PIYL0506-06A4RROLLER GIRL

® K9817-0520 INSTRUCTIONS • MODE D’EMPLOI • ANLEITUNG ISTRUZIONI • GEBRUIKSAANWIJZING • INSTRUCCIONES INSTRUÇÕES • ANVISNINGAR • KÄYTTÖOHJE • ΟΔΗΓΙΕΣ CAUTION: To prevent entanglement, keep hair away from wheels. ATTENTION : Pour éviter tout risque d'enchevêtrement, tenir les cheveux éloignés des roues. VORSICHT: Um Verfangen zu vermeiden, die Haare von den Rädern fern halten. AVVERTENZA: per prevenire che le ruote si blocchino, tenere i capelli lontano dalle ruote. WAARSCHUWING: Om verstrikking te voorkomen, je haar uit de buurt van de wielen houden. PRECAUCIÓN: para evitar posibles accidentes, mantener el pelo de la niña alejado de las ruedas del juguete. ATENÇÃO: Para evitar emaranhamento, manter o cabelo longe das rodas. VIKTIGT: Håll håret borta från hjulen för att förhindra att det fastnar. HUOMAUTUS: Varo etteivät hiukset takerru pyöriin. ΠΡΟΣΟΧΗ: Κρατάτε τα μαλλιά μακριά από τις ρόδες για να μην μπερδευτούν. CONTENTS • CONTIENT • INHALT • CONTENUTO • INHOUD CONTENIDO • CONTEÚDO • INNEHÅLL • SISÄLTÖ • ΠΕΡΙΕΧΟΜΕΝΑ 66 K9817 K3659 L0506 K3660 Mattel Canada Inc., Mississauga, Ontario L5R 3W2. You may call us free at 1-800-524-8697. • Mattel U.K. Ltd., Vanwall Business Park, Maidenhead SL6 4UB. Helpline 01628500303 • Mattel France, 27/33 rue d'Antony, Silic 145, 94523 Rungis Cedex N° Indigo 0 825 00 00 25 (0,15 € TTC/mn) ou www.allomattel.com. • Mattel B.V., Postbus 576, 1180 AN Amstelveen, Nederland. 0800 - 2628835. • Mattel Belgium, Trade Mart, Atomiumsquare, Bogota 202 – B 275, 1020 Brussels. • Deutschland: Mattel GmbH, An der Trift 75 D-63303 Dreieich. • Schweiz: Mattel AG, Monbijoustrasse 68, CH-3000 Bern 23. • Österreich: Mattel Ges.m.b.H., Triester Str., A-2355 Wiener Neudorf. • Mattel Scandinavia A/S, Ringager 4C, DK-2605 Brøndby. • Mattel Northern Europe A/S., Sinikalliontie 3, 02630 ESPOO, Puh. 0303 9060. • Mattel Srl., 28040 Oleggio Castello, Italy. • Mattel España, S.A., Aribau 200. 08036 Barcelona. [email protected] Tel: 902.20.30.10 http://www.service.mattel.com/es • Mattel Portugal Lda., Av. da República, nº 90/96, 2º andar Fracção 2, 1600-206 Lisboa • Mattel AEBE, EÏÏËÓÈÎÔ‡ 2, ∂ÏÏËÓÈÎfi 16777. ∂§§∞¢∞. • Mattel Australia Pty., Ltd., Richmond, Victoria. 3121.Consumer Advisory Service - 1300 135 312. • Mattel East Asia Ltd., Room 1106, South Tower, World Finance Centre, Harbour City, Tsimshatsui, HK, China. • Diimport & Diedarkan Oleh: Mattel SEA Ptd Ltd.(993532-P) Lot 13.5, 13th Floor, Menara Lien Hoe, Persiaran Tropicana Golf Country Resort, 47410 PJ. Tel:03-78803817, Fax:03-78803867. • Mattel, Inc., 333 Continental Blvd., El Segundo, CA 90245 U.S.A. Consumer Affairs 1 (800) 524-8697. • Importado y distribuido por Mattel de México, S.A. de C.V., Insurgentes Sur # 3579, Torre 3, Oficina 601, Col. Tlalpan, Delegación Tlalpan, C.P. 14020, México, D.F. R.F.C. MME-920701-NB3. 