Profile Plane #K8887 27.145MHz TRANSMITTER OPERATIONAL DESCRIPTION The remote control transmitter of the Profile Plane is a low power consumption, hand-holding device for controlling the movement of a toy plane. The transmitter uses two 1.5volt AA batteries as the power supply. It is designed to operate on a single fixed frequency which the band is between 26.98MHz to 27.28MHz. Refer to the attached block diagram and schematic diagram. The input switches trigger integrated circuit (U1) to generate the digital signals that will modulate the carrier wave. The carrier wave is generated by a oscillation circuit which comprised of a 27.145MHz crystal (Y1) and amplifier circuit. The RF carrier wave is modulated by the digital signals of U1. The modulated RF signal is transmitted out from PIN RFO of U1.It is coupled (via C1) to the antenna through a “Pi” matching network that comprised of C3,C4,T2,L3 and L4 .The antenna is 15inches long and permanently attached. The charger circuit is comprised of Q8~Q12 and the protection circuit of the charger include Q1,Q5,Q6. A red led acts as a power-on indicator. All tuning and verifications are performed by the manufacturer and there are no adjustments that can be made by the User .No external ground is required or used with this transmitter.

1 2 3 4 5 6 78 ABCD 8 7 6 5 4 3 2 1 D CBA Title Number Revision Size A3 Date: 20-Oct-2006 Sheet of File: D:\hbpe40\ 李更 \10 -11 \K72 56 (~2.DD B Drawn By: VDD 1 D4 12 OSCI 3 OSCO 4 RFO 5 VSS 6 D0 2 TXD 7 D3 11 D2 9 ROSC 10 D1 8 U1 SPRC205 X2 27.145MHz C1 68PF C3 150pF C4 33PF L2 1uH C5 0.1uF C2 68pF C10 22pF R1 1M R2 200K +/-1% C60.1uF R34.7 R ANT L3 3.9UH T2 C7 0.1uF C21 47uF C8 0.1uF C11 39P L40.68uH D1LED R4 510 R51K R61K R71K R81K R91K Profile Plane (MATTEL) T BF G SW1 TO Charger DC 9V R1010K C12104 D5 1N4148 R14180K Q59015C R15100 Q6S9014C R1110K C13104 D31N4148 R161KD6 LED2 R179.1K R18 5.6K Q8 S9014C R1210K R191K Q99015C Q108550D Q11 8550D R20 2ohm 0.5W R215.1K Q1 S9014C R2268K R23 470 R243K 1% R25 1.3K 1% R26 4.7R R274.7R D41N4007 CH+CH- 3 TL4312.5V 1% R1310K C14 104 DC 9V IN Q128550D R284.7R ZD14.7V 1 2 red green L1 1.2uH VDD D4 OSC1OSC0 RFO TXD D3 D2 ROSC D1D0 T B F C90.1uF D2 IN4148 +3V+9V R29 R30 RL Wiper K8887(27MHz TX) 00 11

TEST REPORT Report No. : AG025417-001 Date : 2006 October 20 Page 1 of 11 FCC ID: PIYK8887-06A2T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Application No. : LG220910(3) Client : Mattel Asia Pacific Sourcing Limited 13/F., South Tower, World Finance Centre, Harbour City, Tsim Sha Tsui, Kowloon, Hong Kong Sample Description : One(1) submitted sample(s) stated to be R/C Squadron of Model No. K8887 Radio Frequency : 27.145MHz Transmitter Rating : 6 x 1.5V AA size batteries No. of submitted sample : Two (2) piece(s) *** Date Received : 2006 September 22 Test Period : 2006 September 22 – 2006 October 04 Test Requested : FCC Part 15 Certification. Test Method : 47 CFR Part 15 (10-1-05 Edition) ANSI C63.4 – 2003 Test Result : See attached sheet(s) from page 2 to 11. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart C. For and on behalf of CMA Industrial Development Foundation Limited Authorized Signature : ____________________________________________________ Danny Chui Deputy Manager - EL. Division TEST REPORT Report No. : AG025417-001 Date : 2006 October 20 Page 2 of 11 FCC ID: PIYK8887-06A2T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Table of Contents 1 General Information............................................................................................................................. 3 1.1 General Description ..................................................................................................................... 3 1.2 Location of the test site ................................................................................................................ 4 1.3 List of measuring equipment........................................................................................................ 5 2 Description of the radiated emission test ............................................................................................. 6 2.1 Test Procedure ............................................................................................................................. 6 2.2 Test Result ................................................................................................................................... 6 2.3 Radiated Emission Measurement Data ........................................................................................ 7 3 Description of the Line-conducted Test............................................................................................... 8 3.1 Test Procedure ............................................................................................................................. 8 3.2 Test Result ................................................................................................................................... 8 3.3 Graph and Table of Conducted Emission Measurement Data ..................................................... 8 4 Photograph ........................................................................................................................................... 9 4.1 Photographs of the Test Setup for Radiated Emission and Conduction Emission....................... 9 4.2 Photographs of the External and Internal Configurations of the EUT......................................... 9 5 Supplementary document................................................................................................................... 10 5.1 Bandwidth .................................................................................................................................. 10 5.2 Duty cycle .................................................................................................................................. 10 5.3 Transmission time ...................................................................................................................... 10 6 Appendices......................................................................................................................................... 11 TEST REPORT Report No. : AG025417-001 Date : 2006 October 20 Page 3 of 11 FCC ID: PIYK8887-06A2T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com 1 General Information 1.1 General Description The equipment under test (EUT) is a transmitter for R/C Squadron. It operates at 27.145MHz which is controlled by a crystal. The EUT is powered by 6 x 1.5V AA size batteries. There are two control sticks and one push button. When the push button is pushed to “Tx” and the forward, left or right stick is pressed once, it will transmit different radio control signal to receiver. When the push button is pushed to “Ch”, it will charge up the battery in the receiver. The brief circuit description is listed as follows: - U1 and associated circuit act as encoder. - X2 and associated circuit act as oscillator. - Q1, Q5, Q6, Q8 ~ Q12 and associated circuit act as charging circuit. TEST REPORT Report No. : AG025417-001 Date : 2006 October 20 Page 4 of 11 FCC ID: PIYK8887-06A2T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chu…
