a LC circuit. The EUT is powered by 2 x 1.5V “AA” size battery. There is a button in front of the EUT, when the button is pressed, a RF signal will transmit to the receiver. The receiver will go straight ahead. The brief circuit description is listed as follows: - T2, C12, C13, C15 and associated circuit act as oscillator. - Q1 and associated circuit act as RF amplifier. - T1, C1, C2, C3, L1 and associated circuit act as matching network. TEST REPORT Report No. : AG000071-001 Date : 2006 January 06 Page 4 of 11 FCC ID: PIYH6948-05A2T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Te…

Text truncated - open the document above for the full version.

CMA Testing and Certification Laboratories Job No.: J00049474 WF-EL-EMC-15 Edition 3 2005 Mar 29 Page of Bandwidth Plot Bandwidth 1

CMA Testing and Certification Laboratories Job No.: J00049474 WF-EL-EMC-15 Edition 3 2005 Mar 29 Page of Duty Cycle Duty Cycle 1 Duty Cycle 2