59-05-51-00. Ext. 5206 ó - 01-800-463 59-89 • Mattel Chile, S.A., Avenida Américo Vespucio 501-B, Quilicura, Santiago. Mattel de Venezuela, C.A., RIF J301596439, Ave. Mara, C.C. Macaracuay Plaza, Torre B, Piso 8, Colinas de la California, Caracas 1071. • Mattel Argentina S.A., Curupaytí 1186, (1607) - Villa Adelina, Buenos Aires. • Mattel Colombia, S.A., calle 123#7-07 P.5, Bogotá. • Mattel do Brasil Ltda. - CNPJ : 54.558.002/0004-72 Av. Tamboré, 1400/1440 Quadra A de 02 a 03 - 06460-000 - Barueri - SP. Atendimento ao Consumidor: SAC 0800550780. Need Assistance? In the US and Canada, service.mattel.com* or 1-800-524-8697, M-F 8AM – 6PM, ET. Besoin d’aide? Au Canada et aux États-Unis, visitez le site service.mattel.com* ou composez le 1 800 524-8697, du lundi au vendredi, de 8 h à 18 h, HNE. ¿Necesita ayuda? En los EE.UU. y Canadá, service.mattel.com* o bien 1-800-524-8697, L-V 8 a.m. – 6 p.m., huso horario del Este. En México: 01 800 463 59 89, L-V 8 a.m. - 4 p.m. *English language only website. • *Site Web en anglais seulement. • *Página web solo en inglés. SERVICE.MATTEL.COM ©2006 Mattel, Inc., 333 Continental Blvd., El Segundo, CA 90245 U.S.A. All Rights Reserved. Tous droits réservés. Product requires 6 AA/LR6 alkaline batteries. For longer life use only alkaline batteries. Fonctionne avec 6 piles alcalines AA/LR6. Utiliser uniquement des piles alcalines pour une durée plus longue. 6 Alkali-Batterien AA (LR6) erforderlich. Für optimale Leistung und längere Lebensdauer nur Alkali-Batterien verwenden. Il prodotto richiede 6 pile alcaline formato stilo AA/LR6. Usa solo pile alcaline per una maggiore durata. Werkt op 6 AA/LR6 alkalinebatterijen. Gebruik uitsluitend alkalinebatterijen; deze gaan langer mee. Funciona con 6 pilas alcalinas AA/LR6. Recomendamos utilizar exclusivamente pilas alcalinas. Las pilas no alcalinas pueden afectar al funcionamiento de este juguete. Please remove everything from the package and compare to the contents shown here. If any items are missing, please contact your local Mattel office. Keep these instructions for future reference as they contain important information. Retirer tous les éléments de l'emballage et les comparer au contenu illustré ci-contre. Si un élément manque, merci de contacter le Service consommateurs de Mattel. Conserver ce mode d’emploi pour s’y référer en cas de besoin car il contient des informations importantes. Bitte alle Teile aus der Verpackung entnehmen und mit der Abbildung vergleichen. Sollten Teile fehlen, wenden Sie sich bitte an die für Sie zuständige Mattel-Filiale zwecks Ersatz. Diese Anleitung bitte für mögliche Rückfragen aufbewahren. Sie enthält wichtige Informationen. Togliere tutti i componenti dalla scatola e confrontarli con la lista inclusa. Contattare gli uffici Mattel locali se dovessero mancare dei componenti. Conservare queste istruzioni per futuro riferimento. Contengono importanti informazioni. Haal alle onderdelen uit de verpakking en controleer ze aan de hand van de hier afgebeelde inhoud. Als er onderdelen ontbreken, kunt u contact opnemen met de plaatselijke Mattel-vestiging. Bewaar deze gebruiksaanwijzing; kan later…

