X X I.CONTENTS/FEATURES Vehicle qSteering adjuster w3 AA Try-me batteries eBattery door rON/OFF/Try-Me switch * This switch has three positions: IVehicle On: Vehicle runs with lights as you drive OVehicle OFF X Vehicle On: Activates 'try me' function with lights tLights yTry-Me button-with lights Keep these instructions for future reference: they contain important information.IMPORTANT: Please read all “Consumer Information” before operating your vehicle. 6.0V R/C CAUTION:Surfaces may become hot and cause burns if electronics get wet. Do not operate vehicle through water or snow. Asst. H2377 J6834/35-0920G1 Hot Wheels ® R/C SUPPORT Questions or problems with your product? DON’T RETURN IT TO THE STORE! Just call us for help. U.S. consumers may also register their products at this number. 1-888-557-8926 w q B A Transmitter qAntenna w Left & Right controls eForward & Reverse controls rBattery door w e t y r q w e r q r e ® y t III.BATTERY INSTALLATION Requires 6 AA Alkaline Batteries (2AA for transmitter and 4 AA for vehicle). Batteries included are for demon- stration purposes only. Vehicle 1. Use a screwdriver (not included) to unscrew the battery door, open the battery door as shown. 2. Remove 3 "AA" batteries (included for Try-Me Lights ONLY) and replace with 4 new "AA" alkaline batteries (not included) with polarity (+/-) as shown inside the battery compartment. 3. Replace the battery door. Transmitter 1. Remove the battery cover as shown. 2. Install 2 AA alkaline batteries (not included) with polarity (+/-) as shown inside the battery compartment. 3. Replace the battery door. * Your transmitter is equipped with a special automatic ON battery-saving feature. Just turn your vehicle ON. Then push either transmitter control to run and control your vehicle. IV.CONSUMER INFORMATION Note to Adults: To ensure that the child’s play is both safe and fun, please review all operating instructions and safety rules with your child. Safety Tips • NEVER drive your vehicle on streets! They’re for real cars! • DO NOT pick up vehicle while in motion. • Keep fingers, hair and loose clothing away from the tires and the wheel hubs while the vehicle is switched ON. X CAUTION:To prevent entanglement, keep hair away from wheels. • Adult supervision is recommended when this vehicle is being operated. • To avoid accidental operation, remove all batteries when not in use. Always turn the vehicle OFF before removing batteries. BATTERY SAFETY INFORMATION In exceptional circumstances batteries may leak fluids that can cause a chemical burn injury or ruin your product. To avoid battery leakage: • Non-rechargeable batteries are not to be recharged. • Rechargeable batteries are to be removed from the product before being charged (if designed to be removable). • Rechargeable batteries are only to be charged under adult supervision (if designed to be removable). • Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries. • Do not mix old and new batteries. • Only batteries of the same or equivalent type as recommended are to be used. • Batteries are to be inserted with the correct polarity. • Exhausted batteries are to be removed from the product. • The supply terminals are not to be short-circuited. • Dispose of battery (ies) safely. • Do not dispose of this product in a fire. The batteries inside may explode or leak. Battery Performance Note: For best performance use regular or high-performance alkaline batteries (where disposable batteries are called for). If your vehicle is supplied with standard (carbon-zinc) batteries for initial use and/or demonstration purposes, we recommend replacing them with alkaline batteries when necessary. Battery life may vary depending on battery brand. II.VEHICLE OPERATION FORWARD REVERSE LEFT RIGHT 1. When your vehicle starts to lose power, it may lose functions or performance. It's time for fresh batteries (or a recharge). Your vehicle's running time may change depending on your driving style. 2. Radio interferance can effect your vehicle's perform- ance. Interference can be caused by other R/C vehi- cles running on the same frequency, electrical wires, large buildings or CB radios. Try to stay away from these! 3. Point your transmitter antenna up - not down toward your vehicle. If your vehicle gets too far away, it won't work properly. If your transmitter has an antenna carry-loop feature, make sure the antenna is removed from the holder and straightened before operating. 4. Don’t drive your vehicle in sand or through water or snow. 5. Don’t store your vehicle near heat or in direct sunlight. Always turn switches OFF and remove all batteries for storage. V.QUICK TIPS SYMPTOM Vehicle runs slowly or will not run. Power indicator light on transmitter does not light. Erratic operation or only short range possible. Vehicle doesn’t work after going through water or snow. • PROBABLE CAUSE • Loose battery connection or vehicle switch not ON. • Weak or uncharged rechargeable NiCd battery. • Weak AA batteries (Power Clip) or transmitter battery. • Transmitter battery weak or not connected. • Radio interference likely. • Water in the electronics area. • CORRECTION • Check battery connector and vehicle switch. • Charge battery or replace. • Replace with fresh alkaline battery. • Check connections and replace battery if required. • Change location - see Point 2, “Quick Tips.” • Vehicle will take several hours to dry. Allow to dry thoroughly overnight before trying again. • Avoid driving in water or snow. TROUBLESHOOTING - PROBLEM? - SOLUTIONS 2 1 3 4 5 90-DAY LIMITED WARRANTY Mattel, Inc. warrants to the original consumer purchaser that this product will be free of defects in material and workmanship for ninety (90) days (unless specified in alternate warranties) from the date of purchase. Mattel will replace the product in the event of such a defect within the warranty period. In the event of a defect covered under this warranty, first call the toll-free number lis…
Text truncated - open the document above for the full version.