Text truncated - open the document above for the full version.

FCC statement flyer Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Mattel, Inc. Consumer Relations 636 Girard Ave East Aurora, NY (800) 524-8697 NOTE: Changes or modifications not expressively approved by the manufacturer responsible for compliance could void the user’s authority to operate the equipment. THIS CLASS B DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003. CET APPAREIL NUMÉRIQUE DE LA CLASSE B EST CONFORME À LA NORME NMB-003 DU CANADA. (VALID FOR CANADA ONLY • VALABLE AU CANADA SEULEMENT) Operation is subject to the following two conditions : (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. L’utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) Il ne doit pas produire de brouillage et (2) il doit pouvoir tolérer tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre son fonctionnement. For product sold in USA For product sold in Canada • Pour les produits vendus au Canada 00007-1849G4 size: 138 x 175 (mm)

L0506 Receiver Circuit Function Description The L0506 Rollergirl toy receiver requires 4PCS AA battery for its power. It can run forward ,backward, split and spin 1. Voltage Regulator: Contains POWER SWITCH, Q1 ,D2 and its associated components. 2. RF Amplifier: Formed by a NPN transistor Q2 and its associated components, it amplifies the AM signal then feed it into the AM receiver module. 3. RF Receiver & Decoder: Contains U1(SPRC206A-C) and its associated components. The U1 receives and decodes the serial bit-stream data and amplifies the signal. The decoded single input U2. 4. Control IC Contains U2 (EST005) and its associated components. U2 receives the control information from U1 or protective circuit. Then the internal controller sends out different signals to driver motor . 5. Protector Circuit: Formed by compactor U2 (LM339) and its associated circuit which inspects the low voltage of 4PCS AA battery and the high current. 6. Diver Circuit: 6.1 Driver 1: right foot Motor driver comprise transistor Q9, Q10, Q14, Q15, and its associated components. 6.2 Driver 2: left foot Motor comprise Q5, Q6, Q20,Q21 and its associated components.

1 2 3 4 5 6 78 ABCD 8 7 6 5 4 3 2 1 D CBA Title Number Revision Size A3 Date: 29-Aug-2006 Sheet of File: C:\Do c umen ts and Sett ing s\pe .J ETT A\ 桌面 \ 新資料夾 \L05 06 (8-1) EST 00 5 4 9MHZ.DD B Drawn By: SW1 BT16V R147K R15 10 C1 100uF C3104 R141 ohm C2100uF C4104 D2 3V3 VBAT VDD R16 1%200K C140.1uF C16 100uF R171K C17 104 C150.1uF C21 220uF R355.6K C226PF L5 6.5T R18100 R44220K Q22712 C310.01uF C300.01uF C19 4.7uF C2520PF L63.3uF C32 222 R43820 C2610PF L41.8uH C29 100 P R413.9M C270.1uF R393.3K R383.9M R403.3K C28100PF R310K P2.1 R4710K 1% R433K 1% VDD C5 104 R48 33K 1% C20 4.7uF R46 9.1K 1% R1010K P2.2 R5133K 1%R49 1K 1% C12 104 VDD R1110K P2.3 VDD VBAT R5233K 1% R501K 1% C13104 R2147 D51N4148 D7 1N4148 R2347 Q128050 R5 2.7K P3.0 Q14SS8050 D6 1N4148 D8 1N4148 Q15SS8050 Q178050 R530.1/2W R12 1K C3333uF R6 2.7K P3.1 R42 470K S1 Split R2947 D3 1N4148 D4 1N4148 R3147 Q188050 R7 2.7K P3.2 Q208050 D9 1N4148 D10 1N4148 Q21 8050 Q238050 R540.1/2W R81K C34 33uF R92.7K P3.3 VBAT VBAT C350.1uF L0506 49MHZ RX 54 2 312 U2ALM339 76 1 U2B LM339 98 14 U2CLM339 ANT Q9SS8550 Q10SS8550 Q68550 Q58550 MOTOR M C6 104 C8 104 C7 104 MOTOR M C9104 C11104 C10104 Q18550 R132.7K Q248050 R452.7K Q258050 02 VDD 7 D03 9 D02 8 D01 6 D00 5 D04 10 VSS 1 ROSC 2 ROSCOUT 3 IN1 11 OUT1 12 IN2 13 OUT2 14 DIN 4 U1SPRC206A L2 100uH VDD C18 0.1uF Roller Girl L5100uH R53 680 LED1 P3.0 40 P3.1 39 P3.2 38 P3.3 37 P1.0 8 P1.1 7 P1.2 6 P1.3 5 P2.0 4 P2.1 3 P2.2 2 P2.3 1 VDD 32 OSCI 13 VSSD 11 VO 28 VO1 30 VCC 27 VSSC 29 CIN 31 RESET 9 U3EST005

TEST REPORT Report No. : AG021626-001 Date : 2006 September 18 Page 1 of 11 FCC ID: PIYL0506-01A4T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Application No. : LG212231(0) Client : Mattel Asia Pacific Sourcing Limited 13/F., South Tower, World Finance Centre, Harbour City, Tsim Sha Tsui, Kowloon, Hong Kong Sample Description : One(1) submitted sample(s) stated to be Roller Girl of Model No. L0506 Radio Control : 49.860MHz Receiver Rating : 4 x 1.5V AA size batteries No. of submitted sample : Two(2) piece(s) *** Date Received : 2006 August 19 Test Period : 2006 August 19 – 2006 August 28 Test Requested : FCC Part 15 Certification. Test Method : 47 CFR Part 15 (10-1-05 Edition) ANSI C63.4 – 2003 Test Result : See attached sheet(s) from page 2 to 11. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart B. For and on behalf of CMA Industrial Development Foundation Limited Authorized Signature : ____________________________________________________ Danny Chui Deputy Manager - EL. Division TEST REPORT Report No. : AG021626-001 Date : 2006 September 18 Page 2 of 11 FCC ID: PIYL0506-01A4T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Table of Contents 1 General Information............................................................................................................................. 3 1.1 General Description ..................................................................................................................... 3 1.2 Location of the test site ................................................................................................................ 4 1.3 List of measuring equipment........................................................................................................ 5 2 Description of the radiated emission test ............................................................................................. 6 2.1 Test Procedure ............................................................................................................................. 6 2.2 Test Result ................................................................................................................................... 6 2.3 Radiated Emission Measurement Data ........................................................................................ 7 3 Description of the Line-conducted Test............................................................................................... 8 3.1 Test Procedure ............................................................................................................................. 8 3.2 Test Result ................................................................................................................................... 8 3.3 Graph and Table of Conducted Emission Measurement Data ..................................................... 8 4 Photograph ........................................................................................................................................... 9 4.1 Photographs of the Test Setup for Radiated Emission and Conduction Emission....................... 9 4.2 Photographs of the External and Internal Configurations of the EUT......................................... 9 5 Supplementary document................................................................................................................... 10 5.1 Bandwidth .................................................................................................................................. 10 5.2 Duty cycle .................................................................................................................................. 10 5.3 Transmission time ...................................................................................................................... 10 6 Appendices......................................................................................................................................... 11 TEST REPORT Report No. : AG021626-001 Date : 2006 September 18 Page 3 of 11 FCC ID: PIYL0506-01A4T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com 1 General Information 1.1 General Description The equipment under test (EUT) is a superregenerative receiver for Roller Girl. It is operating at 49.860MHz which is controlled by a LRC circuit. The EUT is powered by 4 x 1.5V ‘AA’ size batteries. When received forward, backward, turn left, turn right signal, it will run to corresponding direction. The brief circuit description is listed as follows: - Q2 and associated circuit act as RF receiver. - U1, U3 and associated circuit act as decoder. - U2 and associated circuit act as low battery control. - Q9, Q10, Q14, Q15 and associated circuit act as M2 motor control. - Q5, Q6, Q20, Q21and associated circuit act as M1 motor control. TEST REPORT Report No. : AG021626-001 Date : 2006 September 18 Page 4 of 11 FCC ID: PIYL0506-01A4T This document shall not be reproduced except in full or with written approval by the laboratory. CMA Industrial Development Foundation Limited Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: …

Text truncated - open the document above for the full version.