AM4EC005D J6835 RX
Mattel #J6835 Tyco RC 06 Drop Stars SLR 49mhz 49. 860 MHz Receiver Operational Description The 6.0V Drop Stars is full function radio controlled toy car which has 4 lights,It operates on 6.0 volts supplied by four 1.5 volts alkaline AA batteries It is designed to operate on a single fixed frequency in the 49.82 – 49.90 MHz band. See the attached block diagram and schematic. The vehicle receiver receives and demodulates the AM transmitted signal from the transmitter, using a standard super-regenerative AM receiver/demodulator circuit comprised of ANT1, Q1, L2, L3,and associated passive components. L3 is a tunable core slug inductor that is used to tune the receiver for maximum sensitivity. The output of the AM receiver/demodulator is AC coupled to a high input impedance CMOS inverter is connected to the U1 decoder IC, it is biased into their linear region through C12, C14, C9, R4, R13, R6, R7 and function as amplify, filter and shape the data. After passing through the last inverter stage, the incoming waveform is a digitized enough to be fed into the IN1 pin for on-chip decoding. A Zener regulator circuit comprised of C11, C13, R3, D1, C8, C15, it supplied voltage VDD for the super-regenerative radio, decoder IC. Drive motor is controlled by the U1 decoder IC, low power switching transistors Q6, Q7, and a high power H-bridge comprised of Q4, Q5, Q8, Q9, The Steering Motor is controlled by the U1 decoder IC low power switching transistors Q12,Q14,and a high power H-bridge comprised of Q10,Q11,Q13,Q15, The light IC U2 is also triggered by the Forward and Reverse output of U1 decoder IC,it lights accordingly when controlling the car All tuning and verifications are performed by the manufacturer and there are no adjustments which can be made by the user. No external ground is required or used with this receiver. PDF created with pdfFactory trial version www.pdffactory.com
123456 A B C D 6 54321 D C B A Title NumberRevisionSize B Date:29-Nov-2005Sheet of File:E:\protel99\MSD.ddbDrawn By: Q8 D886 Q6 D886 Q7 B776 Q5 B776 M1 Q3 2SC1623 Q4 2SC1623 R13 47 R12 47 Q1 2SC2712Y R14 1K R11 1K R10 1K R15 1K L3 L2 3.3uH R2 220K C4 332 C2 2P C5 4.7uF C1 5P ANT C3 18P R4 6.8K C8 220uF R18 47 R1 430 C16 104 C13 104 C6 103 C11 220uF Q29012 1 2 4 5 6 7 8 9 10 11 12 13 14 S P R C 2 0 6 A C9 102 R9 180K R5 3.3M C12120 C7104 R3 2.2K C10 103 R6 2.2K C14 104 R7 3.3M R8 2.2K RF Enable Forwaurd Backwand VDD VCC GND L4 6.8uH L5 6.8uH Q14 8050 Q12 8050 Q13 8550 Q11 8550 M2 Q9 2SC1623 Q10 2SC1623 R17 56 R16 56 C15 104 4.5V Z1 3.9V SW-3D2P 1.5V T r y M e NORMAL OFF TRY ME NORMAL OFF TRY ME Rx 100 VDD A0 A1 A2 A3 OSC B0 B1 B2 GND AM4EC005D M3 AM4EC005D R23 1K R22 1K SW-PB TRY ME R20 362K R25 1K R26 1K D1 LED D2 LED D3 LED D4 LED D5 LED D6 LED D7 LED D8 LED R27 100 R28 100 R29 100 R30 100 R31 100 R32 100 R33 100 R34 100 Q15 2SC1623 Q16 2SC1623 C15 104 R19 10 R21 1K J6835 49M PDF created with pdfFactory trial version www.pdffactory.com
TEST REPORT Report No. : AF028659-001 Date : 2005 December 20 Page 1 of 11 FCC ID: PIYJ6835-05A4R This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Application No. : LF224027(6) Client : Mattel Asia Pacific Sourcing Limited 13/F., South Tower, World Finance Centre, Harbour City, Tsim Sha Tsui, Kowloon, Hong Kong. Sample Description : One(1) submitted sample(s) stated to be Tyco RC 06 Drop Stars SLR of Model No. J6835 Rating : 4 x 1.5V AA size batteries No. of submitted sample : Three (3) piece(s) Date Received : 2005 December 06 Test Period : 2005 December 06 – 2005 December 19 Test Requested : FCC Part 15 Certification. Test Method : FCC Rules and Regulations Part 15 – July 2004 ANSI C63.4 – 2003 Test Result : See attached sheet(s) from page 2 to 11. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart B. For and on behalf of CMA Industrial Development Foundation Limited Authorized Signature : ____________________________________________________ Danny Chui EMC Engineer - EL. Division TEST REPORT Report No. : AF028659-001 Date : 2005 December 20 Page 2 of 11 FCC ID: PIYJ6835-05A4R This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Table of Contents 1 General Information............................................................................................................................. 3 1.1 General Description ..................................................................................................................... 3 1.2 Location of the test site ................................................................................................................ 4 1.3 List of measuring equipment........................................................................................................ 5 2 Description of the radiated emission test ............................................................................................. 6 2.1 Test Procedure ............................................................................................................................. 6 2.2 Test Result ................................................................................................................................... 6 2.3 Radiated Emission Measurement Data ........................................................................................ 7 3 Description of the Line-conducted Test............................................................................................... 8 3.1 Test Procedure ............................................................................................................................. 8 3.2 Test Result ................................................................................................................................... 8 3.3 Graph and Table of Conducted Emission Measurement Data ..................................................... 8 4 Photograph ........................................................................................................................................... 9 4.1 Photographs of the Test Setup for Radiated Emission and Conduction Emission....................... 9 4.2 Photographs of the External and Internal Configurations of the EUT......................................... 9 5 Supplementary document................................................................................................................... 10 5.1 Bandwidth .................................................................................................................................. 10 5.2 Duty cycle .................................................................................................................................. 10 5.3 Transmission time ...................................................................................................................... 10 6 Appendices......................................................................................................................................... 11 TEST REPORT Report No. : AF028659-001 Date : 2005 December 20 Page 3 of 11 FCC ID: PIYJ6835-05A4R This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Test Result : 1 General Information 1.1 General Description The equipment under test (EUT) is a superregenerative receiver for Tyco RC 06 Drop Stars SLR. Operating at 49.860MHz which is controlled by a LRC circuit. The EUT is powered by 4 x 1.5V AA size battery. When it switches on, it can receive radio frequency and running to forward, backward left and right. The brief circuit description is listed as follows: - Q1 and associated circuit act as super regenerative. - SPRL206 and associated circuit act as decoder. - Q3 ~ Q8 and associated circuit act as motor control for M1. - Q9 ~ Q14 and associated circuit act as motor control for M2. - AM4EC005D, Q15, Q16 and associated circuit act as LED control. - Q2 and associated circuit act as voltage control. TEST REPORT Report No. : AF028659-001 Date : 2005 December 20 Page 4 of 11 FCC ID: PIYJ6835-05A4R This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing…
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15B | 49.86 MHz - 49.86 MHz | - |
